Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 1 / 7 http://www.fujitsu.com/
Data Sheet
FUJITSU Server PRIMERGY BX920 S3 Dual Socket
Server Blade
Universal dual socket server blade with advanced computing and I/O performance
Datasheet for Red Hat certication
FUJITSU Server PRIMERGY systems provide the
most powerful and exible data center solutions
for companies of all sizes, across all industries
and for any type of workload. This includes
expandable PRIMERGY tower servers for remote
and branch ofces, versatile rack-mount servers,
compact and scalable blade systems, as well as
density-optimized scale-out servers. They convince
by business proven quality with a wide range of
innovations, highest efciency cutting operational
cost and complexity, and provide more agility in
daily operations in order to turn IT faster into a
business advantage.
FUJITSU Server PRIMERGY BX blade systems
are the perfect platform to build a converged
infrastructure designed to reduce IT costs, time
and efforts. PRIMERGY Blade Servers utilizes a
modular architecture and contain in addition to
the compute power, all required infrastructure and
network components, storage capacity as well as
management modules that helps companies to
simplify their infrastructure, achieve signicant
cost reductions and increase exibility.
PRIMERGY BX920 S3
The Fujitsu PRIMERGY BX920 S3 is a dual-socket
server blade which offers the ideal balance of
performance and cost-efciency. It is designed for
large enterprise data centers, midsized businesses
and branch ofces and delivers efcient compute
power that is suitable for mainstream business
applications and virtual client computing
scenarios.
The server blade leverages CPUs of the latest Intel®
Xeon® processor E5-2400 product family utilizing
enhanced QuickPath Interconnect architecture. By
packing two processors, two hot-plug disk drives,
up to 384 GB of DDR3 memory, and a exible
dual-channel 10 Gigabit Converged Network
Adapter on board, the PRIMERGY BX920 S3 server
blade delivers highest performance to ensure
today’s demand while being prepared for future
requirements. In addition, the PRIMERGY BX920
S3 server blade is equipped with the state-of-the-
art integrated Remote Management Controller
(iRMC S3) which enables extensive control even at
remote locations. With its wide range of processor,
disk and memory options, it provides IT managers
with the performance and scalability they need
for all their applications. The optimal and secure
support of I/O-intensive applications like terminal
servers is ensured by the optional use of a RAID
controller with a write-back cache on board,
optionally protected by a Flash Backup Unit.

Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 2 / 7 http://www.fujitsu.com/
Features & Benefits
Main Features Benefits
Memory and Compute Density
Two CPUs with up to 8 cores and 20 MB smart cache, each out of
the latest Intel® Xeon® processor E5-2400 product family. The Intel®
QPI link provides the BX920 S3 with a high-speed bandwidth of up
to 8 GigaTransfers/second (GT/s) between the individual processors
as well as the processors and the up to 12 memory slots, which are
accessed via 3 channels per CPU.
With its wide range of processor, memory and IO options, the server
blade provides IT managers with tunable performance for their
mainstream business applications.
Modular storage connections
Up to two hot-plug HDD/SSD drives. The optimal and secure support
of I/O-intensive applications like terminal servers is ensured by the
optional use of a RAID controller with a write-back cache on board,
optionally protected by a Flash Backup Unit (RAID module does not
consume any slot for I/O mezzanine cards).
High versatility of data access provides choice for the most
appropriate solution in terms of costs, performance, and safety.
Industry-leading management
Save time and conserve valuable IT resources by simplifying remote
management with the integrated Remote Management Controller
(iRMC S3).
Deploy servers quickly, manage virtual or physical server health,
and optimize power consumption with Fujitsu’s ServerView Suite.
Management via the integrated Remote Management Controller
(iRMC S3) enables access to each server and extensive control, even
at remote locations.
Simplied and comprehensive power management with different
selectable power modes results in signicant cost savings.
Peak performance levels on the data highway
The integrated dual-channel 10 Gbit/s Converged Network Adapter
delivers high bandwidth for network intensive applications.
Two PCI Express 3.0 mezzanine slots for a combination of quad
channel 1 Gb or dual channel 10 Gb Ethernet, dual channel 8 Gb
Fibre Channel, dual channel 10 Gb CNA (FCoE), and dual channel 40
or 56 Gb Inniband offer excellent I/O connection options.
The high I/O capacity of the server blade allows optimal use of
multiple I/O protocols, ensuring smooth operations for demanding
applications as well as a balanced operation of virtualized and
physical servers in business-critical environments.

Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 3 / 7 http://www.fujitsu.com/
Technical details
PRIMERGY BX920 S3
Mainboard
Mainboard type D3142
Chipset Intel® C600
Processor quantity and type 1 - 2 x Intel® Xeon® processor E5-2400 product family
Processor Intel® Xeon® processor E5-2403
(4C/4T, 1.80 GHz, TLC: 10 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,066 MHz, 80 W)
Intel® Xeon® processor E5-2407
(4C/4T, 2.20 GHz, TLC: 10 MB, Turbo: No, 6.4 GT/s, Mem bus: 1,066 MHz, 80 W)
Intel® Xeon® processor E5-2420
(6C/12T, 1.90 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 95 W)
Intel® Xeon® processor E5-2430
(6C/12T, 2.20 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 95 W)
Intel® Xeon® processor E5-2430L
(6C/12T, 2.00 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 60 W)
Intel® Xeon® processor E5-2440
(6C/12T, 2.40 GHz, TLC: 15 MB, Turbo: Yes, 7.2 GT/s, Mem bus: 1,333 MHz, 95 W)
Intel® Xeon® processor E5-2450
(8C/16T, 2.10 GHz, TLC: 20 MB, Turbo: Yes, 8.0 GT/s, Mem bus: 1,600 MHz, 95 W)
Intel® Xeon® processor E5-2450L
(8C/16T, 1.80 GHz, TLC: 20 MB, Turbo: Yes, 8.0 GT/s, Mem bus: 1,600 MHz, 70 W)
Intel® Xeon® processor E5-2470
(8C/16T, 2.30 GHz, TLC: 20 MB, Turbo: Yes, 8.0 GT/s, Mem bus: 1,600 MHz, 95 W)
Memory slots 12 (3 channels per CPU with 2 slots each)
Memory slot type DIMM (DDR3) registered
Memory capacity (min. - max.) 4 GB - 384 GB
Memory protection Advanced ECC
Memory Scrubbing
SDDC (Chipkill™)
Memory Mirroring support
Hot-spare memory support
Memory options 4 GB (1 module(s) 4 GB) DDR3 LV, registered, ECC, 1,333 MHz, PC3-10600, DIMM, single rank
4 GB (1 module(s) 4 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
4 GB (1 module(s) 4 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, single rank
8 GB (1 module(s) 8 GB) DDR3 LV, registered, ECC, 1,333 MHz, PC3-10600, DIMM, dual rank
8 GB (1 module(s) 8 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
16 GB (1 module(s) 16 GB) DDR3 LR LV, registered, ECC, 1,333 MHz, PC3-10600, LRDIMM, quad rank
16 GB (1 module(s) 16 GB) DDR3 LV, registered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
32 GB (1 module(s) 32 GB) DDR3 LR LV, registered, ECC, 1,333 MHz, PC3-10600, LRDIMM, quad rank
Memory options 2 GB (1 module(s) 2 GB) DDR3 LV, unbuffered, ECC, 1,600 MHz, PC3-12800, DIMM, single rank
4 GB (1 module(s) 4 GB) DDR3 LV, unbuffered, ECC, 1,600 MHz, PC3-12800, DIMM, dual rank
Interfaces
USB 2.0 ports 5 (4 x USB at the front via special cable)
Graphics (15-pin) 1 x VGA at the front via special cable
Serial connection 1 x RS232 (9-pin) at the front via special cable
LAN / Ethernet (RJ-45) 2 x 10 Gbit CNA via Midplane to Ethernet Connection Blade
Management LAN (RJ45) Management LAN trafc can be switched to shared onboard Gbit LAN port
I/O controller on board
Remote Management Controller Integrated Remote Management Controller (iRMC) incl. graphics controller

Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 4 / 7 http://www.fujitsu.com/
I/O controller on board
Trusted Platform Module (TPM) Inneon / 1.2 (option)
Slots
PCI-Express 3.0 x8 2 x BX900 Mezzanine card
Drive bays
Storage drive bays 2 x 2.5-inch hot-plug SAS/SATA
Operating panel
Operating buttons On/off switch
ID button
Status LEDs Power (amber / green)
System status (orange)
LAN connection (green)
Identication (blue)
CSS (yellow)
BIOS
BIOS features BIOS settings save and restore
Local and remote update via ServerView Update Manager
Remote PXE boot support
SMBIOS V2.6
Online update tools for main Windows and Linux versions
ROM based setup utility
Local BIOS update from USB device
Operating Systems and Virtualization Software
Certied or supported operating
systems and virtualization software
Microsoft® Hyper-V™ Server 2008 R2
Microsoft® Windows Server® 2008 R2 Datacenter
Microsoft® Windows Server® 2008 R2 Enterprise
Microsoft® Windows Server® 2008 R2 Standard
Microsoft® Windows HPC Server® 2008 R2 Suite
Microsoft® Windows® Small Business Server 2011 Premium Add-On
Microsoft® Windows® Small Business Server Standard 2011
Microsoft® Windows® Server 2008 Enterprise
Microsoft® Windows® Server 2008 Standard
VMware vSphere™ 5.0 Embedded
VMware vSphere™ 5.0
VMware vSphere™ 4.1
VMware vSphere™ 4.1 Embedded
VMware vSphere™ 4.1 Installable
VMware vSphere™ 4.0
VMware vSphere™ 4.0 Embedded
VMware vSphere™ 4.0 Installable
SUSE® Linux Enterprise Server 11
SUSE® Linux Enterprise Server 10
SUSE® Linux Enterprise Server 10 with XEN
Red Hat® Enterprise Linux 7
Red Hat® Enterprise Linux 6
Red Hat® Enterprise Linux 5
Red Hat® Enterprise Linux 5 with XEN
Citrix® XenServer®
Operating system release link http://docs.ts.fujitsu.com/dl.aspx?id=d4ebd846-aa0c-478b-8f58-4cfbf3230473
Operating system notes Support of other Linux derivatives on demand

Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 5 / 7 http://www.fujitsu.com/
Server Management
Standard ServerView Suite - Deploy
SV Installation Manager
SV Scripting Toolkit
ServerView Suite - Control
Operations Manager incl. PDA and ASR & R
(Prefailure and Analysis; Automatic Server Recovery and Restart)
Agents and CIM Providers
System Monitor
RAID Manager
Capacity Management
Power Management
Storage Support
ServerView Suite - Maintain
Remote Management (iRMC)
Update Management (BIOS, Firmware, Windows Drives and SV Agents)
Performance Measurement
Asset Management
Online Diagnostics
ServerView Suite - Integrate
Integration packs e.g. for Microsoft System Center, VMware vCenter, Nagios, HP SIM and others
Deployment Solutions and others
Option ServerView VIOM - Virtual IO Manager
Server Management notes Regarding Operating System dependencies for ServerView Suite Software Products see dedicated Product Data sheets.
ServerView VIOM
Dimensions / Weight
Dimensions (W x D x H) 45 x 500 x 210 mm
Weight 7 kg
Weight notes Actual weight may vary depending on conguration
Environmental
Temperature note In accordance with the corresponding PRIMERGY BX900 System Unit
Operating environment FTS 04230 – Guideline for Data Center (installation specication)
Operating environment Link http://docs.ts.fujitsu.com/dl.aspx?id=e4813edf-4a27-461a-8184-983092c12dbe
Electrical values
Compliance
Global CB
RoHS (Restriction of hazardous substances)
WEEE (Waste electrical and electronical equipment)
Germany GS
Europe CE Class A *
Compliance link http://globalsp.ts.fujitsu.com/sites/certicates
Compliance notes In combination with corresponding PRIMERGY BX system unit
There is general compliance with the safety requirements of all European countries and North America. National
approvals required in order to satisfy statutory regulations or for other reasons can be applied for on request.
* Warning:
This is a class A product. In a domestic environment this product may cause radio interference in which case the user
may be required to take adequate measures.

Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 6 / 7 http://www.fujitsu.com/
Components
Storage drives SSD SATA, 3 Gb/s, 32 GB, SLC, hot-plug, 2.5-inch, enterprise
SSD SAS, 6 Gb/s, 200 GB, MLC, hot-plug, 2.5-inch, enterprise
HDD SATA, 6 Gb/s, 500 GB, 7,200 rpm, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 250 GB, 7,200 rpm, hot-plug, 2.5-inch, business critical
HDD SATA, 6 Gb/s, 1 TB, 7,200 rpm, hot-plug, 2.5-inch, business critical
HDD SAS, 6 Gb/s, 900 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 600 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 450 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 300 GB, 15,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 300 GB, 10,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 146 GB, 15,000 rpm, hot-plug, 2.5-inch, enterprise
HDD SAS, 6 Gb/s, 73 GB, 15,000 rpm, hot-plug, 2.5-inch, enterprise
RAID Controller SAS RAID HDD module, 6 Gbit/s, Fujitsu ,
RAID level: 0, 1, 10, 5, 50, 6, 60, 512 MB Cache, Optional FBU (based on LSI SAS2208)
Mezzanine Cards Ethernet Mezzanine Card 4 x 1 Gbit/s PCIe x4 Fujitsu
CNA Mezzanine Card 2 x 10 Gbit/s PCIe 2.0 x8 Emulex
Ethernet Mezzanine Card 2 x 10 Gbit/s PCIe 2.0 x8 Fujitsu
Fibre Channel Mezzanine Card 2 x 8 Gbit/s PCIe 2.0 x8 Emulex
InniBand CX2 Mezzanine Card 2 x 40 Gbit/s PCIe x8 Mellanox
SAS HBA Mezzanine Card 2 x 6 Gbit/s PCIe 2.0 x8 Fujitsu
LAN Controller notes The dual-channel 10 Gbit/s onboard CNA provides 2 additional 1 Gbit/s ports, thus 4 ports in total.
Warranty
Standard Warranty 3 years
Maintenance and Support Services - the perfect extension
Recommended Service 24x7, Onsite Response Time: 4h - For locations outside of EMEA please contact your local Fujitsu partner.
Spare Parts availability 5 years
Service Weblink http://www.fujitsu.com/fts/services/support

Data Sheet FUJITSU Server PRIMERGY BX920 S3 Dual Socket Server Blade
Page 7 / 7 http://www.fujitsu.com/
Contact
FUJITSU LIMITED
Website: www.fujitsu.com
2014-05-21 CE-EN
Fujitsu OPTIMIZATION Services
In addition to Fujitsu PRIMERGY BX920 S3,
Fujitsu provides a range of platform solutions.
They combine reliable Fujitsu products with
the best in services, know-how and worldwide
partnerships.
Fujitsu Portfolio
Build on industry standards, Fujitsu offers a full
portfolio of IT hardware and software products,
services, solutions and cloud offering, ranging
from clients to datacenter solutions and
includes the broad stack of Business Solutions,
as well as the full stack of Cloud offering. This
allows customers to leverage from alternative
sourcing and delivery models to increase
their business agility and to improve their IT
operation’s reliability.
Computing Products
www.fujitsu.com/global/services/computing/
Software
www.fujitsu.com/software/
More information
Learn more about Fujitsu , please contact your
Fujitsu sales representative or Fujitsu
Business partner, or visit our website.
http://www.fujitsu.com/
Fujitsu green policy innovation
Fujitsu Green Policy Innovation is our
worldwide project for reducing burdens on the
environment.
Using our global know-how, we aim to
contribute to the creation of a sustainable
environment for future generations through IT.
Please nd further information at http://www.
fujitsu.com/global/about/environment
Copyrights
All rights reserved, including intellectual
property rights. Changes to technical data
reserved. Delivery subject to availability. Any
liability that the data and illustrations are
complete, actual or correct is excluded.
Designations may be trademarks and/or
copyrights of the respective manufacturer,
the use of which by third parties for their
own purposes may infringe the rights of such
owner.
For further information see http://www.fujitsu.
com/fts/resources/navigation/terms-of-use.
html
Copyright © Fujitsu Technology Solutions
Disclaimer
Technical data are subject to modication and
delivery subject to availability. Any liability
that the data and illustrations are complete,
actual or correct is excluded. Designations
may be trademarks and/or copyrights of the
respective manufacturer, the use of which
by third parties for their own purposes may
infringe the rights of such owner.
More information
All rights reserved, including intellectual property rights. Changes to technical data reserved. Delivery subject to availability.
Any liability that the data and illustrations are complete, actual or correct is excluded.
Designations may be trademarks and/or copyrights of the respective manufacturer, the use of which by third parties for their
own purposes may infringe the rights of such owner.
For further information see http://www.fujitsu.com/fts/resources/navigation/terms-of-use.html
Copyright © Fujitsu Technology Solutions
