Fujitsu FTP-624CU102 User manual

FTP-624MCL001/002/FTP-624DCL/DSL
■OVERVIEW
FTP-624MCL/FTP-624DCL Series is a high speed line thermal
printer driven by battery, printing on 2-inch wide paper (58 mm/
60 mm).
This printer is compact and lightweight, and the design allows
easy head maintenance, head cleaning and head
replacement.
This printer is suitable for a variety of applications, such as
hand held terminals, POS terminals, ticket machines, coupon
machines, label printers, etc.
■HIGHLIGHTS
• High speed printing
It can print at 60 mm/s (480 dotlines/s) maximum by using
Fujitsu Components' unique head drive control.
• Compact and lightweight
This printer has a low profile of only 20 mm, and a light
weight of approximately 80 g.
• Low power consumption
The peak current for head drive is only 2.6 A (8.5 VDC, 64
dots on)
• Easy head access
It is designed for easy head cleaning and head replace-
ment.
• Paper auto loading function
Thermal paper can be loaded without head-up lever
operation.
• UL recognized
File No. E171434
BATTERY DRIVE, MICRO LINE THERMAL PRINTER
2” TYPE MECHANISM AND INTERFACE BOARD
FTP-624MCL001
FTP-624DCL/DSL002
FTP-624CU102
1

FTP-624MCL001/002/FTP-624DCL/DSL002
2
■DESIGNATION
*1: 001 is for front paper insertion (curl path) and 002 is for rear paper insertion (straight path).
*2: 002 supports ANK, 102 supports ANK and Kanji.
*3: 002 supports ANK, 103 supports ANK and Kanji.
Part number FTP-624MCL001/002
Printing method Thermal-sensitive line dot method
Dot structure 384 dots/line
Dot pitch (Horizontal) 0.125 mm (8 dots/mm)—Dot density
Dot pitch (Vertical) 0.125 mm (8 dots/mm)—Line feed pitch
Effective printing area 48 mm
Paper width (MCL001) 58 mm
Paper width (MCL002) 60 mm
Paper thickness 60 to 100 µm*1
Number of columns 48 columns/line (16 ×8 dot font)
480 dotlines/s (60 mm/s)
Conditions: 1 ply, printing on high sensitive thermal paper,
8 columns of “H” /line, double density 16 ×8 dot font,
room temperature, 8.5 VDC drive
JIS ANK : 128 International : 195
Character types ASCII : 31
24 ×12 dots, (3.0 ×1.5 mm), 32 columns
16 ×8 dots, (2.0 ×1.0 mm), 48 columns
16 ×16 dots, (4.0 ×2.0 mm), 24 columns
24 ×24 dots, (6.0 ×3.0 mm), 16 columns
Interface Centronics / RS-232C
■GENERAL SPECIFICATIONS
SpecificationsItem
Maximum printing speed
Character, dimensions (H×W), number of
characters
(Continued)
Part number
Printer mechanism FTP-624MCL001/002*1
RS-232C
LSI Micro Controller Unit FTP-624CU102
Thermal head cable FTP-624Y001
Parallel interface cable FTP-441Y201
Cables Serial interface cable FTP-624Y301
Power cables FTP-621Y401
FTP621Y601
Item
FTP-624DCL002*2
FTP-624DSL002*3
Centronics
Interface Board

3
FTP-624MCL001/002/FTP-624DCL/DSL
For head Voltage: 4.2 to 8.5 VDC (equivalent to 2 Lithium lon batteries)
Peak current: approx. 2.6 A (conditions: room temp., 7.2 VDC, 64 dots on)
For motor Voltage: 4.2 to 8.5 VDC (equivalent to 2 Lithium lon batteries)
Peak current: approx. 0.8 A (conditions: room temperature, 7.2 VDC)
For logic Voltage: 5 VDC ±5%
Current: 0.2 A maximum
Mechanism 82 (W) ×46 (D) ×20 (H) mm (excluding lever and knob diameter)
Dimensions Interface board 131 (W) ×89 (D) ×24 (H) mm
Weight (Mechanism) Approximately 80 g
Expected life Mechanism Pulse durability: 1 ×108pulse/dot (using Fujitsu Takamisawa's standard
driving method)
Wear resistance: 50 km (at 12.5% print ratio)
Operating temperature 0 to +50°C*2
Operating humidity 20 to 85% RH (no condensation)
Storage temperature –20 to +60°C (excluding paper)
Storage humidity 5 to 95% RH (no condensation)
Head temperature By thermistor (applied energy control, abnormal temperature detection)
Detection Paper out/Mark detect By photointerrupter
Head-up By microswitch
For front insertion use (58 mm width) : FTP-020PU001, FTP-020PG021
For rear insertion use (60 mm width) : FTP-020P0020, FTP-020PG106
Recommended thermal sensitive paper In Europe (58 mm width) : FTP-021P0060-45
· Oji Paper : PD150R, PD160R, PD170R
· NIPPON Paper : TF50KS-E4,TF60KS-E,TF50KS-E
· MITSUBISHI Paper Mills : P220VBB-1, AFP-235
SpecificationsItem
(Continued)
Power
supply
Environmental
conditions
*1: There may be exceptions.
*2: Guarantee +5°C to +40°C.

FTP-624MCL001/002/FTP-624DCL/DSL002
4
■DIMENSIONS
Printer mechanism
Unit: mm
20.1
(150) (7.5)
45.5 1.5
41.7 47.8
±1
(89.5)
HEAD CONNECTOR
2-MOUNTING HOLE(M2)
CENTER OF PAPER
HEAD UP LEVER (AT HEAD DOWN)
PAPER INSERTION
(MCLOO1)
PAPER INSERTION
(MCLOO2)

5
FTP-624MCL001/002/FTP-624DCL/DSL
Interface board
Unit: mm
* CN9 on FTP-624DSL only
**CN6, CN7, CN11, CN12 not used
88.9 78.7
39.4
39.4
5.1
15.2
5.1 5.1
5.1 5.1
5.1
5.1
5.1
120.7
105.4
120.7
105.4
130.8
73.7
CN1
CN11**
CN5
CN3
CN8
CN4
26.7
CN6**
CN7**
52.1
CN2
86.4
59.7
CN12**
CN10
71.1
33.0
CN9*
Mounting Height
Mounting Height
17.0
5.0
1.6
4-ø3.6
114.2

FTP-624MCL001/002/FTP-624DCL/DSL002
6
■CONNECTOR PIN ASSIGNMENT FOR PRINTER MECHANISM
1. Thermal Head
Head side : B16B-PH-K-S-2.2 (J.S.T.) or equivalent
Board side : PHR-16 (J.S.T.) or equivalent
2. Motor connectors
Motor side : PHR-4 (J.S.T.) or equivalent
Board side : B4B-PH-K-S (J.S.T.) or equivalent
*1: Symbol: " " means a negative logic signal
1, 2, 3, ......................................15, 16
Motor Thermal head heat sink Head up level
Connector Pin No.
3. Sensor connectors
Sensor : PHR-5 (J.S.T.) or equivalent
Board side : B5B-PH-K-S (J.S.T.) or equivalent

7
FTP-624MCL001/002/FTP-624DCL/DSL
■FUNCTION
metImetI
.1noitcnuftnirptseT.8noitcnufgnivasrewoprotoM
.2noitcetedtuorepaP.9noitcnufnoitcetedkraM
.3noitceteddneraenrepaP.01noitcetedytilamronbanoitarepoUCM
.4noitcetedpudaeH.11noitcetorpecneuqesFFO/NOrewoP
.5noitcetedytilamronbaerutarepmetdaehlamrehT.21noitcetorptnerruc-revorotoM
.6noitcetedesuftuo-wolB.31remiterawdraH
.7noitcetedytilamronbaegatlovdaeH
■INTERFACE, COMMAND, OPTIONS
Please refer to the FTP-624DCL/DSL DATA SHEET.
