Fujitsu AirStage AB 12TF Series User manual

KEEP THIS OPERATION MANUAL
FOR FUTURE REFERENCE
FUJITSU GENERAL LIMITED P/N9369308017
OPERATING MANUAL
AIR CONDITIONER
OPERATING MANUAL
BEDIENUNGSANLEITUNG
MODE D’EMPLOI
MANUAL DE FUNCIONAMIENTO
MANUALE DI ISTRUZIONI
ΕΓΧΕΙΡΙ∆ΙΟ ΛΕΙΤΟΥΡΓΙΑΣ
РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ
MANUAL DE INSTRUÇÕES
Indoor Unit
AB 12TF
AB 14TF
AB 18TF
AB 24TF
FLOOR CONSOLE/
UNDER CEILING DUAL TYPE
English
Deutsch
Français
Español
Italiano
EλληvIkά
Русский
Português
TM
En-1
CONTENTS
SAFETY PRECAUTIONS ....................................... 1
NAME OF PARTS ................................................... 2
MANUAL AUTO OPERATION ............................... 3
CLEANING AND CARE .......................................... 4
TROUBLESHOOTING ............................................ 5
OPERATING TIPS................................................... 6
SPECIFICATIONS ................................................... 7
●Do not attempt to install this air conditioner by yourself.
●This unit contains no user-serviceable parts. Always consult authorized service per-
sonnel for repairs.
●When moving, consult authorized service personnel for disconnection and installa-
tion of the unit.
●Do not become over-exposed to cold air by staying in the direct path of the airflow of
the air conditioner for extended periods of time.
●Do not insert fingers or objects into the outlet port or intake grilles.
●Do not start and stop air conditioner operation by turning off the electrical breaker
and so on.
●In the event of a malfunction (burning smell, etc.), immediately stop operation, turn
off the electrical breaker, and consult authorized service personnel.
●Provide occasional ventilation during use.
●Do not direct air flow at fireplaces or heating apparatus.
●Do not climb on, or place objects on, the air conditioner.
●Do not hang objects from the indoor unit.
●Do not set flower vases or water containers on top of air conditioners.
●Do not expose the air conditioner directly to water.
●Do not operate the air conditioner with wet hands.
●Turn off power source when not using the unit for extended periods.
●Always turn off the electrical breaker whenever cleaning the air conditioner or the air
filter.
●Connection valves become hot during Heating; handle with care.
●Check the condition of the installation stand for damage.
●Do not place animals or plants in the direct path of the air flow.
●When restarting after a long period of disuse in the winter, do:
Turn the power switch on at least 12 hours before starting the unit.
●Do not drink the water drained from the air conditioner.
●Do not use in applications involving the storage of foods, plants or animals, precision
equipment, or art works.
●Do not apply any heavy pressure to radiator fins.
●Operate only with air filters installed.
●Do not block or cover the intake grille and outlet port.
●Ensure that any electronic equipment is at least one metre away from either the in-
door or outdoor units.
●Avoid installing the air conditioner near a fireplace or other heating apparatus.
●
When installing the indoor and outdoor unit, take precautions to prevent access to infants.
●Do not use inflammable gases near the air conditioner.
CAUTION!
SAFETY PRECAUTIONS
●Before using the appliance, read these “PRECAUTIONS” thoroughly and operate in the correct way.
●The instructions in this section all relate to safety; be sure to maintain save operating conditions.
●“DANGER”, “WARNING” and “CAUTION” have the following meanings in these instructions:
DANGER!
WARNING!
CAUTION!
This mark indicates procedures which, if improperly performed, are most likely to
result in the death of or serious injury to the user or service personnel.
This mark indicates procedures which, if improperly performed, might lead to the
death or serious injury of the user.
This mark indicates procedures which, if improperly performed, might possibly result
in personal harm to the user, or damage to property.
DANGER!
En-2
NAME OF PARTS
Fig. 1
Fig. 2
Fig. 1 Indoor Unit
1Operating Control Panel (Fig. 2)
2MANUAL AUTO button
3Remote Control Signal Receiver
4OPERATION Indicator Lamp (red)
5TIMER Indicator Lamp (green)
6SWING Indicator Lamp (orange)
(VERTICAL SWING)
7SWING Indicator Lamp (orange)
(HORIZONTAL SWING)
8Intake Grille
9Air Filter
0UP/DOWN Air Direction Flaps
ARIGHT/LEFT Air Direction Louvers
(behind UP/DOWN Air Direction Flaps)
BDrain Hose
Fig. 3
Fig. 3 Outdoor Unit
CIntake Port
DOutlet Port
This breaker is installed during
the electrical installation.
Electrical Breaker
Fig. 4
C
D
D
C
En-3
MANUAL AUTO OPERATION
Use the MANUAL AUTO operation in the event the remote control unit is lost or otherwise unavailable.
How To Use the Main Unit Controls
Press the MANUAL AUTO button on the main unit control
panel.
To stop operation, press the MANUAL AUTO button once again.
●When the air conditioner is operated
with the controls on the Main unit, it
will operate under the same mode as
the AUTO mode selected on the re-
mote control unit.
However, the Heat pump model will
follow the operating mode of the other
indoor unit.
●The fan speed selected will be “AUTO”
and the thermostat setting will be
23 °C.
En-4
●When used for extended periods, the unit may accumulate dirt inside, reducing its performance. We recommend that the
unit be inspected regularly, in addition to your own cleaning and care. For more information, consult authorized service
personnel.
●When cleaning the unit’s body, do not use water hotter than 40 °C, harsh abrasive cleansers, or volatile agents like
benzene or thinner.
●Do not expose the unit body to liquid insecticides or hairsprays.
●If the unit will not be operated for a period of one month or more, be sure to allow the inner parts of the unit to dry
thoroughly, in advance, by operating the unit in fan mode for half a day.
CLEANING AND CARE
●Before cleaning the unit, be sure to stop the unit and disconnect the power supply.
●Turn off the electrical breaker.
●Be sure the intake grille is installed securely.
●When removing and replacing the air filters, be sure not to touch the heat exchanger, as per-
sonal injury may result.
CAUTION!
Cleaning the Air Filter
1. Pull out both sides and the center of the
intake grille.
2. Pull the air filters upward to remove them.
Push the air filter handles away from the intake grille in
direction 1, then pull out the air filters.
3. Clean the air filters.
Remove the dust from the air filters by vacuuming or
washing them. After washing, allow the air filters to dry
thoroughly in an area protected from sunlight.
4. Re-attach the air filters to the intake grille.
1The air filters fit onto the inside of the intake grille.
(figure 1)
2The bottom edges of the air filters should fit into the
filter brackets. (figure 1)
3The air filters should be pushed down so that their
top edges fit under the projections at the top of the
intake grille. (figure 2)
5. Push in both sides and the center of the
intake grille.
●Dust can be cleaned from the air filter either with a vacuum
cleaner, or by washing the filter in a solution of mild de-
tergent and warm water. If you wash the filter, be sure to
allow it to dry thoroughly in a shady place before rein-
stalling.
●If dirt is allowed to accumulate on the air filter, air flow
will be reduced, lowering operating efficiency and increas-
ing noise.
●During periods of normal use, the air filters should be
cleaned every two weeks.
About 30 mm
Side Panel
Intake Grille
Notch
Arm
Hook
Handle
Intake Grille
Base
Arm
1
Air Filter
Bracket
(figure 1)
Filter bracket
Air Filter
(figure 2)
En-5
TROUBLESHOOTING
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL”(Reverse Cycle).
In the event of a malfunction (burning smell, etc.), immediately stop operation, turn off the elec-
trical breaker, and consult authorized service personnel.
Merely turning off the unit’s power switch will not completely disconnect the unit from the power
source. Always be sure to turn off the electrical breaker to ensure that power is completely off.
Before requesting service, perform the following checks:
Symptom
Doesn’t operate immedi-
ately:
Noise is heard:
Smells:
Mist or steam are
emitted:
Airflow is weak or stops.
Water is produced from
the outdoor unit.
Problem
●If the unit is stopped and then immediately started again, the com-
pressor will not operate for about 3 minutes, in order to prevent
fuse blowouts.
●Whenever the electrical breaker is turned off then on again, the
protection circuit will operate for about 3 minutes, preventing unit
operation during that period.
●During operation and immediately after stopping the unit, the
sound of water flowing in the air conditioner’s piping may be
heard. Also, noise may be particularly noticeable for about 2 to 3
minutes after starting operation (sound of coolant flowing).
●During operation, a slight squeaking sound may be heard. This is
the result of minute expansion and contraction of the front cover
due to temperature changes.
*●During Heating operation, a sizzling sound may be heard occa-
sional. This sound is produced by the Automatic Defrosting op-
eration.
●Some smell may be emitted from the indoor unit. This smell is
the result of room smells (furniture, tobacco, etc.) which have
been taken into the air conditioner.
●During Cooling or Dry operation, a thin mist may be seen emitted
from the indoor unit. This results from the sudden Cooling of
room air by the air emitted from the air conditioner, resulting in
condensation and misting.
*●During Heating operation, the outdoor unit’s fan may stop, and
steam may be seen rising from the unit. This is due to Automatic
Defrosting operation.
*●When Heating operation is started, fan speed is temporarily very
low, to allow internal parts to warm up.
*●During Heating operation, if the room temperature rises above
the thermostat setting, the outdoor unit will stop, and the indoor
unit will operate at very low fan speed. If you wish to warm the
room further, set the thermostat for a higher setting.
*●During Heating operation, the unit will temporarily stop opera-
tion (between 2 and 16 minutes) as the Automatic Defrosting mode
operates. During Automatic Defrosting operation, the OPERATION
indicator lamp will flash.
●The fan may operate at very low speed during Dry operation or
when the unit is monitoring the room’s temperature.
●In the monitor AUTO operation, the fan will operate at very low
speed.
*●During Heating operation, water may be produced from the out-
door unit due to Automatic Defrosting operation.
See Page
—
—
6
—
—
6
—
6
—
—
6
NORMAL
FUNCTION
WARNING!
En-6
TROUBLESHOOTING
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL”(Reverse Cycle).
Symptom
Doesn’t operate at all:
Poor Cooling
(or *Heating)
performance:
See Page
—
—
—
CHECK ONCE
MORE
Items to check
●Has there been a power failure?
●Has a fuse blown out, or a circuit breaker been tripped?
●Is the main power switch set to the OFF position?
●Is the timer operating?
●Is the air filter dirty?
●Are the air conditioner’s intake grille or outlet port blocked?
●Did you adjust the room temperature settings (thermostat) cor-
rectly?
●Is there a window or door open?
●In the case of Cooling operation, is a window allowing bright sun-
light to enter? (Close the curtains.)
●In the case of Cooling operation, are there heating apparatus and
computers inside the room, or are there too many people in the
room?
If the problem persists after performing these checks, or if you notice burning smells, stop operation immediately, turn off the
electrical breaker, and consult with authorized service personnel.
OPERATING TIPS
*Heating Performance
●This air conditioner operates on the heat-pump principle,
absorbing heat from outdoor air and transferring that heat
indoors. As a result, the operating performance is reduced
as outdoor air temperature drops. If you feel that insuffi-
cient heating performance is being produced, we recom-
mend you use this air conditioner in conjunction with
another kind of heating appliance.
●Heat-pump air conditioners heat your entire room by
recirculating air throughout the room, with the result that
some time may be required after first starting the air con-
ditioner until the room is heated.
*
Cooling/Heating Priority (HEAT PUMP MODEL only)
●If another indoor unit in the same system is already oper-
ating in the cooling mode or dry mode, heating mode
settings cannot be performed. (Operation in the cooling
or dry mode will continue.)
●If another indoor unit in the same system is already oper-
ating in the heating mode, cooling mode or dry mode
settings cannot be performed. (Operation in the cooling
or dry mode will continue.)
Operation and Performance
*Microcomputer-controlled Automatic Defrosting
When using the Heating mode under conditions of low out-
door air temperature high humidity, frost may form on the
outdoor unit, resulting in reduced operating performance.
In order to prevent this kind of reduced performance, this
unit is equipped with a Microcomputer-controlled Automatic
Defrosting function. If frost forms, the air conditioner will
temporarily stop, and the defrosting circuit will operate
briefly (for about 4 to 15 minutes).
During Automatic Defrosting operation, the OPERATION in-
dicator lamp (red) will flash.
Oil Recovery Operation
Periodically, the oil recovery operation is performed in or-
der to return compressor oil to the outdoor unit. Operation
is stopped during this oil recovery operation. During oil re-
covery operation, the OPERATION indicator lamp (red) will
flash.
Low Ambient Cooling
When the outdoor temperature drops, the outdoor unit’s fans
may switch to Low Speed, or one of the fans may stop inter-
mittently.
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL”(Reverse Cycle).
En-7
OPERATING TIPS
Instructions relating to heating (*) are applicable only to “HEAT & COOL MODEL”(Reverse Cycle).
Cooling/Dry Mode
About –5 to 52 °C
About –5 to 52 °C
About 18 to 30 °C
About 80 % or less
If the unit is used for long pe-
riods under high-humidity
conditions, condensation
may form on the surface of
the indoor unit, and drip onto
the floor or other objects un-
derneath.
*Heating Mode
—
About –15 to 21 °C
About 16 to 30 °C or less
—
COOLING MODEL
HEAT & COOL MODEL
HEAT RECOVERY MODEL
(Reverse Cycle)
Outdoor temperature
Indoor temperature
Indoor humidity
●If the air conditioner is used under higher temperature conditioner than those listed, the built-in protection circuit may
operate to prevent internal circuit damage. Also, during Cooling and Dry modes, if the unit is used under conditions of
lower temperature than those listed above, the heat-exchanger may freeze, leading to water leakage and other damage.
●Do not use this unit for any purposes other than the Cooling, (*)Heating, Dehumidifying, and air-circulation of rooms in
ordinary dwellings.
SPECIFICATIONS
Temperature and Humidity Range
MODEL
POWER
COOLING CAPACITY [kW]
HEATING CAPACITY [kW]
DIMENSIONS & WEIGHT
HEIGHT [mm]
WIDTH [mm]
DEPTH [mm]
WEIGHT [kg]
AB 12TF AB 14TF AB 18TF AB 24TF
220-240 V~50 Hz
3.40-3.50 3.95-4.05 5.2-5.3 6.5-6.6
4.00-4.10 4.9-5.0 5.5-5.6 7.6-7.7
199
990
655
28 30
●Acoustic Noise Information : The maximum sound pressure level is less than 70 dB (A) for both indoor unit and outdoor
unit.
According to IEC 704-1 and ISO 3744.

This manual suits for next models

3

Other Fujitsu Air Conditioner manuals

Fujitsu AIRSTAGE UTP-RU08AH User manual

Fujitsu

Fujitsu AIRSTAGE UTP-RU08AH User manual

Fujitsu ASY14FSACW User manual

Fujitsu

Fujitsu ASY14FSACW User manual

Fujitsu Inverter ART Series User manual

Fujitsu

Fujitsu Inverter ART Series User manual

Fujitsu ASY7USA-W User manual

Fujitsu

Fujitsu ASY7USA-W User manual

Fujitsu ASF18UI-MI User manual

Fujitsu

Fujitsu ASF18UI-MI User manual

Fujitsu AUXG07-22KVLA Service manual

Fujitsu

Fujitsu AUXG07-22KVLA Service manual

Fujitsu ABYA36LCT User manual

Fujitsu

Fujitsu ABYA36LCT User manual

Fujitsu Halcyon ASU9RLS2 Service manual

Fujitsu

Fujitsu Halcyon ASU9RLS2 Service manual

Fujitsu ASYG07KMCC Service manual

Fujitsu

Fujitsu ASYG07KMCC Service manual

Fujitsu ARXC45GATH User manual

Fujitsu

Fujitsu ARXC45GATH User manual

Fujitsu General ABG36UIAT-LR User manual

Fujitsu

Fujitsu General ABG36UIAT-LR User manual

Fujitsu AST9QM User manual

Fujitsu

Fujitsu AST9QM User manual

Fujitsu AIR CONDITIONER User manual

Fujitsu

Fujitsu AIR CONDITIONER User manual

Fujitsu AS*G24LFCA Original operating manual

Fujitsu

Fujitsu AS*G24LFCA Original operating manual

Fujitsu ARTC72L User manual

Fujitsu

Fujitsu ARTC72L User manual

Fujitsu AUYA30LBLU User manual

Fujitsu

Fujitsu AUYA30LBLU User manual

Fujitsu ASU18C1 User manual

Fujitsu

Fujitsu ASU18C1 User manual

Fujitsu AOTR18LCL User manual

Fujitsu

Fujitsu AOTR18LCL User manual

Fujitsu Airstage AUXB07L User manual

Fujitsu

Fujitsu Airstage AUXB07L User manual

Fujitsu General ARXG36KHTAP Service manual

Fujitsu

Fujitsu General ARXG36KHTAP Service manual

Fujitsu 18RLX Reference manual

Fujitsu

Fujitsu 18RLX Reference manual

Fujitsu Halcyon HFI Systems User manual

Fujitsu

Fujitsu Halcyon HFI Systems User manual

Fujitsu ADUH09LUAS1 Service manual

Fujitsu

Fujitsu ADUH09LUAS1 Service manual

Fujitsu Halcyon User manual

Fujitsu

Fujitsu Halcyon User manual

Popular Air Conditioner manuals by other brands

American Standard 4A6V8024A1000B Service facts

American Standard

American Standard 4A6V8024A1000B Service facts

Sanyo KS2432 instruction manual

Sanyo

Sanyo KS2432 instruction manual

Mitsubishi Electric PUHZ-RP50VHA4 Service manual

Mitsubishi Electric

Mitsubishi Electric PUHZ-RP50VHA4 Service manual

Daikin FFQ09Q2VJU Operation manual

Daikin

Daikin FFQ09Q2VJU Operation manual

Olimpia splendid maeStro Pro Instructions for installation, use and maintenance

Olimpia splendid

Olimpia splendid maeStro Pro Instructions for installation, use and maintenance

Frigidaire FAZ12ES2A installation instructions

Frigidaire

Frigidaire FAZ12ES2A installation instructions

Carrier 42HVM109303 Service manual

Carrier

Carrier 42HVM109303 Service manual

GOETTL GH UNITS User's information manual

GOETTL

GOETTL GH UNITS User's information manual

Panasonic CU-2S18NBU-1 Service manual

Panasonic

Panasonic CU-2S18NBU-1 Service manual

Airwell Electra JMF Hi wall Series Service manual

Airwell

Airwell Electra JMF Hi wall Series Service manual

Dometic FreshWell3000 installation manual

Dometic

Dometic FreshWell3000 installation manual

York DJ 300 Technical guide

York

York DJ 300 Technical guide

ACS Marvair 8AA1024A-8AA1060A product manual

ACS

ACS Marvair 8AA1024A-8AA1060A product manual

GE AGE07 Owner's manual and installation instructions

GE

GE AGE07 Owner's manual and installation instructions

Thermal CS011126 User's & technical manual

Thermal

Thermal CS011126 User's & technical manual

Beko BEP 09C user manual

Beko

Beko BEP 09C user manual

Dometic BRISK AIR 579 SERIES installation instructions

Dometic

Dometic BRISK AIR 579 SERIES installation instructions

Whirlpool BHAC1000XS0 Use & care guide

Whirlpool

Whirlpool BHAC1000XS0 Use & care guide

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
