Frymaster PERFORMANCE PRO SERIES 45 Building instructions

Performance Pro Series
Service and Parts Manual
Gas Fryers Models 35 & 45
Frymaster, a member of the Commercial Food Equipment Service Association, recommends
using CFESA Certified Technicians.
24-Hour Service Hotline [phone] MARCH 2011

IF, DURING THE WARRANTY PERIOD, THE CUSTOMER USES A PART FOR THE ENODIS
EQUIPMENTOTHERTHANANUNMODIFIEDNEWORRECYCLEDPARTPURCHASEDDIRECTLY
FROM FRYMASTER AND DEAN, OR ANY OF ITS AUTHORIZED SERVICE CENTERS, AND/OR
THE PART BEING USED IS MODIFIED FROM ITS ORIGINALCONFIGURATION, THIS WARRANTY
WILL BE VOID. FURTHER, FRYMASTER AND DEAN AND ITS AFFILIATES WILL NOT BE LIABLE
FOR ANY CLAIMS, DAMAGES OR EXPENSES INCURRED BY THE CUSTOMER WHICH ARISE
DIRECTLY OR INDIRECTLY, IN WHOLE OR IN PART, DUE TO THE INSTALLATION OF ANY
MODIFIED PART AND/OR PART RECEIVED FROM AN UNAUTHORIZED SERVICE CENTER.
NOTICE
This appliance is intended for professional use only and is to be operated by qualified personnel only.
A Frymaster/DEAN Factory Authorized Service Center (FASC) or other qualified professional should
perform installation, maintenance, and repairs. Installation, maintenance, or repairs by unqualified
personnel may void the manufacturer’s warranty.
NOTICE
This equipment must be installed in accordance with the appropriate national and local codes of the
country and/or region in which the appliance is installed.
NOTICE TO U.S. CUSTOMERS
This equipment is to be installed in compliance with the basic plumbing code of the Building Officials
and Code Administrators International, Inc. (BOCA) and the Food Service Sanitation Manual of the
U.S. Food and Drug Administration.
NOTICE
Drawings and photos used in this manual are intended to illustrate operational, cleaning and technical
procedures and may not conform to onsite management operational procedures.
NOTICE TO OWNERS OF UNITS EQUIPPED WITH COMPUTERS
U.S.
This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:
1) This device may not cause harmful interference, and 2) This device must accept any interference
received, including interference that may cause undesired operation. While this device is a verified
Class A device, it has been shown to meet the Class B limits.
CANADA
This digital apparatus does not exceed the Class A or B limits for radio noise emissions as set out by
the ICES-003 standard of the Canadian Department of Communications.
Cet appareil numerique n’emet pas de bruits radioelectriques depassany les limites de classe A et B
prescrites dans la norme NMB-003 edictee par le Ministre des Communcations du Canada.
DANGER
Improperinstallation,adjustment,maintenanceorservice,andunauthorizedalterationsormodifications
can cause property damage, injury, or death. Read the installation, operating, and service instructions
thoroughly before installing or servicing this equipment. Only qualified service personnel may convert
this appliance to use a gas other than that for which it was originally configured.

DANGER
Adequate means must be provided to limit the movement of this appliance without depending upon the
gas line connection. Single fryers equipped with legs must be stabilized by installing anchor straps. All
fryers equipped with casters must be stabilized by installing restraining chains. If a flexible gas line is
used, an additional restraining cable must be connected at all times when the fryer is in use.
DANGER
The front ledge of the fryer is not a step! Do not stand on the fryer. Serious injury can result from slips
or contact with the hot oil.
DANGER
Do not store or use gasoline or other flammable liquids or vapors in the vicinity of this or any other ap-
pliance.
DANGER
Instructions to be followed in the event the operator smells gas or otherwise detects a gas leak must
be posted in a prominent location. This information can be obtained from the local gas company or
gas supplier.
DANGER
The crumb tray in fryers equipped with a filter system must be emptied into a fireproof container at the
end of frying operations each day. Some food particles can spontaneously combust if left soaking in
certain shortening material.
WARNING
Do not bang fry baskets or other utensils on the fryer’s joiner strip. The strip is present to seal the joint
between the fry vessels. Banging fry baskets on the strip to dislodge shortening will distort the strip,
adversely affecting its fit. It is designed for a tight fit and should only be removed for cleaning.

PERFORMANCE PRO SERIES GAS FRYERS MODELS 35 & 45
Table of Contents
CHAPTER 1: Service Procedures
1.1 General.................................................................................................................................................1-1
1.1.1 Pilot Ignition..............................................................................................................................1-1
1.1.2 Electronic Ignition.....................................................................................................................1-1
1.1.3 Controller Options.....................................................................................................................1-2
1.1.4 Thermostats and Temperature Probes .......................................................................................1-2
1.2 Moving the Fryer for Servicing...........................................................................................................1-2
1.3 Diagnostic Procedures.........................................................................................................................1-3
1.3.1 Cleaning the Gas Valve Vent Tube............................................................................................1-3
1.3.2 Checking the Burner Manifold Gas Pressure............................................................................1-3
1.3.3 Adjusting the Pilot Flame..........................................................................................................1-5
1.3.4 Adjusting Burner Ceramic Target Spacing and Alignment.......................................................1-5
1.3.5 Calibrating the Thermostat........................................................................................................1-5
1.3.6 Testing the Temperature Probe..................................................................................................1-7
1.4 Replacing Fryer Components..............................................................................................................1-7
1.4.1 Replacing a Controller or Computer.........................................................................................1-7
1.4.2 Replacing the Operating Thermostat in Units with Thermostat Control Panels.......................1-8
1.4.3 Replacing the Operating Thermostat in Units with Thermostat Access Doors.........................1-8
1.4.4 Replacing the Temperature Probe .............................................................................................1-9
1.4.5 Replacing the High-Limit Thermostat in Fryers with Thermostat Controls.............................1-9
1.4.6 Replacing the High-Limit Thermostat in Fryers with Other Controls......................................1-9
1.4.7 Replacing the Heat Mode Indicator Light in Fryers with Thermostat Controls .....................1-10
1.4.8 Replacing the Power or Melt Cycle Switch in Fryers with Thermostat Controls...................1-10
1.4.9 Replacing Burner Ceramic Targets .........................................................................................1-11
1.4.10 Replacing the Gas Valve........................................................................................................1-11
1.4.11 Replacing the Pilot Assembly or Thermopile........................................................................1-12
1.4.12 Replacing the Frypot.............................................................................................................1-12
1.4.13 Replacing the Pump/Motor ...................................................................................................1-14
1.5 Troubleshooting and Problem Isolation.............................................................................................1-15
1.5.1 Typical Problems.....................................................................................................................1-15
Pilot Failure.............................................................................................................................1-15
Ignition Failure........................................................................................................................1-15
Improper Burner Function.......................................................................................................1-16
Improper Temperature Control................................................................................................1-18
Gas Valve Malfunction............................................................................................................1-18
Computer Malfunction............................................................................................................1-18
Filtration Malfunction.............................................................................................................1-20
Leakage...................................................................................................................................1-22
Basket Lift Malfunction..........................................................................................................1-22
1.5.2 Interpretation of Analog Controller Lights .............................................................................1-24
1.6 Probe Resistance Chart......................................................................................................................1-24
1.7 Troubleshooting Guides ....................................................................................................................1-25
1.7.1 Troubleshooting the 24 VAC Circuit: Analog Controller........................................................1-25
Troubleshooting the 24 VAC Circuit: Electronic Ignition (Computer Controller).................1-25
Troubleshooting the 24 VAC Circuit: Standing Pilot (Computer Controller) ........................1-26
1.7.2 Troubleshooting the Gas Valve ...............................................................................................1-26
1.7.3 Troubleshooting the Thermostat .............................................................................................1-26
1.7.4 Troubleshooting the Temperature Probe.................................................................................1-27
1.8 Wiring Diagrams ...............................................................................................................................1-28
1.8.1 Standing Pilot..........................................................................................................................1-28
1.8.2 Electronic Ignition...................................................................................................................1-29
1.8.3 Non-Computer Controlled ......................................................................................................1-30
1.8.4 Electronic Ignition...................................................................................................................1-31
1.8.5 Filter Box ................................................................................................................................1-32
1.8.6 Modular Basket Lift 100/120V...............................................................................................1-33
1.8.7 Modular Basket Lift 208/250V...............................................................................................1-34

PERFORMANCE PRO SERIES GAS FRYERS MODELS 35 & 45
Table of Contents
CHAPTER 2: Parts List
2.1 Accessories ..........................................................................................................................................2-1
2.2 Basket Lift and Associated Parts..........................................................................................................2-2
2.3 Cabinetry..............................................................................................................................................2-4
2.3.1 FPP/FMP Model Cabinetry .......................................................................................................2-4
2.3.2 PMJ (Non-filter) Model Cabinetry ............................................................................................2-6
2.4 Casters, Legs, and Associated Hardware.............................................................................................2-8
2.5 Component Boxes................................................................................................................................2-9
2.6 Control Panel Assemblies, Flue Caps, and Related Items .................................................................2-11
2.7 Controller Assemblies........................................................................................................................2-13
2.8 Door Assembly...................................................................................................................................2-15
2.9 Drain System Components ................................................................................................................2-16
2.9.1 Drain Tube System ..................................................................................................................2-16
2.9.2 Drain Valves; FPP/FMP Models..............................................................................................2-17
2.9.3 Drain Valves; PMJ Models......................................................................................................2-19
2.10 Filter Boxes......................................................................................................................................2-20
2.11 Filter Pan Assembly .........................................................................................................................2-22
2.12 Frypots .............................................................................................................................................2-23
2.13 Frypot Cabinetry..............................................................................................................................2-24
2.13.1 PMJ45 Frypot Cabinetry........................................................................................................2-24
2.13.2 PMJ35 Frypot Cabinetry........................................................................................................2-25
2.14 Gas Valves and Burners ...................................................................................................................2-26
2.14.1 PMJ45 Gas Valves and Burners.............................................................................................2-26
2.14.2 PMJ35 Gas Valves and Burners.............................................................................................2-28
2.14.3 Ignitors...................................................................................................................................2-30
2.15 Oil Return Components ...................................................................................................................2-31
2.16 Oil Return Assembly........................................................................................................................2-33
2.17 Thermostats and Timers...................................................................................................................2-34
2.18 Wiring Harnesses, Pin Terminals, and Power Cords .......................................................................2-35
2.19 Garland Range (S35) Parts...............................................................................................................2-36
2.20 Power Shower..................................................................................................................................2-36

1-1
PERFORMANCE PRO SERIES GAS FRYERS MODELS 35 & 45
CHAPTER 1: SERVICE PROCEDURES
1.1 General
Performance Pro Series gas fryers (formerly Master Jet 35- and 45-series fryers) contain a welded
stainless steel frypot directly heated by gas flames diffused evenly over its lower surface by ceramic
targets. The flames originate from orifices in a U-shaped burner manifold positioned beneath the frypot.
They are equipped with either a millivolt gas valve or electromechanical gas valve that regulates gas flow
to the manifold. For operating information, refer to the Performance Pro Series Gas Fryers Models 35 &
45 Installation and Operation manual (P/N 819-6042). (Furthermore, referred to as the Installation and
Operation manual.)
1.1.1 Pilot Ignition
The pilot system is the pilot orifice, pilot hood, and thermopile. The pilot serves two purposes: lighting
the burners and heating the thermopile. In operation, the thermopile is in contact with the pilot flame
and generates millivolts. The millivolt output passes through a normally closed high-limit switch and
energizes the gas valve pilot coil, which opens the pilot valve. If the pilot flame is extinguished, the gas
valve pilot coil loses voltage and the pilot valve closes.
In units equipped with 24-volt electromechanical gas valves, a separate 24-volt circuit activated by the
fryer power switch provides voltage through the thermostat or controller to the gas valve main coil,
which opens the main valve. The main gas valve will not open if the pilot valve is not open. Light the
pilot flame manually using a match or the optional built-in piezo ignitor after installing the fryer.
1.1.2 Electronic Ignition
In units configured for electronic ignition, a black ignition module connected to an ignitor assembly
replaces the pilot system. The ignition module performs three important functions: supply voltage to the
gas valve, provide an ignition spark, and proof the pilot flame. The module contains a 4.5-second time
delay circuit and a coil that activates the gas valve. The ignitor assembly consists of a spark plug, a pilot,
and a flame sensor element.
At start-up the power switch is placed in the ON position, supplying 12 VDC to the heat control circuitry
in the controller or computer and to one side of the heat relay coil on the interface board. If resistance in
the temperature probe indicates the temperature in the frypot is below 180°F (82°C), the current flows
through a melt cycle circuit where a timer switch alternately closes for 3 seconds and opens for 24
seconds. If the temperature is 180°F (82°C) or above, the current flows through a heat circuit, bypassing
the timer switch. In either case, current is supplied to the other leg of the heat relay coil, which closes an
electronic switch in the 24 VAC circuit to provide current to the ignition module.
Circuitry in the ignition module sends 24 VAC current to the gas valve via a normally closed high-limit
switch and a drain safety switch. Simultaneously, the module causes the ignitor to spark for 4 seconds
to light the pilot flame. A flame sensor verifies that the pilot is lit by measuring the flow of microamps
through the flame (can vary, averages 1.9 microamps). If the pilot does not light or is extinguished,
current to the ignition module is stopped, preventing the main valve from opening, and the ignition
module locks out until the power switch is turned OFF, then back ON.

1-2
1.1.3 Controller Options
Performance Pro gas fryers may be equipped with thermostat controls, analog controllers, digital
controllers, basket lift timers, or Computer Magic computers. In fryers equipped with thermostatcontrol
panels, the fryer and melt cycle are turned on and off using rocker switches and the temperature is set by
a knob connected directly to the frypot-mounted thermostat. These units have no interface board. When
the melt cycle switch is placed in the ON position, the fryer stays in the melt cycle mode until the switch
is manually placed in the OFF position, even if the oil is at setpoint temperature. In units equipped with
thermostat access doors, the temperature control knob is located behind the hinged front panel. Service
procedures for this type of thermostat are slightly different from units with other thermostat controls.
Fryers equipped with other types of controllers have an interface board located in the component shield
behind the control panel.
1.1.4 Thermostats and Temperature Probes
Performance Pro gas fryers may have different kinds of thermostats depending on their configuration.
Fryersequippedwiththermostatcontrolshaveanadjustablecontrollingthermostat.Adjustthetemperature
at which the thermostat opens and closes by turning the attached knob. The Fenwal controlling thermostat
used in these fryers is sensitive to 1° changes in temperature.
Fryers equipped with other types of controls have a temperature probe. In these units, the probe resistance
varies directly with the temperature. As the temperature rises, so does the amount of resistance at a rate
of approximately 2 ohms for every 1° (F or C) of temperature (see Probe Resistance Chart, Section 1.6).
Circuitry in the controller monitors the probe resistance and controls burner firing when the resistance
exceeds or falls below programmed temperatures (i.e., setpoint). To program temperatures into the fryer,
use the keypad on the face of the controller. When testing temperature probes, unplug the 15-pin wiring
harness from the controller; otherwise, the reading may be incorrect due to extra resistance.
All open burner fryers are equipped with a high-limit thermostat. If the fryer fails to properly control oil
temperature, the high-limit thermostat prevents the fryer from overheating to flash point. The high-limit
thermostat acts as a normally closed power switch that opens when exposed to temperatures between
425°F to 450°F (218°C to 232°C). It will automatically reset when the oil temperature drops below
350°F (177°C).
1.2 Moving the Fryer for Servicing
If it is necessary to move the fryer before servicing, complete the following actions:
1. Drain the frypot.
2. Turn off the gas supply to the unit. Unplug any power cords. Disconnect the unit from the gas
supply.
3. Remove attached restraining devices, including chain restraints and anchor straps.
4. Relocate the fryer to an appropriate area for servicing.

1-3
After servicing is complete:
5. Return the fryer to its original location, reconnect the unit to the gas supply, and open the gas supply
valve. Be sure to reattach all restraining devices and plug in all electrical cords.
6. Refill the fryer with oil.
1.3 Diagnostic Procedures
1.3.1 Cleaning the Gas Valve Vent Tube
1. Carefully unscrew the vent tube from the gas valve.
NOTE: Straighten the vent tube for easy removal.
2. Pass a piece of binding wire (.052-inch diameter) or equivalent through the tube to remove
obstructions.
3. Remove the wire and blow through the tube to ensure that it is clear.
4. Reinstall the tube and bend it so that the opening is pointing down.
1.3.2 Checking the Burner Manifold Gas Pressure
1. Ensure that the gas valve knob or button is in the OFF
position.
2. Remove the pressure tap plug from the end of the manifold.
3. Connect a manometer or pressure gauge to the port.
4. Place the gas valve in the PILOT position and light. When the burner lights and continues to burn,
note the gas pressure reading and compare it to the accompanying tables.
To adjust burner gas pressure:
5. On non-CE valves, remove the cap from the regulator adjustment screw.
6. On all units, increase the setting on the thermostat until the burner comes on.
7. Monitor the gas pressure reading on the manometer or pressure gauge.
Remove this plug and
connect a manometer or
pressure gauge to the
port.
WARNING
The frypot must be filled
with oil or water during this
procedure.

1-4
To access the pilot adjustment
screw on non-CE valves, this cap
must be removed.
Pilot Adjustment Screw
Honeywell Valve
(Non-CE Units) Honeywell Valve (CE Units)
Gas Valve Regulator
Adjustment Screw
Locating the gas valve regulator adjustment screw and pilot adjustment screw.
35-Series Non-CE Standard
Burner Manifold Gas Pressures
Gas Pressure
Natural 4.0” W.C.
0.87 kPa
Propane 9.0” W.C.
2.24 kPa
35-Series CE Standard
Burner Manifold Gas Pressures
Gas Pressure
Natural Gas Lacq
(G20) under 20 mbar 9 mbar
Natural Gas Gronigue*
(G25) under 25 mbar 11 mbar
Natural Gas Gronigue*
(G20) under 20 mbar 11 mbar
Propane
(G31) under 37 or 50 mbar 22.5 mbar
* Belgian G25 and G20 = 9.0 mbar
45-Series Non-CE Standard
Burner Manifold Gas Pressures
Gas Pressure
Natural 3.5” W.C.
0.73 kPa
Propane 8.25” W.C.
2.05 kPa
45-Series CE Standard
Burner Manifold Gas Pressures
Gas Pressure
Natural Gas Lacq
(G20) under 20 mbar 7.5 mbar
Natural Gas Gronigue*
(G25) under 25 mbar 10 mbar
Natural Gas Gronigue
(G20) under 20 mbar 10 mbar
Propane
(G31) under 37 or 50 mbar 20.6 mbar
* Belgian G25 = 7.0 mbar
8. Use a flat-head screwdriver to adjust the gas valve regulator adjustment screw to obtain the prescribed
pressure written on the rating plate or one of the charts above. (Use the diagram on below to locate
this screw.) Turn the screw clockwise to increase gas pressure and counterclockwise to decrease gas
pressure.
9. On non-CE units, reinstall the gas valve regulator cap screw when the correct manifold pressure is
obtained.
10. Place the gas valve in the OFF position. Remove the fitting from the pressure tap hole and reinstall the
pressure tap plug.
11. Place the gas valve in the PILOT position. Re-light and check for any gas leaks.
12. Place the gas valve in the OFF position.

1-5
1.3.3 Adjusting the Pilot Flame
1. On non-CE valves, remove the cap covering the pilot adjustment screw. On all valves, use a flat-
tipped screwdriver to turn the pilot adjustment screw counterclockwise to increase the length of the
flame or clockwise to decrease the length of the flame. (Use the diagram on the previous page to
locate this screw.) Adjust the flame to a length of 1- to 1½- inches (25 to 38 mm).
2. On non-CE valves, reinstall the pilot adjustment screw cap.
1.3.4 Adjusting Burner Ceramic Target Spacing and Alignment
Proper spacing of the top edge of the ceramic targets is ¾-inch (13 mm) from the frypot side. To adjust
target spacing, bend the brackets away or toward the frypot, as needed.Alength of board ¾-inch thick is
useful as a gauge to verify spacing and alignment.
1.3.5 Calibrating the Thermostat
Fryers with thermostat access doors:
1. Fill the frypot to the lower OIL-LEVEL line with cooking oil. If using solid shortening, pack it
tightly into the frypot before starting the calibration procedure.
2. Light the pilot. (See Chapter 3 of the Installation and Operation manual for detailed lighting
instructions.)
3. Insert a thermometer or pyrometer into the frypot, about 1-inch from the thermostat.
4. Open the thermostat access door and set the thermostat on the fryer to 325°F (162°C).
5. When oil reaches 325°F (162°C), allow the burners to cycle on and off three times.
6. Take a temperature reading when the burners go off for the third time.
7. Loosen the setscrews in the thermostat knob and turn the knob to the temperature established by the
thermometer/pyrometer reading.
There should be approximately ¾-inch spacing between the top edge
of the targets and the side of the frypot.
¾-inch

1-6
8. Allowtheburnerstocycleonand offthreemoretimesandrecheckthethermometer/pyrometerreading
against the thermostat setting. Temperature readings should be within 5°F (2.8°C) of setpoint.
Fryers with thermostat control panels:
NOTE: Remove the thermostat knob from its shaft to allow the control panel to hinge downward.
Follow the instructions in Section 1.4.2 to remove the knob and control panel.
1. Fill the frypot to the lower OIL-LEVEL line with cooking oil. If using solid shortening, pre-melt it
before starting the calibration procedure.
2. Ensure the fryer power switch is in the OFF position, and light the pilot. (Refer to Chapter 3 of the
Installation and Operation manual for detailed lighting instructions.)
3. Insert a thermometer or pyrometer into the frypot so that it
touches the thermostat guard.
4. Loosen the setscrew and stop screw securing the thermostat
shaft extension to the flexible shaft. Remove the extension to
expose the slot in the end of the flexible shaft.
5. Place the fryer power switch in the ON position.
NOTE: If the burner does not light at this time, it does not
mean the thermostat is defective.
Use a small flat-head screwdriver to slowly turn the flexible shaft counterclockwise until the burner
lights.
6. When the oil temperature reaches 325°F (162°C), slowly turn the flexible shaft clockwise until the
burner turns off. Then, allow the fryer to sit for a few minutes.
7. Repeat Steps 5 and 6 at least three times to ensure that the setting is accurate. The thermostat control
is considered properly calibrated if the burner lights when the cooking oil cools to 325°F (162°C).
Do not take the reading when the burner shuts off after raising the temperature.
8. Once the thermostat is calibrated, allow the burner to cycle on and off at least three times to ensure
that it lights at the correct temperature.
9. After the calibration is complete, place the fryer power switch in the OFF position and disconnect
the fryer from the electrical supply.
10. Carefully replace the thermostat shaft extension so that the stop screw points straight up. Without
rotating the flexible shaft, tighten the stop screw, locking nut, and setscrew.
11. Close the fryer control panel and replace the screws and bezel.
12. Reinstallthethermostat knob.Align itspointerwith the325°F(162°C) indexmarkon thetemperature
dial.
13. Reconnect the fryer to the electrical supply.
CAUTION
The thermostat flexible shaft
must not be rotated while
installing the thermostat
shaft extension!
Donotrotatetheflexibleshaft
more than two turns in either
direction. Doing so will cause
damage to the thermostat.

1-7
1.3.6 Testing the Temperature Probe
1. While it is still in the frypot, inspect the probe body for damage. Inspect the leads for fraying,
burning, breaks, or kinks. If the probe is bent, dented, or cracked, or if the leads are damaged, replace
the probe.
2. Determine the temperature of the cooking oil using a thermometer or pyrometer placed at the tip of
the probe.
3. Disconnect the 15-pin wiring harness from the interface board. Measure the probe resistance using
J2 pins 13 and 14.
4. Resistance should approximately equal the given probe resistance for the corresponding temperature
on the chart in Section 1.6, Page 1-23. If not, the probe has failed and must be replaced. Probes
cannot be calibrated.
NOTE: A defective probe will cause inaccurate temperature measurements. If the temperature,
as measured by the probe, varies by more than 5°F!(2.8°C!) from the thermometer or pyrometer
reading, the probe should be replaced. Temperature probes cannot be calibrated.
1.4 Replacing Fryer Components
1.4.1 Replacing a Controller or Computer
1. Disconnect the fryer from the electrical power supply.
2. Slide the metal bezel up to disengage the lower tabs. Then, slide the bezel down to disengage the
upper tabs.
3. Remove the two screws holding the controller to the control panel frame.
4. Hinge the controller down to access the 15-pin wiring harness on the back and unplug it.
5. Lift the controller up and out of the hinged tab slots.
6. Use a
5/16-inch nut driver (P/N 802-0352) to remove the nut and green grounding wire from the back
of the controller.
7. If replacing the 15-pin wiring harness, do so now. Plug the new 15-pin wiring harness into the
interface board with the metal ring on the controller-end of the connector.
8. Connect the 15-pin wiring harness and the green ground wire to the new controller. When the
connector on the harness is completely engaged, the clips on either side will snap into place.
9. Re-hinge the controller by inserting the tabs on the bottom into the slots on the control frame panel.
10. Move it into the closed position against the control panel frame and replace the screws in the top
corners.
11. Insert the top tabs on the bezel into the slots on the underside of the top cap. Slide the bezel down to
engage the lower tabs in the lower slots.

1-8
1.4.2 Replacing the Operating Thermostat in Units with Thermostat Control Panels
1. Disconnect the fryer from the electrical power supply. Turn
off the gas and disconnect the fryer.
2. Drain the frypot.
3. Loosen the setscrew securing the thermostat knob and remove
the knob. Remove the screws from the upper left and right
corners of the control panel. The control panel hinges at the
bottom and will swing open from the top.
4. Disconnect the 9-pin wiring harness and remove the control
panel from the fryer by disengaging its tabs from the hinge
slots in the mounting frame.
5. Loosenthesetscrewssecuringtheflexibleshafttothethermostat
shaft. Slip the flexible shaft off the thermostat shaft.
6. Remove the flexible shaft guide by removing the two sheet
metal screws securing it to the upper frame.
7. Disconnect the thermostat leads from pin 14 in the 20-pin
terminal block and from the gas valve terminal.
NOTE: If the fryer has a melt cycle, the thermostat leads
connect to the PC board rather than to the terminal block and
gas valve. Disconnect the leads from the PC board if this is
the case.
8. Unscrew the thermostat from the frypot and remove it.
9. Apply Loctite™ PST56765 thread sealant or equivalent to
the threads of the replacement thermostat.
10. Reverse Steps 1-8 to install the replacement thermostat.
1.4.3 Replacing the Operating Thermostat in Units with Thermostat Access Doors
1. Disconnect the fryer from the electrical power supply. Turn off the gas and disconnect the fryer.
2. Drain the frypot.
3. Use an allen wrench to loosen the setscrew at the side of the thermostat knob. Remove the knob.
4. Remove the two setscrews on both sides of the thermostat shaft and remove the dial plate.
5. Disconnect the thermostat wires from the gas valve.
6. Use a slotted socket to unscrew the thermostat from the frypot.
7. Apply Loctite™ PST56765 thread sealant or equivalent to the threads of the replacement thermostat.
8. Reverse Steps 1-7 to install the replacement thermostat.
stop screw
locking nut
setscrew
Loosen these setscrews and slip the
flexible shaft off of the thermostat shaft.
CAUTION
The thermostat flexible shaft
must not be rotated while
installing the thermostat
shaft extension!
Donotrotatetheflexibleshaft
more than two turns in either
direction. Doing so will cause
damage to the thermostat.

1-9
1.4.4 Replacing the Temperature Probe
1. Disconnect the fryer from the electrical supply.
2. Drain the frypot.
3. Remove the controller or computer according to the instructions in Section 1.4.1.
4. Unplug the 12-pin wiring harness from the front of the interface board.
5. Use a pin-pusher to remove the temperature probe wires (pins 1 and 2) from the 12-pin wiring harness
6. Unscrew the temperature probe from the frypot and remove.
7. Apply Loctite™ PST56765 thread sealant or equivalent to threads of the replacement probe.
8. Screw the new probe into the frypot.
9. Reverse Steps 1-5 to reassemble.
10. Check the probe according to the instructions in Section 1.3.6.
1.4.5 Replacing the High-Limit Thermostat in Fryers with Thermostat Controls
1. Disconnect the fryer from the electrical supply.
2. Drain the frypot.
3. Remove the thermostat knob and/or control panel as instructed in Section 1.4.2 or 1.4.3.
4. Disconnect the high-limit thermostat leads from the gas valve pilot coil.
5. Unscrew the high-limit thermostat from the fryer and remove.
6. Apply Loctite™ PST56765 thread sealant or equivalent to the threads of the replacement high-limit
thermostat.
7. Reverse Steps 1-5 to the install replacement high-limit.
1.4.6 Replacing the High-Limit Thermostat in Fryers with Other Controls
1. Disconnect the fryer from the electrical supply.
2. Drain the frypot.
3. Remove the bezel and controller as instructed in Section 1.4.1, Steps 2 and 3.
4. Unplug the 15-pin wiring harness and grounding wire from the controller.
5. Remove the high-limit thermostat wires from the gas valve pilot coil.
CAUTION
Drain the frypot before pro-
ceeding.
CAUTION
Drain the frypot before pro-
ceeding.
CAUTION
Drain the frypot before pro-
ceeding.

1-10
6. Unscrew the high-limit thermostat from the fryer and remove it.
7. Attach the appropriate terminals (instructions furnished in the replacement kit) to the thermostat
leads.
8. Apply Loctite™ PST56765 thread sealant or equivalent to the threads of the replacement high-limit
thermostat.
9. Reverse Steps 1-6 to install the replacement high-limit.
1.4.7 Replacing the Heat Mode Indicator Light in Fryers with Thermostat Controls
1. Disconnect the fryer from the electrical power supply.
2. Remove the thermostat knob and control panel as instructed in Section 1.4.2 or 1.4.3, as appropriate.
3. Carefully press the light out from the back of the control panel.
4. Disconnect one wire at a time and reconnect it to the replacement light (before disconnecting the
next wire). Continue until all wires are transferred.
5. Carefully press the light back into the control panel.
6. Reinstall the thermostat knob and control panel by reversing Step 2.
7. Reconnect the fryer to the electrical power supply.
1.4.8 Replacing the Power or Melt Cycle Switch in Fryers with Thermostat Controls
1. Disconnect the fryer from the electrical power supply.
2. Remove the thermostat knob and control panel as instructed in Section 1.4.2.
3. Using a flat-head screwdriver, disconnect the chrome bezel from the tabs on the switch and press the
switch out from the front.
4. Carefully press the new switch into the chrome bezel, making sure the tabs on the switch engage the
slots in the bezel.
5. Disconnect one wire at a time and reconnect it to the replacement switch (before disconnecting the
next wire). Continue until all wires are transferred.
6. Reinstall the thermostat knob and control panel by reversing Step 2.
7. Reconnect the fryer to the electrical power supply.

1-11
1.4.9 Replacing Burner Ceramic Targets
1. Disconnect the fryer from the electrical power supply. Turn off the gas and disconnect the fryer.
2. Drain the frypot or remove the handle from the drain
valve.
3. Remove the round drain sections as necessary to expose the
burners and heat shield.
4. Disconnect the wires from the gas valve terminal block, marking each wire to facilitate reconnection.
5. Remove the high-limit thermostat wires from the gas valve pilot coil.
6. Disconnect the pipe union collar located on the bottom of the gas valve.
7. Remove the burner heat shield hanger screws at the front of the burner and remove the heat shield.
In units with built-in filtration, there may be a second heat shield located under the burner manifold.
Remove the screws holding it in place and remove it.
8. Remove the filter pan by sliding it out of the unit and lifting it up and out of the roller track.
9. Remove the burner hanger screws and lower the front of the main burner. Pull it forward to clear the
rear burner hanger and lower the burner to the floor.
10. Raise the front of the fryer enough to slide the burner from under the fryer cabinet.
11. To replace only the ceramic targets, straighten the
target locking tabs with a pair of needle nose pliers or a
screwdriver and slide the target up and off the bracket. Slide
the replacement target onto the bracket and bend the locking
tabs down.
To replace the entire target assembly, use a ½-inch (13mm) box end wrench to remove the two brass
orifices that hold the assembly to the burner manifold. Position the new assembly and replace the
orifices.
12. Reverse Steps 1-9 to reinstall the burner assembly. Compare spacing and alignment of targets with
the parameters in Section 1.3.4.
1.4.10 Replacing the Gas Valve
1. Disconnect the fryer from the electrical power supply. Turn
off the gas and disconnect the fryer.
2. Drain the frypot or remove the handle from the drain valve.
3. Disconnect the wires from the gas valve terminal block, marking each wire to facilitate reconnection.
CAUTION
Avoid cross-threading and
stripping when reinstalling
the brass orifices.
WARNING
Drainthefrypotorremovethe
handle from the drain valve
before proceeding further.
WARNING
Drainthefrypotorremovethe
handle from the drain valve
before proceeding further.

1-12
4. Remove the high-limit thermostat wire from the gas valve pilot coil.
5. Disconnect the pilot gas line fitting from the gas valve.
6. Disconnect both pipe union collars from the gas valve and remove the valve.
7. Remove the pipefittings from the old gas valve and install them on the replacement valve. Use
Loctite™ PST56765 or equivalent pipe thread sealant on the threads.
8. Reverse Steps 1-6 to install the replacement gas valve.
1.4.11 Replacing the Pilot Assembly or Thermopile
1. Remove the burner assembly in accordance with Steps 1-10
in Section 1.4.9.
2. To replace only the thermopile:
a. Bend the clip at the bottom of the pilot assembly and press
the thermopile out of the pilot assembly from the top.
b. Disconnect the thermopile fitting from the gas valve pilot coil.
c. Reverse Steps a and b to install the replacement thermopile.
3. To replace the complete pilot assembly:
a. Disconnect the pilot tubing from the bottom of the pilot assembly.
b. Remove the screw from the pilot mounting bracket to release the pilot assembly.
c. Disconnect the thermopile fitting from the gas valve pilot coil.
d. Reverse Steps a-c to install the replacement assembly.
4. Reinstall the burner assembly by reversing Steps 1-8 of Section 1.4.9.
1.4.12 Replacing the Frypot
1. Drain the frypot.
2. Disconnect the fryer from the electrical power supply. Turn off the gas supply and disconnect the
fryer.
3. Remove all accessories (i.e., frypot covers, basket lift arms, etc.) from the fryer.
4. If the fryer is equipped with a thermostat control, remove the thermostat knob and control panel
according to Steps 3-8 in Section 1.4.3.
NOTE: If the fryer is configured with a melt cycle, the thermostat leads will be connected to the PC board
rather than to the terminal block and gas valve. Disconnect the leads from the PC board if this is the case.
Bend the clip to release the thermopile.
WARNING
Drainthefrypotorremovethe
handle from the drain valve
before proceeding further.

1-13
5. If the fryer is not equipped with a thermostat control, remove the controller according to Steps 2-6
in Section 1.4.1.
6. Disconnect the 12-pin plug from the interface board. Use a pin-pusher to remove the temperature
probe wires (pins 1 and 2) and the high-limit thermostat leads (pins 6 and 8) from the plug. Leave
all other wires connected.
7. Remove the control panel frame by removing the screws in the upper left and right corners that
secure the control panel to the topcap. Remove the screws in the top and bottom holes of each brace
of the control panel that secure it to the fryer. Pull the control panel straight out of the fryer frame.
It may require a rubber mallet to loosen it.
8. Disconnectthewiresfromthecomponentsinthecomponentshieldandmarktofacilitatereconnection.
9. Disconnect the wires from the gas valve terminal block and mark each to facilitate reconnection.
10. Remove the cover from the drain safety switch, disconnect the wires from the switch, and pull them
out of the switch box.
11. Pull up and forward on the component shield to clear the rear mounting stud on the front of the
frypot and remove it from the fryer by rotating its right side up and to the left.
12. Disconnect the pipe union on the bottom of the gas valve.
13. On units with filtration, disconnect the section of drain connected to the drain valve of the frypot to
be removed.
14. Take off the topcap by removing the pairs of screws from each tab in the upper corners. Pull up to
slide it off the fryer. It may require a rubber mallet to loosen it.
15. Remove the frypot hold-down bracket, which attaches the front of the frypot to the frame of the fryer.
It is held in place by three screws: two securing it to the frame and one securing it to the frypot.
16. Remove the flue cap:
a. Remove all of the screws attaching the back panels to the
fryer and remove the panels.
b. Remove the screws in the bottom left and right corners of
the flue cap.
c. Slide the flue cap up to remove it.
17. Remove the oil return line from the front of the frypot to be removed.
18. Lift the complete frypot assembly (frypot, burner, gas valve, and flue) from the fryer cabinet.
19. Transfer the burner heat shield and burner to the replacement frypot.
20. Remove the drain valve, thermostat or temperature probe, and high-limit thermostat and install them
on the replacement frypot.
CAUTION
Clean all threads and apply
Loctite™ PST56765 thread
sealant or equivalent when
installing the drain valve,
high-limit, and thermostat
or temperature probe on the
replacement frypot.

1-14
21. In units with multiple frypots, add a bead of silicon along the joint between the frypots to ensure a
seal. Then, insert the top connecting strip.
22. Reverse Steps 1-25 to reassemble the fryer.
1.4.13 Replacing a Pump/Motor
1. Disconnect the unit from the electrical power supply.
2. Remove the filter pan from the unit and drain the frypots into a Shortening Disposal Unit (SDU) or
other appropriate metal container.
DANGER
DO NOT attempt to drain more than one full frypot or two split frypots into the SDU at one time.
3. Position a container beneath the oil return fitting at the front of the cabinet. Disconnect the flexible
oil line from the fitting, allowing any residual oil to drain into the container.
4. At the rear of the fryer, unplug the left connector (as viewed from the rear of the fryer) from the
transformer box. Using a pin pusher, push the pump solenoid valve wires from Pins 7 and 9.
5. Remove the four nuts and bolts attaching the motor mount to the rear motor mount support.
6. At the front of the fryer, remove the cover plate from the front of the motor and disconnect the motor
wires.
7. Place a 1-foot (30.5-cm) length of wood (or similar support) beneath the motor mount near the front
of the unit and remove the two remaining nuts and bolts attaching the motor mount to the front
cabinet cross-brace.
8. Carefully remove the support and lower the motor mount to the floor, allowing the rear of the mount
to slide forward and off the rear motor mount support.
9. Disconnect the Power Shower flexline (if applicable) or the oil return flexline from the pump. The
motor and pump assembly can now be pulled from beneath the fryer and the failed component can
be removed and replaced.
10.Position the new/repaired motor and pump assembly beneath the fryer and reconnect the Power
Shower flexline (if applicable) or the oil return flexline to the pump. Lift the rear of the motor mount
up and onto the rear motor mount support.
11. Lift the front of the motor mount up and support it with a 1-foot (30.5-cm) piece of wood or a similar
support. Install but do not tighten the two nuts and bolts that attach the motor mount to the front
cabinet cross-brace.
12.Install and tighten the four nuts and bolts that secure the motor mount to the rear motor mount
support. Reconnect the solenoid valve wires to Pins 7 and 9 of the 9-pin connector (polarity does
not matter) and reconnect the plug.
13.At the front of the fryer, tighten the two nuts and bolts at the front of the motor mount. Reconnect
the motor power wires and reinstall the wiring cover plate.
14.Reconnect the oil return flexline and reinstall the filter pan.
15.Reconnect the unit to the electrical power supply, fill the frypots with oil, and check for proper
operation.
1.5 Troubleshooting and Problem Isolation
Because it is not feasible to include every issue that might occur, this section is intended to provide
technicians with a general knowledge of the broad problem categories associated with this equipment
and the probable causes of each. With this knowledge, the technician should be able to isolate and

1-15
correct any problem encountered.
1.5.1 Typical Problems
You are likely to encounter problems in these broad categories:
Read the following sections to learn more about each category. A series of troubleshooting guides is
also included at the end of the chapter to assist in identifying some of the more common problems. In
addition, Section 1.5.2 will guide technicians through interpretation of digital controller lights, helpful
in diagnosing problems.
Pilot Failure
There are two types of pilot failure: no pilot flame and unreliable pilot flame.
Ignition Failure
Ignition failure occurs when the gas valve no longer receives power, the gas supply stops, or the pilot
flame goes out. Solid-state controllers indicate ignition failure by illuminating the heat light and trouble
light simultaneously. Computers and digital timers will read HELP to indicate ignition failure. There are
three primary areas of focus in diagnosing and correcting ignition failure:
1. The gas and electrical power supplies
2. The electronic circuits
3. The gas valve.
1. Pilot Failure
2. Ignition Failure
3. Improper Burner Function
4. Improper Temperature Control
5. Gas Valve Malfunction
6. Computer Malfunction
7. Filtration Malfunction
8. Leakage
9. Basket Lift Malfunction
No pilot flame:
• Insufficient gas supply
• Clogged pilot orifice
• Air in gas lines (usually in new installations).
Unreliable pilot flame:
• Open or grounded high limit
• Loose or corroded wire connections
• Low or no voltage out of thermopile
• Bad gas valve.
The Gas and Electrical Power Supplies
The main indicators that the gas or electrical power supply is the cause of ignition failure are as follows:
an entire battery of fryers fails to light, and/or there are no indicator lights illuminated on the fryer
experiencing ignition failure. Verify that the quick disconnect hose is properly connected, the fryer is
plugged in, the main gas supply valve is open, and the circuit breaker for the fryer electrical supply is
not tripped.
