Frontgate CASSARA User manual

37793 - CASSARA 48" ROUND DINING TABLE
F R O N T G A T E *
O U T F I T T I N G A M E R I C A ' S F I N E S T H O M E S
Page 1 of 3

37793 - CASSARA 48" ROUND DINING TABLE
PART LIST :
HARDWARE :
Part #
QTY
Part #
QTY
A. TABLE TOP 1 PC H1 ALLEN HEAD BOLT 8 PCS
and SLEEVE NUT
B LEGS 4 PCS H2 ALLEN HEAD BOLT 4 PCS
C. LEG BASE 1 PC H3 UMBRELLA PLUG AND BRASS 1 SET
COLLAR
NUMBER OF PEOPLE TO INSTALL :
RECOMMENDED 2 Persons
TOOLS NEEDED (INCLUDED) :
T.1 ALLEN KEYS (Included)
ASSEMBLY TIME :
UNDER 30 MINUTES
PRE ASSEMBLY INSTRUCTIONS:
1 Do not throw away packaging materials until the assembly is complete. Part might be
accidentally thrown away.
ASSEMBLY INSTRUCTION :
STEP 1 :
1. a Lay Top Table (A) on the floor with underside facing up. Use the packaging material to
protect the Top Table against the floor to avoid scratches.
1.b Insert the Legs (B), DETAIL 1. Lock the Legs and the top by using Allen Head Bolt with
Sleeve nut (H1), 2pcs in each legs then tighten them with Allenkeys (T1), DETAIL 2.
Legs can be used in any corner. Repeat the Step 1.b on all corners.
Description Description
F R O N T G A T E *
O U T F I T T I N G A M E R I C A ' S F I N E S T H O M E S
DETAIL 2
DETAIL 1
T1
H1
B
A
A
B
Page 2 of 3

37793 - CASSARA 48" ROUND DINING TABLE
STEP 2 :
2. a Attached the Leg Base ( C) to the Legs (B) by aligning the holes and tenon, and lock by
the use of Allen head Bolt (H2), then tighten it by the Allen key (T1), Detail 3 and Detail 4
ASSEMBLY IS COMPLETE
Let the table stand. Insert Brass colar and Umbrella Plug (H4) to the predrilled center
part of the table, DETAIL 5
To level the table on un even surface, the leveler can be adjusted as per DETAIL 6
CARE & MAINTENANCE : Use mild detergent and water to clean. Store in dry, covered area
when not in use and at the end of the season. Occassionally check the nuts and bolts and re tighten if
needed.
Please contact one of Our Product Specialists for assembly assistence of questions at 1-800-537-8484
or email [e-mail]. Specialists are available weekdays 8:00 a.m. to 8:00 p.m. EST or
Saturday 9:30 a.m. to 6:00 p.m.
F R O N T G A T E
*
O U T F I T T I N G A M E R I C A ' S F I N E S T H O M E S
DETAIL 6
DETAIL 5
H4
DETAIL 3
T2
DETAIL 4
CH3
Page 3 of 3
