Fromm A431 Guide

OPERATION MANUAL / SPARE PARTS LIST
MANUAL COMBINATION
PUSHER TYPE TOOL
MODEL A431
13.3071.01
13307101.en/MAS/© 09.06

2
1 SAFETY INSTRUCTIONS
Read these instructions carefully. Failure to follow these instructions can result in severe personal injury.
Eye injury hazard
Failure to wear safety glasses with side shields can result in severe eye injury or blindness. Always wear safety glasses with side shields
which conform to ANSI Standard Z87.1.
Operation
Tool must not be used by persons not properly trained in their use. Before tensioning strap, read and understand the tool operating
instructions. Failure to follow the operating instructions or improper load positioning could result in strap breakage.
Become familiar with your tool and keep fingers away from areas that can pinch or cut.
INDEX PAGE
1 SAFETY INSTRUCTIONS 2
2 WARRANTY CONDITIONS AND LIABILITY 4
3 APPROPRIATE USE 4
4 TECNICAL DATA 5
5 CHART OF TYPES A431 5
6 SPARE PARTS LIST 13.3071.01 8
7 OPERATION 10
8 JOINT CONTROL 11

3
Joints
You are fully responsible to review the joints made by your tool. Become familiar with the seal control and seal adjustment described in
this operation manual. Misformed joints may not secure the load and could cause serious injury. Never handle or ship any load with
improperly formed joints.
Dispensing strap
Only dispense strap from a dispenser specifically designed for strap.
Tuck strap end back into dispenser when not in use.
Protective gloves
When handling strap, always wear protective gloves.
Strap warnings
Never use strap as a means of pulling or lifting loads. Failure to follow these warnings can result in severe personal injury.
Strap breakage hazard
Improper operation of the tool, excessive tensioning, using strap not recommended for this tool or sharp corners on the load can result in
a sudden loss of strap tension or in strap breakage during tensioning, which could result in the following:
• A sudden loss of balance causing you to fall.
• Both tool and strap flying violently towards your face.
Note as follows:
• If the load corners are sharp, use edge protectors.
• Place the strap correctly around a properly positioned load.
• Positioning yourself in-line with the strap, during tensioning and sealing, can result in severe personal injury from flying strap or
tool. When tensioning or sealing, position yourself to one side of the strap and keep all bystanders away.
• Use the correct strap quality, strap width, strap gauge and strap tensile strength recommended in this manual for your tool. Using
strap not recommended for this tool can result in strap breakage during tensioning.
Cutting tensioned strap
When cutting strapping, use the proper strapping cutter and keep other personnel and yourself at a safe distance from the strap. Always
stand to side of the strap, away from the direction the loosened strap end will fly. Use only cutters designed for strap and never hammers,
pliers, hacksaws, axes, etc.
Fall hazard
Keep your working area tidy. Untidiness of your working area may cause a risk of injury. Maintaining improper footing and/or balance
when operating the tool can cause you to fall. Before tensioning and especially in elevated areas, always establish good balance. Both
feet should be securely placed on a flat, solid surface, especially when working in elevated areas. Do not use the tool when you are in an
awkward position.
Pay attention to the rules and regulations for preventions of accident which are valid for the work place.
Tool hazards
A well maintained tool is a safe tool!
Check tool regularly for broken or worn parts. Do not operate a tool with broken or worn parts.
Never modify any tool. Modification can result in severe bodily injury.

4A431en.teil1.fm
2 WARRANTY CONDITIONS AND LIABILITY
FROMM Holding AG warrants all its strapping tools and machine heads during a period of 90 days from the
date of sale. The warranty includes all deficiencies clearly resulting from poor manufacturing or faulty materials.
Damage claims as a result of production shutdowns and claims for damage to persons and to property resulting
from warranty deficiencies cannot be asserted by the customer.
The warranty excludes:
• wearing parts
• deficiencies resulting from improper installing, incorrect handling and maintaining the tool
• deficiencies resulting from using the tool without or with defective security- and safety devices
• disregard of directions in the operation manual
• arbitrary modifications of the tool
• deficient control of wearing parts
• deficient repair works of the tool
• Use of consumable products not recommended by FROMM Holding AG
We reserve the right to modify the product at any time in order to improve its quality.
3 APPROPRIATE USE
The tool model A431 has been designed to strap packages with steel strapping exclusively.
The warranty / liability excludes:
•non appropriate use of the tool,
•disregard of directions in the operation manual,
•disregard of control- and maintenance instructions.

5
A431en.teil1.fm
4 TECNICAL DATA
Dimensions without suspension bracket
Tool Package
Length: 400 mm / 15.75" 406 mm / 15.98"
Width: 400 mm / 15.75" 406 mm / 15.98"
Height: 210 mm / 8.27" 167mm / 6.58"
Weight: 3.4 kg / 7.5 lbs 0.5 kg / 1.1 lbs
Joint strength
Approx. 55% of the strap’s tensile strength.
Steel strapping
Width: 10 - 19 mm / 3/8 - 3/4" (see chart of types)
Thickness: 0.38 - 0.63 mm / 0.015 - 0.025"
Quality: Fundamentally the A431 allows the use of all current steel straps with tensile
strengths ranging from 850 to 1100N/mm2/ 123 000 - 160 000 psi.
Straps with a low breaking elongation are unsuitable.
5 CHART OF TYPES A431
UNI = Uniflex (Regular Duty max. 850 N/mm2/ 123‘000 psi)
ULT = Ultraflex (High Tensile max. 1100 N/mm2/ 160‘000 psi)
Item No. Model Strap width Strap thickness
13.3050 A431/10/0.38-0.63/UNI 10mm / 3/8" 0.38-0.63 / 0.015-0.025"
13.3051 A431/10/0.38-0.63/ULT 10mm / 3/8" 0.38-0.63 / 0.015-0.025"
13.3070 A431/13/0.38-0.63/UNI 13mm / 1/2" 0.38-0.63 / 0.015-0.025"
13.3071 A431/13/0.38-0.63/ULT 13mm / 1/2" 0.38-0.63 / 0.015-0.025"
13.3090 A431/16/0.38-0.63/UNI 16mm / 5/8" 0.38-0.63 / 0.015-0.025"
13.3091 A431/16/0.38-0.63/ULT 16mm / 5/8" 0.38-0.63 / 0.015-0.025"
13.3110 A431/19/0.38-0.63/UNI 19mm / 3/4" 0.38-0.63 / 0.015-0.025"
13.3111 A431/19/0.38-0.63/ULT 19mm / 3/4" 0.38-0.63 / 0.015-0.025"

2 31AA
B
C
D
E
A43.1108
A43.1110
N4.9134
N2.4902
N1.3106
N1.1106
A48.1131
A43.1201
A48.1131
N1.6402
N7.1102
A43.1202
A43.1212
A48.1213
N2.2130
N1.1539
➀ N1.2135
N1.5103
➀ N1.2136
N2.2102
A48.1130
➁ A48.1133
A48.1134
N4.1112
A48.1129
A48.1133 ➁
N1.2135 ➀
N1.1110 ➂
A48.1128 ➁
N2.2129
N2.1119
N1.6307
A43.1207
N3.2315
N3.2316
N7.1103
A43.1203 ➁
N2.5200 ➁ A48.1109 ➁
N1.2105
N1.1208
N1.6207
➁ A48.1114
➁ A48.1113
➁ A48.1111
➁ A43.1102
➁ A43.1104
A48.1117
A48.1111 ➁
A48.1110 ➁
➁ A48.1116
A48.1115
A43.0102
A48.1204
A43.1211
A48.1102
A48.1106
A48.1125
N41.9128
13307101.z

4567
N1.5302
A43.1105
N1.1170
N1.2124 ➀
A48.1132
N2.1119 N1.6307
N3.2316 A43.1101 ➁
N3.2403
N3.2315
A43.1106
N2.1119
A43.1107
N2.3201
N4.1112
N2.3201
N2.5154
A43.1204
➁ A43.1205 A43.1208
A43.1209 ➁
A43.1207
A43.1206 ➁
N2.1122
A43.1104 ➁
A48.1106
➀ Loctite 222
➁ Mobilux EP2
➂ Loctite 243

[ ] = Group * = Wearing parts
813307101.een.fm
6 SPARE PARTS LIST 13.3071.01
13.3071.01 A431/13/0.38-0.63/ULT A431.0001.01 25.02.00
Item-No. in group Pcs. Description Dimension Field
[A43.0102] 1 JAW ASSEMBLY 13 MM A3
A43.1101 1 GEAR WHEEL B5
A43.1102 A43.0102 1 PISTON ROD A3
A43.1104 2 SUPPORTING PLATE A4
A43.1105 1 COVER PLATE A4
A43.1106 1 SEALING SHAFT B6
A43.1107 1 SEALING HANDLE C6
A43.1108 A43.1110 1 SEALING BODY A2
[A43.1110] 1 SEALING HOUSING A2
A43.1201 1 STANCHION C2
A43.1202 A43.1212 1 ROCKER C2
A43.1203 1 PIVOT PIN C3
A43.1204 1 TENSION SHAFT D4
A43.1205 1 RETURN STOP D5
A43.1206 1 TENSION HANDLE E6
A43.1207 2 DISK D6+
A43.1208 1 INTERMEDIATE WASHER D5
A43.1209 *4 CATCH PAWL D6
A43.1211 *1 TENSIONING WHEEL C3
[A43.1212] 1 ROCKER C1
A48.1102 *A43.0102 2 CUTTING JAW C4
A48.1106 *A43.0102 2 NOTCHING KNIFE C4+
A48.1109 A43.0102 2 JAW PIN C3
A48.1110 A43.0102 2 FRONT TOGGLE LINK B4
A48.1111 A43.0102 2 LEVER BOLT B4+
A48.1113 A43.0102 1 ROD BAR BOLT A3
A48.1114 A43.0102 1 SIDE PLATE A3
A48.1115 A43.0102 1 SPACER BUSH A4
A48.1116 A43.0102 1 SIDE PLATE B4
A48.1117 A43.0102 2 SPACER BUSH B3
A48.1125 *1 CUTTER 13 MM B3
A48.1128 *1 CUTTER JACK D4
[A48.1129] A48.1134 1 CONNECTION PLATE D3
A48.1130 A48.1134 2 STOP BOLT D3
A48.1131 2 JAW GUIDE B2+
A48.1132 1 COVER PLATE B5
A48.1133 2 TONG GUIDE D3+
[A48.1134] 1 CONNECTION PLATE D3
[A48.1204] *1 TENSIONING BODY D1
A48.1213 *1SLIDEPLATE D2
N1.1106 1 SCREW M6 X 20 B2
N1.1110 2 SCREW M5 X 8 D4
N1.1170 2 SCREW M6 X 35 A5
N1.1208 A43.0102 2 SCREW M5 X 25 B3
N1.1539 1 HEXAGON SCREW M5 X 14 D2
N1.2105 A43.0102 1 COUNTERSUNK SCREW M5 X 25 B3
N1.2124 4 COUNTERSUNK SCREW M5 X 20 A5
N1.2135 2 COUNTERSUNK SCREW M5 X 12 D4+
N1.2136 1 COUNTERSUNK SCREW M5 X 8 E2
N1.3106 1 SOCKET SET SCREW M5 X 6 B2
N1.5103 1 HEXAGON NUT M5 D2

[ ] = Group * = Wearing parts
9
13307101.een.fm
N1.5302 A43.0102 3 RETAINING NUT M5 B5
N1.6207 A43.0102 2 SPRING LOCK WASHER M5 B3
N1.6307 2 SPACER WASHER 15 X 21 X 1.5 C3+
N1.6402 1 TOOTH WASHER M6 B3
N2.1119 3 SECURITY RING E10 C3+
N2.1122 1 SECURITY RING E21 D7
N2.2102 1 PARALLEL PIN 5 m6 X 16 E2
N2.2102 A48.1134 2 PARALLEL PIN 5 m6 X 16 E2
N2.2129 A48.1134 2 PARALLEL PIN 5 m6 X 10 C3
N2.2130 A43.1212 1 PARALLEL PIN 8 m6 X 24 C2
N2.3201 3 WOODRUFF KEY 4 X 6.5 X 15.72 B6+
N2.4902 2 HAMMER HEAD BOLT 1.85 X 4.76 B1
N2.5154 4 PRESSURE SPRING 0.45 X 3.9 X 7 C5
N2.5200 1 PRESSURE SPRING 2X9,8X63/23.5 C3
N3.2315 A43.1110 1 NEEDLE BEARING B6
N3.2315 A43.1212 1 NEEDLE BEARING C4
N3.2316 A43.1110 1 NEEDLE BUSH B5
N3.2316 A43.1212 1 NEEDLE BUSH C3
N3.2403 1 INNER RACEWAY B5
N41.9128 1 ADHESIVE LABEL A2
N4.1112 2 GRIP BALL E4+
N4.9134 1 LABEL <<A431>> B1
N7.1102 A43.1212 1 BUSH C1
N7.1103 A43.1212 1 BUSH C3
13.3071.01 A431/13/0.38-0.63/ULT A431.0001.01 25.02.00
Item-No. in group Pcs. Description Dimension Field

10
A431en.teil2.fm
7 OPERATION
Feeding the strapping
The strap is fed through the seal, around the package to be
strapped and again through the seal. The strap end is then
bent. The operator then tensions the loose hoop manually
making sure that the bent strap end is adjacent to the object
to be strapped.
Loading the strapping
Hold the upper strap with the left hand, lift the feed
wheel lifting handle with the right hand and slide the
tool over the strap from the right to the left
respectively from the rear to the front.
Tensioning the strapping
The tool is held tightly with the left hand being placed
on the sealing handle.The tension handle is now
moved forward and backward with the right hand until
the desired tension is attained.
When handling strap, always wear protective
gloves and safety glasses with side shields
which conform to ANSI Standard Z87.1.

11
A431en.teil2.fm
Sealing the strapping
With the right hand on the tension handle (in back
position as illustrated) push the sealing handle
forward to the stop with the left hand. Move sealing
handle backward into the initial position after
completion of the sealing action.
Releasing the tool
After completion of the sealing action the tool can be
released easily from the seal. By relifting the feed
wheel lifting handle the strap end can be removed from
the tool.
8 JOINT CONTROL
A regular control of the joint is necessary. The joint can be checked visually and the person controlling can
easily judge the quality of the joint. Following illustration shows a proper joint:
Sharp edged or misformed joints which do not appear as shown have to be taken away from the load
immediately. The tensile strength of these joints is insufficient and they could cause serious injury.
Having faulty joints proceed as follows:
• Checking the sealing cycle for improper use.
• Having faulty joints in spite of proper use inspect the tool for worn or damaged parts. In case of
wearing out or damaging replace tool parts as needed.
