Fujitsu PRIMERGY RX300 S6 User manual

Options Guide - English
PRIMERGY RX300 S6
Server
Options Guide
Edition July 2010

Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
email: [email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright and Trademarks
Copyright © 2010 Fujitsu Technology Solutions GmbH.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
– The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other
rights arising from the use of any information in this manual.
– No part of this manual may be reproduced in any form without the prior written
permission of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

RX300 S6 Options Guide
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety notes and other important information" and
ensure these safety notes are understood before using the product. Keep this
manual and the manual "Safety notes and other important information" in a safe
place for easy reference while using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the product
is used in a hot environment. The customer shall bear the cost of replacing
replaceable components which have exceeded their operating life. Note that
these are only guidelines, and do not constitute a guarantee of trouble-free
operation during the maintenance support period.
High safety use
This product has been designed and manufactured for general uses such as
general office use, personal use, domestic use and normal industrial use. It has
not been designed or manufactured for uses which demand an extremely high
level of safety and carry a direct and serious risk to life or body if such safety
cannot be ensured.

Options Guide RX 300 S6
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance control
in weapons systems (hereafter, "high safety use"). Customers should not use
this product for high safety use unless measures are in place for ensuring the
level of safety demanded of such use. Please consult the sales staff of Fujitsu if
intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for the Japanese market:
About SATA hard disk drives
The SATA version of this server supports hard disk drives with SATA / BC-SATA
storage interfaces. Please note that the usage and operation conditions differ
depending on the type of hard disk drive used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of hard disk drive:
http://primeserver.fujitsu.com/primergy/harddisk/

RX300 S6 Options Guide
Only for the Japanese market:
IAlthough described in this manual, some sections do not apply to the
Japanese market. These options and routines include:
– Trusted Platform Module (TPM)

Options Guide RX 300 S6

RX300 S6 Options Guide
Content
1 Preface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
1.1 Concept and target groups . . . . . . . . . . . . . . . . . . 12
1.2 Documentation overview . . . . . . . . . . . . . . . . . . . 12
1.3 Expansions and conversions . . . . . . . . . . . . . . . . . 14
1.4 Notational conventions . . . . . . . . . . . . . . . . . . . . 16
2 Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
3 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 19
4 Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
4.1 Removing the server from the rack . . . . . . . . . . . . . . 28
4.2 Opening the server . . . . . . . . . . . . . . . . . . . . . . . 29
4.3 Removing the air duct . . . . . . . . . . . . . . . . . . . . . 30
4.4 Removing the fan box . . . . . . . . . . . . . . . . . . . . . 31
4.5 Removing the power supply cage . . . . . . . . . . . . . . . 32
5 Main memory . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.1 Population rules . . . . . . . . . . . . . . . . . . . . . . . . 36
5.2 Expanding the main memory . . . . . . . . . . . . . . . . . 38
6 Processors . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
6.1 Installing a second processor . . . . . . . . . . . . . . . . . 42
6.2 Replacing the processor . . . . . . . . . . . . . . . . . . . . 49
6.3 Replacing the heat sink . . . . . . . . . . . . . . . . . . . . 52

Options Guide RX 300 S6
Contents
7 Accessible drives and LSP/LSD . . . . . . . . . . . . . . . . 55
7.1 Installing LSP or LSD . . . . . . . . . . . . . . . . . . . . . . 56
7.2 Installing an optical drive . . . . . . . . . . . . . . . . . . . . 61
7.3 USB tape drive/USB RDX drive . . . . . . . . . . . . . . . . . 66
7.3.1 Installing a USB drive in a 6x 3.5" variant . . . . . . . . . . . . . 66
7.3.1.1 Installing a USB drive in a drive cage . . . . . . . . . . . . . 66
7.3.1.2 Installing a USB drive . . . . . . . . . . . . . . . . . . . . . 69
7.3.2 Installing a USB drive in the 8x 2.5" variant . . . . . . . . . . . . 78
7.3.2.1 Installing a USB drive . . . . . . . . . . . . . . . . . . . . . 78
7.3.2.2 Connecting a USB drive . . . . . . . . . . . . . . . . . . . . 81
8 Expansion cards and BBU . . . . . . . . . . . . . . . . . . . 89
8.1 Installing expansion cards . . . . . . . . . . . . . . . . . . . 90
8.2 Upgrading a SAS/SATA RAID controller . . . . . . . . . . . . 91
8.3 Installing a BBU . . . . . . . . . . . . . . . . . . . . . . . . . 95
9 Further options . . . . . . . . . . . . . . . . . . . . . . . . 103
9.1 T-handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
9.2 Front video connector (VGA) . . . . . . . . . . . . . . . . . 104
9.3 TPM . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
9.4 USB Flash Module (UFM) . . . . . . . . . . . . . . . . . . . 112
10 Completion . . . . . . . . . . . . . . . . . . . . . . . . . . . 115
10.1 Installing a fan box . . . . . . . . . . . . . . . . . . . . . . 115
10.2 Installing a power supply cage . . . . . . . . . . . . . . . . 116
10.3 Inserting the air duct . . . . . . . . . . . . . . . . . . . . . 118
10.4 Closing the server . . . . . . . . . . . . . . . . . . . . . . . 119
10.5 Installing the server in the rack . . . . . . . . . . . . . . . . 120

RX300 S6 Options Guide
Contents
11 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.1 Cable list . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
11.2 Cabling plans . . . . . . . . . . . . . . . . . . . . . . . . . . 125
11.3 Configuration schema . . . . . . . . . . . . . . . . . . . . . 130
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131

Options Guide RX 300 S6
Contents

RX300 S6 Options Guide 11
1 Preface
The PRIMERGY RX300 S6 rack server is a universal and high-performance
platform designed for a whole range of application areas in data center and
server farm concepts. The system was developed specifically for configurations
with multiple servers (clusters), front-end solutions, e-commerce applications
and ERP solutions. The PRIMERGY RX300 S6 is ideal for applications and
operational areas that require maximum scalability, performance and availability
in a space-saving rack cabinet.
The PRIMERGY RX300 S6 offers a balanced architecture that incorporates
next generation main memory (DDR3) and I/O technologies (PCIe Gen2). The
backplanes for 6*3.5",8*2.5" and 12*2.5"hard disk drives are already provided
for SAS 2.0 and 6 Gbit/s SAS and the chipset prepared for the next generation
of 6-core processors. High performance, scalability, impressive reliability and
excellent extension options are combined in a powerful design.
The Cool-safe™ cooling concept with improved air flow cooling technology
(honeycomb design) ensures the highest possible performance of the
processors at work; at the same time, the system is extremely reliable thanks to
the reduced heat dissipation.
The server occupies just two height units (HU) in the rack.
Security functions in the BIOS Setup and on the system board protect the data
on the server against manipulation. Additional security is provided by the
lockable rack door.

12 Options Guide RX 300 S6
Concept and target groups
1.1 Concept and target groups
This Options Guide shows you how to extend and upgrade your server.
VCAUTION!
The activities described in this manual may only be performed by
technical specialists.
IThe installation and removal of the hot-plug components is described in
the Operating Manual supplied with the server.
1.2 Documentation overview
More information on your PRIMERGY RX300 S6 can be found in the following
documents:
– "Quick Start Hardware - PRIMERGY RX300 S6" leaflet
"はじめにお読みください -PRIMERGY RX300 S6" for theJapanese market
(only included as a printed copy)
– "Quick Start Software - Quick Installation Guide" DVD booklet
(only included with the PRIMERGY ServerView Suite as a printed copy)
except for the Japanese market
– "Safety notes and other important information" manual
"安全上の注意およびその他の重要情報 " for the Japanese market
– "Warranty" manual
"保証書 " for the Japanese market
– "PRIMERGY ServerView Suite Local Service Concept - LSC" manual
– "Returning used devices" manual and "Service Desk" leaflet
"サポート＆サービス " for the Japanese market
– "PRIMERGY RX300 S6 Server Operating Manual"
– "PRIMERGY RX300 S6 Server Options Guide"
– "System Board D2619-N for PRIMERGY RX/TX300 S6 Technical Manual"
– "D2619-N BIOS Setup Utility for PRIMERGY RX300 S6 and TX300 S6"
manual

RX300 S6 Options Guide 13
Documentation overview
IPRIMERGY manuals are available in PDF format on the PRIMERGY
ServerView Suite DVD 2. The PRIMERGY ServerView Suite DVD 2 is
part of the PRIMERGY ServerView Suite supplied with every server.
If you no longer have the ServerView Suite DVDs, you can obtain the
relevant current versions using the order number U15000-C289 (the
order number for the Japanese market: please refer to the configurator
of the server http://primeserver.fujitsu.com/primergy/system.html).
The PDF files of the manuals can also be downloaded free of charge
from the Internet. The overview page showing the online documentation
available on the Internet can be found using the URL (for EMEA market):
http://manuals.ts.fujitsu.com. The PRIMERGY server documentation can
be accessed using the Industry standard servers navigation option.
For the Japanese market please use the URL:
http://primeserver.fujitsu.com/primergy/manual.html.
Further sources of information:
– PRIMERGY Abbreviations and Glossary on the PRIMERGY
ServerView Suite DVD 2
– Manual for the monitor
– Documentation for the boards and drives
– Operating system documentation
– Information files in your operating system

14 Options Guide RX 300 S6
Expansions and conversions
1.3 Expansions and conversions
Main memory
The system board offers 18 slots for memory modules. 9 memory slots can be
used in mono processor configurations.
ECC with memory scrubbing and the Single Device Data Correction (SDDC)
function is standard.
There are three modes of operation for the main memory:
– Independent Channel Mode / Performance Mode (recommended)
– Mirrored Channel Mode
– Spare Channel Mode
Depending on the mode of operation there are different population
requirements.
Second processor
The system board can be upgraded with a second processor. Only processors
of the same type may be used on the system board. That means the number of
the internal processor cores as well as the primary clock and the FSB frequency
have to be the same. For dual operation, use a suitable multiprocessor
operating system.
Accessible drives
A number of mounting locations are available:
– one bay for a ServerView Local Service Panel (optional) or a ServerView
Local Service Display (optional)
– one bay for a slimline optical drive (option)
IThe accessible drives integrated in these bays cannot be replaced during
operation.
In a 6x 3.5" or 8x 2.5" HDD configuration, a USB magnetic tape drive or a USB
RDX drive can be optionally installed in the right drive cage.
IIn a 6x 3.5" HDD configuration, two bays are occupied in the drive cage.
These bays are no longer available for HDD modules.
The magnetic tape drive or the RDX drive cannot be replaced during
operation.

RX300 S6 Options Guide 15
Expansions and conversions
LSD/LSP
The system board supports the CSS (Customer Self Service) functionality
(description see the Operating Manual). You can install a ServerView Local
Service Display (LSD) or ServerView Local Service Panel (LSP) for an easier
identification of the defective components.
Additional expansion cards in the PCI Express slots
The system board offers seven PCI Express slots. Slots 1-5 are connected as
x4 interfaces, whereby slot 3 and slot 5 are used as x8 interfaces if slot 2 and
slot 4 are empty.
ISlot 1 is the preferred slot for the SAS/SATA RAID controller (bootable).
Slot 5 and slot 7 allow the mechanical installation of x16 PCIe expansion
cards. The bus width is restricted to 8 lanes.
Battery Backup Unit
A Battery Backup Unit (BBU) backs up the memory contents of the SAS/SATA
RAID controller in the event of a power failure. One BBU can be installed for
each SAS/SATA RAID controller (max. 2 BBUs can be installed in one system).
T-handles on the front cover
The T-handles can be installed optionally.
IIn the figures of this manual the option T-handles is installed.
Trusted Platform Module (TPM)
A Trusted Platform Module (TPM) for safer storage of keys can be implemented
as an option. This module enables programs from third party manufacturers to
store key information (e.g. drive encryption using Windows Bitlocker Drive
Encryption).
The TPM is activated via the BIOS system (for more information, refer to the
"D2619-N BIOS Setup Utility for PRIMERGY RX300 S6 and TX300 S6"
manual).
VCAUTION!
– When using the TPM, note the program descriptions provided by the
third party manufacturers.

16 Options Guide RX 300 S6
Notational conventions
– You must also create a backup of the TPM content. To do this, follow
the third party manufacturer's instructions. Without this backup, if the
TPM or the system board is faulty you will not be able to access your
data.
– If a failure occurs, please inform your service about the TPM
activation before it takes any action, and be prepared to provide them
with your backup copies of the TPM content.
USB Flash Module (UFM) (option)
The system board is equipped with a UFM slot by the manufacturer.
IThe "internal USB stick" and the "UFM" slots must not be used in parallel.
Either an internal USB stick or a UFM may be used.
1.4 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items.
"Quotation marks" indicate names of chapters and terms that are being
emphasized.
Êdescribes activities that must be performed in the order
shown.
VCAUTION! pay particular attention to texts marked with this symbol.
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips.

RX300 S6 Options Guide 17
2Procedure
VCAUTION!
●The actions described in this manual shall be performed by technical
specialists. A technical specialist is a person who is trained to install
the server including hardware and software.
●Repairs to the device that do not relate to CSS failures shall be
performed by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
ÊFirst of all, carefully read the safety instructions in the chapter "Safety
instructions" on page 19.
ÊMake sure that all necessary manuals (see the section "Documentation
overview" on page 12) are available; print the PDF files if required. Most
importantly, you will need the Operating Manual for the server and the
Technical Manual for the system board.
ÊShut the server down correctly, switch it off, disconnect the power cords and
open the server as described in the chapter "Preparation" on page 27.
ÊCarry out the expansion or upgrade of your server as described in the
pertinent chapter.
IInstallation and removal of the hot-plug components are described in
the Operating Manual.
ÊClose the server, connect it to the power outlet, and switch it on as described
in the chapter "Completion" on page 115.
ÊStart the operating system and make the appropriate configuration if
necessary (see the Operating Manual).
IFor the latest information on optional products provided for the RX300 S6
see the configurator of this server:
https://sp.ts.fujitsu.com/dmsp/docs/cnfgrx300s6.pdf

18 Options Guide RX 300 S6

RX300 S6 Options Guide 19
3 Safety instructions
IThe following safety instructions are also provided in the manual "Safety
notes and other important information".
This device meets the relevant safety regulations for IT equipment. If you have
any questions about whether you can install the server in the intended
environment, please contact your sales outlet or our customer service team.
VCAUTION!
●The actions described in this manual shall be performed by technical
specialists. A technical specialist is a person who is trained to install
the server including hardware and software.
●Repairs to the device that do not relate to CSS failures shall be
performed by service personnel. Please note that unauthorized
interference with the system will void the warranty and exempt the
manufacturer from all liability.
●Any failure to observe the guidelines in this manual, and any improper
repairs could expose the user to risks (electric shock, energy
hazards, fire hazards) or damage the equipment.
●Before installing/removing internal options to/from the server, turn off
the server, all peripheral devices, and any other connected devices.
Also unplug all power cords from the power outlet. Failure to do so
can cause electric shock.
Before starting up
VCAUTION!
●During installation and before operating the device, observe the
instructions on environmental conditions for your device.
●If the device is brought in from a cold environment, condensation may
form both inside and on the outside of the device.
Wait until the device has acclimatized to room temperature and is
absolutely dry before starting it up. Material damage may be caused
to the device if this requirement is not observed.
●Transport the device only in the original packaging or in packaging
that protects it from knocks and jolts.

20 Options Guide RX 300 S6
Installation and operation
VCAUTION!
●This unit should not be operated in ambient temperatures above
35 °C.
●If the unit is integrated into an installation that draws power from an
industrial power supply network with an IEC309 connector, the power
supply's fuse protection must comply with the requirements for non-
industrial power supply networks for type A connectors.
●The unit automatically adjusts itself to a mains voltage in a range of
100 V - 240 V. Ensure that the local mains voltage lies within these
limits.
●This device must only be connected to properly grounded power
outlets or insulated sockets of the rack's internal power supply with
tested and approved power cords.
●Ensure that the device is connected to a properly grounded power
outlet close to the device.
