DocuCentre-V C7785 / C6685 / C5585
Premium DocuCentre models feature versatile, sophisticated
performance
DocuCentre-V C7785 / C6685 / C5585

2
In addition to outstanding printing productivity of 70 pages/minute* (colour) and 75 pages/
minute* (monochrome), our premium DocuCentre models deliver optimal performance,
including outstanding image quality, high energy efficiency and solid durability.
Thanks to support for cloud services and enhanced compatibility with mobile devices (such
as smartphones and tablets), you can input and output while on the go for even greater
convenience.
DocuCentre-V series satisfies your need for speedy business development.
* A4 LEF. For DocuCentre-V C7785.
Fast, beautiful and more convenient
Delivering top-of-the-line performance
Colour, B/W : 100 ppm*2
1 pass, 2 sided scanning : 200 ppm*2
Scan
Copy
Print
Super G3 Supported
Fax
*1: A4 LEF
*2: Fuji Xerox Standard Paper (A4 LEF), 200 dpi, to Folder.
* The photo shows the DocuCentre-V C7785 ,C3 Finisher with Booklet Maker.
DocuCentre-V C7785 DocuCentre-V C6685 DocuCentre-V C5585
Colour 70 ppm*1 60 ppm*1 50 ppm*1
B/W 75 ppm*1 65 ppm*1 55 ppm*1
DocuCentre-V C7785 / C6685 / C5585

3
Expansion of
the workspace
On the go
Serviced Office
Office
Home
Working Folder
Work wherever you are, however you like.
Smooth, impressive client presentations
Eliminate the hassle and worry of lugging around bulky, confidential documents.
Working Folder, our Cloud-based document sharing service, keeps your documents
secure and your briefcase light.
Use a PC or Fuji Xerox multifunction device to store documents in Working Folder,
then access and view with a smart device while at your client’s office.
You can also print from a tablet or smartphone to multifunction devices when out of
the office via wireless LAN.
On the road, at home, dashing off to a client in the morning, or returning home in the evening.
There’s no doubt about it: Workstyles are changing.
To support people in all facets of their jobs, Fuji Xerox offers comprehensive mobile computing
functions and keeps everyone connected via the Cloud.
We always look for ways to help bring out your best, wherever and however you work.

4
Boosting Productivity and User
Friendliness
The new DocuCentre-V series includes
features that deliver genuine productivity
gains. These include a high quality output
resolution of 2400 dpi.
High-speed continuous output is available
in both monochrome and colour, to suit
your current priorities, and you know you
can count on superior engine reliability.
Real 2400 dpi High Resolution
The DocuCentre-V series is capable of achieving a full-colour output
resolution of 2400 dpi. Fuji Xerox has adopted Multibeam Scan
technology with the vertical cavity surface emitting laser VCSEL, which
emits 32 beams. The HQ digital screen “MACS” technology provides a
much smoother representation of gradation and halftone. Bi-directional
image and edge enhancement processes produce crisp, smooth text
and fine lines.
High Speed Scanning at 200 ppm
The DocuCentre-V series uses a dedicated colour sensor to scan both
sides of documents simultaneously. This “one path duplex scanning”
feature combines Fuji Xerox’s new "Power LED", which offers the
brilliance of a Xenon lamp using just a quarter of the power, and the
improved CCD sensor, maintaining high image quality and limiting
power consumption. The combination of high image quality, high speed
scanning and lower energy use will deliver tangible benefits to every
office environment.
* Our standard document (A4 LEF), 200 dpi, stored to folders.
Auto Duplex Print on Heavy Paper
The new DocuCentre-V series can handle coated and art paper from
64 gsm to 300 gsm, and will print at 50 sheets/min*1 for 176 gsm and
coated 150 gsm*2. The paper feeding system has been upgraded to
allow auto duplex printing even on heavy grades of paper up to 220
gsm.
*1: With DocuCentre-V C7785, Colour Gloss Off mode, and A4 SEF.
*2: With DocuCentre-V C7785, Colour Gloss Off mode, A4 SEF, and Offset Catch
Tray/Single Catch Tray connection.
Various File Formats and Processing Supported
Users can convert scanned documents and data to numerous file
formats including TIFF, JPEG, DocuWorks document, PDF and XPS*1
before you send them by email. OCR processing can assist in searching
for and compressing documents to reduce their size for e-mail
communications *2, and password settings can also be set.
*1: Stands for XML Paper Specification.
*2: Optional.
Conversion to Editable Word and Excel Files
Scanned data can also be converted to files in Word or Excel format, and
hardcopy documents can be converted into editable digital documents.
The DocuCentre-V series devices can also convert tables and illustrations
to objects suitable for reproduction with Word and Excel.
* Optional.
An auxiliary function that allows you to reuse materials such as text, tables,
shapes, and photos on paper documents. However, we cannot guarantee the
accuracy when they are reused.
Word data
Output media
Speed and quality for faster,
more efficient business

5
A3 Output Sample with Crop Mark
"A3 with Crop Mark" Support
With paper up to 330 x 457 mm in size loaded in Tray 1 in the printer
unit, you can print documents with A3 full crop marks. Solid and
halftone colour images can also be imaged on A3 size paper sheets, so
you have unlimited potential to produce captivating A3 documents and
marketing material.
Data Compression Cuts Transmission Loads
Data compression is applied during full colour document scanning
so the file size is smaller. When originals use fewer colours, the full-
colour scanned document will be reduced in file size to a monochrome
equivalent. This reduces the file size of e-mail attachments, and speeds
up communication.
Print in different environments
The DocuCentre-V series can be shared and printing can be performed
in two independent network environments. With two network ports, you
can maximise the use of the multifunction device while maintaining
tight security of having separate network.
* Optional.
* Print function only. Supported protocol: TCP/IP (lpd, Port9100) only.
AirPrint
Supports AirPrint, iOS and OS X standard print functions.
You can output e-mails and documents created with
Apple applications, including Safari, Map, Numbers,
Pages and Keynote, and Microsoft applications such as
Word, Excel and PowerPoint.
Mopria® Print
You can output on a Mopria-certified device from
Mopria Print Service* installed on mobile devices
without installing different printing applications
of models or manufacturers.
* Mopria Print Service can be downloaded for free from Google Play™.
(Android™ 4.4 or later)
Easy printing wherever you are
Print Utility for iOS / Android
This free Fuji Xerox application lets you output web pages, pictures,
DocuWorks and PDF documents*1, and import scanned documents
to mobile devices. You can configure it to print N-up and duplex.
Server-less On-demand printing*2 is also available by assigning
authentication information. Additionally, the application is
supported by standard printing frameworks on Android™ OS 4.4 or
later. More applications allow output using Print Utility for Android.
* Print Utility can be downloaded for free from the App Store (iOS) or
Google Play™(Android).
*1: Outputting DocuWorks and PDF documents requires DocuWorks Viewer
Light for iPhone/iPad or DocuWorks Viewer Light for Android.
*2: Optional.
Google Cloud Print
By registering the multi-function device
with Google Cloud Print, you can output
documents via the cloud from Android™ devices,
Chromebook™ and computers. Giving permission
to office visitors provides them with a printing environment without
connecting to your Intranet.
* Google Could Print is a web printing service from Google.
Wi-Fi Direct®
Wi-Fi Direct® can be used with a wireless LAN adaptor. You can
connect personal mobile devices directly to the multi-function
device then print. Using a wireless LAN access point allows you to
separate connections from business mobile devices and computers
on an Intranet.
* Optional.
®

6
Easy Fingertip Control.
The new DocuCentre-V series take
advantage of technology seen in
smartphones and tablets by enabling
users to operate the devices intuitively,
for faster and more efficient production.
Four different gestures – tap, double-tap,
drag and flick – can be used to scroll and
switch functions smoothly and quickly.
* Pinch in and pinch out operations (zooming
in/out with two fingers) are not supported.
Feature-rich and easy to use
Simpler Scanning Operation
Scanning failure happens often. Settings are too many and complex.
Manual setup every time for routine task is troublesome. In order to
solve such problems, installed applications improve scanning usability
and offer automatic operation.
Easier scanning for personal use
ScanAuto determines paper
orientation and simplex/
duplex for you. Blank pages are
automatically detected then
deleted. Destinations for scanned
data can be selected from the
send history. Moreover, when
authenticated, your e-mail address
will be automatically input.
* ScanAuto is pre-installed, but must be configured before use.
Easy to scan and save file for individual work
Scan Delivery* provides automatic
operation to name a file in
accordance with pre-defined rule
and save scanned data directly in
specified folder instead of using
PC to save them. You can improve
operating efficiency in routine
scanning task.
* Optional.
Simpler Operations
Operation screens can be simplified and made easier than ever to
navigate by installing a free optional software application – EasyUI
Solution 3. This offers individual users a simple and easy-to-use
operation screen, reducing working time.
Easy Copy lets you preview copy
jobs – for example, N-up, two-sided
and stapled – when you set these
functions. Any finishing applications
for Private Charge Print jobs can
also be previewed before printing.
This eliminates set-up mistakes and
reduces waste from unnecessary
printing and copying errors.
Users can also create a customised
menu screen showing their most
frequently used function buttons. As
the device authenticates the user,
their personal screen is displayed so
they can start working immediately.
You can register most frequently
used settings for Easy Copy and
Easy Store to Folder as a One-touch
App. This lets you start copying or
scanning at the touch of a button
on the Custom Menu.

7
Leverage of Timely Information with Paperless Fax
[Receiving]
Received fax documents can be
sorted into different device folders
by dial number or G3ID. After
viewing the thumbnails, users can
choose to print only designated
documents. As soon as fax
documents are received in a folder,
they can also be sent as a fax,
printed, sent as an e-mail, transferred via FTP, and transferred via SMB
automatically.
[Sending]
Direct Fax (sending fax directly from PC) can also be used. Sent fax
documents can also be saved as PDF and sent as e-mail attachments.
[Reject]
Allows administrators to block incoming faxes from certain numbers and
anonymous numbers.
Offices Using Five or More Devices
By utilising ApeosWare Management Suite 2*, administrators can
distribute print drivers, restrict use of the device to certain accounts,
gather print counts, improve running efficiency, automate distribution
processes and manage job logs. These applications make it a simple
task to plan and manage usage of the device, while maintaining full
security.
* Software sold separately.
Printable from Any Machine on Demand
After a job has been sent to the device, users can choose the
“Server-less On-demand” feature to print it from any machine on the
network on demand, simply by logging on to the machine. Even if
the selected device is in use, users can choose their job from another
machine and print it. No dedicated server is required for this feature.
It is also possible to use up to five devices in this way by grouping them
– for example, by floor or workgroup.
* Optional.
On a machine having fewer load
on the network, login through
authentication, select a stored
job, and print it.
Output
Transferring of data
The specified
machine is in use.
Store data.
Authentication with
IC card reader
Authentication Based on Registered User Information
DocuCentre checks user information registered on the machine to
manage authentication, when local authentication is enabled. The
job history function can tally usage of the device on a user basis. By
adding a built-in IC Card Reader* to the device, IC Card authentication
can be used. This feature can also provide access control to specific
functions on the device, enhancing both security management and
user convenience.
*Optional.
Do Your Own Colour Corrections
You can perform your own colour
corrections using the correction tool
“ColorProfileTuner”, which runs on
a PC. You no longer need to be an
expert in colour correction to improve
the quality of your images. Just do
it yourself! You can also ensure that
colour reproduction of colour logos
and promotional material is precise
and meets corporate guidelines.
Adjust brightness and
sharpness
Adjust on the display
Adjust brightness and
sharpness
Check the output
Built-in IC Card Reader
External IC Card Reader
IC Card Reader IC Card Reader
for HID Prox

8
No Power Applied to Units not Used, Saving Power
Save Power
Why use power when you don’t need to? Fuji Xerox’s “Smart Power
Saver” technology controls energy use when it isn’t required. When the
device wakes up from Sleep mode, power is only applied to the functions
to be used, not the whole device. This effectively reduces power
consumption, but doesn’t affect performance or interfere with the user’s
activities.
Cut Noise Levels
Reducing noise levels in offices is a key environmental initiative by Fuji
Xerox. Noise generated by fans in output devices and the document
feeder can be reduced if they are not used. At wake-up from Sleep mode,
output or scanning devices that are not being used are not powered up.
This power saving technology saves energy and significantly reduces
noise in offices.
Start Working Immediately
You don’t have to wait for the device to wake up from Sleep mode. Using
Smart Power Saver, the control panel is ready to work two seconds after
you press the Energy Saver button.
Power LED Delivers Brilliant Scanning
Our new “Power LED” delivers a level of brilliance equivalent to a Xenon
lamp, yet uses only a quarter of the power. Combined with an improved
CCD sensor, it delivers scanning speeds up to 100 sheets/minute without
increasing power consumption, and ensures high image quality. These
technologies deliver the performance and reliability you expect in all
scanning operations, with the bonus of lower energy costs.
EA-Eco Toner Reduces Thermal Emissions
Fuji Xerox uses “EA-Eco Toner” containing base materials that melt at
a lower temperature than conventional toner. This can reduce power
consumption during the fusing process, and delivers vibrant glossy
images. The use of fusing oil is no longer necessary because wax is
incorporated in the toner particles, so you can attach sticky notes or
write on the printed surface without marking it.
User- and environment-friendly
Save Power without
Sacrificing User Convenience
Fuji Xerox’s “Smart Power Saver”
technology controls energy use when
it isn’t required.

9
C3 Finisher C3 Finisher with Booklet
Maker
C3 Finisher with Booklet Maker +
Folder Unit CD1
D2P Finisher with Booklet Maker
+ D2 Folder Unit
Stapling thickness 50 sheets 50 sheets 50 sheets*1100 sheets*1
Punch 2/4 hole punch*2 or
2/3 hole punch*3
2/4 hole punch*2 or
2/3 hole punch*3
2/4 hole punch*2 or
2/3 hole punch*3
2/4 hole punch or
3 hole punch*4
Saddle Staple —
Single Fold —
Tri-fold — — *5*6
Z Fold Half sheet — — *5*6
Tray
capacity *7
Output tray 500 sheets 500 sheets 500 sheets 500 sheets
Finisher tray 3000 sheets 1500 sheets 1500 sheets 2000 sheets
Extra Functionality
in Finishing
A3 oversized tray is also
available
The High Capacity Feeder B1-S is also
available to accommodate up 2000
sheets* sized 330 x 488 mm, in weights
ranging from 64 to 300 gsm. The Air
Assist feature ensures stable feeding
of media such as coated paper. The
upper section can be used to house
consumables.
* 80 gsm paper.
Standard Capacity of
3260 Sheets
The standard configuration can hold
a total of 3260 sheets - 3010 sheets*
in four trays and 250 sheets* in bypass
tray. In addition, an optional High
Capacity Feeder which can hold up to
2000 sheets* of A4-size media (one
tray) is available. It can also support
large-volume output demands.
* 80 gsm paper.
*1: Staple capacity decreases when Z-fold sheets are mixed.
*2: 2/4 Hole Punch Kit for C3 Finisher is required.
*3: US 2/3 Hole Punch Kit for C3 Finisher is required.
*4: 3 Hole Punch Kit is required. 2/4 Hole Punch Kit cannot be attached at the
same time.
*5: Folder Unit CD1 is required. Can also be installed on C3 Finisher.
*6: D2 Folder Unit is required.
*7: 64 gsm paper in A4 size.
Note: C3 Finisher or C3 Finisher with Booklet Maker requires Transport Unit V1.
Stapling*1
Stapling multiple pages
documents, such as meeting
materials into sets, is
available.
Punch
A hole punch process can be
used for filing documents in
binders.
Saddle Staple
This Single Fold and stapling
process is ideal for creating
catalogues and booklets.
Z Fold Half sheet*2
Z Fold Half sheet is a useful
method to combine A3
documents into A4 size.
Tri-fold*2
The C-fold is useful when
creating materials enclosed
in envelopes.
*1: Dual / four-position stapling (parallel) is available with D2P Finisher with Booklet Maker.
*2: Folder Unit is required.
A “Z Fold Half sheet” folding capability is now available.
Further Finishing Functions with Introduction of our new finishers that supports “Tri-fold”

10
Specifications of DocuCentre-V C7785 / C6685 / C5585
Basic Specifications/Copy Function
Item DocuCentre-V C7785 DocuCentre-V C6685 DocuCentre-V C5585
Type Console
Memory capacity 3 GB (Max: 3 GB)
Hard disk capacity*1 320 GB or larger (Usable space: 128 GB)
Colour Capability Full Colour
Scan Resolution 600 x 600 dpi
Printing Resolution 2400 x 2400 dpi (High Resolution Photo)
600 x 600 dpi (Text / Text-Photo / Photo / Map)
Warm-up Time 90 seconds or less, 90 seconds or less if the main power is on (At room
temperature 23ºC)
Original Size Maximum of 297 x 432 mm (A3, 11 x 17") for both Sheet and Book
Paper Size Max SRA3 (320 x 450 mm), 13 x 18" (330 x 457 mm)
[13 x 19.2" (330 x 488 mm) when using Bypass Tray]
Min A5
[Postcard (100 x 148 mm) and Quadrate NO.3 Envelope (120 x 235 mm) when
using Bypass Tray]
Image loss
width
Lead Edge 4.0 mm, Trail Edge 4.0 mm, Right & Left Edges 3.5 mm
Paper
Weight*2
Paper Tray 64 to 220 gsm
Bypass Tray 64 to 300 gsm
First Copy Output Time B/W : 4.1 sec.(A4 LEF / Monochrome priority mode)
Colour : 6.5 sec.(A4 LEF / Colour priority mode)
Continuous
Copy Speed*3
A4 LEF /
B5 LEF
B/W: 75 ppm
Colour: 70 ppm
B/W: 65 ppm
Colour: 60 ppm
B/W: 55 ppm
Colour: 50 ppm
A4 / B5 B/W: 54 ppm
Colour: 51 ppm
B/W: 47 ppm
Colour: 44 ppm
B/W: 40 ppm
Colour: 36 ppm
B4 B/W: 44 ppm
Colour: 39 ppm
B/W: 39 ppm
Colour: 36 ppm
B/W: 33 ppm
Colour: 30 ppm
A3 B/W: 37 ppm
Colour: 35 ppm
B/W: 33 ppm
Colour: 30 ppm
B/W: 27 ppm
Colour: 25 ppm
Paper Tray
Capacity*4
Standard 500 sheets x 2-tray + 870 sheets + 1140 sheets + Bypass Tray 250 sheets
Optional HCF2 : 2000 sheets
HCF B1-S : 2000 sheets
Max 5260 sheets [Standard + HCF2 or HCF B1-S]
Output Tray Capacity*4 500 sheets (Simple Catch Tray)
Power Supply AC220-240 V +/- 10 %, 10 A, 50/60 Hz common
Maximum Power
Consumption
2.4 kW or less (AC220-240 V +/- 10%)
Sleep Mode: 1.0 W or less
Low Power Mode: 107 W or less
Ready Mode: 192 W or less
Dimensions [ 9" WVGA UI ] W 700 x D 804 x H 1154 mm
[ Large Size UI ] W 1022 x D 804 x H 1392 mm
Weight*5 [ 9" WVGA UI ] 240 kg
[ Large Size UI ] 247 kg
*1 The Storage Hard disk capacity is not totally available for customers.
*2 You are encouraged to use paper recommended by Fuji Xerox. Printing may not be performed correctly depending on
the conditions of usage.
*3 The speed may be reduced due to the image quality adjustment.
*4 80 gsm paper.
*5 Excluding Toner Cartridge.
Print Function
Item Description
Type Built-in type
Continuous Print Speed*1 Same as the Basic Specifications / Copy Function
Printing Resolution 600 x 600 dpi, 1200 x 1200 dpi, 2400 x 2400 dpi
Page
Description
Language
Standard PCL5 / PCL6
Optional Adobe® PostScript® 3TM
Supported
Operating
System
Standard
(PCL Driver)
Windows 10 (32bit), Windows 10 (64bit), Windows 8.1 (32bit),
Windows 8.1 (64bit), Windows 8 (32bit), Windows 8 (64bit),
Windows 7 (32bit), Windows 7 (64bit), Windows Vista (32bit),
Windows Vista (64bit), Windows Server 2019 (64bit),
Windows Server 2016 (64bit), Windows Server 2012 R2 (64bit),
Windows Server 2012 (64bit), Windows Server 2008 R2 (64bit),
Windows Server 2008 (32bit), Windows Server 2008 (64bit),
Windows Server 2003 (32bit), Windows Server 2003 (64bit)
Standard
(Mac OS X
Driver)
macOS 10.14/10.13/10.12, OS X 10.11/10.10/10.9/10.8, Mac OS X 10.7/10.6/10.5
Optional
(Adobe
®
PostScript
®
3
TM
Driver)
Windows 10 (32bit), Windows 10 (64bit), Windows 8.1 (32bit),
Windows 8.1 (64bit), Windows 8 (32bit), Windows 8 (64bit),
Windows 7 (32bit), Windows 7 (64bit), Windows Vista (32bit),
Windows Vista (64bit), Windows Server 2019 (64bit),
Windows Server 2016 (64bit), Windows Server 2012 R2 (64bit),
Windows Server 2012 (64bit), Windows Server 2008 R2 (64bit),
Windows Server 2008 (32bit), Windows Server 2008 (64bit),
Windows Server 2003 (32bit), Windows Server 2003 (64bit)
macOS 10.14/10.13/10.12, OS X 10.11/10.10/10.9/10.8, Mac OS X 10.7/10.6
Interface Standard Ethernet 100BASE-TX / 10BASE-T, USB2.0
Optional Ethernet 1000BASE-T*2
*1 The speed may be reduced due to the image quality adjustment. The printing speed may be reduced depending on
the document.
*2 When this option is equipped, Ethernet 100BASE-TX/10BASE-T will not be available.
Fax Function ( Optional )
Item Description
Original Size Max: A3, 11 x 17", Long document (Longest600 mm)
Recording Paper Size Max: A3, 11 x 17"
Min: A5
Transmission Time 2 seconds and more but fewer than 3 seconds*1
Transmission Mode ITU-T G3
Applicable Lines Telephone subscriber line, PBX, Fax communication (PSTN), Maximum 3 ports*2
(G3-3 ports)
*1 When A4 size document with approximately 700 characters is transmitted in standard image-quality (8 x 3.85 lines /
mm) and in high-speed mode (28.8 kbps or faster, JBIG). Only indicates the time for transmitting the image information
and does not include the communication control time. The total communication time will vary depending on the
contents of the document, the type of machine receiving the fax, and line condition.
*2 No.of FAX lines is up to 3 ports. Port refers to number of channels for FAX.
Duplex Automatic Document Feeder
Item Description
Original Size Max: A3, 11 x 17"
Min: A5*1
Paper Weight 38 to 200 gsm (In Duplex: 50 to 200 gsm)
Capacity*2 250 sheets
Feeding Speed
(A4 LEF Simplex)
B/W: 80 ppm
Colour: 75 ppm
*1 The minimum custom size is 139.7 x 139.7 mm.
*2 64 gsm paper.
HCF2 (2000sheets) ( Optional )
Item Description
Paper Size A4 LEF, Letter LEF, B5 LEF
Paper Weight 64 to 220 gsm
Feeding Capacity / Number
of Tray*1
2000 sheets x 1-tray
Dimensions W 389 x D 610 x H 377 mm
Weight 29 kg
*1 80 gsm paper.
HCF B1-S ( Optional )
Item Description
Paper Size Postcard (100 x 148 mm)
*1
, B5, B5 LEF, 8 x 10" LEF (203 x 254 mm), Letter, Letter
LEF, A4, A4 LEF, 8.5 x 13" (216 x 330 mm), Legal, B4, A3, 11 x 17", 12 x 18" (305 x
457 mm), 12.6 x 17.7" (320 x 450 mm), 12.6 x 19.2" (320 x 488 mm), 13 x 18" (330
x 457 mm), 13 x 19" (330 x 483 mm)
Paper Weight 64 to 300 gsm
Feeding Capacity / Number
of Tray*2
2000 sheets x 1-tray
Power Supply*3 AC220-240 V +/- 10 %, 1.5 A, 50/60 Hz common
Dimensions W 988 x D 762 x H 992 mm
Weight 160 kg*4
Note When installing the both HCF B1-S and Large Size UI, not only Large Size UI Installation Kit but also Large Size UI
Installation Kit 2 are required.
*1 When using postcard guide.
*2 80 gsm paper.
*3 Additional Power Cord (optional) is required.
*4 Excluding Bypass tray and operational panel.
Scan Function
Item Description
Type Colour Scanner
Scan Resolution 600 x 600 dpi, 400 x 400 dpi, 300 x 300 dpi, 200 x 200 dpi
Scan Speed*1 B/W: 100 ppm, Colour: 100 ppm
(1 pass, 2 sided scanning, B/W: 200 ppm, Colour: 200 ppm)
[Fuji Xerox Standard Paper (A4 LEF), 200dpi, to Folder.]
Interface Standard Ethernet 100BASE-TX / 10BASE-T
Optional Ethernet 1000BASE-T
*1 The scanning speed varies depending on the documents.

11
Notes
1) If the storage media (such as hard disk drives) of the base unit fail, loss of received data, accumulated data,
registered setting data, etc. may occur. In no event shall Fuji Xerox be liable for any damages whatsoever arising
from loss of data.
2) Functional spare parts will be available for at least 7 years after the product is no longer manufactured.
3) The available model varies depending on the country/region. Please ask the sales representatves for details.
C3 Finisher / C3 Finisher with Booklet Maker ( Optional )
Item C3 Finisher C3 Finisher with Booklet Maker
Type Output Tray Sort / Stack
Finishing Tray Sort (Offset available) / Stack (Offset available)
Booklet Tray ― Sort / Stack
Paper Size Output Tray Max: 13 x 19" (330 x 483 mm), 12.6 x 19.2" (320 x 488 mm)
Min: Postcard (100 x 148 mm)
Finishing Tray Max: 13 x 19" (330 x 483 mm), 12.6 x 19.2" (320 x 488 mm)
Min: B5 LEF
Booklet Tray ― Max: 13 x 18" (330 x 457 mm)
Min: B5
Paper Weight Output Tray 64 to 300 gsm
Finishing Tray 64 to 300 gsm
Booklet Tray ― 64 to 220 gsm
Paper
Capacity*1
Output Tray 500 sheets (A4)
Finishing Tray (Without Stapling)
A4: 3000 sheets
B4or larger: 1500 sheets
Mixed Size Stacking
*2
: 300 sheets
(With Stapling)
A4: 200 sets or 3000 sheets
B4or larger: 100 sets or 1500 sheets
Mixed Size Stacking
*2
: 70 sets or 200
sheets
(Without Stapling)
A4: 1500 sheets
B4or larger: 1500 sheets
Mixed Size Stacking
*2
: 300 sheets
(With Stapling)
A4: 200 sets or 1500 sheets
B4or larger: 100 sets or 1500 sheets
Mixed Size Stacking
*2
: 70 sets or 200
sheets
Booklet Tray ― 20 sets*3
Staple Capacity 50 sheets (90 gsm or less)*4
Paper Size Max: A3, 11 x 17"
Min: B5 LEF
Position Single stapling, Dual stapling
Punch*5 Number of
Holes
2-hole / 4-hole punch or 2-hole / 3-hole punch (US Specifications)
Paper Size A3, 11 x 17", B4, A4*6 , A4 LEF, Letter*6 , Letter LEF, B5 LEF, 7.25×10.5" (184 x 267
mm), 8 x 10" (203 x 254 mm)*6 , 16K (194 x 267 mm), Cover A4 (223 x 297 mm),
9 x 11" (229 x 279 mm), 215 x 315 mm, 8.5 x 13" (216 x 330 mm)*6 , Legal, 11 x
15" (279 x 381 mm), 8K (267 x 388 mm)
Paper Weight 64 to 200 gsm
Booklet
Finishing
Capacity ― Saddle Staple: 16 sheets*7
Middle-Fold: 5 sheets
Single Fold: 1 sheet
Paper Size ― Max: 13 x 18" (330 x 457 mm)
Min: B5
Paper Weight ― Saddle Staple: 64 to 220 gsm
Middle-Fold: 64 to 220 gsm
Single Fold: 64 to 220 gsm
Dimensions*8 W 840 x D 589 x H 1056 mm
When Folder Unit CD1 is installed: W
1023 x D 726 x H 1056 mm
W 898 x D 589 x H 1056 mm
When Folder Unit CD1 is installed: W
1083 x D 726 x H 1056 mm
Weight 44 kg
When Folder Unit CD1 is installed: 100 kg
61 kg
When Folder Unit CD1 is installed: 117 kg
Note Transport Unit V1 is required.
*1 64 gsm paper.
*2 When larger size sheets are stacked on top of smaller size sheets.
*3 When the output paper size is the same.
*4 Up to 65 sheets can be stapled when the C3 Finisher Staple Unit 65 Sheets is installed. However, depending on the
paper type, incorrect stapling such as uneven edge alignment of sets may occur.
*5 Optional
*6 3-hole punch is not applicable.
*7 The maximum number of sheets varies depending on the type of paper used for the cover. The booklet may become
unfolded depending on the paper size or the type of paper used.
*8 Main Unit + Finisher + Transport Unit V1; when the Extension Tray is fully extended.
D2P Finisher with Booklet Maker ( Optional )
Item Description
Type Output Tray Sort / Stack
Finishing Tray Sort (Offset available) / Stack (Offset available)
Booklet Tray Sort / Stack
Paper Size Output Tray Max: 13 x 19" (330 x 483 mm), 12.6 x 19.2" (320 x 488 mm)
Min: Postcard (100 x 148 mm)
Finishing Tray Max: 13 x 19" (330 x 483 mm), 12.6 x 19.2" (320 x 488 mm)
Min: B5 LEF
Booklet Tray Max: 13 x 18" (330 x 457 mm)
Min: A4, Letter
Paper Weight Output Tray 64 to 300 gsm
Finishing Tray 64 to 300 gsm
Booklet Tray 64 to 220 gsm
Paper
Capacity*1
Output Tray 500 sheets (A4)
Finishing Tray [Without Stapling]
A4: 2000 sheets, B4 or larger: 1500 sheets, Mixed Size Stacking*2 : 300 sheets
[With Stapling]
A4: 200 sets or 2000 sheets, B4 or larger: 100 sets or 1500 sheets
Booklet Tray 20 sets*3
Staple Capacity 100 sheets*4 (90 gsm or less)
Paper Size Max: A3, 11 x 17"
Min: B5 LEF
Position Single stapling, Dual stapling, Four-position stapling*5
Punch Number of
Holes
2-hole / 4-hole punch or 2-hole / 3-hole punch (US Specifications)
Paper Size A3*6 , 11 x 17"*6 , B4, A4, A4 LEF*6 , Letter, Letter LEF*6 , B5 LEF, 7.25 x 10.5" LEF (267
x 184 mm)*6 , 8 x 10" (203 x 254 mm), 8 x 10" LEF (254 x 203 mm), 16K LEF (267
x 194 mm)*6 , Cover A4 LEF (297 x 223 mm)*6 , 9 x 11" (229 x 279 mm)*6 , 215 x
315 mm, 8.5 x 13" (216 x 330 mm), Legal, 11 x 15" (279 x 381 mm)*6 , 8K (267 x
388 mm)*6
Paper Weight 64 to 220 gsm
Booklet
Finishing
Capacity Saddle Staple: 20 sheets*7
Middle-Fold: 5 sheets
Single Fold: 1 sheet
Paper Size Max: 13 x 18" (330 x 457 mm)
Min: A4, Letter
Paper Weight Saddle Staple: 64 to 220 gsm
Middle-Fold: 64 to 220 gsm
Single Fold: 64 to 220 gsm
Interposer*8 Paper Size Max: A3, 11 x 17", Min: B5 LEF
Paper Weight 64 to 220 gsm
Paper
Capacity*1
200 sheets
Power Supply*9 AC220-240 V +/- 10 %, 1 A, 50/60 Hz common
Maximum Power
Consumption
240 W or less
Dimensions W 1050 x D 725 x H 1165 mm*10
When D2 Folder Unit is installed: W 1250 x D 725 x H 1165 mm*10
Weight 135 kg
When D2 Folder Unit is installed: 175 kg
*1 64 gsm paper.
*2 When larger size sheets are stacked on top of smaller size sheets.
*3 Paper may not be accepted depending on paper type and other usage conditions.
*4 65 sheets for sizes exceeding A4 or letter. The staple capacity may be less than 100 sheets for paper that is larger than 80 gsm.
*5 Only available on A4 landscape and 8.5 x 11".
*6 4-hole punching available.
*7 19 sheets with a cover.
*8 Nothing will be printed on the sheets loaded in the Interposer.
*9 Power supply separate from the main unit is required.
*10 When the Extension Tray is pulled out.
Folder Unit ( Optional )
Item Folder Unit CD1 (C3 Finisher /
C3 Finisher with Booklet Maker)
D2 Folder Unit (D2P Finisher with
Booklet Maker)
Z Fold Half
Sheet
Paper Size A3, 11 x 17", B4
Paper Weight 64 to 90 gsm
Tri-fold Paper Size A4, Letter
Paper Weight 64 to 90 gsm
Paper
Capacity*1
40 sheets
Power Supply AC220-240 V +/- 10 %, 0.6 A, 50/60 Hz
common*2
( ― )
(Supplied via D2P Finisher with Booklet
Maker)
Maximum Power
Consumption
144 W or less (AC220-240 V +/- 10%) ( ― )
(Supplied via D2P Finisher with Booklet
Maker)
Dimensions W 232 x D 726 x H 991 mm W 200 x D 725 x H 1165 mm*3
Weight 53 kg 40 kg
*1 64 gsm paper.
*2 When equipped with a folder unit, a power source separate from the main unit is required.
*3 Depth and Height indicate the depth and height when connected with a D2P Finisher with Booklet Maker.

Xerox, Xerox and Design, as well as Fuji Xerox and Design are registered trademarks or trademarks of Xerox Corporation in Japan and / or other countries.
Reproduction Prohibitions Please note that reproduction of the following is prohibited by law :
Domestic and foreign currencies, government-issued securities, and national bonds and local bond certificates. Unused postage stamps, post cards, etc.
Certificate stamps stipulated by law. Reproducing works forming the subject matter of copyright (literary works, musical works, paintings, engravings,
maps, cinematographic works, drawings, photographic works, etc.) is not permitted unless the reproduction is for the purpose of personal use, family use
or other similar uses within a limited circle.
For Your Safety
Before using the product, read the Instruction Manual carefully
for proper use. Use the product with the power source and voltage
specified. Be sure to establish ground connection. Otherwise,
electronic shock may result in the case of a failure or short circuit.
All product names and company names mentioned in this brochure are trademarks or registered trademarks of their respective companies.
The product specifications, appearance and other details in this brochure are subject to change without notice for improvements.
The information is as of April, 2019. PIC-0089 A (1510-R2)
8 Khartoum Road MACQUARIE PARK NSW 2113 Australia
Tel. [phone]
https://www.fujixerox.com.au/
For more information or detailed product specification, please call or visit us at
