Fujitsu ETERNUS DX100 S4 Technical manual

FUJITSU Storage
ETERNUS DX100 S4/DX200 S4,
ETERNUS DX100 S3/DX200 S3
Hybrid Storage Systems
Site Planning Guide
Requirements for transportation/installation
P3AM-7632-18ENZ0

Table of Contents
1. ETERNUS DX Installation 7
Installation Specifications............................................................................................................... 7
ETERNUS DX100 S4..................................................................................................................................................7
ETERNUS DX100 S3................................................................................................................................................10
ETERNUS DX200 S4................................................................................................................................................13
ETERNUS DX200 S3................................................................................................................................................16
Storage System Dimensions.......................................................................................................... 19
Compliance Standards .................................................................................................................. 24
Package Size ................................................................................................................................. 25
Installation Area ........................................................................................................................... 26
Installation Environment .............................................................................................................. 28
Installation of the ETERNUS DX in High Altitude Locations....................................................................................28
Air Conditioning ....................................................................................................................................................28
Installation Methods.............................................................................................................................................29
Load Bearing Capacity for Floors ...........................................................................................................................29
Outlet/Socket Specifications.......................................................................................................... 29
Specifications for Optional Power Supply Products ................................................................................................30
Required Number of Outlets/Sockets.....................................................................................................................35
Circuit Protectors ...................................................................................................................................................35
Input Power Supply Lines ......................................................................................................................................41
2. Rack Installation Specifications 43
Rack Installation Requirements .................................................................................................... 43
Placement in the Rack ..........................................................................................................................................43
Cable Connection ..................................................................................................................................................44
Installable Racks........................................................................................................................... 54
Fujitsu Racks .........................................................................................................................................................54
Non-Fujitsu Racks .................................................................................................................................................54
2
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

List of Figures
Figure 1 2.5" Type Controller Enclosure Dimensions...............................................................................................19
Figure 2 3.5" Type Controller Enclosure Dimensions...............................................................................................20
Figure 3 2.5" Type Drive Enclosure Dimensions......................................................................................................21
Figure 4 3.5" Type Drive Enclosure Dimensions......................................................................................................22
Figure 5 High-Density Drive Enclosure Dimensions................................................................................................23
Figure 6 Installation Area and Service Area............................................................................................................26
Figure 7 Installation and Service Areas (When a High-Density Drive Enclosure Is Installed_1) ..............................26
Figure 8 Installation and Service Areas (When a High-Density Drive Enclosure Is Installed_2) ..............................27
Figure 9 Service Area (When a High-Density Drive Enclosure Is Installed in the Top Part of the Rack) ...................27
Figure 10 Power Distribution Units (AC8A/200-240V, 1U, 4 Outlets, 2 Inlets) ..........................................................32
Figure 11 Power Distribution Units (AC24A/200-240V, 1U, 4 Outlets, 1 Inlet)..........................................................32
Figure 12 Power Distribution Units (2U) ..................................................................................................................33
Figure 13 Power Distribution Units (2U) ..................................................................................................................34
Figure 14 Breaking Characteristics of Distribution Board Circuit Protectors ..............................................................36
Figure 15 Example of a Power Supply Connection When a Power Distribution Unit (1U) Is Used .............................37
Figure 16 Example of a Power Supply Connection When a Power Distribution Unit (2U) Is Used .............................38
Figure 17 Example of a Power Supply Connection When a Power Distribution Unit Is Not Used...............................40
Figure 18 Dual-Line Power Supply (When Connecting to Power Sockets).................................................................41
Figure 19 Dual-Line Power Supply (When Connecting to a UPS Unit).......................................................................41
Figure 20 Single-Line Power Supply (When Connecting to Power Sockets) ..............................................................42
Figure 21 Single-Line Power Supply (When Connecting to a UPS Unit) ....................................................................42
Figure 22 Single-Line Power Supply (When Connecting to a Power Socket and a UPS Unit).....................................42
Figure 23 Distance between Each Enclosure and the Power Distribution Unit (Example) ........................................44
Figure 24 AC Cable Connection.................................................................................................................................45
Figure 25 Connection Example 1 (2U DE Connections in the Same Rack) ................................................................48
Figure 26 Connection Example 2 (Connections in Multiple Racks)...........................................................................49
Figure 27 Connection Example 3 (2U DE Connections in the Same Rack) ................................................................50
Figure 28 Connection Example 4 (4U DE Connections in the Same Rack) ................................................................51
Figure 29 Connection Example 5 (Connections When 2U and 4U DEs Are Used Together in the Same Rack)...........52
Figure 30 Connection Example 6 (Connections in Multiple Racks)...........................................................................53
Figure 31 Unit Installation Area ...............................................................................................................................55
3
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

List of Tables
Table 1 ETERNUS DX100 S4 Installation Specifications ...........................................................................................7
Table 2 Efficiency and Power Factor of the Power Supply Unit (ETERNUS DX100 S4) ............................................10
Table 3 ETERNUS DX100 S3 Installation Specifications .........................................................................................10
Table 4 ETERNUS DX200 S4 Installation Specifications .........................................................................................13
Table 5 Efficiency and Power Factor of the Power Supply Unit (ETERNUS DX200 S4) ............................................15
Table 6 ETERNUS DX200 S3 Installation Specifications .........................................................................................16
Table 7 Package Size (for Regions other than the EMEIA, Central American, and Caribbean Regions) .................25
Table 8 Current Consumption of Each Power Cord.................................................................................................30
Table 9 Specifications for AC200V Power Cords (for the EMEIA, Central American, and Caribbean Regions) .........30
Table 10 Specifications for AC200V Power Cords (for Regions other than the EMEIA, Central American, and Carib-
bean Regions)..........................................................................................................................................31
Table 11 Specifications for AC125V Power Cords (for Regions other than the EMEIA, Central American, and Carib-
bean Regions)..........................................................................................................................................31
Table 12 Specifications for AC100V and AC200V Power Cords (for Regions other than the EMEIA, Central American,
and Caribbean Regions)...........................................................................................................................31
Table 13 Specifications for Power Distribution Units (AC8A/200-240V, 1U, 4 Outlets, 2 Inlets)...............................32
Table 14 Specifications for Power Distribution Units (AC24A/200-240V, 1U, 4 Outlets, 1 Inlet) ..............................32
Table 15 Power Distribution Unit (AC200-240V, 2U, 12 Outlets) Specifications ......................................................33
Table 16 Power Distribution Unit (AC200-240V, 2U, 16 Outlets) Specifications ......................................................33
Table 17 Power Distribution Unit (AC16A/200-240V, 2U, 16 Outlets) Specifications ...............................................34
Table 18 Power Distribution Unit (AC24A/200-240V, 2U, 16 Outlets) Specifications ...............................................34
Table 19 Required Conditions for Distribution Board Circuit Protectors...................................................................35
Table 20 Enclosure Installation Order .....................................................................................................................43
Table 21 Cable Lengths When Connecting Each Enclosure to the Power Distribution Unit......................................44
Table 22 Usage of Cables for Connecting Enclosures...............................................................................................47
Table 23 Specifications for the Unit Installation Area .............................................................................................55
4
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Preface
Fujitsu would like to thank you for purchasing the FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS
DX100 S3/DX200 S3 (hereinafter collectively referred to as ETERNUS DX).
The ETERNUS DX is designed to be connected to Fujitsu servers (Fujitsu SPARC Servers, PRIMEQUEST, PRIMERGY,
and other servers) or non-Fujitsu servers.
This manual describes the environmental requirements that are necessary to install and use the ETERNUS DX.
This manual is intended for use of the ETERNUS DX in regions other than Japan.
Please carefully review the information outlined in this manual.
Eighteenth Edition
June 2021
Trademarks
Third-party trademark information related to this product is available at:
https://www.fujitsu.com/global/products/computing/storage/eternus/trademarks.html
About This Manual
Intended Audience
This manual is intended for managers of facilities where the ETERNUS DX is installed.
Related Information and Documents
The latest version of this manual and the latest information for your model are available at:
https://www.fujitsu.com/global/support/products/computing/storage/manuals-list.html
Document Conventions
■Third-Party Product Names
•Oracle Solaris may be referred to as "Solaris", "Solaris Operating System", or "Solaris OS".
•Microsoft® Windows Server® may be referred to as "Windows Server".
■Notice Symbols
The following notice symbols are used in this manual:
Indicates information that you need to observe when using the ETERNUS storage system.
Make sure to read the information.
Indicates information and suggestions that supplement the descriptions included in this
manual.
5
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Warning Signs
Warning signs are shown throughout this manual in order to prevent injury to the user and/or material damage.
These signs are composed of a symbol and a message describing the recommended level of caution. The follow-
ing explains the symbol, its level of caution, and its meaning as used in this manual.
This symbol indicates the possibility of serious or fatal injury if the ETERNUS DX is not used
properly.
This symbol indicates the possibility of minor or moderate personal injury, as well as dam-
age to the ETERNUS DX and/or to other users and their property, if the ETERNUS DX is not
used properly.
This symbol indicates IMPORTANT information for the user to note when using the ETERNUS
DX.
The following symbols are used to indicate the type of warnings or cautions being described.
The triangle emphasizes the urgency of the WARNING and CAUTION contents. Inside the
triangle and above it are details concerning the symbol (e.g. Electrical Shock).
The barred "Do Not..." circle warns against certain actions. The action which must be
avoided is both illustrated inside the barred circle and written above it (e.g. No Disassem-
bly).
The black "Must Do..." circle indicates actions that must be taken. The required action is
both illustrated inside the black disk and written above it (e.g. Unplug).
How Warnings are Presented in This Manual
A message is written beside the symbol indicating the caution level. This message is marked with a vertical rib-
bon in the left margin, to distinguish this warning from ordinary descriptions.
A display example is shown here.
Warning level indicator
Warning type indicator
Warning details
•To avoid damaging the ETERNUS storage system, pay attention to the
following points when cleaning the ETERNUS storage system:
Warning layout ribbon
Example warning
- Make sure to disconnect the power when cleaning.
- Be careful that no liquid seeps into the ETERNUS storage system
when using cleaners, etc.
- Do not use alcohol or other solvents to clean the ETERNUS storage system.
CAUTION Do
Preface
6
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

1. ETERNUS DX Installation
This chapter provides the installation specification of the ETERNUS DX.
Installation Specifications
ETERNUS DX100 S4
Table 1 shows the installation specifications of the ETERNUS DX100 S4 and Table 2 shows the efficiency and the
power factor of the power supply unit.
Table 1 ETERNUS DX100 S4 Installation Specifications
Item ETERNUS DX100 S4
Dimensions
(W ´ D ´ H)
Controller enclosure 2.5" type 482 ´ 645 ´ 88mm (2U)
3.5" type 482 ´ 670 ´ 88mm (2U)
Drive enclosure 2.5" type 482 ´ 540 ´ 88mm (2U)
3.5" type 482 ´ 560 ´ 88mm (2U)
High-density type 482 ´ 980 ´ 176mm (4U)
Power distribution unit (*1) 1U 435 ´ 148 ´ 38mm (*2),
482 ´ 111 ´ 44mm (*3)
2U (*4) (485 ´ 280 ´ 43mm) ´ 2 (*5),
(485 ´ 123 ´ 44mm) ´ 2 (*6)
Maximum weight
(*7)
Controller enclosure 2.5" type 35kg
3.5" type 35kg
Drive enclosure 2.5" type 35kg
3.5" type 35kg
High-density type 100kg
Power distribution unit (*1) 1U 2.0kg (*2),
2.5kg (*3)
2U (*4) (6.0kg) ´ 2 (*5),
(3.0kg) ´ 2 (*6)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
7
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Item ETERNUS DX100 S4
Maximum power
consumption (*7)
Controller enclosure 2.5" type AC 100 – 120V 770W (780VA)
AC 200 – 240V 770W (780VA)
3.5" type AC 100 – 120V 670W (680VA)
AC 200 – 240V 670W (680VA)
Drive enclosure 2.5" type AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
3.5" type AC 100 – 120V 340W (350VA)
AC 200 – 240V 340W (350VA)
High-density type AC 100 – 120V 1,300W (1,320VA)
AC 200 – 240V 1,300W (1,320VA)
Maximum heat
generation
(*7)
Controller enclosure 2.5" type AC 100 – 120V 2,800kJ/h
AC 200 – 240V 2,800kJ/h
3.5" type AC 100 – 120V 2,500kJ/h
AC 200 – 240V 2,500kJ/h
Drive enclosure 2.5" type AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
3.5" type AC 100 – 120V 1,300kJ/h
AC 200 – 240V 1,300kJ/h
High-density type AC 100 – 120V 4,700kJ/h
AC 200 – 240V 4,700kJ/h
Maximum amount
of exhaust air
Controller enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
Drive enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
High-density type 12.0m3/min
1. ETERNUS DX Installation
Installation Specifications
8
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Item ETERNUS DX100 S4
Environmental con-
ditions
Temperature Operating 10 – 40°C
Not operating 0 – 50°C
Shipping -40 – 60°C
Temperature gradient 15°C/Hr or less
Humidity Operating 20 – 80%RH
Not operating 8 – 80%RH
Shipping 8 – 90%RH
Humidity gradient 30%/day or less
Maximum wet bulb temperature 29°C
Altitude above sea level 0 – 3,000m
Airborne dust 0.15mg/m3 or less
Gas concentration tolerance level Cl2: 6.8ppb or less, H2S: 7.1ppb or less,
SO2: 37ppb or less,
NH3: 423.5ppb or less,
NO2: 52ppb or less, O3: 5ppb or less,
HCl: 6.6ppb or less, HF: 3.6ppb or less
Oil vapor 0.2mg/m3 or less
Seawater (salt corrosion) If the storage system is installed on the
ocean or premises within 0.5km from the
coast, necessary measures must be taken
to prevent salt corrosion.
Vibration limit Operating 400gal
Not operating 1,000gal
Noise emission
(*8)
Sound pressure level 49dB (A)
Sound power level 6.7B
*1: For power distribution units, there are multiple types of exteriors. For details, refer to "Specifications for
Optional Power Supply Products" (page 30).
*2: These values are for product ID ETFP4BU-L.
*3: These values are for product ID ETFP4DU-L.
*4: A 2U power distribution unit is composed of two 1U power distribution units.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
*7: These values are for each drive enclosure when 24 drives are installed in a 2.5" type drive enclosure, 12
drives are installed in a 3.5" type drive enclosure, or 60 drives are installed in a high-density drive enclo-
sure.
*8: These values are measured when a single controller enclosure and a single drive enclosure are configured
in an environment in which the temperature is 23 ± 2°C at 0 meters above sea level.
1. ETERNUS DX Installation
Installation Specifications
9
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Table 2 Efficiency and Power Factor of the Power Supply Unit (ETERNUS DX100 S4)
Component name 80PLUS®Efficiency Power fac-
tor Output
20% (*1) 50% (*1) 100% (*1) 50% (*1)
Controller enclosure 2.5" type GOLD (*2) 89.3% 92.5% 90.2% 0.975 Multiple output
3.5" type
Drive enclosure 2.5" type 89.3% 92.5% 90.2% 0.975
3.5" type
High-den-
sity type
90.1% 92.4% 90.3% 0.975
*1: Indicates the rated load against the rated output of the PSU.
*2: 80PLUS® GOLD certified power supply units are used. 80PLUS® is a power saving program for electrical
equipment promoted by the 80PLUS® program.
ETERNUS DX100 S3
The following table shows the installation specifications of the ETERNUS DX100 S3.
Table 3 ETERNUS DX100 S3 Installation Specifications
Item ETERNUS DX100 S3
Dimensions
(W ´ D ´ H)
Controller enclosure 2.5" type 482 ´ 645 ´ 88mm (2U)
3.5" type 482 ´ 670 ´ 88mm (2U)
Drive enclosure 2.5" type 482 ´ 540 ´ 88mm (2U)
3.5" type 482 ´ 560 ´ 88mm (2U)
High-density type 482 ´ 980 ´ 176mm (4U)
Power distribution unit (*1) 1U 435 ´ 148 ´ 38mm (*2),
482 ´ 111 ´ 44mm (*3)
2U (*4) (485 ´ 280 ´ 43mm) ´ 2 (*5),
(485 ´ 123 ´ 44mm) ´ 2 (*6)
Maximum weight
(*7)
Controller enclosure 2.5" type 35kg
3.5" type 35kg
Drive enclosure 2.5" type 35kg
3.5" type 35kg
High-density type 100kg
Power distribution unit (*1) 1U 2.0kg (*2),
2.5kg (*3)
2U (*4) (6.0kg) ´ 2 (*5),
(3.0kg) ´ 2 (*6)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
1. ETERNUS DX Installation
Installation Specifications
10
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Item ETERNUS DX100 S3
Maximum power
consumption (*7)
Controller enclosure 2.5" type AC 100 – 120V 770W (780VA)
AC 200 – 240V 770W (780VA)
3.5" type AC 100 – 120V 670W (680VA)
AC 200 – 240V 670W (680VA)
Drive enclosure 2.5" type AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
3.5" type AC 100 – 120V 340W (350VA)
AC 200 – 240V 340W (350VA)
High-density type AC 100 – 120V 1,300W (1,320VA)
AC 200 – 240V 1,300W (1,320VA)
Maximum heat
generation
(*7)
Controller enclosure 2.5" type AC 100 – 120V 2,800kJ/h
AC 200 – 240V 2,800kJ/h
3.5" type AC 100 – 120V 2,500kJ/h
AC 200 – 240V 2,500kJ/h
Drive enclosure 2.5" type AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
3.5" type AC 100 – 120V 1,300kJ/h
AC 200 – 240V 1,300kJ/h
High-density type AC 100 – 120V 4,700kJ/h
AC 200 – 240V 4,700kJ/h
Maximum amount
of exhaust air
Controller enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
Drive enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
High-density type 12.0m3/min
1. ETERNUS DX Installation
Installation Specifications
11
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Item ETERNUS DX100 S3
Environmental con-
ditions
Temperature Operating 10 – 40°C
Not operating 0 – 50°C
Shipping -40 – 60°C
Temperature gradient 15°C/Hr or less
Humidity Operating 20 – 80%RH
Not operating 8 – 80%RH
Shipping 8 – 90%RH
Humidity gradient 30%/day or less
Maximum wet bulb temperature 29°C
Altitude above sea level 0 – 3,000m
Airborne dust 0.15mg/m3 or less
Gas concentration tolerance level Cl2: 6.8ppb or less, H2S: 7.1ppb or less,
SO2: 37ppb or less,
NH3: 423.5ppb or less,
NO2: 52ppb or less, O3: 5ppb or less,
HCl: 6.6ppb or less, HF: 3.6ppb or less
Oil vapor 0.2mg/m3 or less
Seawater (salt corrosion) If the ETERNUS DX is installed on the ocean
or premises within 0.5km from the coast,
necessary measures must be taken to pre-
vent salt corrosion.
Vibration limit Operating 400gal
Not operating 1,000gal
Noise emission
(*8)
Sound pressure level 49dB (A)
Sound power level 6.7B
*1: For power distribution units, there are multiple types of exteriors. For details, refer to "Specifications for
Optional Power Supply Products" (page 30).
*2: These values are for product ID ETFP4BU-L.
*3: These values are for product ID ETFP4DU-L.
*4: A 2U power distribution unit is composed of two 1U power distribution units.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
*7: These values are for each drive enclosure when 24 drives are installed in a 2.5" type drive enclosure, 12
drives are installed in a 3.5" type drive enclosure, or 60 drives are installed in a high-density drive enclo-
sure.
*8: These values are measured when a single controller enclosure and a single drive enclosure are configured
in an environment in which the temperature is 23 ± 2°C at 0 meters above sea level.
1. ETERNUS DX Installation
Installation Specifications
12
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

ETERNUS DX200 S4
Table 4 shows the installation specifications of the ETERNUS DX200 S4 and Table 5 shows the efficiency and the
power factor of the power supply unit.
Table 4 ETERNUS DX200 S4 Installation Specifications
Item ETERNUS DX200 S4
Dimensions
(W ´ D ´ H)
Controller enclosure 2.5" type 482 ´ 645 ´ 88mm (2U)
3.5" type 482 ´ 670 ´ 88mm (2U)
Drive enclosure 2.5" type 482 ´ 540 ´ 88mm (2U)
3.5" type 482 ´ 560 ´ 88mm (2U)
High-density type 482 ´ 980 ´ 176mm (4U)
Power distribution unit (*1) 1U 435 ´ 148 ´ 38mm (*2),
482 ´ 111 ´ 44mm (*3)
2U (*4) (485 ´ 280 ´ 43mm) ´ 2 (*5),
(485 ´ 123 ´ 44mm) ´ 2 (*6)
Maximum weight
(*7)
Controller enclosure 2.5" type 35kg
3.5" type 35kg
Drive enclosure 2.5" type 35kg
3.5" type 35kg
High-density type 100kg
Power distribution unit (*1) 1U 2.0kg (*2),
2.5kg (*3)
2U (*4) (6.0kg) ´ 2 (*5),
(3.0kg) ´ 2 (*6)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
Maximum power
consumption (*7)
Controller enclosure 2.5" type AC 100 – 120V 850W (860VA)
AC 200 – 240V 850W (860VA)
3.5" type AC 100 – 120V 780W (790VA)
AC 200 – 240V 780W (790VA)
Drive enclosure 2.5" type AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
3.5" type AC 100 – 120V 340W (350VA)
AC 200 – 240V 340W (350VA)
High-density type AC 100 – 120V 1,300W (1,320VA)
AC 200 – 240V 1,300W (1,320VA)
1. ETERNUS DX Installation
Installation Specifications
13
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Item ETERNUS DX200 S4
Maximum heat
generation
(*7)
Controller enclosure 2.5" type AC 100 – 120V 3,100kJ/h
AC 200 – 240V 3,100kJ/h
3.5" type AC 100 – 120V 2,900kJ/h
AC 200 – 240V 2,900kJ/h
Drive enclosure 2.5" type AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
3.5" type AC 100 – 120V 1,300kJ/h
AC 200 – 240V 1,300kJ/h
High-density type AC 100 – 120V 4,700kJ/h
AC 200 – 240V 4,700kJ/h
Maximum amount
of exhaust air
Controller enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
Drive enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
High-density type 12.0m3/min
Environmental con-
ditions
Temperature Operating 10 – 40°C
Not operating 0 – 50°C
Shipping -40 – 60°C
Temperature gradient 15°C/Hr or less
Humidity Operating 20 – 80%RH
Not operating 8 – 80%RH
Shipping 8 – 90%RH
Humidity gradient 30%/day or less
Maximum wet bulb temperature 29°C
Altitude above sea level 0 – 3,000m
Airborne dust 0.15mg/m3 or less
Gas concentration tolerance level Cl2: 6.8ppb or less, H2S: 7.1ppb or less,
SO2: 37ppb or less,
NH3: 423.5ppb or less,
NO2: 52ppb or less, O3: 5ppb or less,
HCl: 6.6ppb or less, HF: 3.6ppb or less
Oil vapor 0.2mg/m3 or less
Seawater (salt corrosion) If the storage system is installed on the
ocean or premises within 0.5km from the
coast, necessary measures must be taken
to prevent salt corrosion.
Vibration limit Operating 400gal
Not operating 1,000gal
Noise emission
(*8)
Sound pressure level 49dB (A)
Sound power level 6.7B
1. ETERNUS DX Installation
Installation Specifications
14
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

*1: For power distribution units, there are multiple types of exteriors. For details, refer to "Specifications for
Optional Power Supply Products" (page 30).
*2: These values are for product ID ETFP4BU-L.
*3: These values are for product ID ETFP4DU-L.
*4: A 2U power distribution unit is composed of two 1U power distribution units.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
*7: These values are for each drive enclosure when 24 drives are installed in a 2.5" type drive enclosure, 12
drives are installed in a 3.5" type drive enclosure, or 60 drives are installed in a high-density drive enclo-
sure.
*8: These values are measured when a single controller enclosure and a single drive enclosure are configured
in an environment in which the temperature is 23 ± 2°C at 0 meters above sea level.
Table 5 Efficiency and Power Factor of the Power Supply Unit (ETERNUS DX200 S4)
Component name 80PLUS®Efficiency Power fac-
tor Output
20% (*1) 50% (*1) 100% (*1) 50% (*1)
Controller enclosure 2.5" type GOLD (*2) 89.3% 92.5% 90.2% 0.975 Multiple output
3.5" type
Drive enclosure 2.5" type 89.3% 92.5% 90.2% 0.975
3.5" type
High-den-
sity type
90.1% 92.4% 90.3% 0.975
*1: Indicates the rated load against the rated output of the PSU.
*2: 80PLUS® GOLD certified power supply units are used. 80PLUS® is a power saving program for electrical
equipment promoted by the 80PLUS® program.
1. ETERNUS DX Installation
Installation Specifications
15
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

ETERNUS DX200 S3
The following table shows the installation specifications of the ETERNUS DX200 S3.
Table 6 ETERNUS DX200 S3 Installation Specifications
Item ETERNUS DX200 S3
Dimensions
(W ´ D ´ H)
Controller enclosure 2.5" type 482 ´ 645 ´ 88mm (2U)
3.5" type 482 ´ 670 ´ 88mm (2U)
Drive enclosure 2.5" type 482 ´ 540 ´ 88mm (2U)
3.5" type 482 ´ 560 ´ 88mm (2U)
High-density type 482 ´ 980 ´ 176mm (4U)
Power distribution unit (*1) 1U 435 ´ 148 ´ 38mm (*2),
482 ´ 111 ´ 44mm (*3)
2U (*4) (485 ´ 280 ´ 43mm) ´ 2 (*5),
(485 ´ 123 ´ 44mm) ´ 2 (*6)
Maximum weight
(*7)
Controller enclosure 2.5" type 35kg
3.5" type 35kg
Drive enclosure 2.5" type 35kg
3.5" type 35kg
High-density type 100kg
Power distribution unit (*1) 1U 2.0kg (*2),
2.5kg (*3)
2U (*4) (6.0kg) ´ 2 (*5),
(3.0kg) ´ 2 (*6)
Power Voltage AC 100 – 120V, AC 200 – 240V
Phase Single
Frequency 50Hz/60Hz
Maximum power
consumption (*7)
Controller enclosure 2.5" type AC 100 – 120V 830W (840VA)
AC 200 – 240V 830W (840VA)
3.5" type AC 100 – 120V 730W (740VA)
AC 200 – 240V 730W (740VA)
Drive enclosure 2.5" type AC 100 – 120V 430W (440VA)
AC 200 – 240V 430W (440VA)
3.5" type AC 100 – 120V 340W (350VA)
AC 200 – 240V 340W (350VA)
High-density type AC 100 – 120V 1,300W (1,320VA)
AC 200 – 240V 1,300W (1,320VA)
1. ETERNUS DX Installation
Installation Specifications
16
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Item ETERNUS DX200 S3
Maximum heat
generation
(*7)
Controller enclosure 2.5" type AC 100 – 120V 3,000kJ/h
AC 200 – 240V 3,000kJ/h
3.5" type AC 100 – 120V 2,700kJ/h
AC 200 – 240V 2,700kJ/h
Drive enclosure 2.5" type AC 100 – 120V 1,600kJ/h
AC 200 – 240V 1,600kJ/h
3.5" type AC 100 – 120V 1,300kJ/h
AC 200 – 240V 1,300kJ/h
High-density type AC 100 – 120V 4,700kJ/h
AC 200 – 240V 4,700kJ/h
Maximum amount
of exhaust air
Controller enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
Drive enclosure 2.5" type 4.0m3/min
3.5" type 4.0m3/min
High-density type 12.0m3/min
Environmental con-
ditions
Temperature Operating 10 – 40°C
Not operating 0 – 50°C
Shipping -40 – 60°C
Temperature gradient 15°C/Hr or less
Humidity Operating 20 – 80%RH
Not operating 8 – 80%RH
Shipping 8 – 90%RH
Humidity gradient 30%/day or less
Maximum wet bulb temperature 29°C
Altitude above sea level 0 – 3,000m
Airborne dust 0.15mg/m3 or less
Gas concentration tolerance level Cl2: 6.8ppb or less, H2S: 7.1ppb or less,
SO2: 37ppb or less,
NH3: 423.5ppb or less,
NO2: 52ppb or less, O3: 5ppb or less,
HCl: 6.6ppb or less, HF: 3.6ppb or less
Oil vapor 0.2mg/m3 or less
Seawater (salt corrosion) If the ETERNUS DX is installed on the ocean
or premises within 0.5km from the coast,
necessary measures must be taken to pre-
vent salt corrosion.
Vibration limit Operating 400gal
Not operating 1,000gal
Noise emission
(*8)
Sound pressure level 49dB (A)
Sound power level 6.7B
1. ETERNUS DX Installation
Installation Specifications
17
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

*1: For power distribution units, there are multiple types of exteriors. For details, refer to "Specifications for
Optional Power Supply Products" (page 30).
*2: These values are for product ID ETFP4BU-L.
*3: These values are for product ID ETFP4DU-L.
*4: A 2U power distribution unit is composed of two 1U power distribution units.
*5: These values are for product ID ETFP16U-L / ETFP12U-L.
*6: These values are for product ID ETFP48U-L / ETFP32U-L.
*7: These values are for each drive enclosure when 24 drives are installed in a 2.5" type drive enclosure, 12
drives are installed in a 3.5" type drive enclosure, or 60 drives are installed in a high-density drive enclo-
sure.
*8: These values are measured when a single controller enclosure and a single drive enclosure are configured
in an environment in which the temperature is 23 ± 2°C at 0 meters above sea level.
1. ETERNUS DX Installation
Installation Specifications
18
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

Storage System Dimensions
■Controller Enclosure Dimensions
●2.5" Type Controller Enclosure
The diagrams below show the dimensions of a 2.5" type controller enclosure.
The dimension values do not include any protruding parts (approximation).
Figure 1 2.5" Type Controller Enclosure Dimensions
645mm88mm
482mm
Top
Front
Side
1. ETERNUS DX Installation
Storage System Dimensions
19
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0

●3.5" Type Controller Enclosure
The diagrams below show the dimensions of a 3.5" type controller enclosure.
The dimension values do not include any protruding parts (approximation).
Figure 2 3.5" Type Controller Enclosure Dimensions
670mm
88mm
482mm
Top
Front
Side
1. ETERNUS DX Installation
Storage System Dimensions
20
FUJITSU Storage ETERNUS DX100 S4/DX200 S4, ETERNUS DX100 S3/DX200 S3 Hybrid Storage Systems Site Planning Guide
Copyright 2021 FUJITSU LIMITED
P3AM-7632-18ENZ0
