Fulham Hotspot FHSCP-UNV Series User manual

NiCd
Installation And Operation Instructions
For FHSCP-UNV Series Emergency LED Drivers
Models:FHSCP-UNV-5WL, FHSCP-UNV-7.8WL, FHSCP-UNV-10.7WL,
FHSCP-UNV-13.7WL, FHSCP-UNV-17WL
IMPORTANT SAFEGUARDS
When using electrical equipment, basic safety precautions should always be followed,
including the following:
READ AND FOLLOW ALL SAFETY INSTRUCTIONS:
1)
The FHSCP-UNV is designed for factory installation and for field installation only if
determined to meet the as installed egress requirements as outlined on page 5 of these
instructions.
2)
Installation should be performed by qualified personnel only.
3)
Install in accordance with the National Electric Code and applicable local codes.
4)
The FHSCP-UNV requires an unswitched AC power source of 100 to 277 volts, 50/60 HZ.
5)
The FHSCP-UNV is suitable for use in dry and damp location where ambient temperature
is 0 to 50C.
6) The FHSCP-UNV should be mounted in locations and at heights where it will not readily be
subjected to tampering by unauthorized personnel.
7) The FHSCP-UNV is suitable for use only with LED lamps having an operating voltage of 10Vdc
minimum, 55Vdc maximum and will provide 90 minutes of emergency operation.
8) To reduce the risk of electrical shock, do not connect FHSCP-UNV converter connector
until installation is complete and AC power is applied to the luminaire.
9) The FHSCP-UNV has more than one power source. To reduce the risk of electrical shock,
remove the normal AC power source(s) to the luminaire and disconnect the FHSCP-UNV
converter connector before servicing.
10) The use of accessory equipment not recommended by the manufacturer may cause an
unsafe condition and will void warranty.
11) Do not use this equipment for other than intended use.
12) Do not mount near gas or electric heaters.
13) Servicing of this equipment should be performed by qualified personnel only
14) The FHSCP-UNV is a sealed unit. Components are not replaceable. Replace entire unit
when necessary.
15) In order to maintain proper operation and warranty coverage, the battery must be recharged
16)
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 1 of 8
Do not connect battery until fixture is installed.
once per year prior to installation.

NiCd
19)
The Driver is intended for ordinary locations and for permanent installation into one or more Listed
emergency luminaires.
20)
For use with a metal enclosed wiring system.
21)
FIXTURE
The FHSCP-UNV can be used with most LED loads that operate at 10-55 VDC. See the FHSCP-
UNV Model Specification Chart for output specifications of the unit being installed.
A)The FHSCP-UNV series has been evaluated to and found compliant to UL standard
924. The as-installed performance of system must meet or exceed all Federal, State,
and Local code requirements.
B)Refer to Addendum 11152019 for detailed specifications and methods to calculate emergency light
levels.
FHSCP-UNV MODEL SPECIFICATION CHART
MODEL # OUTPUT POWER (CONSTANT)
FHSCP-UNV-5WL 5.0 WATTS
FHSCP-UNV-7.8WL 7.8 WATTS
FHSCP-UNV-10.7WL 10.7 WATTS
FHSCP-UNV-13.7WL 13.7 WATTS
FHSCP-UNV-17WL 17.0 WATTS
SAVE THESE IMPORTANT SAFETY INSTRUCTIONS
The installation and use of this product must comply with all national, federal, state,
municipal, or local codes that apply. Please read this manual thoroughly before installing or
operating FHSCP-UNV Emergency LED Drivers.
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 2 of 8
18)
Use with grounded, UL Listed, damp location rated fixtures and case should be grounding.
17)
The FHSCP-UNV contains a non-replaceable NiCd battery that must be recycled properly

Installation Instructions
CAUTION: Before installing, make certain the AC power is off and the FHSCP-UNV
converter connector is disconnected.
2.
MOUNTING THE EMERGENCY LED DRIVER (FHSCP-UNV)
Mount FHSCP-UNV to the top of the
luminaire with suitable fasteners (not
provided).
Drill or punch a 7/8 ” hole (1/2 ” knockout) on
top of luminaire for flexible conduit.
Attach flexible conduit to luminaire.
Refer to Figure 1 at right.
3.
WIRING THE FHSCP-UNV
Perform all wiring with exception of the Violet and Brown
wires. Note: wiring must be performed in accordance with the
National Electric Code and applicable local codes. Consult
Customer Service for
additional wiring diagrams.
Refer to Figure 2 at right.
NiCd
4.
INSTALLING THE LED COMBO TEST SWITCH (LCTS)
Recessed Troffer Luminaire – Select a convenient location with
proper clearance in the LED Driver cover and drill or punch a 7/8”
hole (1/2” knockout). Insert the 7/8” bushing into the hole. Push
the plastic tube through the bushing.
Route the leads of the LCTS through the plastic tube.
Connect the wires from the FHSCP-UNV to the LCTS
(Violet to Violet, Brown to Brown).
Refer to Figure 3 at right.
Strip Luminaire – Select a convenient location on the fixture
where the LCTS will be visible after installation.
Allow for proper clearance inside the fixture and drill or punch a ½”
hole. Push the LCTS housing into the ½” hole and secure with nut.
Connect the wires from the FHSCP-UNV to the LCTS (Violet to
Violet, Brown to Brown).
Refer to Figure 4 at right.
FIGURE 1
EMERGENCY DRIVER (FHSCP-UNV) LUMINAIRE
*
7/8" HOLE WITH
CONDUIT CONNECTOR
*
*INSTALL FHSCP-UNV MOUNTING FASTENERS (2 PLACES)
FIGURE 2
(FHSCP-UNV)
LCTS
DIFFUSER
LUMINAIRE HOUSING
LED DRIVER COVER
7/8" BUSHING
PLASTIC TUBE
FHSCP-UNV
FIGURE 3
FIGURE 4
FHSCP-UNV
LUMINAIRE HOUSING
LCTS
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 3 of 8

Installation Instructions
5.
WIRING THE AC INPUT
A) The FHSCP-UNV and AC LED Driver must be on the same branch circuit.
B) The FHSCP-UNV requires an unswitched AC power source of 100 to 277 volts.
C) When the FHSCP-UNV is used in a switched luminaire, the AC input to the FHSCP-UNV must
be connected to ahead of the luminaire switch (line side of luminaire switch).
Refer to Figure 2.
6.
COMPLETING INSTALLATION
When the installation is complete, switch the AC power ON and join the FHSCP-UNV converter
connector.
Refer to Figure 2.
OPERATION
Normal Mode – AC power is present. The AC LED Driver operates the LED lamp(s) as intended. The
LCTS will be illuminated indicating that the FHSCP-UNV is in the standby charging mode.
Emergency Mode – AC power fails. The FHSCP-UNV senses the AC power failure and automatically
switches to Emergency Mode. One or multiple LED lamps will be illuminated for a minimum of 90
minutes. When AC power is restored, the FHSCP-UNV switches the system back to the Normal Mode
and resumes battery charging.
NiCd
TESTING AND MAINENANCE
Pressing the LCTS simulates an AC power failure and forces the system into the Emergency Mode.
Only the emergency LED lamp (s) will be illuminated. Testing may also be performed by opening
circuit breaker powering the system.
Initial Testing – Allow the unit to charge for approximately 1 hour, then press the LCTS to conduct a short
test. Allow a 24 hour charge before conducting a 1 ½ hour test.
Monthly – Insure that the LCTS is illuminated. Conduct a 30 second test by depressing the LCTS
Annually – Insure that the LCTS is illuminated. Conduct a 1 ½ hour test by opening circuit breaker
controlling the FHSCP-UNV unit(s) to be tested.
“Written records of testing shall be kept on file for inspection by the authority having
jurisdiction.”
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 4 of 8

5.51"[140mm]
0.39"[10mm]
Installation Instructions
7.
INSTALLATION DIAGRAMS
NiCd
Test Switch Leads
Note: When remote mounting the test button use compliant wire (for example UL CL2 plenum rated wire) or
conduit, depending on local code for low voltage signal wiring. Mount no further than 5ft.
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 5 of 8

Installation Instructions
FHSCP-UNV Series System Coordination Guidelines
These guidelines were developed to allow the lighting system Designer/Specifier to predict the
operating performance levels of LED luminaires when powered by an electrically compatible FHSCP-
UNV Series model. It is ultimately the responsibility of the Designer/Specifier to insure that the as
installed system delivers code-compliant path of egress illumination.
1)
Determine Electrical Compatibility
A)
Verify that the Luminaire LED Driver, where applicable, is Class 2 compliant.
B)
Verify that the Luminaire LED Lamp(s) have an operating voltage between 10Vdc and 55Vdc.
C)
Verify that the Luminaire LED Lamp(s) have a power rating equal to, or greater than, the
emergency power rating of the FHSCUNV model under consideration.
Refer to Table 1 below.
TABLE 1
FHSCP-UNV MODEL EMERGENCY OUTPUT (CONSTANT)
FHSCP-UNV-5WL 5.0 WATTS
FHSCP-UNV-7.8WL 7.8 WATTS
FHSCP-UNV-10.7WL 10.7 WATTS
FHSCP-UNV-13.7WL 13.7 WATTS
FHSCP-UNV-17WL 17.0 WATTS
2)
Calculate Lumen Output During Emergency Operation
A)
Access luminaire data by logging onto Design Lites Consortium (www.designlights.org).
B) Select “Search the DLC Qualified Product List ” on the DLC homepage.
C)
Enter manufacture name and P/N of luminaire under consideration in the “search by keyword ”
text window.
D)
Select “Search ” tab to open the “Qualified Products List ”.
E)
Determine luminaire Lumens per Watt efficacy in “Rated Data ” specifications.
F) Multiply luminaire Lumens per Watt by Emergency Output of the FHSCP-UNV model under
consideration.
Refer to Table 1 above.
This figure is the Lumens available from the luminaire during emergency operation.
3) Determine Suitability of Means of Egress Lighting Levels
A) Using industry standard lighting design software, along with IES files for the luminaire under
consideration, verify that the as installed available Lumens (as calculated in 2F above) are
sufficient to meet Code-compliant path of egress illumination levels.
While the FHSCP-UNV series has been found compliant with the requirements of UL
Standard 924, it is ultimately the responsibility of the Designer/Specifier to assure the
as-installed system delivers code-compliant path of egress illumination in accordance with
Federal, State or local municipal requirements.
NiCd
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 6 of 8

Installation Instructions
FHSCP-UNV Detailed Wiring Diagram
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 7 of 8

Installation Instructions
FHSCP-UNV Series Compatibility and Suitability of Use Guidelines
Addendum (Rev.11152019)
The purpose of this addendum is to sufficiently identify electrical compatibility and predictable emergency light output of the LED
luminaire when used with the F
ulham
FHSCP-UNV Series LED emergency drivers. Verification of these operating traits does
not constitute a code-compliant, as-installed emergency egress system. It is still the responsibility of the Designer/ Specifier to
assure appropriate light levels are achieved during emergency operation of the luminaire in accordance with Federal, state and
local municipal codes regarding path of egress illumination.
A)Determining Electrical Compatibility
• Verify Class 2 compliant driver per driver manufacture specifications.
• Verify that the Emergency Driver (FHSCP-UNV Series) selected does not exceed the power delivered to the LED
array (voltage and current) of the normal driver.
B)Calculating Lumen Output During Emergency Operation
• Assess luminaire/fixture data.
• DESIGNLIGHTS CONSORTIUM
• Log onto the DesignLights Consortium website (www.designlights.org).
• Click on “search the DLC Qualified Product List” button on the DLC homepage.
• In the “search by keyword” text window enter: luminaire manufacturer name and part number.
• Click on “Search” tab to open the “Qualified Products List.”
• Determine per “RATED DATA” efficacy shown in lumens per watt - (lm/w).
• Multiply lumens per watt by FHSCP-UNV rated output (example: lm/w x 5 watts). Refer to table
“FHSCP-UNV MODEL SPECIFICATION CHART” below for the wattage of the specific FHSCP-
UNV model to be used in the luminaire. (lm/w) x (FHSCP-UNV Watts) = Minimum emergency
lumens offixture.
• Determine per “RATED DATA” the “wattage of the luminaire.
FHSCP-UNV MODEL SPECIFICATION CHART
MODEL # OUTPUT POWER (CONSTANT)
FHSCP-UNV-5WL 5.0 WATTS
FHSCP-UNV-7.8WL 7.8 WATTS
FHSCP-UNV-10.7WL 10.7 WATTS
FHSCP-UNV-13.7WL 13.7 WATTS
FHSCP-UNV-17WL 17.0 WATTS
C) Determining Adequacy of Means-of-Egress Lighting Levels
• Follow industry standards by utilizing available .ies files and lighting design software for yourdedicated
emergency luminaires, with the above calculated emergency lumens, and validate your as-installed plans in
accordance with the applicable life safety codes governing your project.
While the FHSCP-UNV series has been found compliant with the requirements of UL Standard 924, it is ultimately
the responsibility of the Designer/Specifier to assure the as-installed system delivers code- compliant path of
egress illumination in accordance with Federal, State or local municipal requirements.
NiCd
.
2020 REV D2
Fulham extends a limited warranty only to the original purchaser or to the first user for a period of 5 years from the date of manufacture when properly installed
and operated under normal conditions of use. For complete terms and conditions, please reference the Fulham Product Catalog (www.fulham.com).
Due to a program of continuous improvement, Fulham reserves the right to make modifications or variations in design or construction to the
equipment described. © Fulham Company Limited, All Rights Reserved. Page 8 of 8
