Fujitsu PRIMERGY CX400 M4 User manual

Upgrade and Maintenance Manual - English
FUJITSU Server PRIMERGY CX400 M4
Server Enclosure
Upgrade and Maintenance Manual
Edition March 2018

Copyright and Trademarks
Comments…Suggestions…Corrections…
The User Documentation Department would like to
know your opinion of this manual. Your feedback helps
us optimize our documentation to suit your individual
needs.
Feel free to send us your comments by e-mail to
[email protected].
Certified documentation
according to DIN EN ISO 9001:2008
To ensure a consistently high quality standard and
user-friendliness, this documentation was created to
meet the regulations of a quality management system
which complies with the requirements of the standard
DIN EN ISO 9001:2008.
cognitas. Gesellschaft für Technik-Dokumentation mbH
www.cognitas.de
Copyright 2018 FUJITSU LIMITED.
All rights reserved.
Delivery subject to availability; right of technical modifications reserved.
All hardware and software names used are trademarks of their respective manufacturers.
–The contents of this manual may be revised without prior notice.
– Fujitsu assumes no liability for damages to third party copyrights or other rights arising
from the use of any information in this manual.
–No part of this manual may be reproduced in any form without the prior written
permission of Fujitsu.
Microsoft, Windows, Windows Server, and Hyper V are trademarks or registered trademarks of
Microsoft Corporation in the USA and other countries.
Intel and Xeon are trademarks or registered trademarks of Intel Corporation or its subsidiaries
in the USA and other countries.

CX400 M4 Upgrade and Maintenance Manual
Before reading this manual
For your safety
This manual contains important information for safely and correctly using this
product.
Carefully read the manual before using this product. Pay particular attention to
the accompanying manual "Safety Notes and Regulations" and ensure these
safety notes are understood before using the product. Keep this manual and the
manual "Safety Notes and Regulations" in a safe place for easy reference while
using this product.
Radio interference
This product is a "Class A" ITE (Information Technology Equipment). In a
domestic environment this product may cause radio interference, in which case
the user may be required to take appropriate measures. VCCI-A
Aluminum electrolytic capacitors
The aluminum electrolytic capacitors used in the product's printed circuit board
assemblies and in the mouse and keyboard are limited-life components. Use of
these components beyond their operating life may result in electrolyte leakage
or depletion, potentially causing emission of foul odor or smoke.
As a guideline, in a normal office environment (25°C) operating life is not
expected to be reached within the maintenance support period (5 years).
However, operating life may be reached more quickly if, for example, the
product is used in a hot environment. The customer shall bear the cost of
replacing replaceable components which have exceeded their operating life.
Note that these are only guidelines, and do not constitute a guarantee of
trouble-free operation during the maintenance support period.
High safety use
This product has been designed and manufactured to be used in commercial
and/or industrial areas as a server.
When used as visual display workplace, it must not be placed in the direct field
of view to avoid incommoding reflections (applies only to TX server systems).
The device has not been designed or manufactured for uses which demand an
extremely high level of safety and carry a direct and serious risk of life or body
if such safety cannot be assured.

Upgrade and Maintenance Manual CX400 M4
These uses include control of nuclear reactions in nuclear power plants,
automatic airplane flight control, air traffic control, traffic control in mass
transport systems, medical devices for life support, and missile guidance
control in weapons systems (hereafter, "high safety use"). Customers should
not use this product for high safety use unless measures are in place for
ensuring the level of safety demanded of such use. Please consult the sales
staff of Fujitsu if intending to use this product for high safety use.
Measures against momentary voltage drop
This product may be affected by a momentary voltage drop in the power supply
caused by lightning. To prevent a momentary voltage drop, use of an AC
uninterruptible power supply is recommended.
(This notice follows the guidelines of Voltage Dip Immunity of Personal
Computer issued by JEITA, the Japan Electronics and Information Technology
Industries Association.)
Technology controlled by the Foreign Exchange and Foreign Trade
Control Law of Japan
Documents produced by Fujitsu may contain technology controlled by the
Foreign Exchange and Foreign Trade Control Law of Japan. Documents which
contain such technology should not be exported from Japan or transferred to
non-residents of Japan without first obtaining authorization in accordance with
the above law.
Harmonic Current Standards
This product conforms to harmonic current standard JIS C 61000-3-2.
Only for Japan: About SATA HDDs
The SATA version of this server supports HDDs with SATA / BC-SATA storage
interfaces. Please note that the usage and operation conditions differ
depending on the type of HDD used.
Please refer to the following internet address for further information on the
usage and operation conditions of each available type of HDD:
http://jp.fujitsu.com/platform/server/primergy/harddisk/

CX400 M4 Upgrade and Maintenance Manual
Version history
Issue number Reason for update
1.0 / March 2017 Initial release
1.1 / May 2017 Final version
1.2 / June 2017 Final version
1.3 / July 2017 Final version
2.0 / November 2017 Update version
3.0 / March 2018 Update version

Upgrade and Maintenance Manual CX400 M4

CX400 M4 Upgrade and Maintenance Manual
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
1.1 Notational conventions . . . . . . . . . . . . . . . . . . . . 14
2 Before you start . . . . . . . . . . . . . . . . . . . . . . . . 15
2.1 Classification of procedures . . . . . . . . . . . . . . . . . 16
2.1.1 Customer Replaceable Units (CRU) . . . . . . . . . . . . . . . 16
2.1.2 Upgrade and Repair Units (URU) . . . . . . . . . . . . . . . . 17
2.1.3 Field Replaceable Units (FRU) . . . . . . . . . . . . . . . . . 18
2.2 Average task duration . . . . . . . . . . . . . . . . . . . . . 19
2.3 Tools you need at hand . . . . . . . . . . . . . . . . . . . . 20
2.4 Documents you need at hand . . . . . . . . . . . . . . . . . 21
2.4.1 Documents for the server enclosure . . . . . . . . . . . . . . . 22
2.4.2 Documents for the server nodes . . . . . . . . . . . . . . . . . 24
3 Important information . . . . . . . . . . . . . . . . . . . . . 25
3.1 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . 25
3.2 ENERGY STAR . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.3 CE conformity . . . . . . . . . . . . . . . . . . . . . . . . . 34
3.4 Environmental protection . . . . . . . . . . . . . . . . . . . 35
4 Basic hardware procedures . . . . . . . . . . . . . . . . . . 37
4.1 Using diagnostics information . . . . . . . . . . . . . . . . 37
4.1.1 Locating the defective server . . . . . . . . . . . . . . . . . . 37
4.1.2 Determining the error class . . . . . . . . . . . . . . . . . . . 38
4.1.2.1 Customer Self Service (CSS) indicator . . . . . . . . . . . 38
4.1.2.2 Global Error indicator . . . . . . . . . . . . . . . . . . . . 39
4.1.3 Locating the defective component . . . . . . . . . . . . . . . . 39
4.1.3.1 Local diagnostic indicators on the front . . . . . . . . . . . 39
4.2 Shutting down the server node . . . . . . . . . . . . . . . . 40

Upgrade and Maintenance Manual CX400 M4
Contents
4.3 Disconnecting the power cord . . . . . . . . . . . . . . . . . 41
4.4 Extending/removing the server enclosure out of the rack . . 42
4.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . . 42
4.4.2 Extending the server enclosure out of the rack . . . . . . . . . . 43
4.4.3 Removing the server enclosure out of the rack . . . . . . . . . . 43
4.5 Removing server nodes from the server enclosure . . . . . . 46
4.5.1 Removing the CX2550 M4 / CX2560 M4 server node . . . . . . 46
4.5.2 Removing the CX2570 M4 server node . . . . . . . . . . . . . 48
4.6 Removing the server node dummy module . . . . . . . . . . 49
4.7 Opening the server enclosure . . . . . . . . . . . . . . . . . 50
4.7.1 Opening the fan cover . . . . . . . . . . . . . . . . . . . . . . 50
4.7.2 Opening the midplane cover . . . . . . . . . . . . . . . . . . . 51
4.8 Closing the server enclosure . . . . . . . . . . . . . . . . . . 51
4.8.1 Installing the midplane cover . . . . . . . . . . . . . . . . . . . 52
4.8.2 Installing the fan cover . . . . . . . . . . . . . . . . . . . . . . 53
4.9 Installing the server node dummy module . . . . . . . . . . . 54
4.10 Installing the server node in the server enclosure . . . . . . 55
4.10.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . . . 55
4.10.2 Installing the CX2550 M4/CX2560 M4 server node . . . . . . . 58
4.10.3 Installing the CX2570 M4 server node . . . . . . . . . . . . . . 60
4.11 Mounting the server enclosure in the rack . . . . . . . . . . 61
4.11.1 Removing the inner rail from the carrier rails . . . . . . . . . . . 61
4.11.2 Attaching the carrier rails to the server enclosure . . . . . . . . 63
4.11.3 Installing the carrier rails . . . . . . . . . . . . . . . . . . . . . 64
4.11.4 Lift the server into the rack cabinet . . . . . . . . . . . . . . . . 65
4.12 Installing the cable management arm (CMA) . . . . . . . . . 69
4.13 Connecting the power cord . . . . . . . . . . . . . . . . . . . 71
4.14 Switching on the server node(s) . . . . . . . . . . . . . . . . 72
5 Basic software procedures . . . . . . . . . . . . . . . . . . . 73
5.1 Starting the maintenance task . . . . . . . . . . . . . . . . . 73
5.1.1 Switching on the ID indicator . . . . . . . . . . . . . . . . . . . 73
5.2 Completing the maintenance task . . . . . . . . . . . . . . . 74
5.2.1 Switching off the ID indicator . . . . . . . . . . . . . . . . . . . 74
5.2.2 Verifying system information backup / restore . . . . . . . . . . 75

CX400 M4 Upgrade and Maintenance Manual
Contents
5.2.3 Performing a RAID array rebuild . . . . . . . . . . . . . . . . . 75
5.2.4 Using the Chassis ID Prom Tool . . . . . . . . . . . . . . . . . 76
5.2.5 Viewing and clearing the System Event Log (SEL) . . . . . . . 77
5.2.5.1 Viewing the SEL . . . . . . . . . . . . . . . . . . . . . . . 77
5.2.5.2 Clearing the SEL . . . . . . . . . . . . . . . . . . . . . . . 78
5.2.6 Performing a fan test . . . . . . . . . . . . . . . . . . . . . . 79
5.2.7 Updating ServerView RAID Manager . . . . . . . . . . . . . . 80
6 Power supply unit (PSU) . . . . . . . . . . . . . . . . . . . . 81
6.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 81
6.1.1 General equipping rules . . . . . . . . . . . . . . . . . . . . . 82
6.2 Replacing the hot-plug PSU . . . . . . . . . . . . . . . . . . 83
6.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 83
6.2.2 Removing the hot-plug PSU . . . . . . . . . . . . . . . . . . 84
6.2.3 Installing the hot-plug PSU . . . . . . . . . . . . . . . . . . . 85
6.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 86
6.3 Removing and installing the PSU dummy module . . . . . . 87
6.3.1 Removing the PSU dummy module . . . . . . . . . . . . . . . 87
6.3.2 Installing the PSU dummy module . . . . . . . . . . . . . . . . 88
7 Hard disk drives (HDD), solid state drives (SSD) and 2.5-inch
PCIe-SSD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
7.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 90
7.1.1 General equipping rules . . . . . . . . . . . . . . . . . . . . . 90
7.1.2 HDD/SSD install order . . . . . . . . . . . . . . . . . . . . . . 91
7.1.3 HDD/SSD backplane types . . . . . . . . . . . . . . . . . . . 92
7.1.4 HDD/SSD cage bezels . . . . . . . . . . . . . . . . . . . . . 94
7.2 Installing 2.5-inch HDD/SSD modules . . . . . . . . . . . . . 95
7.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 95
7.2.2 Removing a 2.5-inch HDD/SSD dummy module . . . . . . . . 96
7.2.3 Installing a 2.5-inch HDD/SSD module . . . . . . . . . . . . . 97
7.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 97
7.3 Removing 2.5-inch HDD/SSD modules . . . . . . . . . . . . 98
7.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 98
7.3.2 Removing a 2.5-inch HDD/SSD module . . . . . . . . . . . . . 99
7.3.3 Installing a 2.5-inch HDD/SSD dummy module . . . . . . . . . 100

Upgrade and Maintenance Manual CX400 M4
Contents
7.4 Replacing a 2.5-inch HDD/SSD module . . . . . . . . . . . 101
7.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 102
7.4.2 Removing a 2.5-inch HDD/SSD module . . . . . . . . . . . . 102
7.4.3 Installing a 2.5-inch HDD/SSD module . . . . . . . . . . . . . 102
7.4.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 102
7.5 Replacing the 2.5-inch HDD/SSD SAS/SATA backplane . . 103
7.5.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 103
7.5.2 Removing the fan modules cage . . . . . . . . . . . . . . . . 104
7.5.3 Removing the 2.5-inch HDD/SSD backplane . . . . . . . . . . 105
7.5.4 Installing the 2.5-inch HDD/SSD backplane . . . . . . . . . . 106
7.5.5 Installing the fan modules cage . . . . . . . . . . . . . . . . . 107
7.5.6 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 110
7.6 Installing the HDD/SSD bridge board . . . . . . . . . . . . 111
7.6.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 111
7.6.2 Installing the HDD/SSD bridge board . . . . . . . . . . . . . . 112
7.6.3 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 113
7.7 Replacing the HDD/SSD bridge board . . . . . . . . . . . . 114
7.7.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 114
7.7.2 Removing the HDD/SSD bridge board . . . . . . . . . . . . . 115
7.7.3 Installing the HDD/SSD bridge board . . . . . . . . . . . . . . 116
7.7.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 117
7.8 Changing HDD/SSD cage bezels . . . . . . . . . . . . . . . 118
7.8.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 118
7.8.2 Removing the HDD/SSD x6 front bezel . . . . . . . . . . . . . 119
7.8.3 Removing the HDD/SSD x6 front bezel (screw type) . . . . . . 120
7.8.4 Removing the HDD/SSD x4 front bezel . . . . . . . . . . . . . 121
7.8.5 Installing the HDD/SSD x6 front bezel . . . . . . . . . . . . . 122
7.8.6 Installing the HDD/SSD x6 front bezel (screw type) . . . . . . 122
7.8.7 Installing the HDD/SSD x4 front bezel . . . . . . . . . . . . . 124
7.8.8 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 125
8 System fan module . . . . . . . . . . . . . . . . . . . . . . 127
8.1 Basic Information . . . . . . . . . . . . . . . . . . . . . . . 128
8.2 Replacing the system fan module . . . . . . . . . . . . . . 130
8.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 130
8.2.2 Removing the fan module . . . . . . . . . . . . . . . . . . . . 131
8.2.3 Installing the fan module . . . . . . . . . . . . . . . . . . . . 133
8.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 141

CX400 M4 Upgrade and Maintenance Manual
Contents
8.3 Replacing the fan cable . . . . . . . . . . . . . . . . . . . . 142
8.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 142
8.3.2 Disconnecting the fan cable . . . . . . . . . . . . . . . . . . . 143
8.3.3 Connecting the fan cable . . . . . . . . . . . . . . . . . . . . 144
8.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 148
9 Midplane kit . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
9.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 150
9.2 Replacing the midplane kit . . . . . . . . . . . . . . . . . . 151
9.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 151
9.2.2 Removing the midplane kit . . . . . . . . . . . . . . . . . . . 152
9.2.3 Installing the midplane kit . . . . . . . . . . . . . . . . . . . . 153
9.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 155
10 Front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . 157
10.1 Basic information . . . . . . . . . . . . . . . . . . . . . . . 158
10.2 Replacing the left front panel . . . . . . . . . . . . . . . . . 159
10.2.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 159
10.2.2 Removing the front panel . . . . . . . . . . . . . . . . . . . . 160
10.2.3 Installing the front panel . . . . . . . . . . . . . . . . . . . . . 162
10.2.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 163
10.3 Replacing the right front panel . . . . . . . . . . . . . . . . 164
10.3.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 164
10.3.2 Removing the front panel . . . . . . . . . . . . . . . . . . . . 164
10.3.3 Installing the front panel . . . . . . . . . . . . . . . . . . . . . 166
10.3.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 167
10.4 Replacing the left front panel cable . . . . . . . . . . . . . . 168
10.4.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 168
10.4.2 Removing the front panel cable . . . . . . . . . . . . . . . . . 169
10.4.3 Installing the front panel cable . . . . . . . . . . . . . . . . . . 170
10.4.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 171
10.5 Replacing the right front panel cable . . . . . . . . . . . . . 172
10.5.1 Preliminary steps . . . . . . . . . . . . . . . . . . . . . . . . 172
10.5.2 Removing the front panel cable . . . . . . . . . . . . . . . . . 173
10.5.3 Installing the front panel cable . . . . . . . . . . . . . . . . . . 174
10.5.4 Concluding steps . . . . . . . . . . . . . . . . . . . . . . . . 175

Upgrade and Maintenance Manual CX400 M4
Contents
11 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
11.1 Cabling overview . . . . . . . . . . . . . . . . . . . . . . . 177
11.2 Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 178
12 Appendix . . . . . . . . . . . . . . . . . . . . . . . . . . . . 179
12.1 Mechanical overview . . . . . . . . . . . . . . . . . . . . . 179
12.1.1 Server enclosure front . . . . . . . . . . . . . . . . . . . . . 179
12.1.2 Rear overview with CX2550 M4 / CX2560 M4 server nodes . . 180
12.1.3 Rear overview with CX2570 M4 server nodes . . . . . . . . . 181
12.1.4 Enclosure interior . . . . . . . . . . . . . . . . . . . . . . . . 182
12.2 Controls and indicators . . . . . . . . . . . . . . . . . . . . 183
12.2.1 Controls and indicators on the front of the server enclosure . . 183
12.2.1.1 Indicators on the front panel (enclosure-related) . . . . . . 185
12.2.1.2 Indicators on the front panel (node-related) . . . . . . . . . 187
12.2.1.3 ID card . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
12.2.1.4 Indicators on the HDDs . . . . . . . . . . . . . . . . . . . 191
12.2.2 Indicator on hot-plug PSU . . . . . . . . . . . . . . . . . . . 192
12.2.3 Fan indicators . . . . . . . . . . . . . . . . . . . . . . . . . . 193
12.2.4 Indicators of the server nodes . . . . . . . . . . . . . . . . . 193
12.3 Minimum startup configuration . . . . . . . . . . . . . . . . 194

CX400 M4 Upgrade and Maintenance Manual 13
1 Introduction
This Upgrade and Maintenance Manual provides instructions for the following
procedures:
●Upgrading the server configuration by adding optional hardware
components
●Upgrading the server configuration by replacing existing hardware
components with superior ones.
●Replacing defective hardware components
This manual focuses on on-site maintenance tasks. It is recommended to
prepare each service assignment following remote diagnostics procedures, as
described in the "ServerView Suite Local Service Concept (LSC)" manual (see
section "Documents you need at hand" on page 21.
VCAUTION!
The document at hand comprises procedures of a wide range of
complexity. Check the profile of qualification for technicians before
assigning tasks. Before you start, carefully read "Classification of
procedures" on page 16.

14 Upgrade and Maintenance Manual CX400 M4
Introduction
1.1 Notational conventions
The following notational conventions are used in this manual:
Text in italics indicates commands or menu items
fixed font indicates system output
semi-bold fixed
font
indicates text to be entered by the user
"Quotation marks" indicate names of chapters and terms that are being
emphasized
Êdescribes activities that must be performed in the order
shown
[Abc] indicates keys on the keyboard
VCAUTION! Pay particular attention to texts marked with this symbol!
Failure to observe this warning may endanger your life,
destroy the system or lead to the loss of data.
Iindicates additional information, notes and tips
indicates the procedure category in terms of complexity
and qualification requirements, see "Classification of
procedures" on page 16
indicates the average task duration, see "Average task
duration" on page 19

CX400 M4 Upgrade and Maintenance Manual 15
2 Before you start
Before you start any upgrade or maintenance task, please proceed as follows:
ÊCarefully read the safety instructions in chapter "Important information" on
page 25.
ÊMake sure that all necessary manuals are available. Refer to the
documentation overview in section "Documents you need at hand" on
page 21. Print the PDF files if required.
ÊMake yourself familiar with the procedure categories introduced in section
"Classification of procedures" on page 16.
ÊEnsure that all required tools are available according to section "Tools you
need at hand" on page 20.
Installing optional components
The "PRIMERGY CX400 M4 Server Enclosure Operating Manual" gives an
introduction to server features and provides an overview of available hardware
options.
Use the Fujitsu ServerView Suite management software to prepare hardware
expansions. ServerView Suite documentation is available online at
http://manuals.ts.fujitsu.com (http://jp.fujitsu.com/platform/server/primergy/system/
for Japan). Please refer to the following ServerView Suite topics:
– Operation
– Tools for Service & Diagnostics
– Virtualization
IFor the latest information on hardware options, refer to your server’s
hardware configurator available online at the following address:
http://ts.fujitsu.com/products/standard_servers/index.html
For Japan:
http://jp.fujitsu.com/platform/server/primergy/system/
Please contact your local Fujitsu customer service partner for details on how to
order expansion kits or spare parts. Use the Fujitsu Illustrated Spares Catalog
to identify the required spare part and obtain technical data and order
information. Illustrated Spares catalogs are available online at
http://manuals.ts.fujitsu.com/illustrated_spares .

16 Upgrade and Maintenance Manual CX400 M4
Before you start
2.1 Classification of procedures
The complexity of maintenance procedures varies significantly. Procedures
have been assigned to one of three unit categories, indicating the level of
difficulty and required qualification.
At the beginning of each procedure, the involved unit type is indicated by one of
the symbols introduced in this section.
IPlease ask your local Fujitsu service center for more detailed
information.
2.1.1 Customer Replaceable Units (CRU)
Customer Replaceable Units are intended for customer self service and may be
installed or replaced as hot-plug components during operation.
IComponents that the customer is entitled to replace may differ according
to the service form in his country.
Hot-plug components increase system availability and guarantee a high degree
of data integrity and fail-safe performance. Procedures can be carried out
without shutting down the server or going offline.
Components that are handled as Customer Replaceable Units
– Hot-plug PSUs
– Hot-plug HDD/SSD modules
Peripherals that are handled as Customer Replaceable Units
– None
Customer Replaceable Units (CRU)

CX400 M4 Upgrade and Maintenance Manual 17
Before you start
2.1.2 Upgrade and Repair Units (URU)
Upgrade and Repair Units are non hot-plug components that can be ordered
separately to be installed as options (Upgrade Units) or are available to the
customer through customer self service (Repair Units).
IFor Japan, customer allows only upgrade. For upgrade units as
customer replaceable, please refer to:
http://www.fujitsu.com/jp/products/computing/servers/primergy/
IServer management error messages and diagnostic indicators on the
front panel and system board will report defective Upgrade and Repair
Units as customer replaceable CSS components.
Upgrade and repair procedures involve shutting down and opening the server.
VCAUTION!
The device may be seriously damaged or cause damage if it is opened
without authorization or if repairs are attempted by unauthorized and
untrained personnel.
Components that are handled as Upgrade Units
– HDD/SSD bridge board
VCAUTION!
Installing procedures involving this units must be performed exclusively
by Fujitsu service personnel or technicians trained by Fujitsu. Please
note that unauthorized interference with the system will void the warranty
and exempt the manufacturer from all liability.
Components that are handled solely as Repair Units
– None
Upgrade and Repair Units (URU)

18 Upgrade and Maintenance Manual CX400 M4
Before you start
2.1.3 Field Replaceable Units (FRU)
Removing and installing Field Replaceable Units involves complex
maintenance procedures on integral server components. Procedures will
require shutting down, opening and disassembling the server.
VCAUTION!
Maintenance procedures involving Field Replaceable Units must be
performed exclusively by Fujitsu service personnel or technicians trained
by Fujitsu. Please note that unauthorized interference with the system
will void the warranty and exempt the manufacturer from all liability.
Components that are handled as Field Replaceable Units
– SAS / SATA backplanes
– Fan module
– Fan cable
– Midplane kit
– Front panel
– Front panel cable
IPlease ask your local Fujitsu service center for more detailed
information.
Field Replaceable Units (FRU)

CX400 M4 Upgrade and Maintenance Manual 19
Before you start
2.2 Average task duration
The average task duration including preliminary and concluding steps is
indicated at the beginning of each procedure next to the procedure class.
Refer to table 1 on page 19 for an overview of steps taken into account for
calculating the average task duration:
Average task duration: 10 minutes
Step included Explanation
Server shutdown no
Shutdown time depends on hardware and
software configuration and may vary
significantly.
Software tasks necessary before
maintenance are described in section
"Starting the maintenance task" on
page 73".
Rack removal,
disassembly yes Making the server available, removing the server from the rack (if applicable)
Transport no
Transporting the server to the service table
(where required) depends on local
customer conditions.
Maintenance
procedures yes Maintenance procedures including preliminary and concluding software tasks
Transport no
Returning the server to its installation site
(where required) depends on local
customer conditions.
Assembly,
rack installation yes Reassembling the server, installing the server in the rack (if applicable)
Starting up no
Booting time depends on hardware and
software configuration and may vary
significantly.
Table 1: Calculation of the average task duration

20 Upgrade and Maintenance Manual CX400 M4
Before you start
2.3 Tools you need at hand
When preparing the maintenance task, ensure that all required tools are
available according to the overview below. You will find a list of required tools at
the beginning of each procedure.
List of used screws for Japan
Screw driver /
Bit insert Screw Usage Type
Phillips
PH2 / (+) No. 2
Enclosure
cover
HDD/SSD x4
front bezel
M3 x 6 mm
countersink
C26192-Y10-C111
Phillips
PH2 / (+) No. 2
hexagonal cross
SW5 / PZ2
Fan modules
cage
HDD/SSD
bridge board
Midplane kit
M3 x 4.5 mm
C26192-Y10-C67
Table 2: List of required tools and used screws for the 2.5-inch chassis
Screw driver /
Bit insert Screw Usage Type
Phillips
PH2 / (+) No. 2
Enclosure
cover
HDD/SSD x4
front bezel
M3 x 6 mm
countersink
Phillips
PH2 / (+) No. 2
hexagonal cross
SW5 / PZ2
Fan modules
cage
HDD/SSD
bridge board
Midplane kit
M3 x 5 mm
with spring and
washer
F6-SW2N3-05121
Table 3: List of required tools and used screws for the 2.5-inch chassis
