DATASHEET FUJITSU LIFEBOOK AH550 NOTEBOOK
Page 1 / 6 http://ts.fujitsu.com/mobile
DATASHEET
FUJITSU LIFEBOOK AH550 NOTEBOOK
THE STYLISH ALL-ROUNDER
LIFEBOOK AH550
The LIFEBOOK AH550 notebook is the stylish all-rounder with a high denition 39.6 cm (15.6-inch)
glossy LCD in 16:9 widescreen format. With the optionally integrated Blu-ray Disc™ drive you can also
enjoy media on the big screen of your TV set via HDMI. Integrated WLAN and optional Bluetooth® and 3G/
UMTS provide you with highest connectivity. Feel special thanks to the high-gloss black nish and brilliant
chrome parts.
HIGH PERFORMANCE
Experience the smart family of Intel® Core™ processors that deliver performance that adapts to your
needs, making laptops faster and more responsive.
New Intel® Core™ processors and latest Intel® mobile platform
APPEALING DESIGN
High-gloss black nish and brilliant chrome parts give the notebook a distinctive character.
High-gloss black covers and brilliant chrome highlights 
MULTIMEDIA AND ENTERTAINMENT
Enjoy high-denition home entertainment - with razer sharp picture quality, 16:9 format to watch DVDs in
their native resolution and optionally an integrated Blu-ray Disc™ drive.
BrilliantView display technology, 16:9 widescreen format, HDMI interface, optional Blu-ray Disc™ drive
HIGH CONNECTIVITY
Anytime, anywhere with highest connectivity for work and private.
Integrated WLAN and optional integrated Bluetooth® and 3G/UMTS, 1.3 megapixel webcam, integrated
digital microphone
HIGH RELIABLILITY AND SECURITY
Protect your most valuable data like pictures, videos and more.
Spill-resistant keyboard, Computrace® enabled BIOS, Advanced Theft Protection (ATP), kensington lock

DATASHEET FUJITSU LIFEBOOK AH550 NOTEBOOK
Page 2 / 6 http://ts.fujitsu.com/mobile
COMPONENTS
PROCESSOR Intel® Core™ i7 processor i7-620M (2.66 GHz, 4 MB)
Intel® Core™ i5 processor i5-540M (2.53 GHz, 3 MB)
Intel® Core™ i5 processor i5-520M (2.4 GHz, 3 MB)
Intel® Core™ i5 processor i5-430M (2.26 GHz, 3 MB) *
Intel® Core™ i3 processor i3-350M (2.26 GHz, 3 MB) *
Intel® Core™ i3 processor i3-330M (2.13 GHz, 3 MB) *
Intel®Celeron® processor P4500 (1.86 GHz, 2 MB)
PROCESSOR NOTES *Processor only for retail, SMB, education and government
MEMORY MODULES 1 GB (1 module(s) 1 GB) DDR3, 1066 MHz, PC3-8500, DIMM
2 GB ( module(s) 2 GB) DDR3, 1066 MHz, PC3-8500, DIMM
4 GB ( module(s) 4 GB) DDR3, 1066 MHz, PC3-8500, DIMM
Supported capacity RAM (max.) 8 GB
Memory slots total 2
Memory slot type SO DIMM (DDR3, 1066 MHz)
HARD DISK DRIVES (INTERNAL) SATA, 5400 rpm, 500 GB, 2.5-inch
SATA, 5400 rpm, 320 GB, 2.5-inch
SATA, 5400 rpm, 250 GB, 2.5-inch
Hard disk notes Accessible capacity may vary, also depending on used software
One Gigabyte equals one billion bytes, when referring to hard disk drive capacity.
WLAN (OPTIONAL) WLAN Atheros 802.11b\g\n 1x1 (WW)
WLAN Atheros 802.11b\g\n 2x2 (WW)
WIRELESS TECHNOLOGIES
Bluetooth V2.1 (optional)
WLAN notes Hardware on/off switch for WLAN is available.#Import and usage according to country-specic regulations.
UMTS notes Optional integrated Gobi 2000 (HSDPA/HSUPA downlink 7.2 MBit/s, uplink 5.76 MBit/s)
3G/UMTS (OPTIONAL) (downlink 7.2 Mbit/s, uplink 5.76 Mbit/s)
DISPLAY 39.6 cm (15.6-inch), TFT, (HD), LED backlight, glossy, 1366 x 768 pixel
BLUETOOTH (OPTIONAL) Bluetooth 2.1
OPTICAL DRIVE OPTIONS Blu-ray Disc™ Combo Drive
Blu-ray Disc™ Triple Writer
DVD Super Multi
Base unit LIFEBOOK AH550
GENERAL SYSTEM INFORMATION
Chipset Intel® HM55
BIOS features BIOS based on Phoenix SecureCore
DISPLAY
Display 39.6 cm (15.6-inch), TFT, (HD), LED backlight, glossy, 1366 x 768 pixel
Aspect ratio 16:9
GRAPHICS
Max. resolution external display 1920 x 1200 pixel
Graphics brand name Intel® HD Graphics
Graphics features DirectX® 10 support
Shared video memory up to 1695 MB

DATASHEET FUJITSU LIFEBOOK AH550 NOTEBOOK
Page 3 / 6 http://ts.fujitsu.com/mobile
INTERFACES
Memory card slots 1 x 4in1 Card Reader (SD /SDHC / MS / MS Pro)
ExpressCard slots 1 (34/54 mm)
eSATA 1
USB 2.0 total 4
FireWire (IEEE1394) 1
VGA 1
HDMI 1
Ethernet (RJ-45) 1
DC-in 1
Audio: line-in / microphone 1
Audio: line-out / headphone 1
Internal microphones 1 (digital)
Kensington Lock support 1
WIRED COMMUNICATION
LAN 10/100/1000 MBit/s Broadcom BCM57780
KEYBOARD AND POINTING DEVICES
Spill-resistant keyboard with number block
Number of keyboard keys: 103, Keyboard pitch: 18,4 mm, Keyboard stroke: 3 mm
Touchpad
Status LED
MULTIMEDIA
Audio type On board
Audio codec Realtek ALC269
Audio features Support of high-denition audio, 2x built-in speakers (stereo), Built-in digital microphone, Sound volume control via function
key (down: Fn+F8; up: Fn+F9)
Camera Built-in webcam, 1.3 megapixel
POWER SUPPLY
AC adapter 19 V / 80 W (4.22 A)
Rated voltage range 100 - 240 V (AC Input)
Rated frequency range 50 - 60 Hz
1st battery Li-Ion battery 6-cell, 4000 mAh, 43 Wh
Li-Ion battery 8-cell, 5200 mAh, 75 Wh
Runtime 1st battery Up to 3:30 h / 5:30 h
Battery notes Battery life may vary depending on product model, conguration, applications, power management settings and features
utilized. Battery recharge time depends on usage.
DIMENSIONS / WEIGHT / ENVIRONMENTAL
Dimensions (W x D x H) 372 x 262 x 41-44 mm
Weight Approx. 2.75 kg
Weight notes Weight may vary depending on actual conguration (including battery pack)
Operating relative humidity 20 - 85 %
OPERATING SYSTEM
Operating system optional preinstalled Microsoft® Windows® 7 Professional
Microsoft® Windows® 7 Home Premium
Microsoft® Windows® 7 Home Basic
Microsoft® Windows® 7 Starter (EM) 32-bit
Operating system compatible Microsoft® Windows® XP Professional
Operating system notes All Windows® 7 versions are Ofce 2007 ready.
Driver support for Microsoft® Windows® XP

DATASHEET FUJITSU LIFEBOOK AH550 NOTEBOOK
Page 4 / 6 http://ts.fujitsu.com/mobile
ADDITIONAL SOFTWARE
Additional software (preinstalled) Adobe Acrobat Reader
CyberLink YouCam
EasyGuide online user documentation
Nero Essentials S (burning software)
Norton Internet Security (incl. Firewall) 90 days version
Additional software (included as a CD/
DVD)
Drivers & Utilities DVD (DUDVD)
SECURITY
Physical security Kensington Lock support
System security Computrace®enabled BIOS
User security Smart HDD
COMPLIANCE
Europe CE Marking
R&TTE (WLAN, Bluetooth®)
Global ENERGY STAR® 5.0
RoHS (Restriction of hazardous substances)
WiFi certied
EPEAT® Silver
Russia GOST
Compliance link https://sp.ts.fujitsu.com/sites/certicates/default.aspx
WARRANTY
Standard Warranty 1 year / 2 years (depending on country)
Service level Collect & Return Service / Bring-in Service (depending on county specic requirements) (depending on country)
MAINTENANCE AND SUPPORT SERVICES - THE PERFECT EXTENSION
Recommended Service 3 years, Collect & Return Service
Spare Parts availability 3 years
Service Weblink http://ts.fujitsu.com/Supportservice
RECOMMENDED ACCESSORIES
Laser Mouse CL3500 The Laser Mouse CL3500 with USB connection is equipped with all the
essential features a user values in home and business applications.
The laser sensor ensures the highest accuracy. Tilt-Wheel-Technology means
high comfort for navigation in documents: up / down, left / right. Two resolution
switch buttons allow you to adjuse the resolution in four levels individually
for different user applications. Besides the technical features, this mouse
convinces with its elegant, trendy design in glossy piano black which is a
pleasure to touch and work with. The ergonomic shape ts both left- and
right-handed users. The advantage of the midi-size is obvious: the Laser
Mouse CL3500 is perfect for long-time usage at the desk and also as a travel
companion when on the road.
Order Code:
S26381-K423-L100

DATASHEET FUJITSU LIFEBOOK AH550 NOTEBOOK
Page 5 / 6 http://ts.fujitsu.com/mobile
HS7100U Dolby Headphone Our outstanding Dolby Headphone HS7100U equipped with the latest Dolby
decoding & Virtual 7.1 Channel Surround Technology, enables all the gamers to
detect the enemy’s moves and dodge the bullets from all directions!
Order Code:
S26391-F7139-L1
Slim Mobile Express DVB-T Receiving digital TV wherever you want: with the new Slim Mobile Express
DVB-T. Once you plug in this unique “Plug & Forget” ExpressCard 34 mm
tuner; then, you need not to remove it from the slot again! You could also travel
up to 140 km/h without any comprise of TV signal quality.
Order Code:
S26391-F7125-L2
Air Command Plus Can’t get away from the game playing with the latest LIFEBOOK notebook or
CELSIUS Gaming Working Station? Air Command Plus is the best companion
for PC and notebook, optimized for all the sports games. The best has yet to
come: Air Command Plus also supports the latest games on the market.
Order Code:
S26391-F7111-L200
SOUNDSYSTEM DS P2100 Tube The new stylish and elegant SOUNDSYSTEM DS P2100 Tube has been added
to our multimedia portfolio. Taking inspiration from a hi- sound bar, the P2100
Tube presents you with living room design art pieces for acoustic enjoyment.
The small & robust satellite speaker is decorated with a deluxe piano nish and
the aluminum tube is adorned with a ne print of an exotic motif at its base - a
nal touch to complete this fantastic artwork.
Order Code:
S26391-F7128-L500
Backpack A16 Lightweight design; padded notebook section; adjustable and padded shoulder
straps;zipper pocket on the front with lots of accessory compartments inside;
mesh compartments; grip handle.
Order Code:
S26391-F119-L165

DATASHEET FUJITSU LIFEBOOK AH550 NOTEBOOK
Page 6 / 6 http://ts.fujitsu.com/mobile
