FS 10Base-T User manual

Industrial10/100/1000Base-Tto100/1000Base-X
SFPPoE+EthernetMediaConverter
Industrieller 10/100/1000Base-T auf 100/1000Base-X SFP PoE+
Ethernet-Medienkonverter
Convertisseur de Média Ethernet PoE+ Industriel, 10/100/1000Base-T
vers 100/1000Base-X SFP
IMC-1F1T
Quick Start Guide
Quick-Start Anleitung
Guide de Démarrage Rapide

- 1 -
EN
1. Introduction
1.1 Package Contents
Thank you for choosing FS IndustrialPoE+MediaConverter. This guide is
designed to familiarize you with the layout of the IndustrialPoE+Media
Converter and describes how to deploy the media converter in your network. In
the following section, “IMC-1F1T” indicates the Industrial PoE+ Media Converter.
Open the box of the IMC-1F1T and carefully unpack it. The box should contain
the following items:
If any of these are missing or damaged, please contact your sales representative
immediately; if possible, retain the box including the original packing material,
and use them again to repack the product in case there is a need to return it to
us for repair.
Industrial PoE+ Media Converter x 1
DIN-rail Kit
Wall-mount Kit
Quick Start Guide x 1

- 2 - EN
1.2 Product Specications
Dimensions (H x W x D)
1.26''x 3.43''x 5.31'' (32x87x135 mm)
PoE: PoE-in-Use
Interface
Copper Interface
Fiber Optic Interface
Power Over Ethernet
PoE Output Standard
PoE Power Supply Type
Power Pin Assignment
PoE Power Budget
Hardware Specications
Speed
Flow Control
Duplex Mode
1x 10/100/1000Base-T RJ45 with Data + Power output
Auto-negotiation, auto MDI/MDI-X
1x 100/1000Base-X SFP
Product IMC-1F1T
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
PoE Power Output
52V DC: 15.4 watts
52V DC: 30 watts
End-span
30 watts
Back pressure for half duplex mode
IEEE 802.3x pause frame for full duplex mode
Full or half duplex mode by auto-negotiation (TP)
Jumbo Frame
9K
LED
System: P1, P2 and Fault
Fiber 100/1000Base-X: LNK/ACT
TP 10/100/1000Base-T: LNK/ACT and 1000
Twisted-pair:
10/100Mbps for half/full duplex
1000Mbps for full duplex
Fiber Optic:
100/1000Mbps for full duplex
1/2(+), 3/6(-)

- 3 -
EN
Power Consumption
Input Voltage
12 ~ 48V DC; 24V AC
DIP Switch (ON/OFF)
LFP function (Enable/Disable) setting
Enclosure
IP30 metal case
Installation
DIN rail and wall-mount mounting
ESD Protection
6KV DC
Standards Conformance
Alarm
Provides one relay output for power failure
Alarm relay current carry ability: 1A @ DC 24V
System on:
24V: 4.3 watts/14BTU
48V: 4.8 watts/16BTU
Full PoE loading:
24V: 33 watts/112BTU
48V: 31 watts/105BTU
Cables
Twisted-pair:
Cat 5/5e/6 Ethernet cable
Fiber Optic:
MM: 50/125μm or 62.5/125μm ber optic cable
SM: 9/125μm ber optic cable
Environment
Temperature
Operating: -40°C to 75°C
Storage: -40°C to 85°C
Relative Humidity
Operating: 5 to 95%, non-condensing
Storage: 5 to 95%, non-condensing
Stability Testing
IEC60068-2-32 (free fall)
IEC60068-2-27 (shock)
IEC60068-2-6 (vibration)
Standards and Protocols
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3z Gigabit Ethernet over Fiber Optic
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus

- 4 - EN
2. Hardware Overview
2.1 Front Panel Ports
Figure 1: Front Panel
10/100/1000Base-T port for Ethernet connection
Hot swappable SFP port for 100/1000Base ber connection
RJ45
SFP
LFP function (enable/disable) setting
DIP Switch
Ports Description
Please refer to 3. Link Fault Pass Through (LFP) section to learn more about
LFP function.
Note
100/1000Base-X
10/100/1000Base-T
Ethernet+DC
802.3at
LNK/ ACT
PoE-
in-Use
LNK/ ACT
IMC-1F1T
1000
LFP
ONOFF
P1 P2 Fault

- 5 -
EN
Green
P1 Lit: To indicate power 1 has power.
LED Color Description
2.2 Front Panel LEDs
Green
P2 Lit: To indicate power 2 has power.
Green
Fault Lit: To indicate either power 1 or power 2 has no power.
Green
Fiber
LNK/ACT
Lit: To indicate the link through ber port is successfully established.
Green
TP
LNK/ACT
Blinks: To indicate the ber port is actively sending or receiving data.
Green
TP 1000
O: To indicate that the ber port is linked down.
Lit: To indicate the link through TP port is successfully established.
Blinks: To indicate the TP port is actively sending or receiving data.
O: To indicate that the TP port is linked down.
Lit: To indicate that the TP port is operating at 1000Mbps.
O: To indicate that the TP port is operating at 10/100Mbps.
Amber
PoE-in-Use
Lit: To indicate that the port is providing PoE Power to remote
powered device.
O: To indicate that the port is not providing PoE Power to remote
powered device.

- 6 - EN
2.3 Wiring the Power Inputs
The terminal block connector on the top panel of IMC-1F1T is used for 12~48V
DC power inputs. Please follow the steps below to insert the power wire.
Step 2: Tighten the wire-clamp screws to prevent the wires from loosening.
When performing any of the procedures like inserting the wires or tightening
the wire-clamp screws, make sure the power is OFF to prevent from getting
an electric shock.
!
V1+
PWR1
Max. fault loading: 24V, 1A
DC Input: 12-48V, 3A max.
AC Input: 24V, 1.5A max.
PWR2Fault
V1- V2+ V2-
1 2 3 4 5 6
1
Power 1
+_
2 3
Fault
4 5
Power 2
+_
6
Step 1: Insert positive and negative DC power wires into contacts 1 and 2 for
POWER 1, or 5 and 6 for POWER 2.

- 7 -
EN
2.4 Wiring the Fault Alarm Contact
The fault alarm contacts are in the middle of the terminal block connector as the
picture shows below. Inserting the wires, the IMC-1F1T will detect the fault status
of the power failure, and then forms an open circuit. The following illustration
shows an application example for wiring the fault alarm contacts.
1. The wire gauge for the terminal block should be in the range between 12
and 24 AWG.
2. The DC power input range is 12V ~ 48V DC and supports 24V AC.
3. Please just use one power input when using 24V AC.
Note
1. The wire gauge for the terminal block should be in the range of
12 ~ 24 AWG.
2. Alarm relay circuit accepts up to 24V, max. 1A currents.
Note
Fault
Fault Alarm Contacts
The Fault Alarm Contacts are
energized (CLOSE) for normal
operation and will OPEN when
failure occurs

- 8 - EN
2.5 Grounding the Device
Users MUST complete grounding wired with the device; otherwise, a sudden
lightning could cause fatal damage to the device. EMD (Lightning) DAMAGE IS
NOT COVERED UNDER WARRANTY.
The LFP function includes LLCF and LLR. LLCF and LLR can immediately alarm
administrators the issue of the link media and provide ecient solutions to
monitor the network. The LFP function can be disabled or enabled by the DIP
switch.
3. Link Fault Pass Through (LFP)
LLCF (Link Loss Carry Forward) means when a device is connected to the
converter and the TP line loses the link, the converter’s ber will disconnect the
transmission link. LLR (Link Loss Return) means when a device connected to the
converter and the ber line loses the link, the converter’s ber will disconnect the
transmission link.
LFP function is ON by default setting. If you are familiar with the network
installation and for diagnostic purpose (i.e. check which end is broken),
you can turn it o and reset the converter to make it take eect. Otherwise,
please remain it in the default position.
Note
V1+
PWR1
Max. fault loading: 24V, 1A
DC Input:12-48V, 3A max.
AC Input:24V, 1.5A max.
PWR2Fault
V1- V2+ V2-
1 2 3 4 5 6
Earth Ground

- 9 -
EN
This section describes the functionalities of the IMC-1F1T’s components and
instructs you to installing it. Please read this chapter completely before
continuing.
There are wall-mount holes on the left side of the IMC-1F1T that allows to be
easily mounted to the wall. Refer to the following steps for the wall-mount
Installation of the IMC-1F1T:
Step 2: Use four screws (not included in the package) to screw the media
converter onto the wall.
4. Installing
4.1 Wall-mount Installing
Step 1: Use the supplied four screws to screw the wall-mount plate on the media
converter.
Step 3: Refer to Chapter
2.3 Wiring the Power Inputs on power supply to the
IMC-1F1T.

- 10 - EN
Step 1: Screw the DIN rail on the IMC-1F1T.
Step 2: Slide the DIN rail into the track.
Step 3: Check whether the DIN rail is tightly on the track.
4.2 DIN-rail Installing
There are DIN-rail holes on the left side of the IMC-1F1T that allows to be easily
installed by DIN-rail mounting. Refer to the following steps for the DIN-rail
mounting of the IMC-1F1T:

- 11 -
EN
The sections describe how to insert an SFP transceiver into the SFP slot on
IMC-1F1T. The SFP transceiver can be plugged into the SFP port without having
to power down the IMC-1F1T.
Before connecting to other switches, workstation or Media Converters, please
make sure both sides of the SFP transceivers are the same type, for example,
1000Base-SX to 1000Base-SX, 1000Base-LX to 1000Base-LX.
Installing the SFP Transceiver
4.3 Cable Connection
1. Connect one end of a ber optic cable to the SFP transceivers.
2. Connect the other end of the cable to a Switch, ber NIC or a Media Converter.
1. Connect an Ethernet cable to the 10/100/1000Base-T RJ45 port on the
IMC-1F1T.
2. Connect the other end of the Ethernet cable to a Switch, ber NIC or a Media
Converter.
Connecting the Fiber Cable
Connecting the Ethernet Network Cable
Be sure the connected network devices support MDI/MDI-X. If it does not
support, then use the crossover Cat 5/5e/6 cable.
Note

- 12 - EN
4.4 PoE Function
The IMC-1F1T provides a way to supply power conveniently and easily for any
IEEE 802.3at/802.3af devices that need to be powered on. The IMC-1F1T needs
DC 12-48V or AC 24V input and it injects the DC power into the pin of the twisted
pair cable (Pins 1, 2, 3 and 6).
Data
Fiber Switch
1000BASE-X Fiber Cable
1000BASE-T Ethernet Cable with PoE
0m-120km
DC 12V-48V,AC 24V Output
PoE+
Speed Dome
IMC-1F1T
Data Power
100 meters
Industrial DIN Rail
Power Supply
Power Line (AC)
Power Line (DC)
DC
AC
AC
DC

- 13 -
EN
5. Troubleshooting
This chapter contains information to help you solve issues. If the IMC-1F1T is not
functioning properly, make sure it is set up according to instructions in this Quick
Start Guide.
Solution: Check the cable connection of the IMC-1F1T.
The per port LED is not lit
Solution: Check the speed duplex mode of the partner device. The IMC-1F1T
usually runs in auto-negotiation mode. If the partner is set to half duplex, the
performance will be poor.
Solution: Check that the attached device is not set to dedicate full duplex. Some
devices use a physical or software switch to change duplex modes. Auto-negoti-
ation may not recognize this type of full duplex setting.
Performance is bad
Per port LED is lit, but the trac is irregular
Solution: Check per port LED on the IMC-1F1T. Make sure the cable is installed
properly. Make sure the cable is the right type. Turn o the power. After a while,
turn on the power again.
The IMC-1F1T doesn’t connect to the network

- 14 - DE
1. Einführung
1.1 Verpackungsinhalt
Vielen Dank, dass Sie sich für den industriellen PoE+-Medienkonverter von FS
entschieden haben. Diese Anleitung soll Sie mit dem Aufbau des industriellen
PoE+-Medienkonverters vertraut machen und beschreibt, wie Sie den
Medienkonverter in Ihrem Netzwerk einsetzen. Im folgenden Abschnitt steht
"IMC-1F1T" für den industriellen PoE+ Medienkonverter.
Önen Sie den Karton des IMC-1F1T und packen Sie ihn vorsichtig aus. Der
Karton sollte die folgenden Teile enthalten:
Wenn etwas davon fehlt oder beschädigt ist, wenden Sie sich bitte sofort an
Ihren Vertriebsmitarbeiter; bewahren Sie den Karton einschließlich des
Originalverpackungsmaterials auf und verwenden Sie dieses, um das Produkt
wieder einzupacken, falls es zur Reparatur an uns zurückgeschickt werden muss.
Industrieller PoE+ Medienkonverter x 1
DIN-Schienen-Kit
Wandmontage-Kit
Quick-Start Anleitung x 1

- 15 -
DE
1.2 Produkt-Spezikationen
Abmessungen (H x B x T)
1,26''x 3,43''x 5,31'' (32x87x135 mm)
PoE: PoE-in-Use
Interface
Kupfer-Interface
Glasfaser-Interface
Power Over Ethernet
PoE Output Standard
PoE Stromversorgungstyp
Power Pin Assignment
PoE Power Budget
Hardware-Spezikationen
Geschwindigkeit
Flow Control
Duplex Mode
1x 10/100/1000Base-T RJ45 mit Data + Power Output
Auto-Negotiation, Auto MDI/MDI-X
1x 100/1000Base-X SFP
Produkt IMC-1F1T
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus
PoE Power Output
52V DC: 15,4 Watt
52V DC: 30 Watt
End-Span
30 Watt
Back pressure für Half-Duplex-Modus
IEEE 802.3x Pause Frame für Full-Duplex-Mode
Full- oder Half-Duplex-Modus durch Auto-Negotiation (TP)
Jumbo Frame
9K
LED
System: P1, P2 und Fault
Fiber 100/1000Base-X: LNK/ACT
TP 10/100/1000Base-T: LNK/ACT und 1000
TTwisted-Pair:
10/100Mbps für Half/full-Duplex
1000Mbps für Full-Duplex
Glasfaser:
100/1000Mbps für Full-Duplex
1/2(+), 3/6(-)

- 16 - DE
Leistungsaufnahme
Eingangsspannung
12 ~ 48V DC; 24V AC
DIP Switch (ON/OFF)
Einstellung der LFP-Funktion (Aktivieren/Deaktivieren)
Gehäuse
IP30 Metallgehäuse
Installation
DIN-Schienen- und Wandbefestigung
ESD Protection
6KV DC
Konformität
Alarm
Verfügt über einen zusätzlichen Relaisausgang für Netzausfall
Strombelastbarkeit des Alarmrelais: 1A @ DC 24V
System Ein:
24V: 4,3 Watt/14BTU
48V: 4,8 Watt/16BTU
Full PoE Loading:
24V: 33 Watt/112BTU
48V: 31 Watt/105BTU
Kabel
Twisted-Pair:
Cat 5/5e/6 Ethernet-Kable
Glasfaser:
MM: 50/125μm oder 62,5/125μm Glasfaserkabel
SM: 9/125μm Glasfaserkabel
Umgebung
Temperatur
Betrieb: -40°C bis 75°C
Lagerung: -40°C bis 85°C
Relative Luftfeuchtigkeit
Betrieb: 5 bis 95%, nicht kondensierend
Lagerung: 5 bis 95%, nicht kondensierend
Stabilitätsprüfung
IEC60068-2-32 (free fall)
IEC60068-2-27 (shock)
IEC60068-2-6 (vibration)
Standards und
Protokolle
IEEE 802.3 Ethernet
IEEE 802.3u Fast Ethernet
IEEE 802.3ab Gigabit Ethernet
IEEE 802.3z Gigabit Ethernet over Fiber Optic
IEEE 802.3x Flow Control
IEEE 802.3af Power over Ethernet
IEEE 802.3at Power over Ethernet Plus

- 17 -
DE
2. Hardware-Übersicht
2.1 Ports an der Vorderseite
Abbildung 1: Vorderseite
10/100/1000Base-T-Port für Ethernet-Anschluss
Hot-Swap-fähiger SFP-Port für 100/1000Base-Glasfaseranschluss
RJ45
SFP
Einstellung der LFP-Funktion (Aktivieren/Deaktivieren)
DIP Switch
Ports Beschreibung
Bitte lesen Sie den Abschnitt 3. Link Fault Pass Through (LFP), um mehr über
die LFP-Funktion zu erfahren.
Hinweis
100/1000Base-X
10/100/1000Base-T
Ethernet+DC
802.3at
LNK/ ACT
PoE-
in-Use
LNK/ ACT
IMC-1F1T
1000
LFP
ONOFF
P1 P2 Fault

- 18 - DE
Grün
P1 Leuchtet: Zeigt an, dass Strom 1 eingeschaltet ist.
LED Farbe Beschreibung
2.2 LEDs an der Vorderseite
Grün
P2 Leuchtet: Zeigt an, dass Strom 2 eingeschaltet ist.
Grün
Fault Leuchtet: Zeigt an, dass entweder Strom 1 oder Strom 2 keinen
Strom hat.
Leuchtet: Zeigt an, dass die Verbindung über den
Glasfaseranschluss erfolgreich hergestellt wurde.
Blinkt: Zeigt an, dass der Glasfaseranschluss aktiv Daten sendet
oder empfängt.
Aus: Zeigt an, dass der Glasfaseranschluss nicht verbunden ist.
Grün
Fiber
LNK/ACT
Leuchtet: Zeigt an, dass die Verbindung über den TP-Port
erfolgreich hergestellt wurde.
Blinkt: Zeigt an, dass der TP-Port aktiv Daten sendet oder empfängt.
Aus: Zeigt an, dass der TP-Port nicht verbunden ist.
Leuchtet: Zeigt an, dass der TP-Port mit 1000Mbps arbeitet.
Aus: Zeigt an, dass der TP-Port mit 10/100Mbps arbeitet.
Leuchtet: Zeigt an, dass der Port PoE-Strom an ein entferntes
Gerät mit Strom versorgt.
Aus: Zeigt an, dass der Port keinen PoE-Strom für ein mit Strom
versorgtes Gerät bereitstellt.
Grün
Grün
TP
LNK/ACT
TP 1000
Braun
PoE-in-Use

- 19 -
DE
2.3 Verkabelung der Stromeingänge
Der Klemmenleistenanschluss auf der Oberseite des IMC-1F1T wird für 12~48V
DC-Leistungseingänge verwendet. Bitte befolgen Sie die nachstehenden
Schritte zum Einstecken des Stromkabels.
Schritt 2: Ziehen Sie die Schrauben der Drahtklemmen fest, damit sich die Drähte
nicht lockern können.
Achten Sie beim Einführen der Drähte oder beim Anziehen der Schrauben der
Drahtklemmen, stellen Sie sicher, dass die Stromversorgung ausgeschaltet ist,
um einen Stromschlag zu vermeiden. einen elektrischen Schlag zu bekommen.
!
V1+
PWR1
Max. fault loading: 24V, 1A
DC Input: 12-48V, 3A max.
AC Input: 24V, 1.5A max.
PWR2Fault
V1- V2+ V2-
1 2 3 4 5 6
1
Leistung 1
+_
2 3
Störung
4 5
Leistung 2
+_
6
Schritt 1: Stecken Sie die positiven und negativen DC-Stromversorgungsdrähte in
die Kontakte 1 und 2 für POWER 1 bzw. 5 und 6 für POWER 2.
