N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
N7100 CONSUMABLE REPLACEMENT
AND CLEANING INSTRUCTIONS
CG00002-291401

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
2
Brake Roller Pick Roller
CONSUMABLES LIST
Description Qty Life Fujitsu P/N
BrakeRoller 1
Pick Roller 1 200,000 PA03706-0001
Note: The Brake Roller and Pick Roller are included when
ordering part number PA03706-0001

3
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
CHECKING THE LIFE OF THE CONSUMABLES
1. On the [Main Menu] or [Job Menu] window, press
the [ConsumableAlert] button.
The [Consumable Alert] window appears.
2. Check which part needs to be replaced and press
the[OK]button.
Partswhose[UsageCounter]valueisbigger than the
[Replaceat]valueshouldbe replaced.
Thevalueof[Usage Counter] istheexactnumberof
scannedsheets.
3. Replace the part.
Refertothefollowing:
Replacing the Roller Set.
HINT
The [Consumables Alert] button on the [Job Menu] window can be shown
by pressing

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
4
REPLACING THE ROLLER SET
TheRollerSetismadeupof the
brakerollerandthepickroller.The
procedureforreplacingeachroller
isasfollows.
1. Turn off the scanner power and wait
for at least 15 minutes.
2. Unplug the power cable from the AC outlet.
3. Remove any documents from the ADF paper chute.
4. Pull the cover release catch toward you, place
your hands at both sides of the LCD cover, and
open the LCD cover.
5. Replace the brake roller.
1. Open the cover of the brake roller.
Be careful that the LCD cover does not shut on your fingers.
Cover
Hold both ends of the cover of the brake roller, and open it in the direction of the arrow.

5
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
REPLACING THE ROLLER SET (CONT.)
2. Remove the shaft.
Lifttherightsideof the rollerfirst,thenpullouttheshaft from the
slotonthe left.
Brake Roller
Shaft
3. Remove the brake roller from its shaft
Shaft
Brake Roller
4. Attach a new brake roller on the shaft.
Insert theprotrusionon theshaftintotheslot.
Shaft
Protrusion
Slot
Brake Roller

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
6
REPLACING THE ROLLER SET (CONT.)
5. Install the brake roller with the shaft on the scanner.
Fit the left end of the shaft in the slot, then install the rest of the shaft in
place.
Brake Roller
Shaft
6. Close the cover of the brake roller.
ATTENTION
Make sure that the shaft is attached properly. If it is not correctly attached,
document jams and other feeding errors may occur.
ATTENTION
Make sure that the shaft is attached properly. If it is not correctly attached,
document jams and other feeding errors may occur.

7
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
REPLACING THE ROLLER SET (CONT.)
1. Open the sheet guide.
Slide the side guides all the way, and pull the sheet guide open from the
dip.
2. Rotate the lock release tab on the shaft in the direction of the
arrow.
Dip
Side Guides
Sheet Guide
Lock Release Tab

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
8
3. Remove the pick roller.
Slightly lift the Lock release tab of the shaft (by approximately 5 mm),
slide the shaft to the direction of the arrow below, and lift it up all the
way.
Lock Release Tab
ATTENTION
Becareful not totouchthegear near the lockreleasetab on the shaftas
it contains grease.
REPLACING THE ROLLER SET (CONT.)

9
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
4. Install a new pick roller on the scanner.
Insert the left end of the shaft into the slot of the scanner, and lower
the other end gradually.
Pick Roller
5. Rotate the lock release tab on the shaft in the direction
of the arrow.
Lock Release Tab
ATTENTION
Make sure that the pick roller is installed properly. Otherwise, paper
jams or other feeding errors may occur.
REPLACING THE ROLLER SET (CONT.)

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
10
6. Close the sheet guide.
Make sure that both ends of the sheet guide are locked firmly.
7. Close the LCD cover.
You should hear a click.
REPLACING THE ROLLER SET (CONT.)
Be careful that the LCD cover does not shut on your fingers.
8. Connect the power cable, and turn on the scanner.
9. Reset the Roller Set usage counter.
After part replacement, the usage counter can be reset to return the part
status to normal.
1.Select [Usage Status] under [Status Details].
The [Usage Status] window appears.
2.Press the [Clear] button for the part replaced.
The counter reset confirmation window appears.
3.Press the [OK] button.

11
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
CLEANING SUPPLIES AND PARTS TO CLEAN
Cleaning Supplies
Contact your FUJITSU scanner dealer or an authorized FUJITSU scan-
ner service provider to obtain these products. For more details, refer to
the following web page:
http://www.fujitsu.com/global/about/resources/shop/computing/peripheral/
scanners/
CG90000-120001
CLEANINGCLOTH (25/PK)

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
12
Cleaning the Exterior of the Scanner
Cleaning the Scanner Body
The scanner exterior (other than the touch panel), the ADF paper chute,
and the stacker must be cleaned using a dry cloth or a cloth slightly
moistened with Cleaner F1 or a mild detergent. Cleaning Wipes can also
be used.
ATTENTION
Do not use paint thinner or other organic solvents. The shape or color may be
changed.
Make sure that water does not get inside the scanner when cleaning.
When a large amount of Cleaner F1 or a mild detergent is used, it may take
some time until it is dry. Use a small amount to moisten the cloths. Also, wipe
off Cleaner F1 well from the part with a dry cloth.
Cleaner F1 or
mild detergent
Paint thinner
Cleaning Wipe
Cleaning the Touch Panel
To prevent the touch panel screen from becoming dirty, it should be
regularly cleaned with a soft, dry cloth.
Take care when cleaning the touch panel. It can be easily damaged,
and should never be scratched or banged with hard objects.
ATTENTION
Do not wipe the touch panel with a damp cloth.
Dust on the panel surface may become stuck between the panel and
frame, causing the touch panel to malfunction.
Cloth

13
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
Cleaning Inside the Scanner
Clean the interior of the scanner with a cloth slightly moistened with
Cleaner F1 or the Cleaning Wipe.
Scanning repeatedly may cause dust and paper dust to accumulate
inside the scanner resulting in a scanning error.
As a guideline, the inside of the scanner should be cleaned every 1,000
sheets scanned.
However, this criteria varies according to the type of documents
scanned. For example, it may be necessary to clean the scanner more
frequently when documents with insufficiently fused toner are scanned.
The glass scanner windows inside theADF can become hot
when the scanner is used.
Turn off the scanner, unplug the power cable, and wait for at least 15 minutes
beforecleaning.
ATTENTION
Do not use water or mild detergent to clean the inside of the scanner.
When a large amount of the cleaner is used, it may take some time until it is
dry.
Use a small amount to moisten the cloths.Also, wipe off Cleaner F1 well from
the part with a dry cloth.

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
14
Cleaning Inside the Scanner (cont.)
Pull the cover release catch toward you and open the LCD cover.
Cover Release Catch
Be careful that the LCD cover does not shut on your fingers.

15
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
Clean the following parts with a soft cloth slightly moistened with
Cleaner F1 or with the Cleaning Wipe.
Ultrasonic sensor (x2)
(Also on the ADF paper
chute)
Brake
roller (x2)
Idler roller
(x4) Glass
(x2)
Eject roller (x2)
Feed roller
(x2)
Pick roller
(x2)
Brake roller (x2)
Remove the brake rollers from the scanner to clean.
Gently wipe the dirt and dust off from along the slots on the surface of
the brake rollers. Take care not to damage the soft rubber.

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
16
CLEANING INSIDE THE SCANNER (CONT.)
Ultrasonic sensor (x2)
Clean lightly with a soft cloth to wipe their surfaces clean. If you have
trouble wiping them with the cloth, use a cotton swab.
Idler roller (x4)
Gently rotate the idler rollers by hand as you wipe them clean. Take care
not to damage the soft rubber. The idler rollers should be cleaned
carefully and thoroughly, as dirty idler rollers can adversely affect the
paper pickup performance.
Glass (x2)
Clean lightly with a soft cloth to wipe their surfaces clean.
HINT
If the glass is dirty, a vertical line may appear on the scanned image.
Pick roller (x2)
Gently wipe the dirt and dust off from along the slots on the surface of
the roller as you rotate it manually. Take care not to damage the soft
rubber. The pick roller should be cleaned carefully and thoroughly, as a
dirty pick roller can adversely affect the paper pickup performance.
Feed roller (x2) and eject roller (x2)
When cleaning, turn on the power and let the feed rollers and eject
rollers rotate.
1 Connect the power cable, and turn on the scanner.
ATTENTION
The scanner needs to be on only when cleaning the feed rollers and
eject rollers.

17
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
CLEANING INSIDE THE SCANNER (CONT.)
2 On the [Main Menu] or [Job Menu] window, press the [Maintenance]
button.
HINT
The [Maintenance] button on the [Job Menu] window can be shown by
pressing .
The [Maintenance] window appears.
3 Press the [Roller Cleaning] button.

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
18
The [Roller Cleaning] window appears.
CLEANING INSIDE THE SCANNER (CONT.)
4 Open the LCD cover.
5 Lightly press a soft cloth slightly moistened with Cleaner F1 or the
Cleaning Wipe against the surface of the rollers.
6 Press the [Cleaning] button on the [Roller Cleaning] window.
When the button is pressed, the feed rollers and eject rollers rotate
slightly.
Pressing the button continuously rotates the feed rollers and eject rollers
for a fixed amount every few seconds.
Gently clean the rollers as you rotate them. Take care not to damage the
soft rubber.
Stop pressing the button to stop the rollers rotating.
The pick rollers should be cleaned carefully and thoroughly, as black
residue on the rollers can adversely affect the paper pickup
HINT
Pressing the [Cleaning] button seven times rotates the feed rollers and eject
rollersapproximatelyone complete revolution.
When Help is shown, close it before pressing the [Cleaning] button.
7 When you have finished cleaning the rollers, press the [OK] button, and
close the [Roller Cleaning] window.
ATTENTION
When cleaning the feed rollers or eject rollers, be careful not to touch the
rollers with your fingers while they are rotating.
Close the LCD cover.
You should hear a click.

19
N7100 CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS

N7100CONSUMABLE REPLACEMENT AND CLEANING INSTRUCTIONS
20
Fujitsu Computer Products of America, Inc.
http://us.fujitsu.com/fcpa
1250 East Arques Avenue Sunnyvale, CA 94085-4701 [phone] (408) 746-
7000 [email protected]
© 2015 Fujitsu Computer Products of America, Inc. All rights reserved, Fujitsu and
the Fujitsu Logo are registered trademarks, ScanCare and ScanAid are trade-
marks of Fujitsu Computer Products of America, Inc
All statements herein are valid only in the U.S. for U.S. residents, are based on
normal operating conditions, are provided for informational purposes only and are
not intended to create any implied warranty of merchantability or fitness for a par-
ticular purpose. Fujitsu Computer Products of America, Inc. reserves the right to
modify at any time without prior notice these statements, our products, their perfor-
mance specifications, availability, price and warranty, post-warranty and service
programs.
PrintedintheU.S.A.
