P3PC-1592-06ENZ0
Operator's Guide
fi-5015C Image Scanner

fi-5015C Image Scanner Operator’s Guide i
CONTENTS
Chapter 1 NAME OF PARTS.................................................... 1
1.1 Units..................................................................................... 2
1.2 Operator Panel.................................................................... 5
Chapter 2 BASIC SCANNER OPERATIONS.......................... 7
2.1 Turning ON/OFF the Scanner ............................................ 8
2.2 Loading Documents on ADF ........................................... 13
2.3 Loading Document on Flatbed ........................................ 18
2.4 Scanning Documents....................................................... 20
2.5 How to use the Scanner Driver........................................ 23
2.6 Image Scanning Application............................................ 31
Chapter 3 MAINTENANCE..................................................... 33
3.1 How to clear the paper jam ............................................ 34
3.2 Cleaning............................................................................. 35
3.3 Replacing Consumable .................................................... 40

ii
Chapter 4 TROUBLESHOOTING........................................... 49
4.1 Error Indications in the Function Number Display........ 50
4.2 Troubleshooting ............................................................... 52
APPENDIX A SCANNER SPECIFICATIONS..................................... AP-1
APPENDIX B Using [Scan] or [Send to] button .............................. AP-3
APPENDIX C GLOSSARY OF TERMS.............................................. AP-7
INDEX ...................................................................................................... IN-1

fi-5015C Image Scanner Operator’s Guide iii
INTRODUCTION
Thank you for purchasing the fi-5015C Color Scanner.
This document describes how to handle fi-5015C and basic operation methods. Before you start using fi-
5015C be sure to thoroughly read this manual to ensure correct use.
This document describes the basic operation methods to perform scanning by using ScandAll PRO.
The version of ScandAll PRO bundled with this product is subject to change without notice, in which case
the screenshots captured in this document may differ from the actual displayed image.
For more information about ScandAll PRO, refer to the separate [ScandAll PRO User's Guide].
Trademarks
Microsoft, Windows, Windows Server, and Windows Vista are either registered trademarks or
trademarks of Microsoft Corporation in the United States and/or other countries.
ISIS is a registered trademark or trademark of EMC Corporation in the United States.
Other company names and product names are the registered trademarks or trademarks of the
respective companies.
How Trademarks Are Indicated In This Manual
References to operating systems (OS) are indicated as follows:
Windows 2000 Windows®2000 Professional operating system
Windows XP Windows®XP Home Edition operating system,
Windows®XP Professional operating system (32/64-bit)
Windows Server
2003
Windows Server®2003, Standard Edition (32/64-bit),
Windows Server®2003 R2, Standard Edition (32/64-bit)
Windows Vista Windows Vista®Home Basic operating system (32/64-bit),
Windows Vista®Home Premium operating system (32/64-bit),
Windows Vista®Business operating system (32/64-bit),
Windows Vista®Enterprise operating system (32/64-bit),
Windows Vista®ultimate operating system (32/64-bit)
Windows Server
2008
Windows Server®2008 Standard (32/64-bit),
Windows Server®2008 R2 Standard
Windows 7 Windows®7 Home Premium operating system (32/64-bit),
Windows®7 Professional operating system (32/64-bit),
Windows®7 Enterprise operating system (32/64-bit),
Windows®7 Ultimate operating system (32/64-bit)

iv
Where there is no distinction between the different versions of the above operating system, the general
term "Windows" is used.
Manufacturer
PFU LIMITED
International Sales Dept., Imaging Business Division, Products Group
Solid Square East Tower, 580 Horikawa-cho, Saiwai-ku, Kawasaki-shi Kanagawa 212-8563, Japan
Phone : [phone]
© PFU LIMITED 2006-2013
About Maintenance
The user must not perform repairs on this scanner.
Contact the store where you purchased the scanner or an authorized FUJITSU Image Scanner service
provider to make repairs to this product.
Safety Precautions
The attached "Safety Precautions" manual describes important details for users to use this product
safely and correctly. Read the Safety Precautions thoroughly before you start using this product.
Warning Indications Used In This Manual
Windows Server
2012
Windows Server®2012 Standard (64-bit)
Windows 8 Windows®8 operating system (32/64-bit),
Windows®8 Pro operating system (32/64-bit),
Windows®8 Enterprise operating system (32/64-bit)
WARNING
This indication alerts operators to an operation that, if not strictly
observed, may result in severe injury or death.
CAUTION
This indication alerts operators to an operation that, if not strictly
observed, may result in safety hazards to personnel or damage to
equipment.

fi-5015C Image Scanner Operator’s Guide v
Symbols Used In This Manual
Screen Examples In This Manual
The screen examples in this manual are subject to change without notice in the interest of product
improvement. If the actual displayed screen differs from the screen examples in this manual, operate
by following the actual displayed screen while referring to the User's Manual of the scanner
application you are using.
The screen examples used in this manual are of the TWAIN driver, ISIS driver, and ScandAll PRO
(image scanning application).
ATTENTION
This symbol alerts operators to particularly important information. Be
sure to read this information.
HINT
This symbol alerts operators to helpful advice regarding operation.

vi

1
fi-5015C Image Scanner Operator’s Guide 1
Chapter 1
NAME OF PARTS
This chapter shows the exterior view and the name of each part to descrive its function.
1.1 Units ......................................................................................................................... 2
1.2 Operator Panel ........................................................................................................ 5

2
1.1 Units
1. Front side
Part Function
1. Automatic docu-
ment feeder (ADF)
Automatically feeds documents one by one to the reading position in the
scanner.
2. Side guides Holds the documents straight.
3. ADF paper chute Holds the documents to be fed by the automatic document feeder (ADF).
4. Extension Extended when long documents are set.
5. Document cover Stacks the documents after being scanned by ADF.
Holds the document to be scanned on Flatbed.
6. Document stopper Prevents ejected documents from dropping off the scanners exit tray.
7. Flatbed Used when the ADF is not appropriate to scan the document.
8. Operator panel Turns on/off the scanner, starts scanning by [Send to] or [Scan] button, or
displays function number.
12345
6
7
8

1.1 Units
fi-5015C Image Scanner Operator’s Guide 3
NAME OF PARTS
1
2. Flatbed
3. Backside
Part Function
1. Document holding
pad
Holds the document on Flatbed.
2. Document bed On which the document is set face down.
Part Function
1. USB connector Connects USB cable to PC.
2. ADF cable connector Connects the cable from ADF.
3. DC inlet Connects the cable from AC adaptor
4. Main Power switch Turns the power ON or OFF to the scanner
1
2
1234

4
4. Side (ADF side)
Part Function
1. Shipping lock Locks the scanning head to prevent the scanner damaged when moving or
transporting.
1
Unlocked Locked

1.2 Operator Panel
fi-5015C Image Scanner Operator’s Guide 5
NAME OF PARTS
1
1.2 Operator Panel
Part Function
1. Function button Changes the function activated by [Send to] button.
2. Function number
display
Indicates the function number or error status. For detail refer "4.1Error
Indications in the Function Number Display" on page 50
3. [Send to] button Launches an application software which is linked by the value of Function
number display.
4. [Scan] button Launches an application software linked.
5. Power LED Lights when the scanner is turned on.
6. Power button Turns the scanner ON or OFF
(WPEVKQP 5GPFVQ 5ECP 2QYGT
123456

6

2
fi-5015C Image Scanner Operator’s Guide 7
Chapter 2
BASIC SCANNER OPERATIONS
This chapter describes how to turn On/Off the scanner, and how to load/scan the documents.
In this chapter Windows XP screenshots are illustrated.
The screens and operations may differ slightly if the OS you are using is not Windows XP.
Also, when TWAIN is updated the screens and operations noted in this chapter will differ slightly.
2.1 Turning ON/OFF the Scanner ................................................................................ 8
2.2 Loading Documents on ADF................................................................................ 13
2.3 Loading Document on Flatbed ............................................................................ 18
2.4 Scanning Documents ........................................................................................... 20
2.5 How to use the Scanner Driver............................................................................ 23
2.6 Image Scanning Application................................................................................ 31

8
2.1 Turning ON/OFF the Scanner
1. Turning the Power On
Switch on the Main Power switch located on the side. Then press [Power] button on the
operator Panel.
The scanner is turned ON, and the green LED on the operator panel lights.
During the initialization, the indication of the Function Number Display changes as follows:
“8”->"P" -> "0" -> "1"
The indication "1" means that the operator panel scanner is in the ready status.
2. Turning the Power Off
Hold the power button down for at least two seconds.
■ About Power ON/OFF Control
You can select either the scanner to be turned on/off with disable the Power button on the
operator panel, or alternately you would then power the scanner on/off by connecting or dis-
connecting the power cable.The procedure is as follows.
1. Open Scanner’s Properties.
1) When turning on the power, check that the scanner is connected to your PC. Refer to "2.3
Connecting the Scanner your a PC" in fi-5015C Getting Started on the Setup DVD-ROM
for information about connecting the scanner to your personal computer.
ATTENTION
Be sure to turn off the Power button on the operation panel before turning
off the main power switch. If you turn off the main power switch without
turning off the Power button first, other USB devices connected with the
USB2.0 hub may fail.
(WPEVKQP 5GPFVQ 5ECP 2QYGT

2.1 Turning ON/OFF the Scanner
fi-5015C Image Scanner Operator’s Guide 9
BASIC SCANNER OPERATIONS
2
2) Double click the "Printer and Other Hardware" icon on the Control panel of your PC.
⇒The [Printer and Other Hardware] window appears.
3) On the [Printers and Other Hardware] window, double click the [Scanners and Cameras]
icon.
⇒The [Scanners and Cameras] window is displayed.
4) Right click the "fi-5015C", and select [Properties] from the menu (for Windows XP), or
double click (for Windows 2000).

10
⇒The [fi-5015C Properties] dialog box appears.
5) Click the "Device Set" tab.
⇒The following panel appears.
2. Click [Power Control] button
⇒The following screen is displayed.

2.1 Turning ON/OFF the Scanner
fi-5015C Image Scanner Operator’s Guide 11
BASIC SCANNER OPERATIONS
2
3. In this screen,
•To power on/off the scanner by pressing the Power button:
⇒select "Enable power switch".
•To power on/off the scanner by connecting or disconnecting the AC cable:
⇒select "Disable power switch".
■Power Save Mode
The Power Save mode keeps the scanner in a low-powered state after it has been turned ON.
If no operation is performed on the scanner for 15 minutes, the scanner automatically switches to
the Power Save mode.
In the Power Save mode, the indication of the Function Number display on the operator panel goes
out, but the green LED stays lit.
To return from the Power Save mode, perform one of the following:
•Load the document on the ADF paper chute.
•Press any button on the operator panel.
(The scanner will be turned OFF when pressing down the power button for at least two
seconds.)
•Execute a command from the scanner driver.
Also, the scanner can be set to turn itself off automatically when it is turned on and left unused for
a certain period of time.
You can save the power consumption by having the scanner turn off automatically.
To enable this setting, select the [Power off after a certain period of time] check box in [Device
Setting] of the Software Operation Panel.
To turn the scanner back on when it is automatically turned off, press the power button on the scan-
ner.
For details, refer to "2.1 Turning ON/OFF the Scanner" (page. 8).
ATTENTION
If [Disable power switch] is selected, the scanner will not turn off even when
the [Power off after a certain period of time] check box is selected in
[Device Setting] of the Software Operation Panel.
ATTENTION
•Depending on the application you are using, the scanner may not be
turned off automatically even when the [Power off after a certain period
of time] check box is selected.
•If the scanner turns itself off automatically while you are using an image
scanning application, close the application first, then turn the scanner
back on.

12
Follow the procedure below to enable auto power OFF.
1. Check that the scanner and the computer are connected and turned on.
2. Select [Start] - [All Programs] - [Scanner Utility for Microsoft Windows] and click [Soft-
ware Operation Panel].
⇒The Software Operation Panel appears.
3. Change the setting in the Software Operation Panel window below.
•Select the [Power off after a certain period of time] check box to enable this function.
•The time until auto-power off can be set to 1 Hour, 2 Hours, 4 Hours or 8 Hours.
HINT
The default setting of this function varies depending on the part number
of the scanner.
* Check the part number on the product label on the scanner.
Part No.
PAxxxxx-Bxx1
PAxxxxx-Bxx2
PAxxxxx-Bxx3
PAxxxxx-Bxx5
PAxxxxx-Bxx7
Default setting
Enabled (power off after 4 hours)
Disabled

2.2 Loading Documents on ADF
fi-5015C Image Scanner Operator’s Guide 13
BASIC SCANNER OPERATIONS
2
2.2 Loading Documents on ADF
This section explains how to check the document condition and load them on ADF. These opera-
tions are very important to avoid paper jam or scanning error.
2.2.1 Checking document condition
Check that the document meets the following condition.
■ Document Size
■ Document Type
The following paper types are recommended for ADF scanning:
•Woodfree paper
•Wood containing paper
When using documents other than above paper types, scan som test sheets of the same type
to see if the documents can be scanned or not, before attempting to scan the documents.
■ Document Thickness
Paper thickness is generally expressed by "paper weight". The following shows the paper
weights that can be used on this scanner:
•52 g/m2to 127 g/m2(14lb to 34lb)
■ Precautions
The following documents may not be scanned successfully:
•Documents of non-uniform thickness (e.g. envelopes and documents with photographs
attached)
•Wrinkled or curled documents (Refer to HINTs on the next page)
•Folded or torn documents
•Tracing paper
•Coated paper
•Carbon paper
•Carbonless paper
•Photosensitive paper
•Perforated or punched documents
HINT
•If the documents do not meet the conditions, scan them on Flatbed
referring to "Loading Document on Flatbed" on page.18
•If you scan sheets of paper that is not recommended for feeding with
ADF, a paper jam may occur in the scanner or a wrinkle may occur on
a sheet. To prevent this from occurring, use Flatbed when scanning
such paper.
For ADF: Minimum 115 (Width) x 140 (Length) mm (4.53 x 5.51 in.)
Maximum 216 (Width) x 355 (Length) mm (8.5 x 14 in.)
