Fujitsu PRIMERGY BX620 S5 User manual

PRIMERGY BX620 S5
Server Blade
Operating Manual
Edition July 2009

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected]ujitsu.com.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4478-003.fm
Copyright © 2009 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability. The right to technical modification is reserved.
All hardware and software names used are trade names and/or trademarks of their respective
manufacturers.

BX620 S5 Operating Manual
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Concept and target groups for this manual . . . . . . . . . . 6
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 6
1.3 Performance features . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 14
1.5 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . 15
2 Overview: Installation procedure . . . . . . . . . . . . . . . 17
3 Important notes . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 19
3.2 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 25
3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . 25
3.4 Transporting the Server Blade . . . . . . . . . . . . . . . . 26
3.5 Environmental protection . . . . . . . . . . . . . . . . . . . 27
4 Installing the hardware . . . . . . . . . . . . . . . . . . . . . 29
4.1 Installation procedure . . . . . . . . . . . . . . . . . . . . . 29
4.2 Unpacking the Server Blade . . . . . . . . . . . . . . . . . . 30
4.3 Installing the Server Blade in the basic unit . . . . . . . . . 31
4.4 Connecting the Server Blade . . . . . . . . . . . . . . . . . 36
5 Installation and operation . . . . . . . . . . . . . . . . . . . 39
5.1 Control and connection panel . . . . . . . . . . . . . . . . . 40
5.2 Switching the Server Blade on and off . . . . . . . . . . . . 43
5.3 Configuring a Server Blade . . . . . . . . . . . . . . . . . . 44
5.4 Updating the firmware (BIOS and BMC) . . . . . . . . . . . 46

Operating Manual BX620 S5
Contents
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4479-003.fm
6 BIOS Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
6.1 Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
6.2 Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
6.3 SysInfo menu . . . . . . . . . . . . . . . . . . . . . . . . . . 55
6.4 Main menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
6.4.1 Boot Features menu . . . . . . . . . . . . . . . . . . . . . . . 58
6.5 Advanced menu . . . . . . . . . . . . . . . . . . . . . . . . . 59
6.5.1 Peripheral Configuration . . . . . . . . . . . . . . . . . . . . . 60
6.5.2 Advanced System Configuration . . . . . . . . . . . . . . . . . 62
6.5.3 Advanced Memory Options . . . . . . . . . . . . . . . . . . . 62
6.5.4 Advanced Processor Options . . . . . . . . . . . . . . . . . . 63
6.6 Security menu . . . . . . . . . . . . . . . . . . . . . . . . . . 65
6.6.1 TPM (Security Chip) Setting . . . . . . . . . . . . . . . . . . . 66
6.7 Power menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
6.8 Server menu . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
6.8.1 CPU STATUS . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.8.2 Memory Status . . . . . . . . . . . . . . . . . . . . . . . . . . 70
6.8.3 Console Redirection . . . . . . . . . . . . . . . . . . . . . . . 70
6.8.4 IPMI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
6.9 Boot menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
6.10 Exit menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
7 Troubleshooting and tips . . . . . . . . . . . . . . . . . . . . 77
8 CSS components . . . . . . . . . . . . . . . . . . . . . . . . 79
8.1 Replacing hot-plug components . . . . . . . . . . . . . . . . 80
8.1.1 Hot-plug hard disk drives . . . . . . . . . . . . . . . . . . . . . 80
8.2 Replacing non-hot-plug components . . . . . . . . . . . . . 86
8.2.1 Opening server blade and identifying defective CSS component . 86
8.2.2 Replacing memory modules . . . . . . . . . . . . . . . . . . . 91
8.2.3 Closing the server blade . . . . . . . . . . . . . . . . . . . . . 92
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93

BX620 S5 Operating Manual 5
1 Preface
The PRIMERGYBX620 S5 dual-socket server blade constitutes the fifth gener-
ation of extremely compact and powerful BX620 server blades. It provides a
range of current technologies such as the latest generation dual-core and quad-
core processors, DDR3 memory modules with powerful 3-channel architecture
per CPU, modular hard disk controller configuration, and 2.5-inch SAS, SATA or
SSD hard disk drives.
Figure 1: PRIMERGY BX620 S5 Server Blade
The modular disk controller concept with three storage module variants allows
you to create different configurations with SAS and SATA hard disks for different
deployment scenarios. The configuration options range from the low-cost
platform with SATA disks to the high-end platform with SAS disks and a SAS
storage module with RAID5 and Cache/iTBBU.
Six onboard Ethernet channels with iSCSI support are available as communi-
cation interfaces and as an option there are two Fibre Channel or two additional
Ethernet channels.
Security functions in the BIOS Setup protect the data on the server blade from
unauthorized changes.
The BX620 S5 server blade occupies one slot in the basic unit PRIMERGY
BX600 S3. It can be installed together with other server blade modules.

6 Operating Manual BX620 S5
Concept and target groups for this manual Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4480-003.fm
1.1 Concept and target groups for this manual
This operating manual shows you how to install the server blade in the basic
unit, how to start up the server blade and how to operate it.
This operating manual is intended for those responsible for installing the
hardware and ensuring that the system runs smoothly. It contains all the infor-
mation you need to put your PRIMERGYBX620 S5 into operation.
You will find all information on the installation, startup and operation of server
blades relating to all server blade models in the "PRIMERGY BX600 S3 Basic
Unit" manual.
To understand the various expansion options, you will need to be familiar with
the fields of hardware and data transmission and you will require a basic
knowledge of the underlying operating system.
1.2 Documentation overview
IPRIMERGY manuals are available in PDF format on the PRIMERGY
ServerView Suite DVD 2. The PRIMERGY ServerView Suite DVD 2 is
part of the PRIMERGY ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289.
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL:
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.
More information on your PRIMERGY BX620 S5 can be found in the following
documents:
– "PRIMERGY BX620 S5 Server Options Guide"
– "PRIMERGY BX620 S5 Server Service Supplement"
– Technical manual for the system board D2686
– "Quick Start Software - Quick Installation Guide" DVD booklet (only included
as a printed copy with the PRIMERGY ServerView Suite)
– “PRIMERGY ServerView Suite Local Service Concept - LSC” manual

BX620 S5 Operating Manual 7
Preface Documentation overview
– “Safety notes and other important information” manual
– “Warranty” manual
– “Returning used devices” manual
– “Helpdesk” leaflet
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the PRIMERGY
ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

8 Operating Manual BX620 S5
Performance features Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4480-003.fm
1.3 Performance features
Processors
In the BX620 S5 Server Blade, one (basic configuration) or two dual-core or
quad-core processors of the Intel®XEON®type ensure fast data flow and high
system performance.
The addition of processors is described in the Options Guide and the
replacement of processors in the Service Supplement.
VCAUTION!
You are only permitted to combine CPUs with the same clock frequency
and cache capacity in one BX620 S4 Server Blade.
Memory
6 DIMM slots for DDR3 memory modules are available per CPU on the
PRIMERGY BX620 S5 server blade (organized in 2 banks and 3 channels).
These 12 slots for the main memory are suitable both for RDIMM (registered
DIMM) and for UDIMM (unbuffered DIMM) memory modules. You must use
modules of the same size within a memory bank.
The maximum memory configuration when equipped with UDIMM memory
modules is 24 GB (capacities: 1024 and 2048 MB) and 96 GB when equipped
with RDIMM memory modules (capacities: 2048, 4096 and 8192 MB).
IYou are not permitted to mix UDIMM and RDIMM memory modules.
Memory scrubbing and ChipKill™are standard.
The installation of memory modules is described in the Options Guide.
Hard disk drives
The BX620 S4 Server Blade can accommodate up to two 2.5-inch HDD
modules (alternatively with SAS or SATA interface).
SATA HDD modules with a capacity of 120 GB are available. The maximum
hard disk capacity is thus 240 GB (2x120 GB).
SAS HDD modules are available with capacities of 36 GB, 73 GB or 146 GB.
The maximum hard disk capacity is thus 292 GB (2x146 GB).

BX620 S5 Operating Manual 9
Preface Performance features
You can replace or add HDD modules during operation (hot-plug) without
having to remove the server blade cover. The installation/replacement of HDD
modules is described in the chapter “CSS components” on page 79.
Storage modules
The hard disks are controlled by a storage module (controller) that can be
plugged into the system board. The storage module can also have other
functions. Altogether, there are three different variants to choose from: SAS,
SAS/MegaRAID and SAS/PCIe. The PCIe variant allows the installation of low-
profile PCIe boards.
You install/replace storage modules via the front of the server blade without
having to remove the housing cover. However, you cannot do this during
operation (no hot-plug). To do this, you must switch the server blade off instead.
The installation/replacement of storage modules is described in the Options
Guide.
LAN availability
The BX620 S4 Server Blade has three onboard LAN controllers with TOE and
iSCSI functionality, which each provide two 1Gbit/s Ethernet channels. The
connection to the Ethernet LAN is via switch blades or pass-thru blades on the
rear of the basic unit. You will find more details in the operating manual for the
basic unit.
Graphics controller
The BX620 S4 Server Blade has an onboard graphics controller. A monitor can
be connected via the VGA interface (via breakout cable) to the front of the server
blade or via the KVM blade to the rear of the basic unit.
Optional Fibre Channel or Ethernet I/O module (daughter card)
The BX620 S4 Server Blade can be equipped with an I/O daughter card for
connection to a SAN or for additional Ethernet connections.
The following I/O daughter cards are available:
– 4 Gbit/s Fibre Channel I/O module (PCIe), which enables transfer rates of 1,
2 or 4 Gbit/s and supports multiple FC storage subsystems with corre-
sponding versions.

10 Operating Manual BX620 S5
Performance features Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4480-003.fm
IThis I/O module can only be used in a BX600 S3 basic unit and only
with a 4/4 Gbit/s FC switch blade. You will find more information on
this in the operating manual for the BX600 S3 basic unit.
– 1 Gbit Ethernet I/O module (PCIe), which also supports TOE (TCP/IP
Offload Engine) and iSCSI.
– 10 Gbit Ethernet I/O module (PCIe)
IThis I/O module can only be used in a BX600 S3 basic unit and only
with a 10 Gbit switch blade 10/2. You will find more information on this
in the operating manual for the BX600 S3 basic unit.
To allow use of the additional I/O functionality, at least one FC pass-thru blade
(or switch blade) or Ethernet pass-thru blade (or switch blade) must be installed
in the NET3 slot of the basic unit.
IIt is not possible to mix different I/O modules in one basic unit.
The installation of I/O modules at a later time is described in the Options Guide.
Accessible Drives
Accessible drives (e.g. floppy disk or DVD drives) can be connected via the two
USB ports (via breakout cable) on the front of the server blade while the system
is running.
Customer Self Service (CSS)
The Fujitsu Technology Solutions Customer Self Service (CSS) concept
enables you to identify and replace the affected component yourself in the case
of certain error scenarios.
In the CSS concept, you may replace the following components yourself for a
server blade in the event of an error:
– Hot-plug hard disk drives
– Memory modules
The CSS indicator on the control panel of the server blade informs you if a CSS
event arises. For more information on the behavior of this indicator, see the
chapter “Installation and operation” on page 39 and the "PRIMERGY
ServerView Suite Local Service Concept - LSC" manual on the PRIMERGY
ServerView Suite DVD 2.

BX620 S5 Operating Manual 11
Preface Performance features
In addition, CSS errors are displayed in the ServerView Operations Manager -
the server management software from Fujitsu Technology Solutions.
In the event of errors, the ServerView Operations Manager refers you directly to
the affected component and its order information in the Illustrated Spares
catalog of the server in question.
USB Flash Module
A USB Flash Module (UFM) can also be installed on the system board. It is used
as memory for software (e.g. VMware) or as a software dongle.
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the system BIOS (see chapter “BIOS Setup”).
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.
High level of availability and data security
When memory data is accessed, 1-bit errors are identified in the main memory
and automatically corrected with the error correcting code (ECC) method.
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the event of an error and automatically "hides" the defective system compo-
nents.

12 Operating Manual BX620 S5
Performance features Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4480-003.fm
The PDA (Prefailure Detection and Analyzing) technology from Fujitsu
Technology Solutions analyzes and monitors all components that are critical for
system reliability.
The onboard RAID controllers on the SAS RAID storage modules support the
RAID levels 0 and 1 by default, thus increasing system availability.
A storage module with the RAID level 0 or 1 with extended logging and BBU can
be installed for SAS HDD modules to further increase availability.
Server management
Server management is implemented using the ServerView Operations Manager
supplied combined with PDA (Prefailure Detection and Analysis) technology
from Fujitsu Technology Solutions. PDA reports the threat of a system error or
overloading early on, so that preventive measures can be taken.
The ServerView Operations Manager enables the management of all
PRIMERGY servers in the network via a central console. The ServerView
Operations Manager supports the following functions:
●Round-the-clock monitoring, regardless of server status
●High-performance, graphical console bypass (AVR) protected by
HTTPS/SSL (128 bit)
●Remote storage via USB
●Remote switch-on via iRMC or MMB
●Monitoring of the ambient and CPU temperatures
●Monitoring of PCI bus loading
●Detailed status and error reports for bus systems, processors and main
memory
●Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event of failure of memory modules or processors
●Power monitoring
●Watchdog timer for monitoring the operating system and applications with
ASR&R
Further information on the ServerView Operations Manager is provided in the
associated documentation.

BX620 S5 Operating Manual 13
Preface Performance features
ServerView Installation Manager
You can configure the server system quickly and precisely with the ServerView
Installation Manager software provided. User-friendly menus guide you through
the installation of the server operating systems.
Service and support
PRIMERGY servers are service-friendly and modular, thus enabling quick and
simple maintenance. The two redundant hot-pluggable management blades of
the BX600 S3 basic unit, with independent LAN and COM ports for
management, enable comprehensive remote administration of the server blade.
Together, they enable remote diagnosis for system analyses, remote configu-
ration and remote restarts, even in the case of operating system failure or
hardware errors.

14 Operating Manual BX620 S5
Notational conventions Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4480-003.fm
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
“Quotation marks” indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

BX620 S5 Operating Manual 15
Preface Technical data
1.5 Technical data
Electrical specifications
Compliance with regulations and standards
Certification
Power consumption ~ 380 W (full configuration)
Thermal dissipation Min. ~ 750 kJ/h, max. ~ 1000 kJ/h
Product safety and
ergonomics
IEC 60950-1 / EN 60950-1, UL/CSA 60950-1,
CNS 14336 / GB 4943 / EN 50371
Electromagnetic
compatibility
FCC class A
CNS 13438 class A; VCCI class A
AS/NZS CISPR 22 class A / GB 9254 class A
GB 17625
interference
emissions
EN 55022 class A
Harmonic current EN 61000-3-2
Flicker EN 61000-3-3
interference
immunity
EN 55024, EN 300386
CE marking to EU direc-
tives
Low Voltage Directive 2006/95/EC
(product safety)
Electromagnetic compatibility 2004/108/EC
Mechanical environ-
mental conditions
EN 60721-3-3; class 3M2
Product safety
Global CB
Europe ENEC
Germany GS, CE
USA/Canada CSAUS / CSAC

16 Operating Manual BX620 S5
Technical data Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4480-003.fm
Mechanical Specifications
Weight
Max. 7,5 kg (depending on the configuration).
Ambient conditions
Condensation during operation must be avoided!
Japan VCCI
China/Taiwan BSMI
Width 286 mm
Depth 470 mm (520 mm incl. handles and plugs)
Height 43 mm (1 slot in basic unit)
Environment class 3K2
Environment class 2K2
EN 60721 / IEC 721 Part 3-3
EN 60721 / IEC 721 Part 3-2
Temperature:
Operation (3K2) 5°C .... 35°C
Transport (2K2) -20°C .... 60°C
Humidity 10% .... 85%

BX620 S5 Operating Manual 17
2 Overview: Installation procedure
This chapter contains an overview of the steps you need to carry out to install
your server blade in the basic unit. The links take you to the sections containing
detailed descriptions of the individual steps.
IYou will find the information you need to install and start up the basic unit
in the "PRIMERGY BX600 S3 Basic Unit - Operating Manual".
ÊFirst read the chapter “Important notes” from page 19, particularly the
section “Safety instructions”.
ÊUnpack the server blade, check the contents of the package for visible
transport damage and that the items delivered correspond to the details on
the delivery note (see the section section “Unpacking the Server Blade” on
page 30).
ÊFamiliarize yourself with the controls and indicators on the front of the
server blade (see chapter “Installation and operation” on page 39).
ÊInstall the operating system and applications on the server blade.
When doing so, you have the following options:
–Clone server blade from a remote image server using RemoteDeploy.
This procedure is recommended if the following conditions are met:
– The RemoteDeploy software is available.
– You have a suitable clone image.
– A Deployment Server and LAN connection are available.
–Remote installation with the ServerView Installation Manager:
This installation method is recommended if you have a LAN connection
and a DHCP server (Deployment Server) available, but the cloning
requirements are not met.

18 Operating Manual BX620 S5
Overview: Installation procedure
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4481-003.fm
–Local installation with or without the ServerView Installation Manager
Local installation is the least convenient method. It is only recommended
if the requirements for remote installation and cloning are not met.
If you want to install an operating system that is not supported by the
ServerView Installation Manager, you can of course install it directly
without the ServerView Installation Manager.
IYou will find more information on installing server blades remotely or
locally in the ServerView Installation Manager manual. This contains
a Quick Start Guide as well as a detailed description of the individual
installation options and wizards. A print version of the ServerView
Installation Manager manual is included in the ServerView Suite,
which is supplied with the BX600 S3 basic unit. A PDF version is
available on the PRIMERGY ServerView Suite DVD 2.
You will find a description on cloning server blades in the
RemoteDeploy manual (print version supplied with RemoteDeploy, a
PDF version is available on the PRIMERGY ServerView Suite
DVD 2).

BX620 S5 Operating Manual 19
3 Important notes
This chapter provides safety instructions which you must observe when
handling your server blade.
3.1 Safety instructions
IThe following safety instructions are also provided in the manual “Safety
notes and other important information”.
This device meets the relevant safety regulations for IT equipment. If you have
any questions about whether you can install the server in the intended
environment, please contact your sales outlet or our customer service team.
VCAUTION!
●The actions described in this manual should only be performed by
technical specialists.
●Repairs to the device that do not relate to CSS failures must only be
carried out by service personnel. Please note that unauthorized inter-
ference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.

20 Operating Manual BX620 S5
Safety instructions Important notes
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: W:\Anwendungsdaten\FCT\tim_local\work\PICHOL\OBJ_DOKU-4482-003.fm
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see section
“Technical data” on page 15).
●If the server has been moved from a cold environment, condensation
may form both inside and on the outside of the machine.
Wait until the server has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the server if this requirement is not met.
●Only transport the server in the original packaging or in packaging
that protects it from impacts and jolts.
Installation and operation
VCAUTION!
●Observe the notes on installation and operation in the operating
manual for the basic unit.
●If the device is integrated in an installation that receives power from
an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for non-industrial (public) power supply networks for the
type A connector.
●Data cables must be adequately shielded to avoid interference.
●The EN 50173 and EN 50174-1/2 standards apply for LAN cabling.
The minimum requirement is the use of a category 5 screened LAN
cable for 10/100 Mbit/s Ethernet, or a category 5e cable for Gigabit
Ethernet. The requirements from the ISO/IEC 11801 specification
must also be met.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the operating manual for the
device.
