Fun & Function SP7172 User manual

Installation Manual 40250
July 2022
Sound Activated Light Up Wall Panel
SP7172
•

3
3
3
4-6
7-10
11
11
11
12
13
14
14
Contents
Warnings
Description
Includes
Installation
Operating Panel
Troubleshooting
Cleaning
Maintenance
Information
Guarantee
Technical
Contact
2

*This product is designed for users with special needs. Adult supervision is required during use at
all times.
*For indoor use only. The equipment uses a mains power supply.
*This product was not designed to be free standing. It must be attached to a wall.
*Turn off the panel when cleaning. Use a mild detergent and a lint free cloth. Never use
abrasive cleaning pads to clean this item.
3
Description
Make your sensory room glow with the sound of your voice! Clap your hands, use
your voice or play music to activate the LED lights. The built-in microphone picks up
sound, bringing the panel to life and illuminating the room with 12 levels of vibrant
colors. You can also use the handheld microphone! Set different programs and adjust the
speed, fade and sensitivity of the sensory lighting. Use to encourage speech and
vocalization. Long-lasting LED lights have 30,000 hour life.
Warnings
Includes
Power Adapter
Screen
Control Panel
Bracket
Carefully check all parts are included in your packaging.
Contact us immediately if parts are missing.
Power Cord
Mic

Installation
The Sound Activated Light Up Wall Panel is designed to be installed on the wall
with the supplied bracket. Screws should be used that are recommended for the
type of wall the panel will be installed (screws are not included). The Sound
Activated Light Up Wall Panel weighs 44 lbs. (20 KG). Professional installation is
recommended. The panel should be installed close to an electrical outlet.
The wall panel comes with brackets
attached to the back of the panel.
Step 1Screw the bracket into the wall.
Baseboard
Measure 42.5" (1080.19mm) above the
baseboard. Mark the wall with a pencil. Use
a level to mark another hole 6.3" (160mm)
horizontally from the first mark.
4

Holes in the wall bracket
Drill 2 x holes and screw bracket to wall using appropriate hardware.
Step 2
Step 3Place the Sound Activated Light Up Wall Panel onto the wall bracket.
Hook the bracket located on the back of the panel onto the wall bracket.
Note: Lift the panel gently and set slowly into place until the brackets are
securely connected.
5
•

Step 4
Mark through the holes on the bottom brackets using a pencil.
Drill holes into the wall and use appropriate hardware to screw
the panel onto the wall. These brackets stop the panel
from being lifted off the wall bracket.
6
•
Connecting the Power
Screen
Control
Panel
•
•Connect the power adapter to the socket
on the left side of the panel
•Connect the power cord to the
power adapter and plug into the
outlet
Power Adapter
Power Cord

Interactive
Panel
When power is supplied to the Sound
Activated Light Up Wall Panel, the splash
panel is displayed and quickly goes to the
program menu.
Program menu
1 Auto Build
Color Dimmer Sensitivity
The program menu may not look like this.
It depends on the last program used when
the power is turned on.
Button Description
Program - Press this button to access the program menu. Press this to gain
access to all the programs.
Speed - Pres this button to activate the speed of any automated program.
Fade - Press this button to alter the fade time in between colors.
Color - Press this button to alter the display panel color.
Sensitivity - Press this button to adjust the microphone sensitivity.
7
Operating Panel
Front Panel
The front panel uses a touch sensitive LCD display and has no moving parts.
Your display may look different due to our constant upgrading of firmware. The display
is self-explanatory. Turn on the panel using the Power/Standby button and play!
Start up splash display

8
Programs and how to change them
Press Program Menu
Speed - Press this button to adjust the speed.
Speed 1 Speed 2 Speed 3 Speed 4 Speed 5
Speed 6 Speed 7 Speed 8 Speed 9 Speed 10
Press one of the buttons to change speed - 1 being slow
Speed Menu
1
Auto Build
2
Bar up
3
Bar right
4
Line up
5
Line right
6
Trig up
7
Trig right
8
Random
9
Auto Line
10
Auto
Random
Fade 1
Fade - Press this button to alter the fade time in-between colors.
Fade 2 Fade 3 Fade 4 Fade 5
Fade 6 Fade 7 Fade 8 Fade 9 Fade 10
Press one of the buttons to change Fade time - 1 being fast
Press one of the buttons to choose a program
Adjusting the speed - Some programs may work better if the speed is adjusted.

9
Brightness - Press this button to adjust the brightness.
10% 20% 30% 40% 50%
60% 70% 80% 90% 100%
Press one of the buttons to change brightness - 10% being low.
Sensitivity
Sensitivity!
10%
Sensitivity!
20%
Sensitivity!
30%
Sensitivity!
40%
Sensitivity!
50%
Sensitivity!
60%
Sensitivity!
70%
Sensitivity!
80%
Sensitivity!
90%
Sensitivity!
100%
Press one of the buttons to change the sensitivity - 10 % being the least.
Sensitivity -Press this button to alter the sensitivity of the microphone.
Colors - Some programs will allow a choice of color options.
Color
Color
Green
Color
Lime
Color
Yellow
Color
Orange
Color
Red
Color
Pink
Color
Purple
Color
Indigo
Color
Blue
Color
Sky
Color
Cyan
Color
Aqua
Color
Rainbow
Press one of the buttons to change display color

10
Using the Sound Activated Light Up Wall Panel
Choosing a program
Press the program button
to move into the program
menu and choose a
program
Programs
All the programs require users to touch the screen
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts.
This program is automatic and requires no noise. Lights move at random Use the speed, color,
dimmer to change how the program reacts.
This program is automatic and requires no noise to activate.
Use the speed, fade, color, dimmer to change how the program reacts.
Make a noise and watch the display move up and down and leave a trail of color as it rises.
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts.
Make a noise and watch the display move up from left to right vertically.
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts.
Make a noise and watch the display move up and down in small segments of light.
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts
Make a noise and watch the display move left to right vertically with a trail of color.
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts.
Make a noise and watch the display rise and climb in steps as you make another noise.
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts.
Make a noise and watch the display move left to right in steps as you make another noise.
This program is automatic and requires no noise. Steps move up and down the display.
Use the speed, fade, color, dimmer to change how the program reacts.
Make a noise and watch the display move randomly with no set pattern.
Use the speed, fade, color, dimmer and sensitivity to change how the program reacts.

Troubleshooting
Q - My Sound Activated Light Up Wall Panel display is completely blank and nothing lights up.
A - Check the power supply is turned on and the power cord is plugged in. If this still does not
light up, check the fuse in the plug.
Q - The display was illuminating but they have gone off. Looks like everything has locked out.
A - Disconnect the power supply for 30 seconds and power back up. If the problem persists,
contact SpaceKraft.
Cleaning
To clean your Sound Activated Light Up Wall Panel, wipe with a soft white cloth and mild
detergent. Never use an abrasive cloth or any solvent such as mineral spirits or chlorine
based products. Always unplug the power cord when cleaning.
Maintenance
Your Sound Activated Light Up Wall Panel requires no maintenance except a visual inspection
for a damaged front panel or case. Periodically, check all wall attachments and make sure
the panel is secure. Make sure all electrical cords are not damaged and still intact.
11
Q - The display is not reacting to my sounds.
A - Make sure the sensitivity is turned up and the program works with sound.

Information about products that generate electrical noise
USA and Canada
This device complies with FCC and industry Canada RF radiate exposure limits set forth
for general population. It must not be colocated or operating in conjunction with any
other antennas or transmitters.
This device complies with Part 15 of the FCC rules. Operation is subject to the following
conditions.
This device must accept any interference received, including interference that may cause
undesired operation.
This equipment compiles with the limits for Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. Should problems occur reorient or
relocate the receiving antenna. Increase the separation between the equipment and the
receiver. Connect to a power outlet on a circuit different from that to which the receiver is
connected.
12

CONDITIONS OF GUARANTEE
This guarantee is in addition to and does not in any way affect any statutory or other rights of
consumer purchasers .If within the applicable guarantee period (as shown in 8 below) the
appliance proves to be defective by reason of faulty design, workmanship or materials, we
undertake subject to the following conditions to have the defective appliance (or any part or
parts thereof) repaired or at our discretion replaced free of charge.
1. The appliance shall have been purchased and used solely in accordance with Standard
operating instructions and the technical and/or Safety Standards required in the country where
this appliance is to be used.
2. All inquiries must be through such dealers. For appliances used in the UK., U.S.A., Channel
Islands, Isle of Man, and Republic of Ireland the appliance should be returned together with this
guarantee and proof of purchase promptly on being found defective, at the purchasers risk and
expense, to the authorized dealer from whom the appliance was purchased.
3. This guarantee shall not apply to damage caused through fire, accident, misuse, wear and
tear, neglect, incorrect adjustment or repair, to damage caused through where this appliance is
used, or to damage occurring during Installation, adaptation, modifications, or use in an improper
manner or inconsistent with the technical and/or safety standards required in the country transit to
or from the purchaser.
4. If at any time during the guarantee period any part or parts of the appliance are replaced
with a part or parts not supplied or approved by us or of an objective quality safe and suitable for
the appliance, or the appliance has been dismantled or repaired by a person not authorized by us,
the purchaser shall not be entitled to any rights and/or remedies under this guarantee.
5. The purchasers sole and exclusive remedy under this guarantee against us is for the repair
(or at our discretion the replacement) of the appliance or any part or parts and no other remedy,
including, but not limited to, incidental or consequential damage or loss of whatsoever nature shall
be available to the purchaser.
6. This guarantee shall not apply to lamps, batteries, color filters, cabinet parts or any other
parts of a limited natural life.
7. Our decision on all matters relating to complaints shall be final. Any appliance or defective
part which has been replaced shall become our property until paid for in full.
8. The guarantee period applicable to all new appliances shall be 24 months.
Guarantee
13

Spacekraft copyright June 2022
PO Box 11, Merion Station, PA 19066
QUESTIONS? call us at 800-231-6329 or email us at [email protected].
We are committed to going above and beyond to address your questions, ideas and feedback.
Technical
The Sound Activated Light Up Wall Panel is a low voltage device using a power supply that is
double insulated. A class 2 device and does not require portable appliance testing. We do
however suggest an annual visual inspection looking for any damaged parts.
Complies to:
BS EN 60355-1
Generic EMC standards -
Emission standard for residential, commercial and
light-industrial environments
In the UK, the Sound Activated Light Up Wall Panel power supply is fitted with a 3 Amp fuse.
Disconnect the mains supply before attempting to replace .
Size - 47.8" x 17.7" x 3.5"
(1215 mm x 450 mm x 90 mm)
Weight - 44 lbs. (20 KG)
Disclaimer
No part of this manual may be reproduced in any form or by any means
(graphic, electronic or mechanical, including recording, taping,
photography or information retrieval system) without express written
permission of the publisher of this material.
All information correct at date of publication.
Electrical data Table 1
Supply Voltage 110 / 240 AC
Power Supply Primary Voltage 110 / 240 AC
Power Supply Secondary Voltage 12 DC
Power Supply Current Rating 3 Amp
Power Supply Plug top Fuse 3 Amp
Working Load Current 1.2 Amp
Power Supply Compliance EN-FCC
14
