Fujitsu Siemens Computers D2300 User manual

System Board D2300
for RX200 S3
Technical Manual
Edition June 2006

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademar s
Copyright © 2006 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

D2300 (RX200 S3) Technical Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.1 Notes on safety . . . . . . . . . . . . . . . . . . . . . . . . . . 7
2.2 CE Certificate of Conformity . . . . . . . . . . . . . . . . . . 10
2.3 Environmental protection . . . . . . . . . . . . . . . . . . . . 11
3 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3.3 PCI-Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.3.1 ISA bus resources . . . . . . . . . . . . . . . . . . . . . . . . 20
3.3.2 PCI resources . . . . . . . . . . . . . . . . . . . . . . . . . . 21
3.4 Screen resolution . . . . . . . . . . . . . . . . . . . . . . . . 23
3.5 Temperature / system monitoring . . . . . . . . . . . . . . . . 23
3.6 Interfaces and Connectors . . . . . . . . . . . . . . . . . . . 25
3.6.1 External ports . . . . . . . . . . . . . . . . . . . . . . . . . . 27
3.7 Settings with jumpers . . . . . . . . . . . . . . . . . . . . . . 29
4 Replacing the lithium battery . . . . . . . . . . . . . . . . . 31
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33

D2300 (RX200 S3) Technical Manual 5
1Introduction
This technical manual describes the system board D2300, which is equipped
with one or two Intel® processors.
Further information you will find in the BIOS description.
For additional driver information, refer to the Readme files located on the server
hard disk and on the supplied "Update CDs" or the "ServerStart" CD.
Notational conventions
The meanings of the symbols and fonts used in this manual are as follows:
italics indicates commands, menu options or software
programs.
fixed font indicate system output on the monitor.
semi-bold fixed font indicates values to be entered through the keyboard.
[Key symbol] indicates keys according to their representation on the
keyboard.
If capital letters are to be entered explicitly, then the
Shift key is shown, e.g. [SHIFT] - [A] for A.
If two keys need to be pressed at the same time, then
this is shown by placing a hyphen between the two key
symbols.
"Quotation marks" Indicates names of chapters and terms that are being
emphasized.
ÊDescribes an operation that must be performed.
VCAUTION! Pay particular attention to texts marked with this
symbol. Failure to observe these warnings may
endanger your life, destroy the system or lead to the
loss of data.
IIndicates additional information, notes and tips
Table 1: Notational conventions

D2300 (RX200 S3) Technical Manual 7
2 Important notes
In this chapter you will find essential information regarding safety when working
with your server.
VCAUTION!
With the system board installed you must open the system to access the
system board. How to dismantle and reassemble the system is described
in the service manual accompanying your system.
When installing the system board, refer to the specific installation infor-
mation in the operating and/or service manual for the receiving server.
2.1 Notes on safety
VCAUTION!
●The actions described in these instructions should only be performed
by authorized, qualified personnel. Equipment repairs should only be
performed by qualified staff. Any failure to observe the guidelines in
this manual, and any unauthorized openings and improper repairs
could expose the user to risks (electric shock, fire hazards) and could
also damage the equipment. Please note that any unauthorized
openings of the device will result in the invalidation of the warranty
and exclusion from all liability.
●Transport the device only in the antistatic original packaging or in
packaging that protects it from knocks and jolts.
●Only install expansions that are allowed for the system board. If you
install other expansions, you may damage the requirements and rules
governing safety and electromagnetic compatibility or your system.
Information on which system expansions are approved for installation
can be obtained from our customer service center or your sales
outlet.
●The warranty expires if the device is damaged during the installation
or replacement of system expansions.

8 Technical Manual D2300 (RX200 S3)
Notes on safety Important notes
V●Components can become very hot during operation. Ensure you do
not touch components when making extensions to the system board.
There is a danger of burns!
●Transmisson lines to peripheral devices must be adequately shielded.
●To the LAN wiring the requirements apply in accordance with the
standards EN 50173 and EN 50174-1/2. As minimum requirement
the use of a protected LAN line of category 5 for 10/100 Mbps
Ethernet, and/or of category 5e for Gigabit Ethernet is considered.
The requirements of the specification ISO/IEC 11801 are to be
considered.
●Never connect or disconnect data transmission lines during a storm
(risk of lightning hazard).
Batteries
VCAUTION!
●Incorrect replacement of lithium battery may lead to a risk of
explosion. The batteries may only be replaced with identical batteries
or with a type recommended by the manufacturer.
It is essential to observe the instructions in the chapter “Replacing the
lithium battery”.

D2300 (RX200 S3) Technical Manual 9
Important notes Notes on safety
Modules with electrostatic-sensitive components
Boards with electrostatic sensitive devices (ESD) are marked with the following
label:
Figure 1: ESD label
You must follow the instructions below when handling modules containing
electrostatic-sensitive components
●You must always discharge yourself of static charges (e.g. by touching a
grounded object) before touching the components.
●The equipment and tools you use must be free of static charges.
●Remove the power plug from the power socket before inserting or removing
boards containing ESDs.
●Always hold boards with ESDs by theit edges.
●Do not touch any exposed pins or conductors on a component.
●Use a grounding cable designed for this purpose to connect yourself to the
system unit as you install/deinstall the board.
●Place all components on a static-free surface.
IYou will find a detailed description for handling ESD components in the
relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).

10 Technical Manual D2300 (RX200 S3)
CE Certificate of Conformity Important notes
Notes about boards
●During installation/deinstallation of the system board, observe the specific
instructions described in the service manual for the server.
●Remove the plug from the mains outlet so that system and system board are
totally disconnected from the mains voltage.
●To prevent damage to the system board, the components and conductors on
it, please take great care when you insert or remove boards. Take great care
to ensure that extension boards are slotted in straight, without damaging
components or conductors on the system board, or any other components,
for example EMI spring contacts
●Be careful with the locking mechanisms (catches, centring pins etc.) when
you replace the system board or components on it, for example memory
modules or processors.
●Never use sharp objects (screwdrivers) for leverage.
2.2 CE Certificate of Conformity
The shipped version of this board complies with the requirements
of the EEC directive 89/336/EEC "Electromagnetic compatibility".
Compliance was tested in a typical PRIMERGY configuration.

D2300 (RX200 S3) Technical Manual 11
Important notes Environmental protection
2.3 Environmental protection
Environmentally-friendly product design and development
This product has been designed in accordance with the Fujitsu Siemens
Computers standard for “environmentally friendly product design and devel-
opment”. This means that key factors such as durability, selection and labeling
of materials, emissions, packaging, ease of dismantling and recycling have
been taken into account.
This saves resources and thus reduces the harm done to the environment.
Energy-saving information
Devices that do not need to be constantly switched on should be switched off
until they are needed as well as during long breaks and after completion of work.
Packaging information
Do not throw away the packaging. You may need it later for transporting the
system. If possible, the equipment should only be transported in its original
packaging.
Information on handling consumables
Please dispose of batteries in accordance with local regulations.
In accordance with EU directives, batteries must not be disposed of with
unsorted domestic waste. They can be returned free of charge to the manufac-
turer, dealer or an authorized agent for recycling or disposal.
All batteries containing pollutants are marked with a symbol (a crossed-out
garbage can). They are also marked with the chemical symbol for the heavy
metal that causes them to be categorized as containing pollutants:
Cd Cadmium
Hg Mercury
Pb Lead

12 Technical Manual D2300 (RX200 S3)
Environmental protection Important notes
To Germany applies:
– Private customers can return spent batteries free of charge at the point of
sale or in its immediate proximity.
– The commercial end-user is legally obliged to return defective or spent
batteries to the distributor or designated return and collection systems
available to you.
Labels on plastic casing parts
Please avoid sticking your own labels on plastic parts wherever possible, since
this makes it difficult to recycle them.
Returns, recycling and disposal
Details regarding the return and recycling of devices and consumables within
Europe can also be found in the "Returning used devices" manual, via your local
Fujitsu Siemens Computers branch or from our recycling center in Paderborn:
Fujitsu Siemens Computers
Recycling Center
D-33106 Paderborn
Tel. [phone]
Fax [phone]
The device must not be disposed of with domestic waste. This
device is labeled in compliance with European directive
2002/96/EG on waste electrical and electronic equipment
(WEEE).
This directive sets the framework for returning and recycling
used equipment and is valid across the EU. When returning
your used device, please use the return and collection systems
available to you. Further information can be found
atwww.fujitsu-siemens.com/recycling.

D2300 (RX200 S3) Technical Manual 13
3 Features
3.1 Overview
Processors
– 1 or 2 x Intel®Dual-Core Xeon™ processors
– 2 processor sockets LGA771 for Intel®Dual-Core Xeon™ processor with
667 / 1066 MHz front side bus (133/266 MHz quadruple transmission rate)
– 2 x 2 Mbyte (Intel Dual-Core 5000 sequence processor) or 1 x 4 Mbyte (Intel
Dual-Core 5100 sequence processor), second level cache, ECC
– Support of SMP, MPS 1.4 compliant
– 2 x VRM 11.0 onboard (EVRD)
Main memory
– 8 slots for main memory FBD-533 and FBD-667 (FBD - Fully Buffered
DIMMs) memory modules,
2 channel with 2 modules per channel with 512 MB, 1 Gbyte, 2 Gbyte and
4Gbyte
– maximum 32 Gbyte of memory
– supports „4 way interleaved memory subsystems“ (4 identical memory
modules have to installed at the same time)
– ECC multiple bit error detection and single bit error correction
– memory scrubbing function
– Single Device Data Correction (SDDC) function (Chipkill™)
– memory mirroring function

14 Technical Manual D2300 (RX200 S3)
Overview Features
Chips on the system board
– Intel®MCH (memory controller hub) chipset (north bridge)
– Intel®ESB2-V processor (south bridge)
– Intel®PXH-V hub for PCI bridge (Option 2, on page 15)
– Broadcom LAN controller (BCM 5715C)
– iRMC chipset with integrated graphics controller
– SAS controller (LSI 1068) with IME functionality
– Super I/O controller (SMSC DME 1737)
– Flash EPROM for:
– IME firmware
–BIOS
–LAN
– Server Management (SM)
internal connectors
– 1 IDE connector (CD-ROM/DVD-ROM)
– 1 SATA connector
– USB Type C (for USB port on front side)
– I2C connector
– main power connector (12V, -12V and 5V auxiliary supply)
– 12V (CPU) power connector
– IPMB connector
– HDD activity connector
– control panel
– battery holder
– connectors for PWM fans (Puls Wide modulation)

D2300 (RX200 S3) Technical Manual 15
Features Overview
external connectors
– 1 serial port (COM1) for system and BMC (shared)
– 2 PS/2 interfaces for keyboard and mouse
– 4 USB 2.0 ports with 480 Mbits/s (2 x front, 2 x rear)
– 1 VGA port
– 2 RJ45 LAN port
PCI slots
There are two PCI expansion slots on the system board:
– PCI-X1 / PCI-X expansion slot
– PCI-Express x8 expansion slot
The riser boards on the PCI riser board assembly convert the functionality of the
system board expansion slots to a pair of slots positioned at a 90° angle from
the system board. There are two possible configuration.
– Option 1
– One standard half length PCI Express x8 slot
– One low-profile half length 64-bit/100 MHz PCI-X slot
– Option 2
– One standard half length 64-bit/100 MHz PCI-X slot*
– One low-profile half length 64-bit/100 MHz PCI-X riser board
* The PXH-V daughter board is mounted on the PCI riser board assembly.

16 Technical Manual D2300 (RX200 S3)
Overview Features
BIOS features
– Phoenix System BIOS V 4.06
– SMBIOS 2.31 (DMI)
– MultiProcessor Specification 1.4
– Server Hardware Design Guide 3.0
– WfM 2.0
– IPMI V2.0
– ACPI 1.0b support
– LSI SCSI BIOS with IME (Integrated Mirroring Enhanced)
– USB keyboard/mouse
– boot possible from:
– CD-ROM
– USB drive
–LAN
– console redirection support
– OEM logo
– CPU, memory disable
– memory mirroring support
Environmental protection
Battery in holder
Form factor
249 x 455 mm

D2300 (RX200 S3) Technical Manual 17
Features Main memory
3.2 Main memory
The system board supports up to 32 Gbyte main memory. 8 slots (4 memory
banks with 2 modules) are available for the main memory. Each memory bank
must be equipped with two 512 Mbyte, 1 Gbyte, 2 Gbyte or 4 Gbyte (FBD - Fully
Buffered DIMM) memory modules.
ECC with memory scrubbing and with the Single Device Data Correction
(SDDC) function is supported.
Figure 2: Structure of the memory in the memory banks and memory modules
Module population
– The memory modules have to be registered Fully Buffered DIMMs (ECC
DDR2 533/667).
– The memory modules have to be populated in pairs.
– Each pair must consist of identical memory modules.
– Each memory bank and channel (module) must be equipped with 2 memory
modules.
– The module capacity between pairs can differ: pair 1A/1B can be populated
with two 512 Mbyte modules and pair 2A/2B with two 1 Gbyte modules.
M e m o r y B a n k 4 - M o d u l e A ( F B D 1 A )
M e m o r y B a n k 4 - M o d u l e B ( F B D 2 A )
M e m o r y B a n k 3 - M o d u l e A ( F B D 1 B )
M e m o r y B a n k 3 - M o d u l e B ( F B D 2 B )
M e m o r y B a n k 2 - M o d u l e A ( F B D 1 C )
M e m o r y B a n k 2 - M o d u l e B ( F B D 2 C )
M e m o r y B a n k 1 - M o d u l e A ( F B D 1 D )
M e m o r y B a n k 1 - M o d u l e B ( F B D 2 D )

18 Technical Manual D2300 (RX200 S3)
Main memory Features
Install identical modules (of the same type, manufacturer, speed, timing, and
organization) per the instructions below:
– When operating in non-mirror mode:
– Install the first pair in the FBD 1A and FBD 1B slots.
– Memory upgrade granularity is two DIMMs.
– Observe the following channel pair sequence during installation:
FDB 1C - FDB 1D, FBD 2A - FDB 2B, then FDB 2C - FDB 2D
– When operating in single DIMM mode, the module should be installed in the
FBD 1A slot.

D2300 (RX200 S3) Technical Manual 19
Features PCI-Bus
3.3 PCI-Bus
Figure 3: Representation of the PCI-outlets
PCI slots
The following table shows an overview of the PCI slots:
PCI slot 64Bit Frequency
in MHz
Description
1 64 bit 100/133 64 bit PCI-X slot, low profile
2 64 bit 133 64 bit PCIe x8 slot, low profile and full
size
P C I e x 8 S l o t 2
P C I - 1 S l o t 1

20 Technical Manual D2300 (RX200 S3)
PCI-Bus Features
3.3.1 ISA bus resources
IIRQ 2, 3, 5, 11 are available for additional devices
„IRQ“ = interrupt assigned as shipped
„Address“ = this address can be used for your particular device
„DMA“ = this DMA can be used for your particular device
Default settings are shown in bold print.
Device IRQ Address DMA
Timer 0 040-043
Keyboard 1 060.064
Serial port COM1 4 3F8-3FF
Floppy disk drive controller 6 3F0-3F5, 3F7 2
Ethernet controller 7
Real-time clock (RTC) 8 070-071
SCI interrupt 9
SMB controller 9
PS/2 mouse controller 12
Numeric processor 13 0F0-0FE
IDE controller (primary) 14 1F0-1F7, 3F6
IDE controller (secondary) 15 170-177, 376
