En-1
OPERATING MANUAL
Keep this manual for future reference.
REMOTE CONTROLLER (WIRED TYPE)
OPERATING TIPS
Cooling / heating priority
(Heat Pump model only)
• If another indoor unit in the same system is already operating in the cooling mode or
dry mode, heating mode settings cannot be performed.
• An indoor unit that is set up as an Administrative Indoor Unit can operate in the
AUTO mode.
• Administrative indoor unit:
Administrative indoor unit has priority for cooling and heating configurations.
TROUBLE SHOOTING
Before requesting service, perform the following checks:
Symptom Problem
Doesn’t operate
at all.
• Has there been a power failure?
• Has a fuse blown out, or a circuit breaker been tripped?
• It is being controlled centralized?
If the problem persists after performing these checks, or if you notice burning smells,
or the LED lamp flashes, immediately stop operation, turn off the electrical breaker and
consult authorized service personnel.
SPECIFICATIONS
Model Name UTY-RHRY
UTY-RHRG
Input voltage DC12V
Dimensions & Weight Height 120 mm (4-3/4 in)
Width 75 mm (2-15/16 in)
Depth 19 mm (3/4 in)
Weight 120 g (4 oz)
SAFETY PRECAUTIONS
• To prevent personal injury, or property damage, read this section carefully before you use
this unit, and be sure to comply with the following safety precautions.
WARNING
This mark indicates procedures which, if improperly performed, might lead
to the death or serious injury of the user.
• In the event of a malfunction (burning
smell, etc.), immediately stop operation,
turn off the electrical breaker, and consult
authorized service personnel.
• Do not repair or modify any damaged cable
by yourself. Let the authorized service
personnel to do it. Improper work will cause
an electric shock or a fire.
• When moving, consult authorized service
personnel for uninstallation and installation
of this unit.
• Do not touch with wet hands. It may cause
an electric shock.
• If children may approach the unit, take
preventive measures so that they cannot reach
the unit.
• Do not repair or modify by yourself. It may
cause a fault or accident.
• Do not use flammable gases near this unit.
It may cause a fire from leaking gas.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.
CAUTION
This mark indicates procedures which, if improperly performed, might
possibly result in personal harm to the user, or damage to property.
• Do not set vessels containing a liquid on
this unit. Doing so will cause heating, fire, or
electric shock.
• Do not expose this unit directly to water.
Doing so will cause trouble, electric shock,
or heating.
• Dispose of the packing materials safely.
Tear and dispose of the plastic packing
bags so that children cannot play with them.
There is the danger of suffocation if children
play with the original plastic bags.
• Do not place electrical devices within 1 m
(40 in) of this unit. It may cause malfunction
or failure.
• Do not use fire near this unit or place a
heating apparatus nearby. It may cause
malfunction.
• Do not touch the switches with sharp
objects.
Doing so will cause injury, trouble, or
electric shock.
PART NO. 9373329428-02
[Original instructions]
EnglishDeutschFrançaisEspañolItalianoΕλληνικάPortuguêsРусскийTürkçe
MADE IN P.R.C.
中 文
