Fujitsu Siemens Computers PRIMERGY BX620 S4 Owner's manual

PRIMERGY BX620 S4
2-way Server Blade
Service Supplement
Edition May 2007

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.vor
Copyright © 2007 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

BX620 S4 Service Supplement
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Documentation overview . . . . . . . . . . . . . . . . . . . . 5
1.2 Notational conventions . . . . . . . . . . . . . . . . . . . . . 7
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . 11
3.2 Environmental protection . . . . . . . . . . . . . . . . . . . 15
4 Replacement routines . . . . . . . . . . . . . . . . . . . . . 19
4.1 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.2 Replacing the control panel board . . . . . . . . . . . . . . 23
4.3 Exchanging processors . . . . . . . . . . . . . . . . . . . . 26
4.4 Replacing the battery . . . . . . . . . . . . . . . . . . . . . 34
5 Diagnosis and maintenance . . . . . . . . . . . . . . . . . . 37
5.1 Server blade diagnostics LEDs . . . . . . . . . . . . . . . . 37
5.2 MAC address labels . . . . . . . . . . . . . . . . . . . . . . 38
5.3 DIP switch settings . . . . . . . . . . . . . . . . . . . . . . . 39
5.4 Recovering the server blade BIOS . . . . . . . . . . . . . . 41
5.5 Spare parts and add-on modules . . . . . . . . . . . . . . . 43
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.ivz

BX620 S4 Service Supplement 5
1 Preface
The PRIMERGY BX620 S4 2-way Server Blade is an Intel-based server blade.
It is designed for the PRIMERGY BX600 S3 basic unit. The server blade can
also be operated in the BX600 S2 basic unit, in which case, however, only 2 of
the 6 onboard Ethernet channels of the server blade can be used.
1.1 Documentation overview
Concept and target groups
This Service Supplement supplements the information contained in the
Operating Manual.
VCAUTION!
The activities described in this manual may only be performed by
specialist personnel with technical training.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
Service DVD
A service DVD is available for service partners of Fujitsu Siemens Computers.
This DVD contains the following manuals in PDF format:
– the “Safety notes and other important information” manual
– the “Ergonomics” manual
– the Operating Manual for PRIMERGY BX620 S4
– the Options Guide for PRIMERGY BX620 S4
– the documentation for the server blade models available for the
PRIMERGY BX600 basic unit
IThese PDF files can also be downloaded from the Internet free of
charge: At http://manuals.fujitsu-siemens.com you will find an overview
page showing the online documentation available on the Internet. You
can go to the PRIMERGY Server documentation by clicking on “industry
standard servers”.

6 Service Supplement BX620 S4
Documentation overview Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k01
Information/Activity Manual
Features and technical data of the server blade Operating Manual
Installation and initial operation, such as:
– Connections to the basic unit
– Operation
– Configuring the server blade
– Firmware update (server blade BIOS and
BMC)
– Installing the server blade in the basic unit
BIOS setup
Troubleshooting
Installing/removing hot-plug components:
– Hard disk modules
Extensions and conversions
– Installing memory modules
– Adding processors
– Replacing the storage module
Options Guide
Replacement routines
– Replacing the control panel
– Exchanging the processor
– Replacing the CMOS-battery
Diagnostics
– Diagnostic LEDs
– MAC/iSCSI address labels
–BIOSrecovery
– DIP Switch Settings
Spare parts list
Service Supplement
Detailed safety information Safety manual
Table 1: Overview of the BX620 S4 server blade documentation

BX620 S4 Service Supplement 7
Preface Notational conventions
1.2 Notational conventions
The following notational conventions are used in this manual:
“quotation marks” indicate names of chapters and terms that need to be
emphasized.
Êindicates an activity that must be performed.
VCAUTION! indicates that, if you ignore the information given at this
point, your health, the correct functioning of your
system or the security of your data may be at risk.
Iindicates supplementary information, remarks and tips.
Table 2: Notational conventions

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k01

BX620 S4 Service Supplement 9
2Procedure
VCAUTION!
The activities described in this manual should only be performed by
engineers, service personnel or technical specialists.
ÊFirst of all please familiarize yourself with the safety instructions in the
chapter “Important notes” on page 11ff.
ÊMake sure that all the manuals you need (see service DVD) are available,
printing out the PDF files if necessary. You will definitely need the Operating
Manual of the basic unit.
ÊShut down the server blade correctly, switch it off and remove it from the
basic unit as described in the chapter “Replacement routines” on page 19f.
ÊReplace the defective component as described in the relevant chapter.
ÊClose the server blade.
ÊStart the server blade.1
ÊIf necessary, configure the operating system as required.1
1See Operating Manual.

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k02

BX620 S4 Service Supplement 11
3 Important notes
This chapter provides safety instructions which you must observe when
handling your system.
3.1 Notes on safety
IThe following safety instructions can also be found in the manual entitled
“Safety notes and other important information”.
This device complies with the relevant safety regulations for IT equipment,
including electronic office machines for use in an office environment.
If you have any questions, contact your sales outlet or the Fujitsu Siemens
Computers customer service center.
VCAUTION!
The activities described in this manual should only be performed by
engineers, service personnel or technical specialists. Equipment repairs
should only be performed by qualified staff! Any failure to observe the
guidelines in this manual could endanger the user (through electric
shock, fire hazards) or damage the equipment. Please note that any
unauthorized opening of the device will result in the invalidation of the
warranty and exclusion from all liability.
Before setting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see
Operating Manual).
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Before operating the device, wait until it is absolutely dry and has
reached approximately the same temperature as the installation site.
Any failure to observe the guidelines in this manual could damage the
equipment.

12 Service Supplement BX620 S4
Notes on safety Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k03
VCAUTION!
●Transport the device only in its original packaging or in packaging
which protects it from knocks and jolts.
Installation and operation
VCAUTION!
●Read the notes on installation and operation in the Operating Manual
of your PRIMERGY BX600 basic unit.
●PRIMERGY BX620 S4 server blades are not for use in slots 4 an 10
of the PRIMERGY BX600 S2 basic unit.
●When installing the server blade in the basic unit, beware of the
energy hazard at the midplane conctacts. A short-circuit on these
contacts may damage the system.
●Data cables must be adequately shielded to avoid interference.
●For the LAN wiring, the requirements according to standards EN
50173 and EN 50174-1/2 apply. The minimum requirement is the use
of a protected LAN line of category 5 for 10/100 Mbps Ethernet,
and/or of category 5e for Gigabit Ethernet. The requirements of the
specification ISO/IEC 11801 must also be taken into account.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the Operating Manual.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
●Be careful to ensure that no objects (e.g. jewelry, paper clips etc.) or
liquids get inside the device (electric shock, short circuit).
●In emergencies (e.g. damaged casing, elements, or cables,
penetration of liquids or foreign bodies), switch off the device immedi-
ately, unplug it from the grounded power outlet, and contact your
customer service centre.
●Proper operation of the device (in accordance with IEC60950/EN
60950) is only ensured if the casing is completely assembled and the
rear covers for the installation openings are in place (electric shock,
cooling, fire protection, interference suppression).

BX620 S4 Service Supplement 13
Important notes Notes on safety
VCAUTION!
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and telecommunica-
tions terminal equipment.
If you install other extensions, you may damage the system or violate
these safety regulations.
Information on which system extensions are suitable can be obtained
from the customer service center or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
may only be opened, removed, or exchanged by authorized, qualified
personnel, with the exception of the hot-plug/hot-swap components.
●If you cause a defect on the device by installing or exchanging system
extensions, the warranty will be invalidated.
●You may only set the resolutions and refresh rates specified in the
operating manual for your monitor.
Otherwise, you may damage the monitor. If you are in any doubt,
contact your sales outlet or customer service center.
Batteries
VCAUTION!
●Incorrect replacement of batteries can lead to risk of explosion. The
batteries must be replaced with an identical battery or with a battery
type recommended by the manufacturer.
●Do not throw batteries into the trash can. Please dispose of them in
accordance with local regulations for special refuse.
●When replacing the lithium battery in the relevant components,
always follow the instructions in this manual.
●All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). The marking also contains the chemical
symbol of the heavy metal that classifies the battery as a pollutant:
Cd Cadmium
Hg Mercury
Pb Lead

14 Service Supplement BX620 S4
Electrostatic-Sensitive Devices Important Notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k03
Modules with electrostatic-sensitive devices
Modules with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When handling modules with ESDs, it is essential that you observe the following
guidelines:
●You must always discharge static build-up, e.g. by touching a grounded
object, before working with such components.
●Any devices or tools that are used must be free of electrostatic charge.
●Always hold components with ESDs at the edges.
●Do not touch any connectors or conduction paths on an ESD.
●Wear a suitable grounding cable that connects you to the external chassis of
the basic unit.
●Place all the components on a pad which is free of electrostatic charge.
IFor a detailed description of how to handle ESD components, see the
relevant European and international standards (EN 61340-5-1,
ANSI/ESD S20.20).

BX620 S4 Service Supplement 15
Important Notes Electrostatic-Sensitive Devices
3.2 Environmental protection
Environmentally friendly product design and development
This product was designed in compliance with the Fujitsu Siemens Computers
standard on ”environmentally friendly product design and development”. This
means that the designers have taken into account crucial criteria such as
durability, selection and labeling of materials, emissions, packaging, the ease
with which the product can be dismantled, and the extent to which it can be
recycled.
This saves on resources and helps to protect the environment.
Notes on saving energy
Devices that do not have to be on permanently should not be switched on until
they are needed and should be switched off during long breaks and when work
is finished.
Notes on packaging
Do not throw away the original packaging as you may need it for future transport.
If possible, the device should be transported in its original packaging.
Notes on dealing with consumables
Please dispose of printer consumables and batteries in accordance with local
regulations.
Do not throw batteries into the trash can. They must be disposed of in accor-
dance with local regulations on special waste.
Notes on labeling plastic housing parts
If possible, do not stick your own self-adhesive labels on plastic housing parts,
as this can hamper the recycling process.

16 Service Supplement BX620 S4
Electrostatic-Sensitive Devices Important Notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k03
Returning used electrical and electronic devices
– Separate disposal
Old electrical and electronic devices should be disposed of separately and
not with household refuse. Separate disposal allows this old equipment to
be reused or recycled, which helps conserve resources.
– Return and collection systems
It may be possible to return old electrical/electronic devices from private
households free of charge. Please use the country-specific return or
collection systems available to you (see “Local contacts” on page 17).
The return of used devices which pose a health or safety risk for human
beings due to soiling during use may be refused.
– Reuse and recycling
By actively using any return or collection systems offered, you will be contrib-
uting to the reuse and recycling of electrical/electronic devices.
– Effects on the environment and human health
Old electrical/electronic devices contain parts which must be handled selec-
tively according to EU directives. Separate disposal and selective treatment
are the basis for environment-friendly disposal and the protection of human
health.
– Meaning of the symbol “Crossed out trash can on wheels"
In accordance with EU directives, electrical (electronic) devices which are
marked with one of the following symbols must not be disposed of with
household refuse.
Figure 2: Symbols on electrical/electronic devices

BX620 S4 Service Supplement 17
Important Notes Electrostatic-Sensitive Devices
Returning batteries
According to EU directives, batteries which are marked with one of the following
symbols must not be disposed of together with household refuse.
Figure 3: Symbols on batteries
With batteries containing harmful substances, the chemical symbol for the
heavy metal contained is indicated below the trash can.
Cd Cadmium
Hg Mercury
Pb Lead
The following applies to Germany:
– Private consumers can return batteries at the point of sale or in the
immediate vicinity thereof free of charge.
– The consumer is obligated to return defective or used batteries to the seller
or to the return points established for this purpose.
Local contacts
For details on take-back and reuse of devices and consumables within Europe,
contact your Fujitsu Siemens Computers branch office/subsidiary or our
recycling centre in Paderborn, Germany:
Fujitsu Siemens Computers
Recycling Center
33106 Paderborn
Germany
Tel. [phone]
Fax [phone]
Internet: www.fujitsu-siemens.com/recycling

© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k03

BX620 S4 Service Supplement 19
4 Replacement routines
VCAUTION!
When working with systems and boards, make sure you observe the
safety information in the chapter “Important notes” on page 11ff.
4.1 Preparation
If you want to replace components which are not hot-pluggable, you must
remove the server blade from the basic unit and open it.
ÊExit all applications and shut down the server blade correctly.
ÊPress the On/Off button on the server blade control panel.

20 Service Supplement BX620 S4
Preparation Replacement routines
© cognitas. Gesellschft für Technik-Dokumentation mbH 2007 Pfad: H:\windows\_projekte\BX620_S4\Service-Supplement\2007-07\InArbeit\BX620S4_suppl.en\BX620S3_suppl_us.k04
Removing the server blade from the basic unit
Figure 4: Removing the server blade
ÊPress the two touch points (1) to unlock the
ejection levers.
ÊOpen out the two ejection levers (2) simul-
taneously to disengage the server blade.
1
1
2
2
