DESKPOWER C600 Series User’s Manual
Fujitsu endeavours to ensure that the information in this document is correct, but accepts no liability
for any error or omission in the same. Any procedures described in this document for operating Fujitsu
products should be read and understood by the operator before such products are used. To ensure
that Fujitsu products function without risk to safety and health, such procedures should be strictly
observed by the operator. The development of Fujitsu products and services is continuous and
published information may not be up to date. Any particular issue of a product may contain facilities
not described herein. It is important to check the current position with Fujitsu. Specifications and
statements as to performance in this document are Fujitsu estimates intended for general guidance.
They may require adjustment in particular circumstances and should therefore not be taken as formal
offers or commitments.
DESKPOWER is a trademark of Fujitsu Limited. The following are registered trademarks of Microsoft
Corporation: MS, MS-DOS, Windows ®NT, Windows ®98, Windows Millennium, Window ®2000 and
Windows XP.
Intel and Pentium are registered trademarks of Intel Corporation in the U.S.
Celeron is a registered trademark of Intel Corporation in the U.S.
Other product names are trademarks or registered trademarks of respective companies.
Other products are copyrighted by individual companies.
All Rights Reserved, Copyright ©Fujitsu PC Asia Pacific 2002
We have been authorized by Microsoft Corporation in the U.S. to use Windows screenshots in this
manual.
DECLARATION OF CONFORMITY
according to FCC Part 15 Class B
This device complies with Part 15 Class B of the FCC Rules. Operations are subject to the following
two conditions:
(1) This device may not be allowed to cause harmful interference, (2) This device must accept any
interference received, including interference that may cause undesired operation.
Wesbite: www.fujitsu-pc-asia.com
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:07 AM1

ii
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions carefully. Save these instructions for future reference.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water.
5. Do notplacethisproductonan unstable cart, stand,or table. The productmay fall, causing serious
damage to the product.
6. Slots and openings in the cabinet and the back or bottom are provided for ventilation; to ensure
reliable operation of the product and to protect it from overheating, these openings must not be
blocked or covered. The openings should never be blocked by placing the product on a bed, sofa,
rug, or other similar surface. This product should never be placed near or over a radiator or heat
register, or in a built-in installation unless proper ventilation is provided.
7. This product should be operated from the type of power indicated on the marking label. If you are
not sure of the type of power available, consult your dealer or local power company.
8. This product is equipped with a 3-wire grounding-type plug, a plug having a third (grounding) pin.
This will only plug into a grounding-type power outlet. This is a safety feature. If you are unable to
insertthe plug into the outlet,contact your electrician to replaceyour obsolete outlet. Do notdefeat
the purpose of the grounding-type plug.
9. Do not allow anything to rest on the power cord. Do not locate this product where persons will
walk on the cord.
10. If an extension cord is used with this product, make sure that the total ampere rating of the
equipment plugged into the extension cord does not exceed the extension cord ampere rating.
Also, make sure that the total rating of all products plugged into the wall outlet does not exceed
15 amperes.
11. Never push objectsof any kindinto this productthrough cabinet slots asthey may touchdangerous
voltagepoints that could result ina fire orelectric shock. Neverspill liquidof any kindon the product.
12. Do not attempt to service this product yourself, as opening or removing covers may expose you
to dangerous voltage points or other risks. Refer all servicing to qualified service personnel.
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:07 AM2

iii
13. Unplug this product from the wall outlet and refer servicing to qualified service personnel under
the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or water.
d. If the product does not operate normally when the operating instructions are followed. Adjust
only those controls that are covered by the operating instructions since improper adjustment
of other controls may result in damage and will often require extensive work by a qualified
technician to restore the product to normal condition.
e. If the product has been dropped or the cabinet has been damaged.
f. If the product exhibits a distinct change in performance, indicating a need for service.
14. CAUTION. When replacing the battery, be sure to install it with the polarities in the correct
position. There is a danger of explosion if the battery is replaced with an incorrect type or
is mistreated. Do not recharge, disassemble or dispose of in fire. Replace only with the
same or equivalent type recommeded by the manufacturer. Dispose of the used battery
according to the manufacturer’s instructions.
15. Use only the proper type of power supply cord set (provided in your accessories box) for this unit.
It should be a detachable type: UL listed/CSA certified, BS1363,ASTA,SS145 certified, rated 10A
250V minimum, VDE approved or its equivalent. Maximum length is 15 feet (4.6 meters).
16. NOTE:
Pleasetake extra precautionwhen connecting the LAN cable; do notconnect the LANcable
to the peripheral device’s connector, that might have excessive voltage.
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:08 AM3

iv
Before reading this manual
This section describes safety precautions and convention used in this manual. Be sure to read this.
For Safe Operation
This manual contains important information for using the DESKPOWER personal computer.
Readthis manualthoroughly before usingyour PC.In particular,“Safety Precautions” inthis manual
must be read and understood.
This manual including “Safety Precautions” must be readily available at all times.
This equipment is compliant with the PC industry standard (PC-11-1988) of the Japan Electronics
and Information Technology Industries Association.
Note
This product is a Class B Information Technology Equipment and conforms to the standard set by
the Voluntary Control Council for Interference by Technology Equipment (VCCI).This product is
designed to be used in a domestic environment, however, it may cause radio interference when
used in the vicinity of a radio or television receiver.
Make sure that you read the manual when using this product.
Fujitsu, as a member of the International Energy Star Program, recognizes that
this equipment is compliant with the standard of the International Energy Star
Program.
The International Energy Star Program is a worldwide program for promoting
energy saving for computers and other office equipment. The program aims at
promoting the development and use of products equipped with the functions that can effectively
reduce energy consumption and uses a voluntary system that allows enterprises to join at their
own discretion. The target products are office equipment including computers, displays, printers,
facsimiles, and copying machines. The standards for individual types of equipment and the mark
( ) prepared by the Program are used commonly among member countries.
Caution
Thisequipment is class B informationtechnology equipment basedon thestandard of theVoluntary
Control Council for Interference by Information Technology Equipment (VCCI). Although the
equipment is intended for use in residential environments, it may create interference if placed near
radio or television.
Handle the equipment in accordance with the manual.
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:08 AM4

v
Using this Product for High-Safety Applications
Thisproduct is for office,personal, home, ordinaryindustry and other generaluse. It isnot designed
and manufactured for use in high-safety applications.
Do not use this product for such applications without taking measures to satisfy the high-safety
requirements.
High-safety applications require extremely high level of safety, and involve serious hazards to life
and health if the required safety is not assured. High-safety applications include the following.
●Nuclear reaction control in nuclear facilities, automatic aviation control, air traffic control, mass-
transportation control, life-supporting medical equipment, and missile launch control.
Some parts (including the CRT display, LCD, or hard disk drive) used on this product have a limited
life. When used continuously for a prolonged period, these parts will need earlier replacement.
Backing Up the Data
Thecustomer is responsiblefor maintaining theintegrity of data(including the basic andapplication
software)stored orinstalled on theproduct. Wedo not warrantthe integrityof data storedor installed
onthe personal computer thecustomer sent for repair. Take appropriate measuressuch as making
a backup.
We assume no responsibility for loss of data and any direct or incidental damage due to any cause
other than those specified in the warranty.
This computer is designed for use within the country. If you are using it abroad, please do so on
your own responsibility.
This equipment may be adversely affected by the momentary drop of the supplied voltage due to
lightning. Use of an AC uninterruptible power supply is recommended for measures against the
momentary drop of the supplied voltage.
(This message is based on the Japan Electronics and Information Technology Industries
Association’s guidelines for measures against momentary voltage drop in PCs.)
Since this equipment contains special materials controlled by the Foreign Exchange and Foreign
Trade Control Law. Authorization under the law may be required to export this equipment.
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:08 AM5

vi
Microsoft Service Pack
Microsoft Corp. offers Service Pack to provide the users of Microsoft®Windows®with more stable
system operation (http://www.microsoft.com/).
Thelatest version of the ServicePack helps you configure the most stable system usingMicrosoft®
Windows®provided at that time by Microsoft Corp.
We recommend you to use the latest version.
In some environments, however, the Service Pack may cause unexpected failure. Read
Readme.txt for the Service Pack before use.
Again, we recommend you to make a system backup in case of failed installation.
Components of this product (motherboard, CD-ROM, hard disk, and floppy disk drive) contain
traces of heavy metals (lead and chrome) and chemical (antimony).
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:08 AM6

vii
Conventions Used in This Manual
Warning messages
Thismanual uses varioussigns. These signsurge the userto use theequipment safely soas to prevent
personal injury and/or property damage. The following are alert signals and explanations. The signs
should be understood before proceeding to subsequent portions of this manual.
This indicates a hazardous situation that could result in death or severe
injury if the user does not perform the procedure correctly.
This indicates a hazardous situation that could result in personal injury or
property damage if the user does not perform the procedure correctly.
Inaddition tothe abovesigns, thefollowing symbols areused toprovide detailedinformation concerning
personal injury and/or property damage:
The symbol marked with [ ] indicates a warning or caution item. An
explanation of an alert is presented in or beside the symbol.
The symbol marked with [ ] indicates what must not be done (prohibited
action). The meaning of a direction is presented in or beside the symbol.
The symbol marked with [●] indicates what must be observed. The meaning
of a direction is presented in or beside the symbol.
Symbols used in the text
Symbol Meaning
Thestatement providedwith this symbolexplains cautionson useor what
must not be done. Be sure to read this first!
The statement provided with this symbol explains what is required to
operate hardware or software correctly. Be sure to read this first!
This symbol indicates the page or manual to refer to.
Representation of keys and their operation method
Key names used in this manual are not exactly represented with the characters appearing on the
keyboard but are represented with characters needed for explanation as follows:
Example: [Ctrl] key, [Enter] key, [→] key...
Two or more keys that must be pressed simultaneously are represented by combining them with a
“+” sign as follows:
Example: [Ctrl] + [F3] keys, [Shift] + [↑] keys...
WARNING
CAUTION
Point
Important
→
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:09 AM7

viii
Command entry (keying in)
In this manual, a command entry is represented as follows:
diskcopy a: a:
↑↑
• Where character spacing is provided as shown by [↑], press the [Space] key once.
Commands, an example of which is given above in lowercase, can also be entered in uppercase.
• [CD-ROM drive] indicates the name of the CD-ROM drive being used. Enter the drive name in
accordance with your PC environment.
[CD-ROM drive]:\setup.exe
Screenshot example and illustrations
The screenshots and illustrations given in this manual are examples. The screenshots and file names
may be different from those actually shown on your PC and the illustrations may be different from the
actual appearance. For the explanatory purpose, illustration used in this manual may omit cables
connected on the actual PC.
Representation of continuous operation
Continuous operation steps are represented in this manual by combining them with a “•••• ” sign as
shown below:
Example: Sequential operation of clicking the [Start] button, pointing [Program], then clicking
[Accessories]
↓
Click the [Start] button →[Program] →[Accessories].
Representation for BIOS Setup
When the BIOS Setup procedure is explained in this manual, a menu, submenu, and item may be
represented by combining them with a hyphen as shown below:
Example: Set the [Serial Port 1] in [Advanced] to [Disable].
↓
[Advanced] - [Serial Port 1]: Disable
Floppy disk and CD-ROM drives
Usersof amodel withouta floppyor CD-ROM drive should usea separatelyavailable drivefor operation
with a necessary drive.
For operation of peripheral devices, refer to the relevant manuals.
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:10 AM8

ix
Reference to products
In this manual, the product names are referred to as follows:
This manual includes information on other operating systems.
Product name Description used in the manual
Microsoft®Windows®XP Professional
Microsoft®Windows®XP Home Edition
Microsoft®Windows®2000 Professional Windows*
Windows
XP
Windows XP
Professional
Windows XP
Home Edition
Windows 2000
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:10 AM9

x
Recycling
Disposal of the PC unit
Disposalof the PC unit(including accessories except the LCD unit) iscontrolled by the WasteDisposal
and Public Cleaning Law.
●To institutional and corporate customers
Personal computers must be disposed of as industrial waste. Institutional and corporate customers
are obliged to entrust an authorized industrial-waste disposer.
●To individual customers
Personal computers should be disposed of as general waste. Individual customers are advised to
follow the disposal rules and regulations set forth by the local municipality.
Disposal of the LCD unit
The fluorescent tubes in the LCD contain mercury.
Disposal of the LCD unit is controlled by the Waste Disposal and Public Cleaning Law.
●To institutional and corporate customers
LCDunits must bedisposed of asindustrial waste. Institutional andcorporate customers areobliged
to entrust an authorized industrial-waste disposer.
●To individual customers
LCD units should be disposed of as general waste. Individual customers are advised to follow the
disposal rules and regulations set forth by the local municipality.
Disposal of batteries
The wireless keyboard and mouse use dry batteries. These batteries may explode when plunged
into the flames.
Disposal of the batteries is controlled by the Waste Disposal and Public Cleaning Law.
●To institutional and corporate customers
Dry batteries must be disposed of as industrial waste. Institutional and corporate customers are
advised to entrust an authorized industrial-waste disposer.
●To individual customers
Dry batteries should be disposed of as general waste. Individual customers are advised to follow
the disposal rules and regulations set forth by the local municipality.
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:10 AM10

xi
Warning and caution labels
Your PC bears the warning and caution labels as shown below.
The warning and caution labels must not be removed or damaged.
Rear of the PC main unit
ATTENTION
115V of voltage switch in the power supply corresponds to 100-127V
230V of voltage switch in the power supply corresponds to 200-240V
WARNING
• Before mounting or dismounting an optional unit in/from your PC, switch off
the PC and all connected units and unplug all power cords from respective
outlets to prevent electric shock.
Electric shock
WARNING
When removing exterior parts in
order to mount option parts or
others inside the cabinet, switch
off the power supply for PC unit
and peripheral devices linked
with it, and disconnect the power
cable from outlet before working
to avoid risk of electric shock.
MODEL
DTN1
DESKPOWER C600
MADE IN SINGAPORE
50/60Hz100-127V(6.5A) (3.0A)
200-240V
Fujitsu Limited.Japan
(M)
By
FUJITSU LIMITED
Electric shock
WARNING
To prevent electric
shock and/or fire, do
not remove the cover
of this unit, which
includes a high
voltage section.
Inside the PC main unit
CHAPTER 0 Tokyo (INTRO) 10/22/02, 4:20 PM11

xii
Before Reading This Manual
This section contains cautions for safe operation, representations and symbols used in this manual.
Be sure to read this first!
Chapter 1Part Names
This chapter provides the names and functions of individual parts.
Chapter 2Installation and Connection
Thissection describes the location of installation and installation of the computer.
Chapter 3Security
Thischapter introduces thesecurity functions available onthe PC unit.To prevent
an illegal use and information leakage to another person, take security measures
in routine use.
Chapter 4Hardware
This chapter provides the basic information on the PC and operation.
Chapter 5System Expansion
Thischapter provides basicinformation on howto handle the peripheralsinstalled
(or can be installed) on the PC.
Chapter 6Technical Information
This chapter describes the specifications of this PC.
Organization of This Manual
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:11 AM12

xiii
Contents
CHAPTER 1 Part Names
1 Part Names and Functions ..............................................................2
Front of the PC Unit.......................................................................................... 2
Rear of the PC Unit .......................................................................................... 4
Inside the PC Unit ............................................................................................ 6
Motherboard ..................................................................................................... 7
CHAPTER 2 Installation and Connection
1 Installation .......................................................................................10
Location of Installation ................................................................................... 10
Mounting Feet ................................................................................................ 10
Example of Installation ................................................................................... 12
2 Connection ......................................................................................14
Connecting the Display/Keyboard/Mouse ...................................................... 15
Connect the Power Cord ................................................................................ 17
3 Power On .........................................................................................19
How to Power On ........................................................................................... 20
4 Setting Up ........................................................................................21
Setting Up Windows XP ................................................................................. 22
Setting Up Windows 2000 .............................................................................. 23
Problem During Setup? .................................................................................. 26
5 Turn Off the Computer....................................................................27
How to Turn Off .............................................................................................. 27
CHAPTER 3 Security
1 Securities.........................................................................................30
2 Security during Network Connection ...........................................31
Computer virus ............................................................................................... 31
Encrypting the communication data ............................................................... 31
Firewall ........................................................................................................... 31
3 Security Against Illegal Use...........................................................32
Passwords for Windows OS ........................................................................... 32
Administrator Authority and User Accounts ................................................... 32
Access Authority and Encrypting ................................................................... 32
Password for the BIOS ................................................................................... 33
4 Burglary Prevention of The PC ......................................................34
CHAPTER 0 Tokyo (INTRO) 3/25/05, 7:11 AM13

xiv
CHAPTER 4 Hardware
1 Mouse ..............................................................................................36
Using the mouse ............................................................................................ 36
2 Keyboard .........................................................................................38
3 CDs...................................................................................................40
Inserting or Removing a CD ........................................................................... 41
4 Floppy Disks ...................................................................................43
Inserting or Removing a Floppy Disk ............................................................. 43
5 Hard Disk .........................................................................................45
6 Maintenance of the Hardware ........................................................46
Maintenance of the PC Unit ........................................................................... 46
Maintenance of the Mouse ............................................................................. 46
Maintenance of the Keyboard ........................................................................ 47
Cleaning CDs ................................................................................................. 47
Cleaning the Floppy Disk Drive ...................................................................... 47
CHAPTER 5 System Expansion
1 Before Installing a Peripheral Device ............................................50
2 Removing the Cover .......................................................................52
Removing the Cover ....................................................................................... 52
3 Installing Memory Modules............................................................53
Location of Memory Modules ......................................................................... 54
Applicable Memory Modules .......................................................................... 54
Installing Memory Modules ............................................................................ 55
4 Installing an Expansion Card ........................................................59
Location of expansion Cards......................................................................... 60
Applicable Expansion Cards .......................................................................... 60
Installing an Expansion Card ......................................................................... 60
CHAPTER 6 Technical Information
1 List of Specifications......................................................................64
PC Specifications ........................................................................................... 64
LAN function ................................................................................................... 66
2 Connector Specifications ..............................................................67
CHAPTER 0 Tokyo (INTRO) 10/22/02, 2:23 PM14

CHAPTER 1
Part Names
CHAPTER 1 Tokyo (01-08) 3/25/05, 7:18 AM1

2
1 Part Names and Functions
This section explains the names and functions of the parts of the PC unit and the
motherboard.
Point
The remaining part of this manual assumes vertical placement.When you place the PC unit
horizontally, be careful about geometrical difference.
■Front of the PC Unit
1 Power button
Press this button to turn on the PC or set the system to the standby (energy-saving) mode.
2 Power lamp
This lamp lights up when the PC is on.
It lights in green when the PC is in operation and in orange when the PC is in the standby mode.
1
2
3
4
5
6
7
8
9
10
11
12
CHAPTER 1 Tokyo (01-08) 10/22/02, 4:22 PM2

3
3 Disk access lamp
This lamp lights up while the hard disk is accessed.
4 USB connector
Slide the cover down and connect a USB peripheral device.
5 Foot
Used for placing the PC.
This also prevents the PC in a vertical placement from tipping over.
6 Smart Card bay
Use this bay to install a Smart Card reader/writer.
7 CD access lamp (on models with a CD-ROM drive)
This lamp lights up while data is read from the CD-ROM drive or a music CD is played.
8 CD eject button
Press this button to insert or remove a CD-ROM or music CD. This button can be used when the
PC is on. Do not press this button when the CD access lamp is on.
9 CD-ROM drive (on models with a CD-ROM drive)
Insert a CD-ROM into this drive to read data or programs, or insert a music CD for playback.
10 Floppy disk eject button
Press this button to remove a floppy disk from the floppy disk drive.
Do not press this button when the floppy disk access lamp is on.
11 Floppy disk drive
This drive accommodates a floppy disk for writing and reading data.
12 Floppy disk access lamp
This lamp lights up while the floppy disk drive is accessed.
CHAPTER 1 Tokyo (01-08) 10/22/02, 4:22 PM3

4
■Rear of the PC Unit
1 Burglarproof lock
Connect a commercial burglarproof cable here.
Point
The burglarproof lock supports the Microsaver security system of Kensington.
2 Expansion card slots
Insert an optional expansion card into this slot.
This slot accommodates a PCI card.
3 USB fixing slit
Fix a USB connector cable here.
Put the supplied nylon band through the USB fixing slit to tie the cable.
4 Inlet
Connect the power cable of the PC unit to this connector.
5 Mouse connector
Connect a mouse.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
CHAPTER 1 Tokyo (01-08) 3/25/05, 7:19 AM4

5
6 Keyboard connector
Connect the keyboard.
7 Serial connector
Connect the cable of an RS-232C device.
8 Parallel connector
Connect the cable of a printer or scanner.
9 CRT connector
Connect the cable of an analog RGB display.
10 LAN connector
Connect the LAN cable.
If the customer has selected the security LAN card of the custom-made option, the LAN connector
is closed on the PC rear panel. Do not use the occupied USB connector.
11 USB connector
Connect a USB device.
12 Line OUT terminal
A terminal for sound output. Connect the input terminal of an audio equipment to this terminal.
Use speakers having a built-in amp when connecting them directly.
13 Line IN terminal
A terminal for sound input. Connect the output terminal of an audio equipment to this terminal.
14 Microphone jack
Plug a capacitor microphone to this jack.
15 Speaker terminal
Plug a commercial speaker to this jack.
16 Outlet
Connect the power cable of the display to this outlet.
CHAPTER 1 Tokyo (01-08) 3/25/05, 7:19 AM5

6
■Inside the PC Unit
1 Internal hard disk drive
This is an IDE-compliant hard disk drive.
2 Expansion card slots
Insert optional expansion cards into these slot.
These slots accommodate PCI cards.
A SCSI card allows you to use an external hard disk drive or magneto-optical disk drive.
3 Power supply
CHAPTER 1 Tokyo (01-08) 3/25/05, 7:20 AM6
