Fromm P355 User manual

OPERATION MANUAL / SPARE PARTS LIST
PNEUMATIC
PLASTIC STRAPPING TOOL
MODEL P355
49.0323.01
CE Declaration of conformity
We declare that the machine P355
is in conformity with the following standard or
standardised documents:
98/37/EEC
FROMM Holding AG
Hinterbergstrasse 26
CH - 6330 Cham
22.01 2002
R.Fromm
Director
49032301.en-3/MAS/© 10.07

2
INDEX PAGE
1 SAFETY INSTRUCTIONS 3
2 TECHNICAL DATA 4
3 CHART OF TYPES 5
4 WARRANTY CONDITIONS AND LIABILITY 5
5 APPROPRIATE USE 5
6 INSTALLATION 6
6.1 Compressed air connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6.2 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
6.3 Adjustments. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 OPERATING ELEMENTS 9
8 OPERATION 9
8.1 Feeding the strap around the package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
8.2 Inserting the strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8.3 Tensioning the strap . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
8.4 Sealing the straps . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8.5 Removing the tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
8.6 Seal - Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
9 EXCHANGE OF WEARING PARTS 12
9.1 Exchange of tensioning wheel and grippers . . . . . . . . . . . . . . . . . . . . . . . . . . 12
9.2 Exchange of cutter, welding stop gripper and welding gripper . . . . . . . . . . . . 13
9.3 Adjustment of the coupler P32.1250 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
10 PNEUMATIC SCHEMATIC 15
11 SERVICE 15
12 CLEANING 15
13 SPARE PARTS LIST 49.0323.01 20

3
P355000101en-3-
1 SAFETY INSTRUCTIONS
Read these instructions carefully. Failure to follow these instructions can result in severe personal injury.
Eye injury hazard
Failure to wear safety glasses with side shields can result
in severe eye injury or blindness. Always wear safety
glasses with side shields which conform to ANSI Standard
Z87.1.
Operation
Tool must not be used by persons not properly trained in
their use. Before tensioning strap, read and understand the
tool operating instructions. Failure to follow the operating
instructions or improper load positioning could result in
strap breakage.
Become familiar with your tool and keep fingers away from
areas that can pinch or cut.
Tool hazards
A well maintained tool is a safe tool!
Check tool regularly for broken or worn parts. Do not
operate a tool with broken or worn parts.
Never modify any tool. Modification can result in severe
bodily injury.
Joints
You are fully responsible to review the joints made by your
tool. Become familiar with the seal control and seal
adjustment described in this operation manual. Misformed
joints may not secure the load and could cause serious
injury. Never handle or ship any load with improperly
formed joints.
Dispensing strap
Only dispense strap from a dispenser specifically designed
for strap.
Tuck strap end back into dispenser when not in use.
Strap warnings
Never use strap as a means of pulling or lifting loads.
Failure to follow these warnings can result in severe
personal injury.
Strap breakage hazard
Improper operation of the tool, excessive tensioning, using
strap not recommended for this tool or sharp corners on
the load can result in a sudden loss of strap tension or in
strap breakage during tensioning, which could result in the
following:
• A sudden loss of balance causing you to fall.
• Both tool and strap flying violently towards your
face.
Note as follows:
• If the load corners are sharp, use edge protectors.
• Place the strap correctly around a properly
positioned load.
• Positioning yourself in-line with the strap, during
tensioning and sealing, can result in severe
personal injury from flying strap or tool. When
tensioning or sealing, position yourself to one side
of the strap and keep all bystanders away.
• Use the correct strap quality, strap width, strap
gauge and strap tensile strength recommended in
this manual for your tool. Using strap not
recommended for this tool can result in strap
breakage during tensioning.
Cutting tensioned strap
When cutting strapping, use the proper strapping cutter
and keep other personnel and yourself at a safe distance
from the strap. Always stand to side of the strap, away from
the direction the loosened strap end will fly. Use only
cutters designed for strap and never hammers, pliers,
hacksaws, axes, etc.
Fall hazard
Keep your working area tidy. Untidiness of your working
area may cause a risk of injury. Maintaining improper
footing and/or balance when operating the tool can cause
you to fall. Before tensioning and especially in elevated
areas, always establish good balance. Both feet should be
securely placed on a flat, solid surface, especially when
working in elevated areas. Do not use the tool when you
are in an awkward position.
Pay attention to the rules and regulations for preventions of
accident which are valid for the work place.

4P355000101en-3-
2 TECHNICAL DATA
Description of the tool
The tool model P355 has been designed to strap packages with plastic strapping. The plastic strapping is fed
around the package manually or in combination with a strap feeder. The straps are inserted in the tool,
automatically tensioned, sealed by friction welding and separated.
Tool size without suspension bracket with suspension bracket
Length: 305 mm / 12" 356 mm / 14"
Width: 104 mm / 4.1" 104 mm / 4.1"
Height: 151 mm / 6" 252 mm / 9.9"
Weight: 4.75 kg / 10.5 lbs 5.0 kg / 11 lbs
Sound information
The A-weighted equivalent continuous sound level at the work place of the machine operator is
typical 79 dB (A).
This value was determined according to DIN 45 635 T3 (11.85).
Vibration information
The weighted effective value of the acceleration typically amounts to less than 2,5m/s2.
This value was determined according to DIN EN 28 662 T1 (01.93).
Strap material
Strap qualities: PET (Polyester) and PP (Polypropylen) plain or embossed.
Use only plastic straps recommended by your sales shop (name and address
on the rear of the operation manual).
Strap dimensions: 10.0 - 16.0 mm / 3/8 - 5/8“ x 0.4 - 1.05 mm / .016 - .041“ (see chart of types).
Use only plastic straps with the correct strap dimensions for your tool.
Strap tension with steady air pressure of 5.5bar/80 psi.
Tensioning force*: Adjustable from 400 - max. 2100 N / 90 - max. 470 lbs.
Thirteen different steps can be preselected.
Tensioning speed*: approx. 120 - 250 mm/s / 4.7 - 10 "/sec.
Joint strength*: approx. 75% of the tensile strength of the plastic strap.
* The value depends on the strap quality.
Air pressure
Joining thread / Air tube: G 1/4 / Min. inside diameter = 9 mm
Air pressure: The maximum air pressure allowed is 6.0 bars / 87 psi.
The standard working air pressure is 5.5 bar / 80 psi.
Air unit: min. G 3/8
Air line in front of air unit : min. 1/2"
Air flow of air unit: min. 480Nl/min / 18 cu.ft/min with a maxim pressure drop of 0.5 bar / 7.25 psi.
Air consumption
Tensioning: approx. 8 Nl / 0.30 cu.ft uncompressed air per second with the air motor running.
Sealing: approx. 4 - 20 Nl / 0.15 - 0.75 cu.ft uncompressed air per cycle
approx. 8 Nl / 0.30 cu.ft uncompressed air per second.
Oil for air unit: HL / CL ISO VG 10

5
P355000101en-3-
3 CHART OF TYPES
4 WARRANTY CONDITIONS AND LIABILITY
FROMM Holding AG warrants all its strapping tools and machine heads during a period of 90 days from the
date sale. The warranty includes all deficiencies clearly resulting from poor manufacturing or faulty materials.
Damage claims as a result of production shutdowns and claims for damage to persons and to property
resulting from warranty deficiencies cannot be asserted by the customer.
The warranty excludes:
• wearing parts,
• deficiencies resulting from improper installing, incorrect handling and maintaining the tool,
• deficiencies resulting from using the tool without or with defective security- and safety devices,
• disregard of directions in the operation manual,
• arbitrary modifications of the tool,
• deficient control of wearing parts,
• deficient repair works of the tool.
• Use of consumable products not recommended by FROMM Holding AG
We reserve the right to modify the product at any time in order to improve its quality.
5 APPROPRIATE USE
The tool model P355 has been designed to strap packages with plastic strapping exclusively.
The warranty / liability excludes:
• non appropriate use of the tool,
• disregard of directions in the operation manual,
• disregard of control- and maintenance instructions.
Item No. Model Strap width Strap thickness
49.0301 P355/10/0.40-0.64 10.0 mm / 3/8" 0.4 - 0.64 mm / .016 - .025"
49.0302 P355/10/0.65-1.05 10.0 mm / 3/8" 0.65 - 1.05 mm / .026 - .041"
49.0311 P355/11.1/0.40-0.64 11.1 mm / 7/16" 0.4 - 0.64 mm / .016 - .025"
49.0312 P355/11.1/0.65-1.05 11.1 mm / 7/16" 0.65 - 1.05 mm / .026 - .041"
49.0321 P355/12/0.40-0.64 12.0 mm 0.4 - 0.64 mm / .016 - .025"
49.0322 P355/12/0.65-1.05 12.0 mm 0.65 - 1.05 mm / .026 - .041"
49.0323 P355/12.7/0.40-0.64 12.7 mm / 1/2" 0.4 - 0.64 mm / .016 - .025"
49.0324 P355/12.7/0.65-1.05 12.7 mm / 1/2" 0.65 - 1.05 mm / .026 - .041"
49.0331 P355/13/0.40-0.64 13.0 mm 0.4 - 0.64 mm / .016 - .025"
49.0332 P355/13/0.65-1.05 13.0 mm 0.65 - 1.05 mm / .026 - .041"
49.0351 P355/15/0.40-0.64 15.0 mm 0.4 - 0.64 mm / .016 - .025"
49.0352 P355/15/0.65-1.05 15.0 mm 0.65 - 1.05 mm / .026 - .041"
49.0353 P355/15.5/0.40-0.64 15.5 mm 0.4 - 0.64 mm / .016 - .025"
49.0354 P355/15.5/0.65-1.05 15.5 mm 0.65 - 1.05 mm / .026 - .041"
49.0361 P355/16/0.40-0.64 16.0 mm / 5/8" 0.4 - 0.64 mm / .016 - .025"
49.0362 P355/16/0.65-1.05 16.0 mm / 5/8" 0.65 - 1.05 mm / .026 - .041"

6P355000101en-3-
6INSTALLATION
6.1 Compressed air connection
The compressed air is to be connected to the tool preferably by a quick disconnector (G1/4).
An air-unit consisting of a separator for water and dirt, a pressure regulator with a manometer and a lubricator
must be installed within a range of 15 ft / 5 meters. The compressed air must be free from dirt, rust and
moisture.
Possible connections at the tool
Factory produced the connection for the
air supply is prepared from the top.
According to requirement the connection
can also be assembled to the rear end of
the tool.
6.2 Accessories
Use only parts and accessories mentioned in the operating instruction. Using other
parts or accessories can cause injuries to you and other persons.
Wearing plate
As an option, tool can be equipped with a
wearing plate to protect base from
excessive wear on abrasive package
surfaces (like bricks, concrete blocks etc.).
The complete wearing plate can be
ordered together with the fastening screws
under item number P32.0111.
P32.0111 P32.1301
N1.2221

7
P355000101en-3-
Suspension of tool
It is possible to suspend the tool on a spring loaded balancer using the suspension bracket P35.0125 which is
supplied with the tool. The suspension bracket has been designed in such a way, that the tool can be used for
all three working positions.
P35.0125
N1.5105
 P35.2073
 N2.5623
P35.2070
P35.2069 
N1.2110
P35.2068
 P35.2067
 N6.6212

Mobilux EP2

8
P355000101en-3-
6.3 Adjustments
6.3.1 Preselecting of strap tension and tensioning speed
Do not adjust the tensioning force too high.
If the tensioning force is higher than the tensioning strength of the strap,
the strap will tear while the tensioning.
Tensioning force and tensioning speed can be
preselected at the control head.
Loose lock screw;
press the control head against the tool
and turn it.
Turning clockwise increases;
turning counterclockwise decreases the
tensioning force and the tensioning speed resp..
Tight lock screw.
6.3.2 Adjusting the welding time
Depending on the size and quality of the strap,
different welding times are required.
The welding time can be adjusted at the
adjusting crew.
Turning clockwise increases,
turning counterclockwise decreases the welding
time.
6.3.3 Adjusting the welding pressure
In order to assure optimal welding, the pressure of the welding gripper to the straps to be welded must be
within a certain range. Depending on the thickness of the strap, this pressure is adjusted by means of the
cam.
When adjusting the welding pressure, the lever must be latched into its start position.
The range of thickness of the strap must be adjusted according to the strap thickness admitted for the tool
(see chart of types) and the thickness of the strap to be processed.
Adjustment:
The lever is latched and in start position!
Pull out the cam of the tool,
turn it into the desired position (observe the marking on the housing),
release the cam (the cam must latch without assistance).
Model Welding pressure,
Possible adjustments
Strap thickness 0.40 - 0.64 mm
(.016 - .025")
0.40 - 0.57 mm (.016 - .022")
0.58 - 0.72 mm (.023 - .028")
Strap thickness 0.65 - 1.05 mm
(.026 - .041")
0.58 - 0.72 mm (.023 - .028")
0.73 - 0.89 mm (.029 - .035")
0.90 - 1.05 mm (.035 - .041")
Adjusting screw welding time
Cam
Lock screw
Control head

9
P355000101en-3-
7 OPERATING ELEMENTS
8OPERATION
8.1 Feeding the strap around the
package
The strapping is fed around the package as
illustrated.
Warning! The plastic strap which will be
welded must be free from oil, grease and other
dirt.
Dirty plastic straps can't be welded correct!
Lever Handle lever
Tensioner valve lever

10 P355000101en-3-
8.2 Inserting the strap
Pull up the handle lever firmly with your right
hand.
Insert the two straps well aligned on each other
into the strap guide using your left hand.
Release the handle lever.
8.3 Tensioning the strap
Press down the tensioner valve lever and then
release it again after the desired strap tension has
been reached.
The tensioning operation can be interrupted and
restarted at any time.
The tool must carry out a balance movement
while tensioning.
Therefore:
- Don’t hinder the tools movement in the signed direction.
Disregard:
The feed wheel slips on the strap without tensioning it.

11
P355000101en-3-
8.4 Sealing the straps
While welding the plastic strap the lever must be pressed forward against the front
stop After the welding operation the lever must be pressed against the front stop for
another 1-2 seconds until the seal is cooled down.
Disregarding of this regulation will cause insufficient seal efficiency, what can cause
severest injuries.
Press the lever with the left hand forward against the
stop and keep it pressed.
The plastic strap is welded and cut off from the strap
coil at the same time.
After the preselected welding time is elapsed, the
lever must be kept pressed for 1 - 2 seconds in
the welding position until the seal is cooled
down.
Turn back the lever until it latches in start position.
8.5 Removing the tool
Pull up the handle lever,
pull the tool right / backwards and off the strapping.
8.6 Seal - Control
A regular control of the seal is necessary. The seal
can be examined visually.
Make a seal, peel it apart and examine it as follows:
Correct seal
The seal must be completely welded over the whole width of the strap
on a length of ca. 19 mm. Minor quantities of fused plastic may
overflow on sides.
Welding time too short
The plastic strap is not welded over the whole width of the strap. The
seal efficiency is insufficient.
Warning! Straps with insufficient seal strength must be removed from
the package!
Adjust the welding time (see 6.3.2).
Welding time too long
If the welding time is too long the straps are overheated. The fused
plastic overflows on both sides of the straps. The seal efficiency is
affected.
Warning! Straps with insufficient seal strength must be removed from
the package!
Adjust the welding time (see 6.3.2).

12 P355000101en-3-
9 EXCHANGE OF WEARING PARTS
Before any maintenance work always disconnect the tool from the air supply.
9.1 Exchange of tensioning wheel and grippers
Disassembling
• Unscrew end cover P32.1238 and remove it;
• Remove the torsion spring N2.5823;
• Remove the tensioning body P32.1254;
• Remove the tensioning wheel together with the bearing N3.1172 from the tool;
• Unscrew the holders P32.1228 and P32.1229 and remove them from the tensioning body;
• Remove the grippers from the tensioning body.
Assembling
Assembling in opposite order. Observe the following:
• Lubricate the internal toothing of the tensioning wheel with Molykote BR 2 plus.
Observe the position of the tensioning wheel. The direction of rotation of the
tensioning wheel is marked at the front of the tensioning wheel (see drawing).
Observe the position of the grippers (see drawing).
P32.1229
P32.1228
P32.1254
N1.6505
N1.1909
N2.5823
N3.1172
P32.1238
N1.6503
N1.1904
Tensioning wheel 
Grippers
 Molykote BR2 plus

13
P355000101en-3-
9.2 Exchange of cutter, welding stop gripper and welding gripper
Disassembling
• Unscrew cover P32.1211 and remove it;
• Unscrew end cover P32.1238 and remove it;
• Disassemble security ring N2.1118, pull the grip axle P35.2064 from the tool;
• Tilt down the handle lever P32.1212 and remove it from the tool;
•Don’t loosen screw N1.1553 at the coupler P32.1250.
• Disassemble the security ring N2.1121 from the coupler P32.1250, remove the coupler;
• Pull out the centering sleeve P32.1208 from the guide case to left, disassemble the guide case;
• Pull out the pressure spring N2.5237 with a screw driver from the cutter P32.1204;
• Remove the cutter from the driving pin P32.1032;
• Disassemble the screws N1.1305, lift slightly the welding stop gripper P32.1203 and the steel insert and
remove them from the tool;
• Adjust the welding pressure with the cam to the thickness of the strap 0.40 - 0.57 mm;
• Push the steel insert without welding stop gripper under the welding gripper P32.1053 until it touches the
parallel pin N2.2110;
• Turn the lever P32.1034 in welding position;
• Disassemble the safety ring N2.1121 from the bolt P32.1028, remove the bolt from the welding gripper;
• Turn the lever P32.1034 in start position;
• Pull out the steel insert with care to right under the welding gripper;
• Lift the rocker P32.1024 behind the welding gripper with a screw driver, remove the welding gripper
together with the ball cage P32.1027 and the balls N3.1702 from the tool;
• Lower the rocker, remove the thrust piece P32.1029 from the tool.
P35.2064
P32.1238
N1.1929
N1.1904
N1.6503
P32.1211
P32.1208
Guide case
P32.1250
N2.1121
N2.1118
P32.1212
P32.1029 
P32.1034
6 x N3.1702 
P32.1027 
P32.1053 
P32.1028 
N2.1121
Steel insert
P32.1203
 P32.1204
N2.5237
N1.1904
N1.6503
 N1.1305
N1.6504
 Klüber Isoflex Alltime SL2
 Mobilux EP2
 Klüber Isoflex NBU 15
 Loctite 222

14 P355000101en-3-
Assembling
Assembling in opposite order. Observe the following:
Pay attention to the proper seat of the thrust piece on the spring bolt P32.1030 when
lifting the rocker.
Pay attention to the fitting position of the cutter (see drawing).
Safe the screws N1.1305 with Loctite 222.
Lubrication
• Lubricate the rocker and the bolt P32.1028 in the area of the welding jaw with Klüber Isoflex NBU 15.
• Lubricate the balls, ball cage and the running surface of the balls on the welding gripper with Klüber Isoflex
Alltime SL2.
• Lubricate the cutter and the driver with Mobilux EP2.
After assembling
Adjust the welding pressure according to the thickness of the strap! (see 6.3.3)
9.3 Adjustment of the coupler P32.1250
The coupler is adjusted in our works.
In case of replacing the seesaw lever, the coupler or the lever body, the coupler has to be readjusted.
Procedure as follows:
Lever P32.1034 in start position.
The tool is disconnected from the air supply.
The coupler is fitted into the tool.
• Loosen screw N1.1553.
• Displace thrust piece P32.1252, so that it touches
the two seesaw levers without moving them.
• Retighten screw N1.1553.
Control:
The thrust piece must touch the seesaw levers (X1).
Both guide pins must sit on the welding stop
gripper(X2).
Coupler
Thrust piece
N1.1553
Seesaw lever
Welding stop
X1
X2
Guide pin
gripper

15
P355000101en-3-
10 PNEUMATIC SCHEMATIC
11 SERVICE
Servicing and repair work must only be carried out by authorized service centres.
If the tool breaks down or does no longer operate do not disassemble it. Send it fully assembled to the local
service center (see name and address on the rear page of this manual). Use original packing.
The pneumatic plastic strapping tool P355 is a high performance tool. We strongly recommend you to have it
serviced by an authorized service shop after 12 months at the latest if used one shift per day. If used two or
more shifts per day the tool has to be serviced after a shorter period of time.
12 CLEANING
Clean strap gripping parts from strap abrasion regularly using compressed air (do not use any mechanical tool
for cleaning).
When cleaning the surface of the tool do not use water or aggressive solvents!
1 Tensioner valve
2 Tension force control valve
3 Tensioning motor
4 Exhaust silencer
5 Welding valve
6 Welding motor valve
7 Welding time valve
8 Welding motor
9 Turn off valve
a Valve lever for tensioning
b Valve lever for welding
P

16 49032301.z
A1
B
C D
23456
A1
B
C D
23456
(5x) P35.2022 (5x) P35.2022 
(5x) P35.2024 
 Mobil Velocite No.6
 Mobilux EP2  Molykote BR2 plus  Klüber Isoflex Alltime SL2  Klüber Isoflex NBU 15  Loctite 603  Loctite 222
P35.2002
P35.2001
N2.2188
N3.1172
P32.1217 
N3.2106 
P32.1218 
P32.1219 
N3.1172
N3.2346
N2.2187
P32.1242
P32.1238
N1.2223
N4.9159
N2.4902
N1.6503 N1.1904
P32.1229
P32.1228
N3.3172
P32.1224
P32.1223
P32.1222
P35.2004
N3.3172
P32.1050 
N2.3342
P32.1216
P32.0136
P35.0120
P32.1254
N2.2189
N1.6505
N1.1909
N1.6505
P32.1233
N2.5823
N1.2216
P32.0110
P32.1123 
N3.1174
P35.2025
N1.3409
N2.2402
P35.2020
N2.2402
P35.0123
P35.2021
P35.2023
N3.1174
N6.6237 
P35.2027
 P35.2026
P35.2028
N1.1818

17
49032301.z
A7
B
C D
8910 11 12
 Mobil Velocite No.6  Mobilux EP2  Molykote BR2 plus  Klüber Isoflex Alltime SL2  Klüber Isoflex NBU 15  Loctite 603  Loctite 222  Orientation
P32.1049 
N3.1160
P32.1048 
P32.0120
P32.0119
N3.1178
N2.1610
 N1.2112
P32.1047
 P32.1046
 N3.2105
N2.2145 
P32.1044 
N3.1157
P35.2029 
 P35.2031
 N6.6235
N6.6163 
P35.2032 
N6.6235 
N6.6268 
N5.2702 P35.2014
N2.5192
N1.6173
P35.2013 
P35.2012
N2.1107
N1.6312
P35.2002
N21.2105
P35.2033
N2.1805 N1.6344
N5.2702
N2.5822
 P32.1051
P32.0118
N1.1935
N1.6504
 N3.1702
N3.1702 
N1.3128
P35.2038
P35.1344 
N2.5259 
P35.0120
P35.2039
(N3.3174)
P35.2035
 P35.2036
 N3.4509
 N1.6331
P35.2034
P32.1011
N6.6214 
P35.2037
N1.6331 
N4.9108
N6.6282 
N1.1936
P35.0134

18 49032301.z
A13
B
C D
14 15 16 17 18
 (6x) N3.1702
(14x) N2.5621 
P32.1210
P30.1157
 P32.1027
 Mobil Velocite No.6  Mobilux EP2  Molykote BR2 plus  Klüber Isoflex Alltime SL2  Klüber Isoflex NBU 15  Loctite 603  Loctite 222
P35.2007 
N2.5152 
N6.6280 
P35.2006 
N6.6117 
P35.2005 
N6.6280 
N3.1711 
N2.5219 
N2.4902
N1.1932
N1.6505
N41.9143
P35.2019
P32.1031 N2.2443
 P35.2047
N2.2473
P35.2065
N6.5693 N2.2190
 N2.5157 P32.1030 
N41.9129
P35.2002
P32.1011
P32.1203
P32.1201
N2.2110 N1.6504
N2.2187
N3.1134
N3.2347
P32.1024 
N3.2347
P32.1022
N3.1134
P32.1023 
P35.2008
P35.2009
N1.6331
N1.6331
P32.1037 
P32.1037 
N3.1159 
N3.1159 
N1.6331
P32.0115
 N2.2125
N2.1121
P32.1035 
P32.1053 
P32.1035 
N2.1121
P32.1028 
P32.1029 
P32.1032
P32.1021
P35.2017
 P35.2016
N1.1820
P35.2018 
N2.5152 
N6.6280 
P35.2015 
N6.6117 
P35.2005 
N6.6280 
N3.1711 
N2.5219 
 P32.1012
P32.1249
N2.2193
N2.5237
 P32.1204
P30.1163
P32.1206
P32.1251
P32.1252 N2.1121
N1.1553
P32.1250
N1.6504
P32.1248
P32.1210
P32.1208
N2.5178
P32.1211
N1.6503
N1.1904
N1.1904
N1.1929 N41.9127
N3.3173
 P35.2010
 N2.5132
P35.2011
 N3.1703
P32.1034
N1.6205
N1.1915
N1.1305 

19
49032301.z
A
B
C D
23 24
A19
B
C D
20 21 22
(5x) P35.2024 
N1.1106
N6.5137
N3.1702
 (5x) P35.2022
 Mobil Velocite No.6  Mobilux EP2  Molykote BR2 plus  Klüber Isoflex Alltime SL2  Klüber Isoflex NBU 15  Loctite 603  Loctite 222
P35.2002
N2.2101
P32.1023
N3.1174
N1.3409
P35.2025 P35.2021
N2.2402
N2.2402
P35.2020
P35.2023
P35.0124 P35.2027
P35.2026
N2.1606
P35.2064
N3.1174
P35.2041
N1.1813
N2.1118
P32.1212
N2.1613
P35.0120
P35.0122
P35.2043
P35.2046
N6.6211 
N6.6121 
P35.2045
N6.6121 
N6.6211
P35.2045
N6.6121 
N6.6211 
P35.2044
N2.1613
N2.5176
P35.2048 
N2.2106
P35.2056 
N6.6117 
N6.6211
P35.2055
N6.6117
N6.6211 
P35.2054
N6.6147 
N6.6211
P35.2053
N6.6147 
P35.2051 
N2.5176 
P35.2052
N6.6211
P35.0127
P35.0126
P35.2049 P35.2062
N6.6269 
N6.6281 
N6.6208 
P35.2057
N6.6269
N6.6157
P35.2058
N2.5224
P35.2059
N6.6269 
N6.6283
P35.2060
N2.1301
P35.2061
(N6.6501)
N1.1151
P35.2066
N1.6506
 (5x) P35.2022

[ ] = Group * = Wearing parts
20 49032301.een.fm
13 SPARE PARTS LIST 49.0323.01
49.0323.01 P355/12.7/0.40-0.64 P355.0001.01 01.07.04
Item-No. in group Pcs. Description Dimension Field
N1.1106 P35.0127 2 SCREW M6 X 20 C24
N1.1151 P35.0122 2 SCREW M6 X 80 B24
N1.1305 2 SCREW M4 X 7.8 D14
N1.1553 P32.1250 1 HEXAGON SCREW M4 X 8 B17
N1.1813 P35.0120 6 SCREW M5 X 16 A23
N1.1818 P35.0120 2 SCREW M5 X 20 C6
N1.1820 P35.0120 1 SCREW M4 X 25 A16
N1.1904 5 SCREW M5 X 20 D5+
N1.1909 2 FLAT HEAD SCREW M3 X 5 D2
N1.1915 P35.0120 2 SCREW M4 X 8 D17
N1.1929 1 SCREW M5 X 50 C18
N1.1932 P35.0120 2 FLAT HEAD SCREW M3 X 8 A14
N1.1935 P35.0120 4 FLAT HEAD SCREW M4 X 35 B7
N1.1936 P35.0120 2 FLAT HEAD SCREW M4 X 45 C7
N1.2110 P35.0125 2 COUNTERSUNK SCREW M5 X 16 --
N1.2112 P32.0118 3 COUNTERSUNK SCREW M4 X 10 B9
N1.2216 1 COUNTERSUNK SCREW M3 X 8 D3
N1.2223 1 COUNTERSUNK SCREW M3 X 6 C4
N1.3128 P35.0120 1 SOCKET SET SCREW M4 X 8 B8
N1.3409 P35.0123 1 SOCKET SET SCREW M4 X 8 A3
N1.3409 P35.0124 1 SOCKET SET SCREW M4 X 8 B19
N1.5105 P35.0125 2 HEXAGON NUT M8 --
N1.6173 P35.0120 1 WASHER 5.3 X 9 X 1 A11
N1.6205 P35.0120 2 SPRING LOCK WASHER M4 D17
N1.6312 P35.0120 1 SUPPORTING DISK 8 X 14 X 1.2 A12
N1.6331 P35.0120 6 SPACER WASHER 6 X 12 X 0.5 D9+
N1.6344 P35.0120 1 SPACER PIECE 6.3 X 15 X 5 C11
N1.6503 6 SAFETY WASHER M5 D4+
N1.6504 2 SAFETY WASHER M4 D14
N1.6504 P32.1250 1 SAFETY WASHER M4 B17
N1.6504 P35.0120 6 SAFETY WASHER M4 C7
N1.6505 2 SAFETY WASHER M3 D2+
N1.6505 P35.0120 2 SAFETY WASHER M3 A14
N1.6506 P35.0122 2 SAFETY WASHER M6 C24
N1.6506 P35.0127 2 SAFETY WASHER M6 C24
N21.2105 P35.0120 1 PARALLEL PIN 6 m6 X 40 B11
N2.1107 P35.0120 1 SECURITY RING 8 A12
N2.1118 1 SECURITY RING 6 A21+
N2.1121 1 SECURITY RING 5 B17
N2.1121 P35.0120 4 SECURITY RING 5 D14+
N2.1301 P35.0127 1 CIRCLIP 6 C23
N2.1606 1 SPRING RING SW6 A21
N2.1610 P35.0120 1 SPRING RING SB44 A9
N2.1613 P35.0126 2 SPRING RING D19+
N2.1805 P35.0120 1 TENSIONING RING 6 C10
N2.2101 P35.0122 2 PARALLEL PIN 5 m6 X 12 C20
N2.2106 P35.0122 1 PARALLEL PIN 5 m6 X 20 C21
N2.2110 P35.2001 1 PARALLEL PIN 4 m6 X 10 D14
N2.2125 P35.0120 1 PARALLEL PIN 4 m6 X 20 A15
N2.2145 P32.0118 3 PARALLEL PIN 4 h6 X 18 B10
N2.2187 P32.0110 2 PARALLEL PIN 3 m6 X 6 C4
N2.2187 P35.2001 1 PARALLEL PIN 3 m6 X 6 D14
