Funkwerk elmeg CS290 User manual

Declaration of conformity and CE mark
This device meets the requirements of the following EC directive R&TTE 1999/5/EG:
»Directive 1999/5/EC of the European Parliament and of the Council of 9 March1999 on radio equip-
mentandtelecommunicationsterminalequipmentandthemutual recognition of their conformity«.
Youcanalso requestthisECdeclarationofconformityatthefollowingInternetURL: http://www.funkwerk-ec.com.
Thewastecontainersymbolwiththe "X" through it on thedeviceindicatesthat the device must be dis-
posed of separately from normal domestic waste at an appropriate waste disposal facility at the end of
its useful service life.
© 2009 Funkwerk Enterprise Communications GmbH - All rights reserved.
Reprinting of this document, even excerpts,is permitted only with the express consent of the publisher andwith pre-
cise source information, regardless of the media used (mechanical or electronic).
Function descriptions included in this documentation which refer to software products of other manufacturers are
based on the software used and valid at the date the documentation was prepared or published. The product and
company names used in this documentation may be protected by trademarks.

Table of contents
User interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Description and installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
elmeg CS290 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
elmeg CS290-U. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
elmeg IP-S290 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Setting up/ Configuring the system telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety notes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Plug-in power supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Elektrostatic charges (protection against electrostatic charges) . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Contents of package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Care and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Telephone location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Telephone installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Connecting the handset cord . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
elmeg CS290 at the ISDN port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
elmeg CS 290-U at the UP0 port. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Important notes for the UP0 connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
elmeg IP-S290 / IP-S290plus at Ethernet port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
elmeg IP-S290 at the Ethernet port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Audio in / Audio out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Connecting a headsets (not included in the scope of supply) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Headset »Firefly F142 N« from Plantronics (not for IP-S290) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Changing the label . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Pictographs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
System telephone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to and operating the system telephone at the PABX system (basic function including DHCP) . . . 7
System telephone configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Setting the display language . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Entering letters and numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Display information when the system telephone is idle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Additional information in the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Softkey »mail« . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
UUS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Making Calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Starting a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Dial number - no correction possible . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Dial call number - correction possible . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Dialing from the PABX telephone directory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Dialing from the VIP memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Direct dial-in using function buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Dialing from the caller list. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Accepting / refusing a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Table of contents
I

Call Deflection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Calling line identification restriction (anonymous call) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Starting a call with a fixed MSN extension number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Extended last number redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Deleting a call number from extended redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Automatic redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Suspending automatic redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Deactivating automatic redialing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Mute on/ off, Open listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Mute on/off . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Open listening . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Hands-free calling (IP-S290) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Using headsets . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Activating and deactivating the headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Activating and deactivating open listening while using the headset . . . . . . . . . . . . . . . . . . . . . . . . 15
Announcement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Making announcements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Automatic recall . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Automatic completion of call to busy subscriber (CCBS) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Programming completion of call on busy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Viewing and clearing call-back calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Tracing (MCID) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Malicious call identification during ongoing call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
After the caller has hung up the handset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Keypad and tone frequency dialing (DTMF dialing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Keypad. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Tone dialing (dtmf dialing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Conducting calls with several subscribers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Inquiry Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Switching calls from a system-parked inquiry to a busy subscriber . . . . . . . . . . . . . . . . . . . . . . . . 18
Call switching. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Broker`s call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Conference call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Telephone operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
VIP memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Programming VIP entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Editing VIP entries . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
SMS / UUS1 messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
UUS1 inhibiting filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
(MWI Message Waiting Indication) (for example T-NetBox).. . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Displaying the caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Deleting the caller list . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SMS and UUS1 text messages. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
SMS Text Messages (subject to terms of network provider) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
UUS1 text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Creating and sending text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Example: Creating a UUS1 text message. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Table of contents
II

Important notes for entering numbers with SMS transmission. . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Viewing newly received text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Displaying received or sent text messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Example: Reading a received UUS1 message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Permanently stored text messages (UUS1 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Automatic sending of text messages (UUS1 only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Configuring the text message reception mode (UUS1 only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Error while receiving an SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Monitoring costs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Procedures for charge rate transmission. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Viewing and deleting costs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Viewing/deleting costs for the last call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Viewing and deleting total costs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Viewing/deleting costs for specific MSN extension numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting the tariff factor and the currency designation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Programming call number display (CLIP/CLIR/COLP/COLR) . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
System telephony . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Advanced telephone settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Activating the extended configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Deactivating the extended configuration mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Entering or modifying MSN extension numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Connected to a PABX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting capital or small letters for the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Setting the User Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Caller list LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Programming buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Function keys . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Description of the key functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
System menu of elmeg PABX systems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Configuring and setting up the system telephone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Acoustic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Selecting a headset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Speaker volume setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the volume of the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the volume while making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the acknowdledgement signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Setting the call waiting signal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Notice tone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Programming call rerouting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Activate call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Viewing current call forwarding . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Deactivating call rerouting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
The following entries are possible for the call waiting feature: . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Setting the contrast (»Settings« menu). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Inhibiting (dial ranges) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
inhibit »list«. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
inhibit »Outgoing calls« . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Setting the language of the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Connection to a PABX . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Table of contents
III

Extension numbers (MSN) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Entering or editing an MSN extension number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Viewing an MSN extension number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting the call signaling melody and volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting the melody . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Setting the ringer melody volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Assigning a name to the MSN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Programming a default call forwarding number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting »Info at end of call« . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Setting for »UUS Dummy Message« . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Configuring the system telephone elmeg IP-S290 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
IP settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Name . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
SMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Telephone BIOS (CS290, CS290-U): . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
The following functions are available in the telephone's BIOS . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Downloading new firmware over the external ISDN connection (CS290, CS290-U) . . . . . . . . . . . . . . . 49
Country . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Brief description of functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Table of contents
IV

User interface
1Function button: This key opens the programming menu. If you are already located in a menu and then
press the key, either menu-specific functions are shown, or you are moved back one programming step.
2Escape button: Pressing the Esc button during programming returns the telephone to its idle status.
33 softkeys
The functions of the softkeys are displayed in capital or small letters (depending on your settings).
4Display: The date and time appear on the top line of the display when you connect the unit to the power
supply system (IPS 290), or to the internal ISDN or UP0 (CS 290, CS290-U) port of the PABX system. The
dateandtimeareimported automaticallyfromthePABXsystem. The textdisplayed for a functiononline2
isalwayslocated above the correspondingsoftkey.Whenyoupressthesoftkey, the next level isdisplayed.
If not all information fits into the screen, this will be indicated by »«« or »««.
5OK button: Press this button to store a setting in the telephone. You then hear the acknowledgement
signal.
6C key: Press this button to move back one menu step in the menu. If you are currently in the input mode,
this button can be used to delete individual characters.
7Call LED: Incoming calls are signaled by a rapidly flashing LED.
8Speaker
9Open listening button (hands-free button IP-S290)
0End a call
ßInquiry button
°Last number redial button
User interface
1
01.01.09 08:30 }
tbuch vip
1
2
345
6
7
89
0ß°
§$%&/
Figure: 1

§Arrow buttons: The arrows »{« and »}« in the right corner on the top line of the display indicate that you
can call up further functions on the lower lines using the arrow buttons.
$Asterisk key, number sign key
%Dial keys / VIP keys
&IP-S290plus, CS290-U: 5 Five programmable function keys with LED: Each button has an inset two-color
LED (level 1 - red / level 2 - yellow). These LEDs can be used to indicate certain functions.
IP-S290: The LEDs for all of these keys are single-colored (Level 1 - red).
CS290: Each button has an LED (red) assigned to it. The LEDs for the two function keys are dual-colored
(Level 1 - red / Level 2 - yellow).These LEDs can be used to indicate certain functions
/Label panel for programmable function keys
Description and installation
You can connect the system telephone at the internal port (S0, Up0 or Ethernet) of a PABX system. The system tele-
phone is connected to the internal port through an ISDN jack (Western or RJ45).
The system telephone provides system features when connected to certain PABX systems. For example:
·Dialing from the PABX telephone directory
·Sending and receiving SMS messages
·Messaging with other system telephones connected to the PABX
·Function keys for controlling special PABX features (switching call modes, team log-in/off, line
buttons, extension buttons).
The status of the programmed features can be displayed by meansof LEDs assigned to the specific
function keys.
·Accessing the PABX system menu. This menu provides further PABX features.
The internal connection of the PABX systems automatically interfaces with the system telephone. Please refer to the
operating instructions of your PABX to determine whether these typical system features are provided with the vari-
ous system telephones.
elmeg CS290
This system telephone is designed for connection to an internal S0-port (4 wires) of an elmeg PABX system.
elmeg CS290-U
This system telephone is designed for connection to an internal Up0-port (2 wires) of an elmeg PABX system. The
system telephone comes with an ISDN port to which further ISDN terminal devices can be connected.
elmeg IP-S290
Connect this system telephone to the corresponding LAN port (or network) of the PABX systemusing a Cat. 5 cable.
The system telephone comes with a PC port to which further IP terminal devices can be connected.
Setting up/ Configuring the system telephone
On the system telephone itself you can only carry out a limited configuration of the supported features. Complete
configuration of the system telephone is possible only via the appropriate ports of the elmeg PABX system.
Description and installation
2

Safety notes
•Mind the storage and operation temperatures for the device listed in the technical specifications. Only connect
the device when the permissible ambient operating temperature has been reached.
•Pleasenotethat condensation on or inthe unit may occur when movingfrom cold to warmsurroundings.Only
remove the telephone from the package when the permissible ambient operating temperature has been rea-
ched.
•You should not make calls or connect or disconnect any lines during thunderstorms.
•Only attach the connecting cords at the connections provided.
•Make sure phone cables are installed in a safe manner to prevent tripping.
•Avoid the following:
Direct sunlight
Sources of heat (for example radiators)
Electronic devices (for example stereo components, office equipment or microwave devices)
Ingress of moisture or liquids
Aggressive fluids or vapors
Dusty environment
•Do not use the unit in excessively humid rooms or hazardous locations.
•Only open those sections of the device specified in the assembly / operating instructions.
•Do not touch plug connectors with pointed, metal, or moist objects.
•If you do not permanently mount the device or any accessories, be sure to place it/them on a non-slip surface.
•When required, clean the unit with a slightly moistened cloth.
•Only use approved accessories.
·Only terminals with SELV and/or which comply with ETS 300047 may be connected to the unit.
This regulation is fulfilled when approved terminal devices are used as intended.
Plug-in power supply
·Use only approved power plug-in units (DSA-0101F-05 UP or L15 D52 AB DDLAWO).
·Do not use power plug-in units with visible defects or damage (fissures, cracks, etc.)
Elektrostatic charges (protection against electrostatic charges)
ThetelephoneissuppliedwithenhancedESD protection against the effects of electrostaticdischargethatexceedsthe
protection level cited in the approval specification. Elevated ESD levels should nevertheless be avoided to the grea-
test possible extent. In some cases, electrostatic discharge levels can far exceed the approval limits or the resistance
levels already implemented in your telephones. Eliminate the causes or conditions that promote these elevated ESD
levels, such as insufficient humidity or carpeting. The telephone manufacturer does not assume any liability for da-
mage caused under such circumstances.
Contents of package
System telephone, handset with connection cord, connection cable, 2 feet, operating instructions, label panel for
programmable function keys. Adapter cord (CS290-U) for headsets equipped with 4-pin connecting cord (8-pin
plug / 4-pin cord).
Care and maintenance
The ISDN system telephone has been manufactured for normal, everyday use. When required, clean the ISDN sys-
temtelephonewith a slightlymoistenedcloth, or withananti-static cloth. Neveruseasolventto clean the phone! Ne-
ver use a dry cloth; electrostatic charges could damage the electronics in the system. It is essential that no liquids pe-
netrate into the inside of the ISDN system telephone, as this could destroy the phone.
Telephone location
Before installing the telephone you must mount the rear feet for the telephone at the positions (6) shown in figure 2.
Depending on the height of these two feet you can adjust the display angle of your phone to your personal angle of vi-
Safety notes
3

sion. Ensure that the two feet have the same height.
To adjust the height, pull the feet off of the bottom of the telephone, rotate them around 60° and place them back in
the enclosure. By turning the feet by around 60° (around the longitudinal axis) each time you can set three different
heights for the phone.
Please note that the plastic feet of your ISDN system telephone may leave marks on sensitive surfaces, such as furni-
ture. The manufacturer of the telephone is not liable for any such damage. Therefore, use appropriate non-skidding
pads under the phone.
Telephone installation
Connecting the handset cord
Connect the handset cord 1as shown in figure 5. Lay the handset cord in the cord groove 2and lock it below the
two cord retainers 3.
elmeg CS290 at the ISDN port
Connect the ISDN-cord 1to the S0-jack as shown
in figure 4. Ensure that the longer ISDN connector
is plugged into the ISDN jack and the shorter ISDN
connector into the ISDN socket on the telephone.
Then lay the ISDN cord in the cord groove 2and
lock it below the two cord retainers 3.
elmeg CS 290-U at the UP0 port
Connect the ISDN cord 1to the UP0jack as shown
in figure 2. Ensure that the longer ISDN connector
is plugged into the ISDN jack and the shorter ISDN
connector into the ISDN socket on the telephone.
Then lay the ISDN cord in the cord groove 2and
lock it below the two cord retainers 3. Figure 2
shows a downstream ISDN telephone connected to
the S0 port of the elmeg 290-U.
Information:
CS290-U phones may not be connected through the S0 jack to the ISDN connection.
Important notes for the UP0 connection
·An ISDN terminal device equipped with S0 port can be connected to the phone's S0 jack.
·The maximum line distance between the elmeg CS290-U and any downstream ISDN terminal de-
vices may not exceed 10 meters.
·Terminating resistors may not be connected.
elmeg IP-S290 / IP-S290plus at Ethernet port
The IP-S290plus system phone can be powered through the Ethernet port asdefined in IEEE Std 802.3af-2003 (PoE),
with power being supplied via Ethernet from the hub or switch. At the port, »Alternative A« and »Alternative B«, as
defined by IEEE Std 802.3af-2003, and »Power classification 1« (up to 4 W) is supported. The PoE port is not polarity
sensitive.
Telephone installation
4
1
236
6
Figure: 2
5
4
3
2
1
Figure: 2

PIN assignment for PoE
1= Transmit Data +
2= Transmit Data -
3= Receive Data +
6= Receive Data -
4/5connected = power supply
7/8connected = power supply
elmeg IP-S290 at the Ethernet port
1Connection for plug-in power supply unit
2Plug-in power supply unit
3Ethernet PC connection
4PC or other IP telephone
5Ethernet port of the PABX
6elmeg pbx
7Audio-In connection (microphone)
8Audio-Out connection (handset)
9Headset with two 2.5mm stereo-connectors.
Audio in / Audio out
Thetelephoneisequippedwithaninput7andan output 8for audio signals.Theseportsareprovidedforheadsets.
The jacks are linked to the corresponding ports for the headset jacks on the bottom of the telephones.
Connecting a headsets (not included in the scope of supply)
Recommended: Headsets supplied by Plantronics mit U10PS Connection cable or GN Netcom.
Connect the headset as shown in figure 5. Then lay the headset cord 3in the cord groove 4and lock it below the
cord retainers 5.
You can use the handset or the headset for making calls.
Headset »Firefly F142 N« from Plantronics (not for IP-S290)
The LED in the mike arm of this headset is activated using the headset button on the telephone.
Telephone installation
5
1
2
35
4
78
9
6
Figure: 4
23
4
56
7
4
61
Figure: 5
87
65
43
2
1

Pin assignments of the headsets Headset jack CS290, IP-S290
1- Microphone +
2- Handset (ground)
3- Handset
4- Microphone (ground)
Headset jack CS290-U
1- DSHG receiver
2- Ground
3- Microphone +
4- Handset (ground)
5- Handset (3.3 V switchable via resistor)
6- Microphone (ground)
7- V+ (3.3V)
8- DSHG transmitter
Changing the label
The labels for the function keys are provided on the last page of this operating manual. Cut out the label you wish to
use.
To change the label panel, press the flexible cover together between your index finger and thumb and lift it out. The
label panel can now be changed.
You can fill in the label panel via your PC yourself. The CD ROM supplied with the PABX contains an Adobe Acrobat
file with templates.
Pictographs
The pictographs (symbols) described below have been used in these operating instructions to illustrate some proce-
dures for setting and using the telephone.
bLiftupthehandsetorstartprepareddialing.
aReplacehandset.
Thetelephone isidle.
lAcallissignaled.
Theringer melodysounds.
gYouare conductingacall.
dAthree-party conferencecallisinitiated.
qYouhear thepositiveornegativeacknowledgementsignal.
tSelectthecallnumber,code,characterortext.
0...9
*,#
Presstheappropriatebuttononthe push-buttonset.
<> Usethearrowbuttonsin ordertoswitchfromonedisplaytexttothe next.
FUsethisfunctionbuttonto starttheconfigurationandsetupmode.
SThisis asoftkeywhosefunctionisdisplayedabove.
OUsetheOKbuttontoconfirm anentry.
ZYouwill thenbeaskedto pressafunctionbuttonoradirect dial-inkey.
zYouwill thenbeaskedto pressaspecificfunctionbuttonordirectdial-in key.
Telephone installation
6
87
65
43
2
1
43
21

EPress Escape to cancel a configuration attempt without storing it. The telephone then returns to idle
state.With theIP-S290,pressEscapetoterminateentriesfor IPfeaturesandhavethemstored.
CUse the clear button to delete specific entries like telephone numbers or names.Each time you press
thisbuttonthelastcharacterisdeleted.
RUsethisbuttontoopen asystemparkedinquiry.
WPresstheRedialbuttononcetoredialthelastnumberorrepeatedlytostartextendedlastnumberredi-
alor automaticredial.
TUsethedisconnectbuttontoterminate existingconnections.
LUsetheopenlisteningbuttontoactivateordeactivate Openlisteningatyoursystemtelephone.
#WhenyouenterthenumberfordialingviaanSIPprovider,dialingisnotperformeduntilaround5se-
condsafterthelastdigithasbeenentered.Dialingisperformedimmediatelywhenyoupressthe#key
after entering the number. In this case, the terminal device must also be capable of dialing into the
phonesystemwiththe#.
System telephone settings
Connecting to and operating the system telephone at the PABX system (basic function
including DHCP)
Consult the installation instructions for the PABX system to determine which port can be used for connecting the
IP-S290. Connect this port with the Ethernet PABX port on the system telephone.
·Configure your PABX system for use with IP system telephones.
·Define the MSNs for the IP system telephones within the PABX system.
·Switch on the power (plug-in power supply unit) to the IP system telephone and wait until the te-
lephone has been initialized.
Once the IP system telephone has been initialized you will be requested to select the language in the display.
·Select the display language.
Press the arrow buttons to view the available
languages and confirm your selection by pres-
sing S.
Welche Sprache? }
deutsch english polski
·Enter one of the MSNs that has been input to the PABX system(in the example shown here, 12) .
Confirm your entry by pressing O.Program dial number
MSN-1>12
If no PIN has been entered in the system configuration, press button Oand button Oagain after being requested
to do so.
Please enter login PIN
TNM-1->
Swtich to »Use DHCP?«.
Select »on«. Use DHCP?
off on
·The telephone and PABX system are synchronized.
Information:
If there is no connection to the PABX (no LAN connection,DHCP switched off, SYS-server not available or telepho-
ne not logged on) the display shows the »©-----/ /----‰« symbol instead of the time.
System telephone settings
7

Possible error:
IP address , IP gateway, IP subnetmask, IP SYS server.
This MSN has not been entered in the PABX or has multiple assignments.
A PIN / logon name has been entered in the PABX but not in the telephone.
There are no subscribers configured in the PABX.
You can now use the IP system telephone just like any other system phone at the ISDN or UP0 port.
System telephone configuration
Setting the display language
You can select the language of your display.
Begin as follows:
aFSSS
Replace handset. config Display language
English Press the arrow buttons to view the available
languages.
Which language? }
deutsch english polski
Example:
English Press the arrow buttons to view the available
languages.
Which language? }
deutsch english polski
SPress the softkey below the desired language. The
display switches to the changed language immedi-
ately.
Entering letters and numbers
You can advance through the characters (letters or numbers) by pressing the appropriate button repeatedly.
The following buttons are configured for the entry of figures and numbers:
Button 1st 2nd press 3rd press 4th press 5th press 6th press 7th press
11
2ABC2ÄÅÆ
3DEF3
4GH I 4
5JKL5
6MNO 6 ÖØ
7PQRS7ß$
8TUV8Ü
9WX Y Z 9
**
##
Every letter that you enter is shown as capitals.
Example: »FUNKWERK«.
System telephone settings
8

Several special characters are assigned to the button »0«.
For ex.: »!«, »&«, »?«, »+«, »-«, »=«, »(«, »)«, »@«, »$«, …
When you press the 0key the first time a space is inserted. When you press this key a second time several special
characters are shown in the display. Press the appropriate key to select the corresponding special characters 1…
9. If you wish to view further special characters, press the 0key.
Display information when the system telephone is idle
When the telephone is idle, the top row displays the date and the time and the bottom row shows the information
tbook and VIP.
22.11.05 08:30 S U }
tbook vip
Additional information in the display
When the telephone is in the idle state, additional information about functions that have been configured are shown
on the top line of the display.
22.11.05 08:30 S U }
tbook vip
»S« The dial filter for the telephone has been configured via the PC configurationprogram. Phone numbers or
partial numbers are now enabled or inhibited for calling.
»U« Call rerouting configured.
»i« A status info text is available (for example router button).
>
S
Press the right arrow button and then the softkey
below the configured function if you wish to get mo-
re information about the configured functions.
22.11.05 08:30 i S U {
mail charge info
Display
Softkey »mail«
Select »uus« and SMS«. Messages
uus sms
UUS
Select »liste« und »new«. Messages / UUS }
list new
Use the arrow buttons to select any one of 5 messa-
ges. Press Oto select the entry you wish to
edit.
Select text {}
1: HELLO
SPress the corresponding softkey to have the message
sent or deleted. »send« oder »delete?« (in this
example: »send«).
1/ HELLO
send delete?
SPress the softkey » UUS<Hello«. Send mail (Abc)
UUS> HELLO
System telephone settings
9

SYou can select the target telephone number for the
UUS message from »direct«, » vip« , »repe
-
at« or »new«. Press the appropriate softkey
Send mail / UUS }
direct vip new
System telephone settings
10

Making Calls
Starting a call
Dial number - no correction possible
btg
Lift up handset Dial number Phone call
Dial call number - correction possible
atbg
Replace handset. Dial number Lift up handset Phone call
To change the number or to correct a wrong entry, select the incorrect figure with the arrow buttons and press C to
delete it. Now enter the correct number.
Ifyouwish to conduct thecallusingthe handset, just lift it up after dialing the number. Any time during acallyou can
switch back and forth between hands-free calling (IP-S290 only), open listening and normal use of the handset.
After you have entered the number you can also press the speaker button to have the number dialed and to use
hands-free calling (IP-S290 only).
Ifyouwish to conduct thecallusingthe handset, just lift it up after dialing the number. Any time during acallyou can
switch back and forth between speaker function and use of the handset.
After you have entered the number you can also press the speaker button to have the number dialed.
Ifacallcan not beputthrough(e.g.numberisinhibitedviathedialrangescontrol), a corresponding messagewillap-
pear in the display. For ex.: »inhibited: msn«, if dial range control is active.
When you lift the handset and there is still no connection set up, you can pick up a waiting call using the »pick up«
softkey without replacing the handset again. You are notified of the call in advance by a brief message. If you have set
up a connection button, you can accept the call immediately simply by pressing this button.
Other options for dialing without lifting the handset
Theoptionofdialingwithoutliftingthehandsetand of correcting or addingtoanumberalsoexists during dialing:
•from the last number redialing memory (see page 13).
•from the caller list (see page 20).
•from the PABX telephone directory (see page 20).
•from the VIP memory (see page 20).
•with the function keys (see page 12).
•via CTI (TAPI) feature of the PABX (CS290 / CS290-U).
If you are using one of these options, you can make further entries prior to initiating the call. You can define which
number (MSN), if any, is to be transmitted to the party being called.
Dialing from the PABX telephone directory
When you use this telephone with a PABX system that supports system telephony, you can dial from the telephone
directory of the PABX.
aStO<>O bg
Replace
handset. tbook Enter first let- ter Select entry Lift up hand- set Conversation
Dialing from the VIP memory
You can program VIP numbers for each of the ten dial buttons1 … 0 including a name (20 characters max.) anda te-
lephone number (26 digits max.).
Making Calls
11

aSor tbg
Replace hand-
set. VIP Select VIP
destination Select VIP destination Lift up handset Conversation
For information on how to program VIP entries, please refer to page 20 of these operating instructions.
Direct dial-in using function buttons
Directdialingisinitiatedusingthedirectdialing keys. Eachof the five keys canbeprogrammedwith two functions or
direct dialing numbers.
aZbg
Replace handset. Press the function key Lift up handset Conversation
Use the function keys to select the desired number.
If you wish to dial a number from the second level, press the corresponding key two times. If you wish to dial a num-
ber from the second level, press the corresponding key rapidly two times.
You can program the direct dialing / function keys via the PC configuration program for the telephone or during ex-
tended configuration.
Dialing from the caller list
Thistelephone has a caller listAmaximum of 10 entries(calls, SMS or UUS1-messages)arestored in this list.Entries
in the caller list are indicated by the »list« softkey.
aS<> bg
Replace handset. list Select entry Lift up handset Conversation
For more information about the caller list, please refer to page 20 of these operating instructions.
Accepting / refusing a call
In its initial status the telephone will accept all calls, regardless of the selected MSN. If two calls are signaled simulta-
neously the first one is accepted when you lift up the handset. The second call can still be signaledy a call waiting sig-
nal.
The telephone display shows the caller's number or the number the caller hasdialed (MSN-1 … MSN-3, or the assig-
ned name). If only MSN-1 has been entered, the name will be displayed but not the number.
albg
Replace handset. Lift up handset Conversation
If you are unable, or do not wish to accept a call, you have the option of rejecting this call. Press the »reject« soft-
keyandthecall will nolongerbe signaled at your telephone.If you are a memberofa team, then this callwill continue
to be signaled at the phones of your team. If the call was signaled only at your phone, the caller will hear the busy sig-
nal when the call is rejected.
al
S
Replace handset. reject
Call Deflection
If you are unable, or do not wish to accept a call, you have the option of forwarding this call. Press the »x-fer« soft-
key if you wish to forward this call directly to another subscriber. The call number of the forwarding target can be
preset for each call number (msn) when configuring the telephone.
Afterpressingthe »x-fer«softkey, you canforwardthecalltothepresetcallnumber or enteranewcallnumber.
Making Calls
12

al
StO
Replace handset. x-fer Dialing a number (no
preset number availa-
ble)
Calling line identification restriction (anonymous call)
You can block the display of your telephone number at your caller's telephone if desired. You can set this function
specifically for the next call, or permanently (see page 27). The »Completion of call on busy« feature must be applied
for at your service provider for this.
Suppressing calling line identification for the next call
During an external or internal call, you can prevent the number from being transmitted (displayed) to the party you
have called.
at
OFS bg
Replace hand-
set. Dial call num- ber secret Lift up handset Conversation
When a call is signaled, you can decide before accepting the call whether your number is to be transmitted to the cal-
ler. If your phone is the final destination of call rerouting you can use this procedure to prevent the caller from seeing
the final destination phone number (i. e. yours).
al
>S bg
Replace handset. secret Lift up handset Conversation
Starting a call with a fixed MSN extension number
You can conduct an internal or external call such that a defined number (MSN)is transferred from your telephone to
the party you are calling. This number must have been entered previously in your telephone. When you call, either
number that is transmitted is shown in the second line of the display(»MSN-1«...»MSN-3«) or the name that you
have assigned to this number (MSN).
You can initiate dialing using the set extension number (MSN) as explained in the following, or you can use a pro-
grammed function key for this (MSN assignment or user button).
at
OFSS bg
Replace
handset. Dial call number msn msn-1 …
msn-3 Lift up hand-
set Conversation
Redialing
The previously dialed call number is stored in the redial memory.
aWg
Replace handset. Conversation
Extended last number redial
In the extended redialing function the telephone numbers of the last 10 calls, connections, connection attempts or
text messages are stored. You can view these by pressing the redial button or the arrow buttons and subsequently
have them redialed automatically.
aWWO bg
Replace handset. Select entry Lift up handset Conversation
The last dialed number is displayed. At theend of the second line the status of this entry is indicated bythe letters dis-
played there.
Making Calls
13

»V« Connection
»A« Call
»M« Mail(extensionnumbers,towhichSMSorUUS1 messagesweresent)
»|«Callsconfigured forautomaticredialing.
noentry You placedacallto somebodybutdidnot reachhim/her,orhis/herlinewasbusy.
Deleting a call number from extended redialing
aWWFS
Replace handset. Select entry delete?
Press the »delete?« softkey to delete the displayed entry immediately. The next telephone number is then
displayed.
Automatic redialing
If you placed a call to a subscriber whose number is busy or who does not answer, you can then activate automatic re-
dialing which will call that same subscriber again after about 10 seconds.
atg
Wor SO a
Replace
handset. Dial call number Subscriber busy auto_dial Replace handset.
After around 10 seconds the phone is activated and the number is dialed automatically. This is repeated for up to
around 2 minutes.auto_dial
Up to 20 call attempts are made if the subscriber can still not be reached. After 20 unsuccessful attempts, automatic
redialing will be cancelled. You will hear the negative acknowledgement signal in that case.
Information:
Ifautomaticredialing isactive,the» auto_dial«softkeyisshownonthedisplay. Presstherightarrowbuttonto
return to the normal display when the telephone is idle.
Suspending automatic redialing
You can suspend automatic redialing that you have started any time using the appropriate procedure and place a
normal call. To suspend automatic redialing, press the open listening button during automatic redialing.
After the call automatic redialing starts again.
Deactivating automatic redialing
You can deactivate automatic redialing at any time. No further calls will be attempted.
To deactivate automatic redialing during the dialing process press ESC.
If you like to deactivate automatic redialing in the idle state of the phone, proceed as follows:
aSS
Replace handset. autodial ok
Making Calls
