PRIMERGY BX920 S1
Server Blade
Options Guide
Edition June 2009

Copyright and Trademarks
Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected]ujitsu.com.
Certified documentation
according to DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4438-002.fm
Copyright © 2009 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability. The right to technical modification is reserved.
All hardware and software names used are trade names and/or trademarks of their respective
manufacturers.

BX920 S1 Options Guide
Contents
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Concept and target groups . . . . . . . . . . . . . . . . . . . 5
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . . 5
1.3 Extensions and conversions . . . . . . . . . . . . . . . . . . 7
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . . 8
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 11
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.1 Opening the Server Blade . . . . . . . . . . . . . . . . . . . 15
5 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
5.1 Installing a second processor . . . . . . . . . . . . . . . . . 17
6 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 23
6.1 Equipping rules . . . . . . . . . . . . . . . . . . . . . . . . . 24
6.2 Expanding/replacing main memory . . . . . . . . . . . . . . 25
7 USB Flash Module (UFM) . . . . . . . . . . . . . . . . . . . 27
7.1 Installing a UFM . . . . . . . . . . . . . . . . . . . . . . . . 27

OptionsGuide BX920 S1
Inhalt
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4439-002.fm
8 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
8.1 Closing the server blade . . . . . . . . . . . . . . . . . . . . 29
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31

BX920 S1 Options Guide 5
1 Preface
The PRIMERGY BX920 S1 server blade is an Intel-based dual-socket server
blade. It is ideal for use in data centers belonging to enterprises or Internet
service providers, and makes an excellent large application server, terminal
server for compute-intensive applications or DBMS server.
1.1 Concept and target groups
This Options Guide shows you how to extend and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
technical specialists.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
1.2 Documentation overview
IPRIMERGY manuals are available in PDF format on the PRIMERGY
ServerView Suite DVD 2. The PRIMERGY ServerView Suite DVD 2 is
part of the PRIMERGY ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289 (the
order number for the Japanese market: please refer to the configurator
of the server http://primeserver.fujitsu.com/primergy/system.html).
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL (for EMEA market):
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.
For the Japanese market please use the URL:
http://primeserver.fujitsu.com/primergy/manual.html.
More information on your PRIMERGY BX920 S1 can be found in the following
documents:

6 OptionsGuide BX920 S1
Documentation overview Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4440-002.fm
– “PRIMERGY BX920 S1 Server Operating Manual”
– “PRIMERGY BX920 S1 Server Options Guide”
– "PRIMERGY BX920 S1 Server Service Supplement"
– Technical manual for the system board D2860
– "Quick Start Software - Quick Installation Guide" DVD booklet (only included
as a printed copy with the PRIMERGY ServerView Suite)
– “PRIMERGY ServerView Suite Local Service Concept - LSC” manual
– “Safety notes and other important information” manual
– “Warranty” manual
– “Returning used devices” manual
– “Helpdesk” leaflet
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the PRIMERGY
ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

BX920 S1 Options Guide 7
Preface Extensions and conversions
1.3 Extensions and conversions
Second processor
If only one processor is installed in your server blade, you can add a second
processor to it. You may only use processors of the same type. The second
processor must have the same clock frequency as the first.
Main memory expansion
The system board has a total of 9 slots for memory modules. Of these, 6 slots
are for CPU 1 and 3 slots for CPU 2.
In total, the system board supports up to 72 GB main memory. Memory
modules with a capacity of 1 GB, 2 GB, 4 GB or 8 GB can be used.
Both registered DDR 3 memory modules (RDIMM) and unbuffered DDR 3
memory modules (UDIMM) are permitted. However, you must not use a mixture
of these two module types.
IYou can find detailed information on the main memory in the technical
manual for the D2680 system board.
Optional I/O modules (mezzanine cards)
The server blade has two slots for expansion boards (known as mezzanine
cards), which can each provide two Fibre Channel connections or four
additional Ethernet connections.
You can choose from the following I/O modules:
– 8 Gbit Fibre Channel mezzanine card with 2 port (PCIe x8)
– 1 Gbit Ethernet mezzanine card with 4 ports (PCIe x4)
IYou will find a description on how to install or exchange mezzanine cards
in the "PRIMERGY BX920 S1 Server Service Supplement" manual.

8 OptionsGuide BX920 S1
Notational conventions Preface
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4440-002.fm
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

BX920 S1 Options Guide 9
2Procedure
VCAUTION!
●The activities described in this manual must be performed by
engineers, service personnel or technical specialists.
●Equipment repairs must be performed by qualified staff.
●Any failure to observe the guidelines in this manual, and any unautho-
rized opening or improper repairs could endanger the user (through
electric shock, fire hazards) or damage the equipment.
●Please note that any unauthorized opening of the device will result in
the invalidation of the warranty and exclusion from all liability.
ÊFirst of all, carefully read the safety instructions in chapter “Safety instruc-
tions” on page 11 and following.
ÊMake sure that you have all necessary manuals (see “Documentation
overview” on page 5); print out the PDF files if required.
Most importantly, you will need:
– the operating manual for the server blade and
– the service supplement.
ÊShut down the server blade properly, switch it off, and remove it from the
system unit as described in chapter “Preparation” on page 15.
ÊCarry out the expansion or upgrade of your server blade as described in the
pertinent chapter.
IInstallation and removal of hot-plug components is described in the
server blade operating manual.
ÊClose the server blade, re-insert it in the system unit and switch it on as
described in chapter “Completion” on page 29 and following.
ÊStart the operating system and make the appropriate configuration if
necessary (see operating manual).

© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4441-002.fm

BX920 S1 Options Guide 11
3 Safety instructions
IThe following safety instructions are also provided in the manual "Safety
notes and other important information".
This device complies with the relevant safety regulations for data processing
equipment, including electronic office machines for use in an office
environment.
If you have any questions as to whether you can set up the device in your
particular environment, please contact your sales outlet or our customer service
centre.
VCAUTION!
●The actions described in this manual shall be performed by technical
specialists. A technical specialist is a person who is trained to install
the server including hardware and software.
●Repairs to the device that do not relate to CSS failures shall be
performed by service personnel. Please note that unauthorized inter-
ference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the device.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.

12 Options Guide BX920 S1
Safety instructions
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4442-002.fm
Installation and operation
VCAUTION!
●Observe the notes on installation and operation in the operating
manual of your BX900 S1 system unit.
●When installing the server blade in the system unit, beware of the
energy hazard at the midplane contacts. A short circuit on these
contacts can damage the system.
●Data cables must be adequately shielded to avoid interference.
●The EN 50173 and EN 50174-1/2 standards apply for LAN cabling.
The minimum requirement is the use of a category 5 screened LAN
cable for 10/100 Mbit/s Ethernet, or a category 5e cable for Gigabit
Ethernet. The requirements of the specification ISO/IEC 11801 must
also be taken into account.
●Route the cables in such a way that they do not form a potential
hazard (tripping) and cannot be damaged. When connecting the
device, refer to the relevant notes in the operating manual for the
device.
●Do not connect or disconnect any data transmission cables during a
thunderstorm (lightning hazard).
●Make sure that no objects (e.g. jewelry, paperclips etc.) or liquids get
inside the unit (electric shock hazard, short circuit).
●In emergencies (e.g. damaged casing, control elements or power
cables, penetration of liquids or foreign bodies), switch off the device
immediately, unplug it from the grounded power outlets, and contact
your customer service team.
●Proper operation of the system (in accordance with IEC 60950/DIN
EN 60950) is only ensured if the casing is completely assembled and
the rear covers for the installation openings have been put in place
(electric shock, cooling, fire protection, interference suppression).
●Only set the resolutions and refresh rates specified in the operating
manual for your monitor.
Otherwise, you may damage the monitor. If you are in any doubt,
contact your sales outlet or customer service center.

BX920 S1 Options Guide 13
Safety instructions
VCAUTION!
●Install only system extensions that satisfy the requirements and rules
governing safety, electromagnetic compatibility, and telecommunica-
tions terminal equipment.
If you install other extensions, you might damage the system or
violate these safety regulations.
You can find out which system extensions are suitable from the
customer service center or your sales outlet.
●The components marked with a warning label (e.g. lightning symbol)
may only be opened, removed or exchanged by authorized, qualified
personnel. The hot-pluggable/hot-swappable components are excep-
tions to this rule.
●If you cause a defect on the device by installing or exchanging system
extensions, the warranty will be invalidated.
Batteries
VCAUTION!
●Incorrect replacement of batteries may lead to a risk of explosion. The
batteries may only be replaced with identical batteries or with a type
recommended by the manufacturer.
●Do not throw batteries into the trash can. They must be disposed of
in accordance with local regulations concerning special waste.
●The battery must be disposed of in accordance with local regulations
concerning special waste.
●Replace the lithium battery on the system board in accordance with
the instructions in the service supplement for the server blade.
●All batteries containing pollutants are marked with a symbol (a
crossed-out garbage can). In addition, the marking is provided with
the chemical symbol of the heavy metal decisive for the classification
as a pollutant:
Cd Cadmium
Hg Mercury
Pb Lead

14 Options Guide BX920 S1
Safety instructions
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4442-002.fm
Modules with Electrostatic-Sensitive Devices
Modules with electrostatic-sensitive devices are identified by the following
sticker:
Figure 1: ESD label
When you handle components fitted with ESDs, you must always observe the
following points:
●Switch off the system and remove the power plugs from the power outlets
before installing or removing components with ESDs.
●You must always discharge static build-up (e.g. by touching a grounded
object) before working with such components.
●Any devices or tools that are used must be free of electrostatic charge.
●Wear a suitable grounding cable that connects you to the external chassis of
the system unit.
●Always hold components with ESDs at the edges or at the points marked
green (touch points).
●Do not touch any connectors or conduction paths on an ESD.
●Place all the components on a pad which is free of electrostatic charge.
IFor a detailed description of how to handle ESD components, see the
relevant European or international standards (EN 61340-5-1,
ANSI/ESD S20.20).

BX920 S1 Options Guide 15
4 Preparation
VCAUTION!
Follow the safety instructions in the chapter “Safety instructions” on
page 11.
4.1 Opening the Server Blade
ÊExit all applications and shut down the server blade correctly. If your
operating system has not switched off the server, press the on/off button on
the server blade control panel.
Removing the Server Blade from the system unit
Figure 2: Removing the Server Blade
ÊPush the release lever (1) up slightly to unlock the ejection lever (2).
ÊSwivel the ejection lever down until it is horizontal.
0
/

16 Options Guide BX920 S1
Opening the Server Blade Preparation
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4443-002.fm
ÊPull the server blade out of the system unit.
Removing the cover
Figure 3: Removing the cover
ÊPress the touch point (1) on the cover to disengage the locking mechanism,
and slide the cover as far as it will go in the direction of the arrow (2).
ÊTake off the cover.
The server blade components are now freely accessible.
1
2

BX920 S1 Options Guide 17
5 Processors
VCAUTION!
Follow the safety instructions in the chapter “Safety instructions” on
page 11.
VCAUTION!
Processors are modules which can react extremely sensitively to electro-
static discharges and which must therefore always be handled with care.
After a processor has been removed from its protective sleeve or from its
socket, place it with its smooth side down on a non-conducting, antistatic
surface.
Never push a processor over a surface.
5.1 Installing a second processor
If only one processor is installed in your server blade, you can upgrade it to
include a second one.
VCAUTION!
●Always use processors of the same type. All processors used must
have the same clock frequency, capacity and organization. For multi-
processor mode use a suitable multi-processor operating system.
ÊOpen the server as described in section “Opening the Server Blade” on
page 15.

18 Options Guide BX920 S1
Installing a second processor Processors
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4444-002.fm
Figure 4: Positions of the two CPUs on the system board
Inserting the processor
Figure 5: Releasing the locking lever of the processor socket
ÊPush the locking lever of the processor socket from its locked position
(arrows) and then swivel it up.
CPU 1
CPU 2
1
2

BX920 S1 Options Guide 19
Processors Installing a second processor
Figure 6: Opening the locking frame of the processor socket
ÊOpen the locking frame of the processor socket and remove the black
protective cover (arrow).

20 Options Guide BX920 S1
Installing a second processor Processors
© cognitas. Gesellschft für Technik-Dokumentation mbH 2009 Pfad: C:\Programme\FCT\tim_app\tim_local\work\WALTER\OBJ_DOKU-4444-002.fm
Figure 7: Inserting the processor
ÊPlace the processor on the socket and make sure that you align the
markings on the processor with those on the socket (a).
a
