Full Gauge Controls TI-44e Plus Operator's manual

FOUR-SENSOR DIGITAL THERMOMETER
WITH SERIAL COMMUNICATION
TI44EPLUSV01-01T-15749
1. DESCRIPTION
2. SAFETY RECOMMENDATIONS
3. APPLICATIONS
4. TECHNICAL SPECIFICATIONS
Temperature indicator designed to monitor average, differential or individual temperatures of up-to four
sensors. It can be connected to Sitrad real-time monitoring and management software or smartphone
APP using RS485 serial communication port.
It features IP65 frontal protection, optional drip protection case at rear and tamper-proof function
lockdown to prevent unauthorized change of parameters.
- Check the controller for correct fastening;
- Make sure that the power supply is off and that it is not turned on during the controller installation;
- Read the present manual before installing and using the controller;
- Use adequate Personal Protective Equipment (PPE);
- For application at sites subject to water spills, such as refrigerated counters, install the protecting vinyl
supplied with the controller;
- For protection under more critical conditions, we recommend the Ecase cover, which we make
available as an optional item (sold separately);
- The installation procedures should be performed by a qualified technician.
• cold storage equipment
• machine tools
• stoves
• furnaces
• motor vehicles
• air conditioned rooms
• food, chemical, and pharmaceutical industries.
evolution
TI-44e plus
Ver.01
Measurement range (**)
5. INDICATIONS AND KEYS
Upper key
TI-44e plus
Lower key
Set Key
Quick Access
Menu Key (Flatec)
Sensor 1 indication LED
Sensor 2 indication LED
Sensor 3 indication LED
Temperature unit indicator LED
Functions lockdown indication LED
Sensor 4 indication LED
-50 to 200°C (-58 to 392°F)
Power Supply Ti-44E Plus:115 or 230 Vac ±10%* (50/60 Hz)
Ti-44EL Plus: 12 or 24Vac/dc +10%*
Operating Temperature 0 to 50° C / 32 to 122°F
Operating humidity 10 to 90% RH (with no condensation)
IMPORTANT: Only sensor S1 is included with the product. Sensors S2, S3, and S4 are sold separately.
(*) Admissible variation in relation to the voltage rating.
(**) This device can measure temperatures of up to 200°C/392°F, when used in conjunction with the SB59 silicon sensor
cable (sold separately).
Dimensions (mm)
Cutout dimensions (mm)
76 x 34 x 77 mm (W x H x D)
X = 71±0,5 Y = 29±0,5 (see Image V)
1 2 3 4
TI-44e plus
TI-44e plus
1
Functions
lock
Protection
level
IP 65
FRONT
Up to four
temperature
sensors
Serial
Programming
Supervisory
system
Differential
temperature
calculation
Average
temperature
calculation
Approximate consumption 0.6 VA
6. WIRING DIAGRAM
6.1. Electrical connections (see Images I to IV)
IMPORTANT
INSTRUMENTS IN THE EVOLUTION SERIES HAVE
TWO DIFFERENT TERMINAL SIZES, BUT BOTH ARE
COMPATIBLE WITH THE SCREWDRIVER 2.0mm.
USING THE APPROPRIATE TOOLS DURING
INSTALLATION ENSURES A LONGER LIFE AND THE
PROPER OPERATION OF THE PRODUCTS.
IMPORTANT: Only the sensor 1 is sold with the
product, the sensors 2,3 and 4 can be purchased
separately.
1
5678
2349 10 11 12 13 14 15 16 17
115 Vac
S1
Image I: TI-44E Plus - 115Vac
1
5678
2349 10 11 12 13 14 15 16 17
230 Vac
S1
Image II: TI-44E Plus - 230 Vac
1
5678
2349 10 11 12 13 14 15 16 17
12 Vac/dc
Image III: TI-44EL Plus - 12Vac/dc
1
5678
2349 10 11 12 13 14 15 16 17
24 Vac/dc
Image IV: TI-44EL Plus - 24Vac/dc
S1
S1
AB
SITRAD
S2*
S3* S4*
S2* S3* S4*
S2*
S3* S4*
S2* S3* S4*
AB
SITRAD
AB
SITRAD
AB
SITRAD
6.2. Temperature sensor connection
- Connect the sensor S1 wires to terminals "7 and 8": the polarity is not relevant.
- The sensor cable can be extended up to 200 meters, by the user itself, using a PP2x24AWG cable.
- For immersion in water, use a thermowell (Image VI - item 13), available in the Full Gauge Controls
product line (sold separately).
6.3. Controller power supply
Use the pins according to table below, considering the set version:
6.4. Recommendations of IEC60364 standard
a) Install overload protectors in the controller supply.
b) The sensor cables may be together, but not in the same conduit where the power supply of the
controller and/or of the loads passes through.
a) Cut out the panel plate (Image V - item 13) where the controller shall be fastened, with sizes
X = 71±0.5 mm and Y = 29±0.5 mm;
b) Remove side locks (Image VI - item 13): to do that, compress the central elliptical part (with the Full
Gauge Controls logo) and displace the locks backwards;
c) Introduce the controller in the notch made on the panel, inwards;
d) Place the locks again and then displace them until they compress into the panel, fastening the
controller to the housing (see arrow indication in Image VI - item 13);
e) Perform the electric installation as described in item 6;
f) Adjust the parameters as described in item 8.
ATTENTION: for installations requiring liquid tight sealing, the notch sizes for the controller
installation should be no more than 70.5x29mm. The side locks should be fastened so that they
press the sealing rubber avoiding infiltration between the notch and the controller.
Protector vinyl - Image VII (item 13)
It is supplied with the instrument in the package.
IMPORTANT: Make the application only after completing the electrical connections.
a) Retreat the side locks (Image VI - item 13);
b) Remove the protective film from the adhesive vinyl face;
c) Apply the vinyl over the entire upper part, bending the flaps, as indicated by the arrows - Image VII
(item 13);
d) Reinstall the locks.
NOTE: The vinyl is transparent, allowing visualization of the wiring system of the instrument.
8.1. Quick Access Menu Map
7. FASTENING PROCEDURE
8. ADJUSTMENT OF THE SETPOINT AND PARAMETERS
To access or browse the quick access menu use the ;key (quick touch) while the controller is
displaying the temperature. With each touch the next function in the list is displayed. To confirm use
the/ key (quick touch). See chapter 8.3. for more details. The map of functions is shown below:
;
FUNCTIONS LOCKDOWN
;
ERASE MAX. AND MIN.
VALUES
EXIT THE FUNCTION
;
FUNCTION SELECTION
;
MIN. AND MAX. TEMPERATURE
RECORD
;
TI-44e plus
TI-44e plus
TI-44e plus
TI-44e plus
TI-44e plus
;
TI-44e plus
;
DISPLAY DIFFERENTIAL
CALCULATION
TI-44e plus
DISPLAY AVERAGE
CALCULATION
LEGEND:
To the terminal of the connecting block
Have this manual in your hands
using the FG Finder application.
Pins TI-44E PLUS TI-44EL PLUS
9 and 10
9 and 11
115 Vac
230 Vac
12 Vac/dc
24 Vac/dc

8.3. Basic Operations
8.3.1. Viewing other temperatures
To switch between the temperature views for sensor 1, sensor 2, sensor 3, sensor 4, differential
temperature, and average temperature, press until the desired temperature is displayed.
[t-1,] Sensor 1 temperature
[t-2,] Sensor 2 temperature
[t-3,] Sensor 3 temperature
[t-4,] Sensor 4 temperature
[diF,] Differential temperature
[AUr,] Average temperature
The selected temperature will be displayed for 15 seconds and then the default indication will return (as
per [,f10] parameter setting). If any temperature is disabled it will not be displayed.
>
8.3.4. Functions Lockdown
The activation of the function locking feature provides safety by preventing undue changes of the
parameters.
In this condition the message [LOC,] will be displayed when trying to change those values. However,
it is still possible to view the parameters.
In order to activate the function lock feature, parameter [,F14] (Time for function lock) must be
configured with a value higher than 14 (if it is less than 15,[no,,] will be displayed meaning that
function lock cannot be activated).
Select using the , key (quick touch), and then press (quick touch). Then keep pressed
until[LOC,] is displayed.
The message [On,,]
; / >
will be displayed upon releasing the key.
TI-44e plus
8.2. Quick access keys map
When controller is on temperature display mode, the following keys can be used as a shortcut for the
following functions:
Hold down for 2 seconds: exit function menu.
Quick touch: display of the maximum and minimum temperatures recorded.
Hold down for 2 seconds: clear history when records are being displayed.
Hold down simultaneously: enter function selection.
/
<
<
<
To unlock, turn the controller off and then turn it on again with the > key pressed. Keep the key pressed
until [LOC,] is displayed. Keep the key pressed for 10 seconds and, upon releasing the key, the
message [OFF,] will be displayed indicating the functions lock is deactivated.
Quick touch: confirmation of the function adjustments.
;
/
<
<
Quick touch: momentarily switches the temperature view.
Quick touch: quick access menu.
8.3.2. Minimum and Maximum Temperature Record
By pressing the < key or also through the quick access menu (see item 8), the message [rEg,] will
be displayed and then message [t-1,]indicating the temperature of sensor 1 and the maximum and
minimum recorded temperatures immediately after, then sensor 2 temperature [t-2,], sensor 3
temperature [t-3,], sensor 4 temperature [t-4,] differential temperature [DiF,], and average
temperature [AVR,]are displayed. To erase the current minimum and maximum values, press the
; key (quick touch) until the message [CrEg] is displayed. Press/to confirm.
NOTA1:If the<key is pressed while the records are being displayed the values will be reset and the
message [rset] will be displayed.
NOTE2: If any sensor is disabled the respective minimum and maximum temperatures are not
displayed.
8.3.3. Unit Selection (ºC / ºF)
To select the units the instrument will use, access the main menu through the quick access menu (;),
option [Func]or by pressing<and>simultaneously while the temperature is being displayed, and
enter function[,F01]with the access code[,231] and press/. Then select the desired
unit[,=C,]or[,=F,] using the<>keys, and press /to confirm.
NOTE: Whenever the units are changed, the functions configuration returns to the factory default
settings so it must be configured again.
8.4. Advanced operations
8.4.1.
<and>
<or>
<or>
<or>
<or>
Adjustment of the parameters
Access function[,F01] by pressing keys simultaneously or through the quick access
menu (item 8.1). When [,F01] is displayed, press /key (quick touch). Use the keys to
enter with access code [,123] and when ready press /. Use the keys to access the
desired function. After selecting the function, press/ key (quick touch) to view the value configured for
that function. Use to change the value and press / to save the configured value and return to
the functions menu. To leave the menu and return to the normal operating mode (temperature
indication), press /(hold down) until [----]is displayed.
NOTE 1: If the functions lock is active, when pressing the keys the controller will show the
message [LOC,]and will not allow the adjustment of the parameters.
NOTE 2: If no button is touched for 15 seconds after providing the access code and / or after configuring
the parameter the controller will return to the operating mode and it will be necessary to enter the access
code again in function[,F01].
Access Code
Sensor 1 on or off
Sensor 2 on or off
Sensor 3 on or off
Sensor 4 on or off
Indication offset for sensor 1
Indication offset for sensor 2
Indication offset for sensor 3
Indication offset for sensor 4
Display indication mode
Differential calculation mode
Average calculation mode
Time for functions lock
Address of the instrument in the RS-485 network
[,F01]
[,F02]
[,F03]
[,F04]
[,F05]
[,F06]
[,F07]
[,F08]
[,F09]
[,F10]
[,F11]
[,F12]
[,F13]
[,F14]
DescriptionFun Min Max Unit
CELSIUS (°C) FAHRENHEIT (°F)
Min Max Unit
Default
Default
0
OFF
OFF
OFF
OFF
-5.0
-5.0
-5.0
-5.0
1
0(off)
0(off)
(no)
1
8.4.2. Parameters Table
Legend: [no,,]= no
[On,,]= on
[Off,]= off
999
ON
ON
ON
ON
5.0
5.0
5.0
5.0
7
6
7
60
247
-
-
-
-
-
°C
°C
°C
°C
-
-
-
sec.
-
0
ON
OFF
OFF
OFF
0.0
0.0
0.0
0.0
1
0(off)
0(off)
(no)
1
0
OFF
OFF
OFF
OFF
-9
-9
-9
-9
1
0(off)
0(off)
(no)
1
999
ON
ON
ON
ON
9
9
9
9
7
6
7
60
247
-
-
-
-
-
°F
°F
°F
°F
-
-
-
sec.
-
0
ON
OFF
OFF
OFF
0
0
0
0
1
0(off)
0(off)
(no)
1
8.4.3. Description of parameters
F01 - Access Code::
Has two different access codes:
[,123] Allows changing the advanced parameters.
[,231] Allows choosing the temperature unit: Celsius or Fahrenheit.
F02/F03/F04/F05 - Sensor 1, 2, 3, 4 on or off:
These function configure whether the temperature reading in sensors 1(F02), 2(F03), 3(F04), 4(F05) is
enabled. In order to switch off these inputs they must not be in use by any other function and at least one
input must be active.
F02 (Sensor 1):
[OFF,]Sensor 1 input off
[ON,,]Sensor 1 input on
F03 (Sensor 2):
[OFF,]Sensor 2 input off
[ON,,]Sensor 2 input on
F04 (Sensor 3):
[OFF,]Sensor 3 input off
[ON,,]Sensor 3 input on
F05 (Sensor 4):
[OFF,]Sensor 4 input off
[ON,,]Sensor 4 input on
F06/F07/F08/F09 - Indication offset for sensor 1(F06), 2(F07), 3(F08), 4(F09):
It allows compensating possible deviations in the temperature reading caused by the replacement of
the sensor or changes in the cable length.
F10 - Display indication mode:
This function allows configuring the preferred temperature indication.
[,,,1]Displays the temperature of sensor 1
[,,,2]Displays the temperature of sensor 2
[,,,3]Displays the temperature of sensor 3
[,,,4]Displays the temperature of sensor 4
[,,,5]Displays the differential temperature
[,,,6]Displays the average temperature
[,,,7]Displays all temperatures in an alternate fashion
NOTE: If any sensor is disabled the option related to that sensor will not be displayed.
F11 - Differential calculation mode:
This function configures how the calculation of the differential temperature is performed.
[,,,0]Differential calculation off
[,,,1]Sensor 1 minus sensor 2 temperature
[,,,2]Sensor 1 minus sensor 3 temperature
[,,,3]Sensor 1 minus sensor 4 temperature
[,,,4]Sensor 2 minus sensor 3 temperature
[,,,5]Sensor 2 minus sensor 4 temperature
[,,,6]Sensor 3 minus sensor 4 temperature
[,,,7]Average temperature of all sensors
NOTE: In order to calculate the difference, it is necessary to enable the two relevant sensors. If not
enabled, it will not be possible to calculate the difference.
F12 - Average calculation mode:
This function configures how the calculation of the differential temperature is performed.
[,,,0] Average temperature calculation off
[,,,1] Average temperature between sensor 1 and sensor 2
[,,,2]Average temperature between sensor 1 and sensor 3
[,,,3] Average temperature between sensor 1 and sensor 4
[,,,4]Average temperature between sensor 2 and sensor 3
[,,,5] Average temperature between sensor 2 and sensor 4
[,,,6]Average temperature between sensor 3 and sensor 4
[,,,7]Average temperature of all sensors
NOTE: The sensors that are in error or switched off will not be considered for the calculation of the
average temperature of all sensors (option 7).
F13 - Time for functions lock:
It authorizes locking the control functions (see item 8.3.4.).
[,,15] - [,,60] - Authorizes functions lock and defines the time in seconds of the command to
activate. If a value below 15 is configured, the message[no,,] will be displayed indicating that
locking is not allowed.
F14 - Address of the instrument in the RS-485 network:
Equipment's network address for communicating with Sitrad® software.
Note: One network must not have different equipment with the same address.

WARRANTY - FULL GAUGE CONTROLS
Products manufactured by Full Gauge Controls, as of May 2005, have a two (02) year
warranty, as of the date of the consigned sale, as stated on the invoice. They are guaranteed
against manufacturing defects that make them unsuitable or inadequate for their intended
use.
EXCEPTIONS TO WARRANTY
The Warranty does not cover expenses incurred for freight and/or insurance when sending
products with signs of defect or faulty functioning to an authorized provider of technical
support services. The following events are not covered either: natural wear and tear of parts;
external damage caused by falls or inadequate packaging of products.
LOSS OF WARRANTY
Products will automatically lose its warranty in the following cases:
- The instructions for assembly and use found in the technical description and installation
procedures in Standard IEC60364 are not obeyed;
- The product is submitted to conditions beyond the limits specified in its technical
description;
- The product is violated or repaired by any person not a member of the technical team of
Full Gauge Controls;
- Damage has been caused by a fall, blow and/or impact, infiltration of water, overload
and/or atmospheric discharge.
USE OF WARRANTY
To make use of the warranty, customers must send the properly packaged product to Full
Gauge Controls together with the invoice or receipt for the corresponding purchase. As much
information as possible in relation to the issue detected must be sent to facilitate analysis,
testing and execution of the service.
These procedures and any maintenance of the product may only be provided by Full
Gauge Controls Technical Support services in the company's headquarters at Rua Júlio de
Castilhos, 250 - CEP 92120-030 - Canoas - Rio Grande do Sul – Brasil
Rev. 03
ENVIRONMENTAL INFORMATION
Packaging:
The materials used in the packaging of Full Gauge products are 100% recyclable. Try to
perform disposal through specialized recyclers.
Product:
The components used in Full Gauge controllers can be recycled and reused if
disassembled by specialized companies.
Disposal:
Do not incinerate or dispose the controllers that have reached the end of their service as
household garbage. Observe the laws in your area regarding disposal of electronic
waste. If in doubt, please contact Full Gauge Controls.
Copyright 2016
13. ANNEXES - Reference Images
Image V
Image VI
Image VII
Y
X
CONTROLLER
LOCKS PANEL CONTROLLER
CONTROLLER
VINYL
PANEL
12. INTEGRATING CONTROLLERS, RS-485 SERIAL INTERFACE
AND COMPUTER
AB
MT-530 super
AB
MT-530 super
AA
B B
A B
A
B
AA
B B
A B
AA
B B
A B
AA
B B
A B
*Connecting Block for Serial Communication
Used to connect more than one instrument to the Interface. The wire's connections must
be made in agreement with the following rules: terminal A of the instrument connects to
the terminal A of the c , that must be connected with the terminal A of the
Interface. Repeat the action for terminals B and , being the cable shield.
onnecting block
the terminal of onnecting block must be connected to the respective terminals of
each instrument.
c
*Sold Separately
CONV. 32
or
CONV. 256
Keep Sitrad updated in website:
http://www.sitrad.com
®
Watch Sitrad installation video in:
http://www.fullgauge.com/
videos/sitrad
9. DISPLAY SIGNALINGS
Sensor 1 disconnected or damaged.
Sensor 2 disconnected or damaged.
Sensor 3 disconnected or damaged.
Sensor 4 disconnected or damaged.
Functions lockdown activated.
Functions lockdown disabled.
Contact Full Gauge Controls.
Reconfigure the values of the functions.
[Err1]
[Err2]
[Err3]
10. GLOSSARY OF ACRONYMS
- °C: Temperature in Celsius degrees.
- °F: Temperature in Fahrenheit degrees.
- LOC: Blocked.
- No: No.
- OFF: Turned off/disabled.
- ON: Turned on, enabled.
- SET (as in "Setting") (setting or configuration).
- Vac: Electrical voltage (volts) of alternating current.
- Vdc: Electrical voltage (volts) of direct current.
- Yes: Yes.
[Err4]
[LOC,][On,,]
[LOC,][OFF,]
[eCAL]
[pppp]
Extended frame
It allows the installation of Evolution line
controllers with sizes 76 x 34 x 77 mm in
many differents situations, since it does
not require precision in the notch of the
instrument fitting panel.
The frame integrates two switches of
10 Amperes that may be used to
actuate interior light, air curtain, fan,
and others.
Ecase protective cover
It is recommended for the Evolution line, avoids water from
entering the back part of the instrument. It also protects the
product when the installation site is washed.
11. OPTIONAL ITEMS - Sold Separately
ECASE PROTECTIVE COVER
CONTROLLER
EXTENDED FRAME
SWITCHES
- version 2 or higherEasyProg
It is an accessory that has as its main function to store the parameters of the controllers. At any time, you
can load new parameters of a controller and unload them on a production line (of the same controller),
for example. It has three types of connections to load or unload the parameters:
- Serial RS-485: It connects via RS-485 network to the controller (only
for controllers that have RS-485).
- USB: it can be connected to the computer via the USB port, using
Sitrad's Recipe Editor.
- Serial TTL: The controller can be connected directly to
EasyProg by the TTL Serial connection. EASYPROG
