Cleaning Instructions for
ScanSnap S510/S510M
It is recommended that these items be
cleaned EVERY 1,000 SCANS
Using F1 Impregnated Cleaning Wipes

Pad Assy
Wipe downwards. When cleaning take care to prevent the cleaning wipe from catching on the
metal parts


Turn the Scanner OFF while cleaning the following locations
ADF Glass Surfaces x 2
Located on the ADF cover and opposite side. Clean lightly.
Pick Roller
Clean lightly taking care not to scratch the surface.
P.T.O.

Plastic Rollers x 4
Clean lightly while rotating with your finger. Take care not to roughen the surface.




Plastic Rollers
Eject Rollers
Feed Rollers
Glass
Pick Roller


Pad Assy
BEFORE CLEANING
Open the ADF while pressing the cover open button
ADF Cover
Cover Open
Lever
Paper Chute
Cover
Consumables Part Number
Consumable Kit CON-3360-001A
Cleaning Kit SC-CLE-WGD


Plastic Rollers x 4
Clean lightly while rotating with your finger. Take care not to roughen the surface.
For further information please refer to the
ScanSnap S510/S510M Operators Guide
which can be found on our Website:
http://www.fujitsu.com/emea/products/
January 2010
Using F1 Impregnated Cleaning Wipes
Eject Rollers x 2
Clean lightly taking care not to roughen the surface.

Turn the Scanner ON while cleaning the following locations
PFU Imaging Solutions Europe Ltd Cleaning Instructions for ScanSnap S510/S510M





Plastic Rollers
Eject Rollers
Feed Rollers
Glass
Pick Roller
Pad Assy

To rotate the Feed and Eject Rollers, press the POWER button while holding down the SCAN button.
As a guideline, six presses of the POWER button makes the rollers rotate one full turn.
While holding down the SCAN button 
Press the POWER button 
Each press of the POWER button will
cause the rollers to rotate
