Fujitsu TeamPoS 7000 Series User manual

User
Guide
TeamPoS 7000 Series,
Model A240/A340
POS Computer
Document
KD96018-0564
Revision 1.0

COPYRIGHT © 2019 FUJITSU FRONTECH. ALL RIGHTS
RESERVED. SHAPING TOMORROW WITH YOU AND
ASSOCIATED LOGOS ARE TRADEMARKS OR
REGISTERED TRADEMARKS OF FUJITSU FRONTECH .
ALL OTHER MARKS ARE THE REGISTERED TRADEMARKS
OR TRADEMARKS OF THEIR RESPECTIVE OWNERS IN
THE UNITED STATES AND/OR OTHER COUNTRIES.
The descriptions and information in this document are guidelines,
detailing the recommendations of Fujitsu Frontech.
Fujitsu endeavors to ensure that the information in this document
is correct and fairly stated . The information within this
document has been reviewed for accuracy, but as with most
documents, errors may be found and corrected in future revisions.
Fujitsu Frontech does not accept liability for any errors or
omissions . The development of Fujitsu products and services is
continuous, and published information may not be up to date. It
is important to check the current position with Fujitsu.
Title:
Team PoS 7000 Series,
Model A240/A340
POS
computer User Guide
(KD96018-0564)
Date:
Dec. 20, 2019
Version:
Version 1.0
Audience:
Corporate clients and field engineers

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - i
To ensure safe use
This manual contains important information required for using the product in a safe manner.
Before using the product, read this manual thoroughly.
Particularly, read and understand Safety Precautions described in this manual thoroughly
before starting operation. Please store this manual on your shelf.
Fujitsu Frontech has taken every effort to ensure no personal injury or economical damage
will result to the user or any other person around the product. Always follow the instructions
contained in this manual when operating this product.
Disclaimer
READ THE ENTIRE MANUAL CAREFULLY BEFORE USING THIS PRODUCT.
INCORRECT USE OF THE PRODUCT MAY RESULT IN INJURY OR DAMAGE TO USERS,
BYSTANDERS OR PROPERTY.
While Fujitsu Frontech has sought to ensure the accuracy of all information in this manual,
Fujitsu Frontech assumes no liability to any party for any damage caused by any error or
omission contained in this manual, its updates or supplements, whether such errors or
omissions result from negligence, accident, or any other cause. In addition, Fujitsu Frontech
assumes no liability with respect to the application or use of any product or system in
accordance with descriptions or instructions contain herein; including any liability for
incidental or consequential damages arising therefrom.
FUJITSU FRONTECH DISCLAIMS ALL WARRANTIES REGARDING THE
INFORMATION CONTAINED HEREIN, WHETHER EXPRESSED, IMPLIED, OR
STATUTORY.
Fujitsu Frontech reserves the right to make change to any products described herein without
further notice and without obligation.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - ii
Getting Started
Thank you for purchasing the Team PoS 7000 system, which is Fujitsu’s Model 7000 series
of POS computer systems . This manual is intended for personnel who operate the Team PoS
7000.
This manual provides notes on handling, describes basic operating procedures, and gives
supplementary information which operators should know before using the Team PoS 7000.
We hope that the Team PoS 7000 will help you operate your business in a more efficient
manner.
Alert signals
This manual uses the following warning labels to prevent personal injury or physical
damage to the product:
This indicates a hazardous situation that could result in serious personal injury if the user
does not perform the procedure correctly.
This indicates a hazardous situation that could result in minor or moderate personal injury
if the
user does not perform the procedure correctly . This alert signal also indicates that
damage to the product or other property may occur if the user does not perform the
procedure correctly.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - iii
Warning Symbols
To ensure that users understand the safety-related information presented in this manual,
it uses warnings and warning symbols that indicate the nature of any danger.
The warning symbols used are defined as follows . Make sure that you understand the
meaning of these symbols before reading the rest of the manual.
This warning symbol indicates that there is a risk of electric shock.
This warning symbol indicates that there is a risk of fire.
This warning symbol indicates that problems could arise if you touch the
area concerned.
This warning symbol indicates that the unit must not be disassembled
since there is a risk of electric shock or other danger.
This warning symbol indicates a general prohibition other than those
above.
This warning symbol indicates a general warning.
This warning symbol instructs the user to unplug the power cord since
there is a risk of electric shock and other danger.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - iv
Safety considerations
• Do not damage or modify the power cord or the interface cables.
Failure to do so may present a risk of fire or electric shock.
Do not place an object on the power cord . Do not route the power cord
where it might trip the user.
•
Install and remove optional equipment only after turning off the unit
and the connected equipment and unplugging the power cord from
the wall outlet.
Failure to do so may present a risk of fire or electric shock.
•
If the unit becomes unusually hot, or produces smoke or an unusual
smell, turn off the power immediately and contact the maintenance
personnel .
Failure to do so may present a risk of fire or electric shock.
• Do not attempt to modify the unit.
Failure to do so may present a risk of fire or electric shock.
•
Do not use optional equipment other than those exclusively designed
for use with the unit .
Failure to do so may present a risk of fire or electric shock.
• Do not place anything containing water, such as a vase, flowerpot or
cup, or a metallic object, on or near the unit.
Failure to do so may present a risk of fire or electric shock.
• Do not use the unit with a voltage other than the specified source
voltage . Avoid connecting multiple loads to a single electrical outlet.
Failure to do so may present a risk of electric shock.
• Do not handle the power cord with wet hands .
Failure to do so may present a risk of electric shock.
• Do not use the power cable when the plug is damaged or the wall
socket is loose .
Using the power cable in such a state may present a risk of fire or
electric shock.
• Do not dispose of the unit in an incinerator or open fire.
Failure to do so may present a risk of fire and/or burns.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - v
• Do not remove covers fastened with screws.
Since doing so may present a risk of electric shock, burns or other
injury.
• Do not place any heavy objects on the unit .
If the objects are not balanced they may fall, resulting in injury.
• Do not leave the unit in a location subject to high temperatures, such
as a location exposed to sunshine or the interior of a parked car, for
an extended period .
The heat may deform or melt the cover, or increase the temperature of
unit's internal parts to the point where it presents a risk of fire.
• Do not touch the keyboard when replacing the paper roll.
Since doing so may activate the printer and trap your clothing or hair.
• Do not insert your fingers into the printer paper insertion opening
when replacing the paper roll.
Since, doing presents a risk of trapping your finger.
• Do not touch the print head immediately after printing.
Since doing presents a danger of burns.
• Firmly insert the plug into the wall socket .
Failure to do may present a risk of fire or malfunction.
• Keep the magnetic card clean . Do not inject oil into the magnetic card
reader .
If dust, oil or water adheres to the card, this may cause an error, a
malfunction, or degradation of the magnetic head.
• Keep the control unit panel closed .
If the panel remains open, it may be damaged when the door is
opened/closed.
• Always turn off the power before cleaning the unit.
•
Always unplug the power cord from the wall socket before relocating
the equipment . Remove any cables that are connected . Take great
care
whenever you move the unit .
Failure to do so may cause damage to the power cable, presenting a risk
of fire or electric shock, or may cause the unit to fall, resulting in injury.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - vi
Handling Precautions
Precautions while installing
The power cord may need to be unplugged from the unit if a fault occurs . Set up the unit in
a location where this can be done easily.
Be sure to comply with all power requirements . If the unit is used in a
location where the power requirements cannot be met, the unit must be
used with a constant voltage constant frequency (CVCF) unit.
Use a ground wire classified as type III (grounding resistance of 100
ohms or less) or better to ensure safety.
Do not put a clip or other similar object into an inter space of the
controller’s rear cover.
Do not place the unit in a location exposed to direct sunshine or in a
location subject to high temperatures and humidity.
Do not place the unit in an adverse environment (locations subject to
large amounts of industrial gas, waste and dust).
Do not place the unit in a location subject to strong vibrations.
When a ground leakage circuit breaker is to be installed, select one
with a breaking current capacity to suit the system, and which is not
likely to respond to high frequencies.
Install lightning protection measures . The provision of a lightning
arrester is recommended in locations prone to electrical storms and
lightning.
Do not place the unit close to a source of electrical noise
Do not place the unit in a strong magnetic field
Place the unit in a location that is not prone to static electricity build-up.
Avoid reflections from room lights . The intensity and radios . of
illumination (400 to 600 lux), equivalent to the lighting level in a normal
office or store, is sufficient.
Always place the unit on a flat surface.
Hold the controller by the side edges whenever you lift it up.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - vii
Precautions while operating
Since certain sections of the unit’s interior employ high voltages, do
not open the cover.
Check that there are no heavy objects on the power cable, and that the
power cable is not under tension.
Do not remove the AC plug while the power is on.
Do not insert or drop a pin or metal rod into the ventilation holes or
spaces between the keys of the keyboard.
Do not place books or other objects around the unit, for example, or
alongside the unit.
Do not place a coffee cup or other objects on or close to the unit.
Do not suddenly increase the room temperature when the unit is cold,
for example, during the winter.
Do not bring a magnet or other magnetized object close to the unit .
Take particular care to not bring such objects close the magnetic card
reader unit.
Do not use volatile liquid such as benzine or thinner to clean the unit.
Do not spray any liquid such as water on the unit.
Always turn off the power before fitting the unit’s dust cover.
Since the plug attached to the unit is designed specifically for it, the plug
cannot be used for home electronics or other equipment.
Unplug the power cable if the unit is to remain out of service for an
extended period.
Never pull the power cable itself when removing the plug from the outlet .
Instead, grasp the body of the plug.
The backup battery will become exhausted and unusable if the unit has
been out of service for six months or longer . Consult the maintenance
personnel in this case.
After turning off the power, always wait at least five seconds before
turning it back on.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - viii
Precautions while using printer
• Avoid using the printer in locations subject to large amounts of dust or debris.
• Always use the recommended paper . Using paper other than the recommended type
may result in a performance deterioration or unit breakdown.
• Check that the paper and print head are set properly before starting printing .
Do not touch the paper while printing is being performed . Pulling the paper may
cause a paper jam.
• Do not move a compartment in the printer unit.
• Remove a cut receipt immediately since failing to do so may cause a paper jam.
• A colored stripe on the receipt paper indicates that the end of the roll is approaching .
Install a new roll.
Precautions while using magnetic cards
• A magnetic card may be damaged depending on the way it is handled or stored . Take
great care when handling and storing a magnetic card.
• Do not place a magnetic card close to home electronics devices that generate a strong
magnetic field, such as a TV or refrigerator.
• Do not place the magnetic card close to a product that generates a strong magnetic
field, such as a telephone card, other magnetic cards, or the medical equipment that
uses magnetic force.
• Do not bring a cell phone, handbag or wallet with a magnetic fastener close to the
magnetic card since the magnet in the fastener generates a strong magnetic field . A
folded, bent or scratched magnetic card may be unusable . Do not keep magnetic
cards, for example, in your back pocket.
• Do not place a magnetic card in a location subject to high temperatures and
humidity.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - ix
Warning Labels
This product has warning label. Do not remove any warning label. If a label becomes
damaged or soiled to the point where it is illegible, contact your maintenance engineer.
Removal Hinge panel: caution with
respect to connecting non-USB
peripherals
Back Panel removed (left to right):
Captive screw removal caution,
Standby power caution, Cover removal
caution (fan cables)
Top of Base (from underneath, left to right):
FCC, Battery replacement, Battery recycling
Top of Base (from above) :power code caution

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - x
Modifying or Reproducing the Unit
Do not modify or reproduce this product.
If the user modifies the product or reproduces this product by overhauling used parts of the
product, unexpected personal injury or damage to the product may result.
High safety required use
This Product is designed, developed and manufactured as contemplated for general use,
including without limitation, general office use, personal use, household use, and
ordinary industrial use, but is not designed, developed and manufactured as
contemplated for use accompanying fatal risks or dangers that, unless extremely high
safety is secured, could lead directly to death, personal injury, severe physical damage
or other loss (hereinafter “High Safety Required Use”), including without limitation,
nuclear reaction control in nuclear facility, aircraft flight control, air traffic control,
mass transport control, medical life support system, missile launch control in weapon
system. You shall not use this Product without securing the sufficient safety required
for the High Safety Required Use. If you wish to use this Product for High Safety
Required Use, please consult with our sales representatives in charge before such use.
Backing up the data
The customer is responsible for maintaining the integrity of data (including the basic and
application software) stored or installed on the product. We do not warrant the integrity of
data stored or installed on the product the customer sends for repair. Take appropriate
measures such as making a backup.
We assume no responsibility for loss of data any direct or incidental damage due to any cause
other than those specified in the warranty.
Characteristics of LCD panels
The phenomena described below are characteristics of LCD panels and do not indicate that
LCD panels are defective.
The TFT color LCD screen composes of many picture elements. It was manufactured
using advanced technologies. For technical reasons, LCD screen may have pixels that do
not light and pixels that are always lit.
LCD panels may display slight varying colors and uneven density.
Computer Virus
Be careful of the infection of the computer virus.
This product will be used under Windows OS and has there is possibility which is infected
with the computer virus from the fragility of the OS. It is recommended that system is
protected from computer virus by anti-virus software.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - xi
Safety
Battery
Danger of explosion if the battery is incorrectly replaced . Replace only with the same or
equivalent type recommended by the manufacturer . Discard used batteries according to
the manufacturer’s instructions.
Limited Power Source
 The 24V powered USB port on the terminal does not meet UL limited power source
(LPS) requirements . This port is limited to only allowing 24V Retail POS powered USB
peripherals that do not exceed a rated current of .2 Amps and are provided with a
molded plastic Fire Enclosure, Rated Min . 94V-1 or Metal enclosure.

The 24V powered Cash Drawer port on the terminal does not meet UL limited power
source (LPS) requirements . This port is
limited to only allowing 24V Retail POS
peripherals that do not exceed a rated current of .2 Amps and are provided with a
molded plastic Fire Enclosure, Rated Min . 94V-1 or Metal enclosure.
Current Loading
Powered USB ports are used for POS peripherals . The current loading for each port is specified in the
following table.
Port
Rating
Note
12V PUSB
+12V:1.3A, +5V:0A
For LCD
12V PUSB
+12V:0.4A, +5V:0A
For VFD
12V PUSB
+12V:0.4A, +5V:0A
For VFD
24V PUSB
+24V:0.2A, +5V:0A
For Printer
USB
+5V:0.5A
USB
+5V:0.5A
USB
+5V:0.5A
For maintenance (Front)
USB
+5V:0.5A
inside the Base unit
USB
+5V:0.5A
inside the Base unit
12V and 24V powered USB ports are used for POS peripherals, all 12V and 24V powered
USB peripherals connect to systems are designed without consuming 5V.
5V USB under PUSB port is only for signal communication.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Preface - xii
Product lifetime
As a guideline, in a normal office environment (25 degree C) operating life is not expected to
be reached within the maintenance support period (5 years). However, operating life may be
reached more quickly if, for example, the product is used in a hot environment. The customer
shall bear the cost of replacing replaceable components which have exceeded their operating
life. Note that these are only guidelines, and do not constitute a guarantee of trouble-free
operation during the maintenance support period.

Page 1
TeamPoS7000 User Guide: Contents
Contents
To ensure safe use...................................................................................................................................i
Disclaimer ...............................................................................................................................................i
Getting Started ......................................................................................................................................ii
Warning Symbols ..................................................................................................................................iii
Safety considerations............................................................................................................................ iv
Handling Precautions ...........................................................................................................................vi
Warning Labels .....................................................................................................................................ix
Modifying or Reproducing the Unit....................................................................................................... x
High safety required use ....................................................................................................................... x
Backing up the data............................................................................................................................... x
Characteristics of LCD panels............................................................................................................... x
Computer Virus...................................................................................................................................... x
Safety .................................................................................................................................................... xi
Product lifetime ...................................................................................................................................xii
Preparing for Use................................................................................................................................... 3
1.1 Unpacking and Checking the product............................................................................................. 3
1.2 Connecting the AC power cable ....................................................................................................... 3
1.3 Relocating the System ..................................................................................................................... 5
1.4 Names and Function........................................................................................................................ 6
1.4.1 Switch and LEDs....................................................................................................................... 6
1.4.2 Connectors ................................................................................................................................. 7
Basic Operations....................................................................................................................................9
2.1 Turning the Power On ..................................................................................................................... 9
2.2 Turning the Power Off ................................................................................................................... 10
2.3 Calibrating the Touch Panel.......................................................................................................... 11
2.4 Adjusting the Display .................................................................................................................... 14
2.4.1 Adjusting the Screen Angle..................................................................................................... 14
2.4.2 Adjusting the Brightness and Volume.................................................................................... 15
2.5 Peripherals (Option) ...................................................................................................................... 16
2.5.1 Single Station Thermal Printer .............................................................................................. 16
2.5.2 Customer display..................................................................................................................... 19

Page 2
TeamPoS7000 User Guide: Contents
2.5.3 Magnetic Stripe Reader (MSR) ............................................................................................... 20
2.5.4 Cash Drawer............................................................................................................................ 21
Daily Maintenance............................................................................................................................... 22
3.1 Cleaning the Product ..................................................................................................................... 22
3.1.1 Cleaning the Main Unit .......................................................................................................... 22
3.1.2 Cleaning the Display............................................................................................................... 22
3.1.3 Cleaning the Magnetic Stripe Reader..................................................................................... 23
3.1.4 Cleaning the Printer................................................................................................................ 23
Troubleshooting.................................................................................................................................... 24
4.1 Trouble shooting............................................................................................................................. 24
4.2 Trouble shooting for printer........................................................................................................... 25
Appendix .............................................................................................................................................. 27
5.1 System Configurations................................................................................................................... 27
5.2 Supplies.......................................................................................................................................... 29
5.3 Components with a limited service life ......................................................................................... 29
5.4 Paper specifications for printer ..................................................................................................... 30
5.4.1 Specifications of thermal paper............................................................................................... 30
5.4.2 Specifications of roll paper ...................................................................................................... 31

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Page 3
1
Preparing for Use
This chapter describes how to set up this product before operation, names and function.
1.1 Unpacking and Checking the product
Unpack all the individual parts.
Check the product for damage incurred during the transportation.
If you discover any damage incurred during the transportation, please consult with our
sales representatives in charge.
1.2 Connecting the AC power cable
1. To remove the base top cover, push the cover in the direction of the arrows below. The tabs are
unlocked.
2. Pry up slightly and then pull the cover up and out.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Page 4
3. Connect AC power cable to power supply unit.
4. To re-install the base top cover, set the far end of the cover to the original position.
Close the base top cover and push it slightly, and the tabs are locked.
• Do not damage or modify the power cord.
Since doing so may present a risk of electric shock, burns or other
injury.
• Do not handle the power cord with wet hands.
Failure to do so may present a risk of electric shock.
•Always unplug the power cord from the wall socket before relocating the
equipment. Remove any cables that are connected. Take great care
whenever you move the unit
Failure to do so may cause damage to the power cable, presenting a risk of
fire or electric shock, or may cause that unit to fall, resulting in injury.
Power supply unit
AC power cable

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Page 5
1.3 Relocating the System
If you need to relocate the system, please lift and carry the unit underneath the base, as shown
below.
Do not lift or carry the system like this:
• Do not handle the power cord with wet hands.
Failure to do so may present a risk of electric shock.
•Always unplug the power cord from the wall socket before relocating the
equipment. Remove any cables that are connected. Take great care
whenever you move the unit
Failure to do so may cause damage to the power cable, presenting a risk of
fire or electric shock, or may cause that unit to fall, resulting in injury.

THIS DOCUMENT CONTAINS CONFIDENTIAL INFORMATION, IS PROVIDED FOR FUJITSU CUSTOMER USE ONLY,
AND IS NOT TO BE SHARED WITH ANY THIRD PARTY WITHOUT FUJITSU’S PRIOR WRITTEN CONSENT.
Page 6
1.4 Names and Function
1.4.1 Switch and LEDs
No.
Name
Function
1
Power button
Turning the power on/off the system
2
Dump switch
When pushed, output the memory dump and reset the system.
This switch may corrupt the programs and data on SSD. So, don’t use
this procedure except in an emergency.
3
Volume control button
Up (+) : increase speaker volume
Down (-) : decrease speaker volume
4
Brightness control button
Up (+) : increase monitor brightness
Down (-) : decrease monitor brightness
5
Power LED
LED turns on when the system is powered
6
Disk access LED
LED turns on when SSD is being accessed.
7
Standby LED
LED turns on when AC power is supplied.
8
Backup LED
LED blinks when the system is running on backup battery.
* Backup battery is option.
9
Diagnostic LED (Memory)
LED turns on when system detect the memory error
10
Diagnostic LED (FAN)
LED turns on when system detect the CPU FAN failure
11
Diagnostic LED
(Disk[Slave])
LED turns on when system detect the SSD error on port1
12
Diagnostic LED
(Disk[Master])
LED turns on when system detect the SSD error on port0
13
Proximity sensor
This sensor can detect the person in front of display
①
⑥
⑦
⑧
⑨
⑩
⑪
②
④
③
⑤
⑫
⑬
