ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
ScanPartner 15C, 600C & 620C CONSUMABLE
REPLACEMENT AND CLEANING INSTRUCTIONS
CG00000-708501Revision B

ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
2
PadAssembly
Qty 2
KIT CONTENTS
Cotton
Swabs
Qty 1 100/pack
F1 Cleaner
Isopropyl Alcohol
Qty1
Cleaning Paper
Qty 1 10/pack
Lint Free
Cleaning Cloths
Qty 2 20/pack

3
ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
CONSUMABLE LIST
Description Qty Life Fujitsu P/N
Pad Assembly 1 150,000Sheets 002-1391-0
Note:
Replacement Cycles are estimated guidelines established by testing
with A4/Letter sized woodfree and wood based 17 lb paper. NCR or
Carbonlesspaper haschemical compositionwhich damagesthe Pad
Assembly. Cleaning of the consumable, rollers and feed path will be
requiredmore frequently toavoid feed problems. Consumablelife will
bereduced ifNCR or Carbonless paper isscanned.
PadAssembly
Note:
The Consumable PadAssembly is replaceable only in the scanners
listed below. Scanners not listed below must have the PadAssembly
replaced by a trained service person. Please consult the Fujitsu
TechnicalAssistanceCenter formore detailsshould youhave a
ScanPartnerScanner thatdoes notfall withinthese parameters.
Scan Partner Model # Definition of Cut-In
SP-15C Serial number of unit is greater than
9110001-S15September 1999
SP-600C Units Manufactured after
September 1998
SP-620C All Units are compatable with a
replaceable PadAssembly.

ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
4
REPLACING THE PAD ASSEMBLY
• Removeallthe
documentsfrom the
ADFPaper Chute.
Open theADF by
pressingtheADF
button.
• RemovetheADF Pad
Assembly by pressing
the two knobs on the
top of the Pad
Assembly and sliding it
outto remove it.
• Attach the new Pad
Assembly by pressing
the two knobs on the
top of the Pad
Assembly and sliding it
down into the slots to
lock it in place.
Adefective or improperly installed PadAssembly can cause miss picks,
skew, or double fed documents. To replace the Pad Assembly perform
the following steps.
Pad Assembly
Pick and
Feed
Rollers
ADFButton
Left
Guide Balance
Wire
Document
Right
Guide

5
ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
CLEANING LOCATIONS AND FREQUENCIES
Note:
The scanner will need to be cleaned every day (or possibly more than
once a day) if the following paper is scanned.
• Paper with special coating such as carbonless paper.
• Paper with large amount of printing. (Heavy toner or ink)
• Documents with toner that is not fused properly.
CLEANING MATERIALS
Cotton
Swabs
F1 Cleaner
Isopropyl Alcohol
Cleaning Paper
Lint Free
Cleaning Cloths
Pick Roller and Pad
Assembly
Location Tools Frequency
Cleaning Paper Every 1,000 Sheets
Cloth & Isopropyl Alcohol Every 5,000 Sheets
Plastic Feed Rollers Cloth & Isopropyl Alcohol Every 5,000 Sheets
Sheet Guides Cloth & Isopropyl Alcohol Every 5,000 Sheets
Eject Rollers Cloth & Isopropyl Alcohol Every 5,000 Sheets
Feed Rollers Cloth & Isopropyl Alcohol Every 5,000 Sheets
Glass Surfaces Cloth & Isopropyl Alcohol Every 5,000 Sheets

ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
6
CLEANING THE ROLLERS WITH THE CLEANING PAPER
• Set the Hopper Guides to the widest width possible.
Thecleaning papersare designed to remove onlyloose paperdust andink
from the rollers. Use the cleaning paperapproximately every 1,000 sheets
scanned. They are to be used in between the thorough cleanings of the
scanner. Using the cleaning paper does not take the place of the
more complete cleanings described later in this section
• Spraythecleaning paperlightly with F1 Cleaner and place the Clean-
ingPaper againstthe right edge of the Hopper Guide.Using the
scanning application scan the cleaning paper. Do Not Save These
Images. This operation is used only to pass the cleaning paper
throughthepaper feedpath.
• Placethe Cleaning Paperagainst theLeft Hopper Guideand perform
theprevious step.
• Check the path to see if it needs further cleaning. If you find debris in
thepaperpathperform thiscleaningor the (CLEANING THE ADF WITH
LINT-FREE CLOTHS) inthe following steps.
LeftSheet
Guide
RightSheet
Guide
Cleaning
Paper
InputTray and Wire
Guide
ADF(Automatic
DocumentFeeder)

7
ScanPartner 15C, 600C & 620C CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
Pad
Assembly
Feed Rollers, Pick
Roller, Sheet guides,
ADFDocument Glass
CLEANING THE ADF WITH LINT-FREE CLOTHS
• Using a lint free cloth clean the PadAssembly, Pick Rollers, Sheet
Guides,Feed Rollersand Sub-document Bed Glass. Clean the Pad
Assembly by wiping a lint-free cloth dampened with F1 cleaner in the
direction of paper travel through theADF. Be sure that the glass is
cleaned and no residue is remaining that will cause visible streaking in
the glass. All surfaces should be dry before beginning to scan
documentsafter cleaning.
• Use a lint free cloth to clean the Flatbed Glass. Be sure that the glass
is cleaned and no residue is remaining that will cause visible streaking
in the glass. All surfaces should be dry before beginning to scan
documentsafter cleaning.
Sub-Document
bed and Flat bed
Glass
