Fujitsu PRIMERGY TX300 User manual

PRIMERGY
PRIMERGY TX300
Server System
Operating Manual
Xenia Fierley
FujitsuSiemens Computers GmbH München
81730 München
e-mail: email: [email protected]
Tel.: [phone]
Fax: 0 700 / 372 00000
A26361-K881-Z102-4-7619
Sprachen: De
Edition October 2003

This manual is printed on
paper treated with
chlorine-free bleach.
Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Fax forms for sending us your comments are included in
the back of the manual.
There you will also find the addresses of the relevant
User Documentation Department.
Certified documentation
according DIN EN ISO 9001:2000
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2000.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademar s
Copyright © 2003 Fujitsu Siemens Computers GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.

Introduction
Insta ation Steps Overview
Important Notes
Hardware Insta ation
Preparation for Use and Operation
Property and Data Protection
Troub eshooting and Tips
Hot-p ug/hot-swap Components
Expansions and Conversions
Abbreviations, Reference Section and Index

A26361-K881-Z102-4-7619
Contents
1Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
1.1 Overview of the Documentation . . . . . . . . . . . . . . . . . . 1
1.2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
1.3 Notational Conventions . . . . . . . . . . . . . . . . . . . . . . 8
1.4 Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2 Installation Steps: Overview . . . . . . . . . . . . . . . . . . 11
3 Important Notes . . . . . . . . . . . . . . . . . . . . . . . . 13
3.1 Safety . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.2 CE Certificate . . . . . . . . . . . . . . . . . . . . . . . . . . 19
3.3 FCC Class A Compliance Statement . . . . . . . . . . . . . . 19
3.4 Transporting the Server . . . . . . . . . . . . . . . . . . . . . 20
3.5 Notes on Installing into the Rack . . . . . . . . . . . . . . . . 21
3.6 Environment Protection . . . . . . . . . . . . . . . . . . . . . 22
4 Hardware Installation . . . . . . . . . . . . . . . . . . . . . . 25
4.1 Installation Steps . . . . . . . . . . . . . . . . . . . . . . . . 26
4.2 Unpacking the Server . . . . . . . . . . . . . . . . . . . . . . 26
4.3 Setting Up the Floorstand Model . . . . . . . . . . . . . . . . 27
4.4 Installing/Removing the Rack Model into the Rack . . . . . . . 29
4.4.1 Mounting into the PRIMECENTER Rack . . . . . . . . . . . . 32
4.4.2 Mounting into the DataCenter Rack . . . . . . . . . . . . . . . 36
4.4.3 Mounting into the Classic Rack . . . . . . . . . . . . . . . . . 39
4.4.4 Mounting into 3rd-Party Racks . . . . . . . . . . . . . . . . . . 44
4.4.5 Installing the Server . . . . . . . . . . . . . . . . . . . . . . . 46
4.5 Connecting Devices to Server . . . . . . . . . . . . . . . . . . 49
4.6 Connecting the Server to the Line Voltage . . . . . . . . . . . 51
4.7 Instructions on Connecting and Disconnecting Cables . . . . . 52
5 Preparation for Use and Operation . . . . . . . . . . . . . . 53
5.1 Locking/Unlocking the Floorstand Model . . . . . . . . . . . . 53
5.2 Operating and Indicator Elements . . . . . . . . . . . . . . . . 55
5.2.1 The Front . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
5.2.2 The Rear Side . . . . . . . . . . . . . . . . . . . . . . . . . . 60
5.3 Switching the Server ON and OFF . . . . . . . . . . . . . . . 63
5.4 Starting up Hot-Plug PCI Slots . . . . . . . . . . . . . . . . . 65
5.5 Configuring the Server . . . . . . . . . . . . . . . . . . . . . . 66
5.5.1 Configuration with ServerStart . . . . . . . . . . . . . . . . . . 66
5.5.2 Configuration without ServerStart . . . . . . . . . . . . . . . . 67
5.6 Cleaning the Server . . . . . . . . . . . . . . . . . . . . . . . 68

A26361-K881-Z102-4-7619
Contents
6 Property and Data Protection . . . . . . . . . . . . . . . . . . 69
6.1 BIOS Setup Security Functions . . . . . . . . . . . . . . . . . . 69
7 Troubleshooting and Tips . . . . . . . . . . . . . . . . . . . . 71
7.1 Power-On Indicator Remains Dark . . . . . . . . . . . . . . . . 71
7.2 The Server switches itself OFF . . . . . . . . . . . . . . . . . . 72
7.3 The Monitor Remains Dark . . . . . . . . . . . . . . . . . . . . 72
7.4 Flickering Stripes Across the Monitor . . . . . . . . . . . . . . 73
7.5 No Monitor Display or the Display Drifts . . . . . . . . . . . . . 73
7.6 No Mouse Pointer Displayed on the Monitor . . . . . . . . . . . 73
7.7 The Floppy Disk Cannot be Read or Written . . . . . . . . . . . 74
7.8 Incorrect Time and/or Date . . . . . . . . . . . . . . . . . . . . 74
7.9 System Fails to Boot . . . . . . . . . . . . . . . . . . . . . . . 74
7.10 Drives Are Reported as „Dead“ . . . . . . . . . . . . . . . . . . 75
7.11 Added Drive Reported Defective . . . . . . . . . . . . . . . . . 75
7.12 Hot-Plug PCI Error Indicator Lighting . . . . . . . . . . . . . . . 76
7.13 Hot-Plug PCI Power Indicator not Lighting
after Replacing the Board . . . . . . . . . . . . . . . . . . . . 76
7.14 Error Messages on the Monitor . . . . . . . . . . . . . . . . . . 77
8 Hot-plug/hot-swap Components . . . . . . . . . . . . . . . . 79
8.1 Hot-swap Power Supply Units . . . . . . . . . . . . . . . . . . 79
8.1.1 Adding a hot-swap Power Supply Unit . . . . . . . . . . . . . . 79
8.1.2 Replacing a Hot-swap Power Supply Unit . . . . . . . . . . . . 80
8.2 Hot-swap Hard Disk Drives . . . . . . . . . . . . . . . . . . . . 81
8.2.1 Handling Hard Disk Drives/HDD Modules . . . . . . . . . . . . 81
8.2.2 Installing/Removing Dummy Module . . . . . . . . . . . . . . . 82
8.2.3 Installing/Removing HDD Module . . . . . . . . . . . . . . . . . 83
8.2.4 Hot-swap for HDD Modules . . . . . . . . . . . . . . . . . . . . 87
8.3 Installing/Removing a hot-swap Magnetic Tape Drive . . . . . . 88
8.4 Replacing a Hot-swap System Fan . . . . . . . . . . . . . . . . 90
8.5 Replacing hot-plug PCI Boards . . . . . . . . . . . . . . . . . . 94
8.6 Opening/Closing the Housing . . . . . . . . . . . . . . . . . . . 97
9 Expansions and Conversions . . . . . . . . . . . . . . . . . 99
Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Related Publications . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

A26361-K881-Z102-4-7619 1
1 Introduction
The PRIMERGY TX300 server is an Intel-based server for mid-size networks
and large companies. The server is suitable for use as a file server and also as
an application, information or Internet server. It is available as a floorstand or
rack model. The floorstand model can be converted to a rack model using an
optional conversion kit.
The PRIMERGY TX300 server offers a high level of reliability and availability
through highly developed hardware and software components. These include
hot-swap hard disk drive modules, redundant system fans and power supply
units, and hot-plug PCI slots, the ServerView server management software,
„Prefailure Detection and Analysing“ (PDA) and „Automatic Server Reconfigu-
ration and Restart“ (ASR&R).
The term hot-swap refers to the online replacement of a component (e.g. a
failed hard disk drive, which is configured as a member of a disk array (RAID)).
The term hot-plug refers to the replacement of components while the power is
switched on. In the special case of hot-plug PCI boards it is ensured that the
corresponding PCI slot is powered off before removing the board.
Security functions in the BIOS Setup and on the system board protect the data
on the server against manipulation. Additional security is provided by the
intrusion detection and the lockable drive cover on the floorstand model and/or
the lockable rack door.
The rack model occupies 4 height units (HU) in the rack.
1.1 Overview of the Documentation
IPRIMERGY manuals are available in PDF format on the
ServerBooks CD. The ServerBooks CD is part of the ServerStart Bundle
delivered with each server system.
The PDF files for the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available in the Internet can be found via the URL: http://manuals.fujitsu-
siemens.com (click intel based server/PRIMERGY ServerBooks).

2 A26361-K881-Z102-4-7619
Overview of the Documentation Introduction
Concept and Target Group of this Manual
This operating manual describes how to install, how to operate and how to
expand your server.
This operating manual is intended for those responsible for installing the
hardware and operating the system. The manual contains all the information
required for mounting and operating your PRIMERGY TX300.
To understand the different expansion options, you need a knowledge of
hardware and data transmission, as well as basic knowledge of the operating
system used.
Additional server documentation
To the PRIMERGY TX300 documentation set belong the following additional
manuals:
– “Safety and Ergonomics” manual (print version delivered together with the
system, PDF file available on the ServerBooks CD)
– “Warranty” manual (print version delivered together with the system, PDF file
available on the ServerBooks CD)
– Technical Manual for the system board D1409 (PDF file available on the
ServerBooks CD)
– BIOS Setup manual (PDF file available on the ServerBooks CD)
– “ServerStart Bundle“ includes the ServerStart CD, the ServerBooks CD and
the print version of the manual „ServerStart Bundle“. The PDF file of the
manual is also available on the ServerBooks CD.
– “Adaptec HostRAID User’s Guide“ (PDF file available on the ServerBooks CD)
IIf you need a backup of the ServerBooks-CD send the details of your
server via email address: [email protected].
Further sources of information
– technical manual for the rack
– manual for the monitor
– server management manual ServerView
– manual for the Remote Test and Diagnostic System RemoteView
– in the documentation for the boards and drives
– operating system documentation
– information files of your operating system
(see also “Related Publications” on page 107).

A26361-K881-Z102-4-7619 3
Introduction Features
1.2 Features
System board
The features of the system board (D1409) are described in the technical manual
for the system board in relation to the hardware and in the BIOS setup manual
for the firmware (see “Related Publications” on page 107).
Hot-plug PCI slots
In addition to standard PCI slots, the server also comprises two hot-plug PCI
slots that allow boards to be installed and removed online assuming the
operating system supports this functionality (for further information see section
“Replacing hot-plug PCI Boards” on page 94).
Hard disk drives
The server has a drive cage that can accommodate up to six ULTRA 320-SCSI
hard disk drive modules. Each hard disk drive module (HDD module) can accom-
modate a SCSI hard disk drive with an SCA (Single Connector Attachment)
interface and a maximum height of 1 inch. The module is connected to the SCSI
backplane without cables via the SCA interface. This allows hard disk drive
modules to be simply plugged in or pulled out (for further details see section “Hot-
swap Hard Disk Drives” on page 81).
The hard disk drive system is designed for Ultra3 SCSI and can be configured
as a dual-channel system with three hard disk drives each or as a single-
channel system with six hard disk drives. The hard disk drives can be controlled
by the onboard controller or by a RAID controller.
A HDD extension box can be installed optionally (with a maximum of three HDD
modules). The hard disk drives in the extension box can likewise be controlled
by the onboard controller or by a RAID controller.
If the server has a RAID controller and a corresponding RAID configuration,
defective HDD modules can also be exchanged online (hot-swap).
An external SCSI interface is also offered optionally to allow external storage
subsystems to be connected. You find further information in the configurator
(see “Related Publications” on page 107).

4 A26361-K881-Z102-4-7619
Features Introduction
SCSI controller with HostRAID functionality
For operating internal hard disk drives the 2-channel Ultra320 SCSI controller with
HostRAID functionality is available. In addition to the SCSI functions HostRAID
offers RAID functionality for the internal disk configuration (HostRAID: level 0, 1, 10).
ITo configure HostRAID the controller has its own RAID-Select Utility. For
further information see “Adaptec HostRAID User’s Guide“ on the Server-
Books CD (choose Controllers from the menu).
Zero Channel RAID (ZCR) controller (option)
Optionally a ZCR controller (PCI card) can be installed. In addition to RAID
levels 0, 1, 10 ZCR controller offers the possibility to configure also RAID-5 or
RAID-50. ZCR controller utilizes both channels of the onboard
Ultra320 SCSI
controller using a special integrated logic.
Accessible drives
Various mounting locations are available:
– Three 5.25 inch half-height (1.6 inch) locations for accessible drives (CD-
ROM, DVD-ROM, CD burner or magnetic tape drive) or a LocalView module.
Alternatively, two of these locations can be used to install a 3.2 inch high
accessible drive (magnetic tape drive) or HDD extension box.
– A flexy bay (slot) for a 3.5 inch slimline floppy disk drive (1.44 MB) and a
slimline DVD-ROM drive.
The accessible drives integrated in the 5.25 inch mounting locations cannot be
replaced online.
A hot-swap tape drive can be installed optionally in the drive cage or in the HDD
extension box (see also the configurator under “Related Publications” on
page 107). Two mounting locations are occupied as a result in the drive cage or
in the HDD extension box, which are then no longer available for HDD modules.
This magnetic tape drive can be replaced online.
Power supply
In its basic configuration, the server has a hot-swap wide-range power supply
unit that adjusts automatically to any power voltage in the range from 100 V to
240 V. An additional power supply unit can be installed optionally in order to
ensure redundancy of the power supply. If one power supply unit fails, the

A26361-K881-Z102-4-7619 5
Introduction Features
second power supply unit in the redundant configuration ensures operation can
continue uninterrupted. The defective power supply unit can be replaced online
(for further details see
section “Hot-swap Power Supply Units” on page 79 ).
Ventilation
Every CPU has a heat sink with fan.
The server is cooled by means of the power supply unit fans and by four system
fans (redundant configuration).
The power supply unit fans are assigned to the respective power supply unit.
Four system fans are integrated in the standard system fan configuration. Each
two system fans form a redundant pair.
If one fan in one redundant pair fails, the other fan ensures operation can
continue uninterrupted. A defective system fan can be replaced online
(for
further details see
section “Replacing a Hot-swap System Fan” on page 90).
High level of availability and reliability
When memory data is accessed, 1-bit errors in the main memory are recog-
nized and automatically corrected with the ECC (Error Correcting Code)
method. The patented memory scrubbing function regularly starts up the EDC
mechanism and thus ensures continuous data integrity.
The memory modules used support Chipkill™ technology, which in addition
increases the effectiveness of the monitoring and correction of memory errors.
Support is likewise provided for hot-spare memory technology, in which a
memory bank is used like a replacement bank. If a memory module fails, the
bank with the defective memory is automatically deactivated and the
replacement bank is activated in its place (assuming it has been configured
appropriately in the BIOS). The deactivated memory bank is no longer used and
the faulty memory module can be replaced at the next opportunity. In order to
be able to use the hot-spare memory function, all occupied memory banks must
have an identical memory configuration.
ASR&R (Automatic Server Reconfiguration and Restart) restarts the system in
the case of an error and automatically „hides“ the defective system components.
The PDA (Prefailure Detection and Analyzing) technology from Fujitsu Siemens
Computers analyzes and monitors all components important for system
reliability.

6 A26361-K881-Z102-4-7619
Features Introduction
Optional RAID controllers support RAID Levels 5 and 50 and increase system
availability.
The hot-swap HDD modules provide additional security.
Server management
Server management is implemented with the aid of the supplied ServerView
software and PDA (Prefailure Detection and Analyzing) technology from Fujitsu
Siemens Computers. PDA reports the threat of a system error or overloading
early on so that preventative measures can be taken.
ServerView enables the management of all PRIMERGY servers in the network
via a central console. The following key features are supported among others
by ServerView in this context.
●Remote power-on (Wake On LAN)
●Intrusion detection in the floorstand model
●Temperature monitoring of the CPU and the surrounding area
●Monitoring of the utilization of the PCI buses
●Detailed status and error reports for bus systems, processors and main
memory
●Watchdog timer for Automatic Server Reconfiguration and Restart (ASR&R)
in the event of failure of memory modules or processors
●Power monitoring
●Early detection of a defective fan
●Watchdog timer for operating system monitoring and application monitoring
with ASR&R
Further information on ServerView server management is provided in the
associated documentation (see “Related Publications” on page 107).
ServerStart
You can configure the PRIMERGY server quickly and purposefully with the
ServerStart software provided. User-guided menus are available for installing the
server operating system (for further details see section “Configuring the Server”
on page 66).

A26361-K881-Z102-4-7619 7
Introduction Features
Service and support
PRIMERGY servers are service-friendly and modular, thus enabling quick and
simple maintenance.
The handles and locks (touch points) of the different hot-plug/hot-swap compo-
nents are colored green to ensure simple and immediate recognition.
In order to avoid damage to components by incorrect handling when they are
being installed and removed, green highlighting also identifies the component
areas that can be touched without causing damage to the respective component.
PRIMERGY Diagnostic LEDs arranged on the system board identify the
component (memory module, CPU, CPU fans) on the system board that is not
functioning correctly.
The flash EPROM program supplied with the Fujitsu Siemens Computers
utilities supports a fast BIOS update. The RemoteView remote test and
diagnostics system allows the PRIMERGY TX300 server to be maintained from
remote locations. Remote diagnosis can be performed as a result for system
analysis, remote configuration and remote restart should the operating system
or hardware fail.
RemoteView
RemoteView is the remote management solution from Fujitsu Siemens
Computers for Intel-based PRIMERGY systems. RemoteView 3.0 and the
relevant hardware components integrated on the system board allow remote
monitoring and maintenance as well as fast restoration of operability in the event
of errors.
Remote monitoring and maintenance avoids time-consuming and costly on-site
repairs and reduces service costs. This leads to a reduction in the total cost of
ownership and an excellent return on investment for the remote management
solution.
RemoteView helps
●switch ON/OFF the system remotely
●monitor systems and analyze the cause of faults
●prepare error resolution or to have this process initiated independently if
possible
●identify potential sources of error
●configure the system
●adjust system settings and initiate system restarts from a remote location.

8 A26361-K881-Z102-4-7619
Notational Conventions Introduction
1.3 Notational Conventions
The following notational conventions are used in this manual:
1.4 Technical Data
Electrical data (hot-swap power supply unit)
text in italics indicate commands, menu items or software programs.
„Quotation marks“ indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown
VCAUTION! pay particular attention to texts marked with this
symbol. Failure to observe this warning may endanger
your life, destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips
Table 1: Notational conventions
Power supply unit Wide range
Rated voltage range 100 V - 240 V
Frequency 50 Hz - 60 Hz
Rated current in basic configuration 100 V - 240 V / 2.2 A - 1.0 A
Max. rated current 100 V - 240 V / 6.0 A - 3.0 A
Effective power 477 W
Apparent power 485 VA
Heat dissipation 1719 kJ/h
Main power fuse 16 A
Protection class I

A26361-K881-Z102-4-7619 9
Introduction Technical Data
National and international standards
Mechanical values
Weight
approx. 25 - 40 kg (depending on the configuration)
Ventilation clearance
at least 200 mm on the front and on the rear side
Maintenance area for the floorstand model
1.2 m2on the left side of the server. The maintenance area can be occupied but
must be freely accessible.
Product safety and ergonomics IEC 60950 / EN 60950 / UL 60950 3rd. Ed.,
CAN/CSA-C22.2 No. 60950 3rd. Ed.
Electromagnetic compatibility FCC class A
VCCI class A
AS / NZS 3548 class A
BSMI class A (CNS 13438)
Interference emission EN 55022
Harmonic current EN 6100-3-2 JEIDA
Flicker EN 61000-3-3
Interference immunity EN 55024
CE label
according to EU directives
Low-Voltage Directive 73/23/EEC
Electromagnetic Compatibility 89/336/EEC
(Product safety)
Floorstand Model Rack Model
Width 286 mm (with feet) 444 mm
Total Depth 743 mm 778 mm (with Handles)
Installation Depth ----- 743 mm
Height 473 mm (with feet) 177 mm or 4 HU

10 A26361-K881-Z102-4-7619
Technical Data Introduction
Environmental conditions
Condensation during operation must be avoided!
Noise level
Environment class 3K2
Environment class 2K2
DIN EN 60721 / IEC 721 section 3-3
DIN EN 60721 / IEC 721 section 3-2
Temperature:
Operation (3K2)
Transport (2K2)
10 °C .... 35 °C
-25 °C .... 60 °C
Humidity 10% ... 85%
Sound power level LWAd (ISO 9296) ≤6.5 B (standby)
≤6.7 B (operating)
Sound pressure level at bystander position
LpAm (ISO 9296) ≤50 dB(A) (standby)
≤52 dB(A) (operating)

A26361-K881-Z102-4-7619 11
2 Installation Steps: Overview
In this chapter you will find an overview of the steps necessary to install your
server system. Links guide you to sections where you can find more detailed
information on the individual steps:
ÊAt first, please take notice of chapter “Important Notes” on page 13 and the
following, especially of „Safety“.
ÊUnpack the system, check the contents of the package for visible transport
damage and check whether the delivery agrees with the details in the
delivery note (see section “Unpacking the Server” on page 26).
ÊTransport the server to the place where you want to set it up.
ÊMake sure all necessary manuals (see section “Overview of the Documen-
tation” on page 1) are available; possibly print of the PDF files.
Ê Set up the floorstand model (see section “Setting Up the Floorstand Model” on
page 27) or mount the rack model into the rack (see
section
“Installing/Removing the Rack Model into the Rack” on page 29
).
ÊCable the server. Please also refer to the section “Connecting Devices to
Server” on page 49 and section “Instructions on Connecting and Discon-
necting Cables” on page 52.
ÊConnect the system to the line voltage (see section “Connecting the Server
to the Line Voltage” on page 51).
ÊMake yourself familiar with the operating and indicator elements on the front
and on the rear side of the server (see section “Operating and Indicator
Elements” on page 55).
ÊConfigure and install the desired operating system and applications. To do
so, you have the following possibilities:
– Remote configuration and installation with ServerStart:
With the ServerStart-CD provided, you can configure the server and install
the operating system in a convenient manner.
To find out how to operate ServerStart and for further information, refer to
the corresponding booklet „ServerStart Bundle“.
You find additional information for configuration section “Configuration
with ServerStart” on page 66).

12 A26361-K881-Z102-4-7619
Installation Steps: Overview
– Local configuration and installation with or without ServerStart (see
section “Configuration with ServerStart” on page 66 and/or section
“Configuration without ServerStart” on page 67).
IFor further information on remote or local installation of the server
please refer to the ServerStart manual, which contains a “Quick Step
Guide“ as well as detailed description of the different installation
options and installation wizards. A print version of the ServerStart
manual is included in the ServerStart Bundle, delivered with the
server system. A PDF version of the manual is contained on the
PRIMERGY ServerBooks CD.

A26361-K881-Z102-4-7619 13
3 Important Notes
In this chapter you will find essential information regarding safety when working
with your server.
3.1 Safety
IThe following safety notes are also provided in the “Safety and
Ergonomics” manual, which contains additional information about
ergonomics.
This device complies with the relevant safety regulations for data processing
equipment, including electronic office machines for use in an office environment.
If you have any questions about where you can set up the device, contact your
sales outlet or our customer service team.
VCAUTION!
The actions described in these instructions should only be performed by
technicians, service personnel or technical specialists. Equipment
repairs should only be performed by qualified staff. Any failure to observe
the guidelines in this manual, and any unauthorized openings and
improper repairs could expose the user to risks (electric shock, fire
hazards) and could also damage the equipment. Please note that any
unauthorized openings of the device will result in the invalidation of the
warranty and exclusion from all liability.

14 A26361-K881-Z102-4-7619
Safety Important Notes
Before operating the device
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device (see section
“Technical Data” on page 8).
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the machine.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.
Installation and operation
VCAUTION!
●If the rack model is integrated in an installation that receives power
from an industrial (public) power supply network with the IEC309
connector, the (public) power supply protection must comply with the
requirements for the non-industrial (public) power supply networks for
the type A connector.
●The server automatically sets itself to a voltage in the range of
100 V to 240 V. Make sure that your local voltage is within this range.
●This device has a specially approved power cable and must only be
connected to a grounded insulated socket.
●Ensure that the power socket on the device or the grounded wall
outlet is freely accessible.
●The ON/OFF button does not disconnect the device from the mains
voltage. To disconnect the line voltage completely, remove the power
plug from the grounded insulated socket.
