Fujitsu A6110 - LifeBook - Core 2 Duo 2.2 GHz User manual

This user’s guide contains information on using the Fujitsu Remote
Control with systems running Microsoft® Windows Vista® Home
Premium or Windows Vista® Ultimate edition as the operating system.
You are strongly advised to read this manual to familiarize yourself with
the features of the remote control.
Determining Your System Configuration
Your remote control can be used with your computer whether you have
a TV tuner or not. If you do not have a TV tuner, you can use the remote
control to perform such operations as playing DVDs, listening to music,
or viewing digital photo albums.
If you have a TV tuner installed (built-in, installed on PC Card, or
connected externally via USB), you can use the remote to control the
channel and volume, pause live TV, and record TV programs.
Figs. 1 through 3 illustrate the three ways your system can be
configured:
■No TV Tuner
■Built-in TV Tuner with direct signal
■External TV Tuner
Note that the port locations and system
configurations illustrated in this manual may differ
from your actual configuration. See you system
user’s guide for actual location/configuration.
INSTRUCTIONS
Remote Control User’s Guide
Fujitsu Computer Systems Corporation
Vista Remote B5FJ-5401-01EN-00.fm Page 1 Thursday, August 9, 2007 3:39 PM

2
Figure 1. Configuration with no TV Tuner
Figure 2. Configuration with TV Tuner and Direct Signal
OK
++
123
456
789
0
CLEAR ENTER
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
Remote
Control
To USB port
Remote
Control
IR Receiver
OK
++
123
456
789
0
CLEAR ENTER
ABC DEF
GHI JKLMNO
PQRS TUV WXYZ
Remote
Control
IR Receiver
Remote Control
To USB port
RF Coaxial
cable to cable
connector
or antenna
Antenna
Adapter
Cable
Vista Remote B5FJ-5401-01EN-00.fm Page 2 Thursday, August 9, 2007 3:39 PM

3
Figure 3. Configuration with External TV Tuner
Items included in Remote Control Package
Before using the remote control, make sure the following items are
included in the remote control package (Figure 5). Be sure to have
these items at hand before you proceed to use the remote control:
■Remote control
■Two size AA alkaline batteries
■Optical remote control receiver
OK
++
123
456
789
0
CLEARENTER
ABCDEF
GHIJKLMNO
PQRS TUVWXYZ
Remote
Control
To USB port
Remote Control
IR Receiver
RF Coaxial cable to
To USB port*
*Some external TV tuners can
be connected via USB; other
designs can be connected
via PC or ExpressCard slot.
cable connector or antenna
Vista Remote B5FJ-5401-01EN-00.fm Page 3 Thursday, August 9, 2007 3:39 PM

4
Figure 4. Remote Control and Accessories
Installing Batteries
Info
■Use only the remote that came with this
package when operating Vista Media Center.
■No cables or accessories other than those
shown in Figure 5 are included. Additional
accessories such as antenna cables, relay
connectors, video cable, S-video cable, or
audio cable are commercially available.
Warning
■Properly insert batteries using the correct
polarities (+, -). If they are incorrectly
inserted, damage to the remote control
could result.
■If you do not intend to use the remote
control for an extended period of time,
remove the batteries.
Remote 2 AA Alkaline
Batteries
Optical Remote
Control IR Receiver
Control
OK
++
123
456
789
0
CLEAR ENTER
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
Vista Remote B5FJ-5401-01EN-00.fm Page 4 Thursday, August 9, 2007 3:39 PM

5
1. Open the lid of the battery compartment on the bottom of the
remote control by pushing it in the direction shown in Figure 5.
Figure 5. Opening the battery compartment
2. Insert the batteries with the polarities indicated on the bottom
of the compartment and replace the cover.
In order to allow a suspended system to “wake
up” using the remote control, you must ensure
that it is enabled in the Windows Mobility
Center. To do so, follow the instructions in
“Setting up Mobility Center to use remote
control” on page 6.
Battery Compartment
Vista Remote B5FJ-5401-01EN-00.fm Page 5 Thursday, August 9, 2007 3:39 PM

6
Connecting optical remote control IR receiver
Connect the USB connector on the end of the remote control to one
of the USB ports on your computer (Figure 7). Note that the loca-
tion of the USB port on your system may not be the same as that
shown in the figure. Refer to the system user’s guide for the location
of the USB ports.
Figure 6. Connecting the optical remote control receiver
Setting up Mobility Center to use remote control
In order for your remote control to work with your LifeBook, you
must first ensure that it is able to “wake up” using a USB device. To
do so, perform the following simple steps:
1. Click on Start -> Control Panel.
2. If you are in Classic View, double-click the Windows Mobility
Center icon. If you are in Control Panel Home View, first click
Mobile PC, then select Windows Mobility Center.
In order to allow a suspended system to “wake
up” using the remote control, you must ensure
that it is enabled in the Windows Mobility
Center. To do so, follow the instructions in
“Setting up Mobility Center to use remote
control” on page 6.
Vista Remote B5FJ-5401-01EN-00.fm Page 6 Thursday, August 9, 2007 3:39 PM

7
3. Find the tile labeled “Wake up by USB device”, and see if it is
set to Enable or Disable.
4. If it is set to Enable, click the [Change] button. If it is set to
Disable, no action is required.
Using the remote control
To use the remote control, you must use the remote control receiver
included with the remote control. If your system has an infrared
port, it cannot be used to operate the remote control.
Note the following when using the remote control:
■The receiver should be placed in a location where it is not
obstructed. You should be able to point the remote control
directly at the receiver. Keep the receiver out of direct sunlight,
otherwise reception may prove faulty and the effective distance
may be affected.
■If a plasma display, plasma TV, or halogen heater is located close
to the device, the remote control may not work properly due to
infrared interference. Relocate the devices if they interfere with
the remote control operation.
Using the remote control is fairly intuitive. For specific information
on using particular features, click the Start button to display the
main menu. Scroll down to Settings and press the OK button. A
submenu containing a variety of help topics appear. Click on the
desired submenu to access related topics.
To exit the Help menu, click on the Start button to return to the
main menu.
Vista Remote B5FJ-5401-01EN-00.fm Page 7 Thursday, August 9, 2007 3:39 PM

8
Effective distance/location for remote control
(Figure 12)
Horizontal (left and right from center-point): Approximately 45
degrees
Vertical (left and right from center-point): Approximately 45
degrees
Distance from remote control to receiver: 3 meters max.
Figure 7. Effective distance/location of remote control
3 meters
3 meters
45
o
45
o
45
o
45
o
OK
++
123
456
789
0
CLEARENTER
ABCDEF
GHIJKLMNO
PQRSTUVWXYZ
Vista Remote B5FJ-5401-01EN-00.fm Page 8 Thursday, August 9, 2007 3:39 PM

9
Remote control features
Each button on the remote control is explained in this section.
Figure 8. Remote control buttons
12
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
OK
++
123
456
789
0
CLEAR ENTER
ABC DEF
GHI JKL MNO
PQRS TUV WXYZ
Vista Remote B5FJ-5401-01EN-00.fm Page 9 Thursday, August 9, 2007 3:39 PM

10
No. Purpose/
Icon Purpose
1
Play Pressing this button causes a selected
recording to start playing.
2
Pause If you press this button while a DVD, a
recording, or live TV is playing, play will
stop temporarily. Pressing this button while
play has been paused, play will restart.
3
Power
Button
Pressing this button while the computer is
active will normally put the computer into
standby. Pressing this button while the
computer is in standby will take the com-
puter out of standby.
Note: When a USB remote control receiver
is connected to your system, the action
invoked by the button on the remote con-
trol can be changed by going to the Power
Options icon on the Control Panel. Select
“Choose what the power button does” in
the left pane. Select the desired action for
the remote control power button from the
available options.
4Stop Pressing this button while recording a pro- gram or while an audio CD or DVD video is
being played, record/play will be stopped.
5Fwd When watching a recorded program or DVD, pressing this button will cause the
program to fast forward.
Vista Remote B5FJ-5401-01EN-00.fm Page 10 Thursday, August 9, 2007 3:39 PM

11
6
Skip Pressing this button will cause the program
or DVD being viewed to jump to the next
chapter.
7
More Pressing this button will display all relevant
information on replaying DVD-VIDEO, CD
music, or recorded programs on screen.
8
Navigation
Buttons Pressing one of these buttons allow you to
move the cursor left, right, up, or down.
9OK Pressing this button will select or execute
the item where the cursor is placed.
10 Mute Pressing the Mute button will turn off
sound temporarily until you press it again.
11
Ch/Pg
When the (+) button or (-) button is
pressed, the channel will switch to the next
higher channel (+) or the next lower
channel (-). This button will also go to the
previous or next page of a menu or on-
screen notification that is more than one
screen high.
12
Live TV Pressing this button will display in full-
screen the program on the channel tuned in
the last time.
13
DVD Menu Pressing this button will display the main
DVD menu.
14
Numeric/
Letter
Keypad
Pressing the buttons allows you to input
numbers or letters on the screen.
No. Purpose/
Icon Purpose
Vista Remote B5FJ-5401-01EN-00.fm Page 11 Thursday, August 9, 2007 3:39 PM

12
15 ENTER Pressing this button will enter the letters or
numbers input on screen.
16 CLEAR Pressing this button will clear the numbers
or letters input on the screen one by one.
17 Recorded TV Pressing this button will display a list of all
recorded programs on the screen.
18 Guide Pressing this button will display the TV
program guide on screen.
19
Volume
Up/Down
When the (+) button or (-) button is
pressed, the volume will switch to the next
higher (+) or the next lower (-)
volume level.
20
Start Pressing this button will start up Media
Center. Pressing this button while Media
Center is running will display the Media
Center Main Menu on the screen.
21 Back Pressing the Back button returns you to the
previously viewed screen.
22 Replay When watching a recorded program or DVD, pressing this button will cause the
program to go back 6-7 seconds per press.
23 Rew When watching a recorded program or DVD, pressing this button will cause the
program to rewind.
24 Record Pressing this button while in television mode brings up a menu from which you
can choose what and when to record.
No. Purpose/
Icon Purpose
Vista Remote B5FJ-5401-01EN-00.fm Page 12 Thursday, August 9, 2007 3:39 PM

13
Vista Remote B5FJ-5401-01EN-00.fm Page 13 Thursday, August 9, 2007 3:39 PM

14
Vista Remote B5FJ-5401-01EN-00.fm Page 14 Thursday, August 9, 2007 3:39 PM

15
Vista Remote B5FJ-5401-01EN-00.fm Page 15 Thursday, August 9, 2007 3:39 PM

16
1250 E. Arques Avenue (M/S 122),
Sunnyvale, California 94085
For more information, call 1-877-372-3473 or visit our Web site
at www.shopfujitsu.com.
For technical support call 1-800-8fujitsu or send e-mail to:
[email protected]
Fujitsu and the Fujitsu logo are registered trademarks of Fujitsu, Ltd.
Microsoft, Windows, and Windows Vista are trademarks or registered
trademarks of the Microsoft Corporation. All other trademarks
mentioned herein are the property of their respective owners. We
cannot guarantee the accuracy of the contents of this document. We
disclaim liability for errors, omissions or future changes.
© 2007 Fujitsu Computer Systems Corporation. All rights reserved.
B5FJ-5401-01EN-00
Vista Remote B5FJ-5401-01EN-00.fm Page 16 Thursday, August 9, 2007 3:39 PM
