Furniture of America CM3559T User manual

EASY
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
CM3559T
Allen Wrench (Included)
Assembly Instructions
Tools Required for Assembly:
Rev.14-02-21
Page 1 of 6
DIFFICULT
ASSEMBLY RATING
2 PERSONS RECOMMENDED
Phillips Screwdriver
(Not Included)

Page 2 of 6

Parts List Hardware List (Continued)
#1 x 1 pc
Table Top
#2 x 4 pcs
Leg
#3 x 2 pcs
Connecting Frame
#C x 16 pcs
Flat-Head Bolt 5/16”x7/8”
#D x 8 pcs
Bolt 5/16”x1-1/4”
Before you begin, please read Page 2
of “Assembly and Care Advice”.
And remember, do not tighten until
each step is completed or instructed.
#E x 24 pcs
Lock Washer 5/16”
Due to the size and weight of this product, it is highly recommended that the assembly
should be done near the area of its intended location. Make sure you have enough
space to move around during the assembly. ALWAYS have at least two people to help
with transporting and assembling the product and to avoid any potential injury and/or
damage, especially with the fragile nature of the glass.
MD
#F x 16 pcs
Flat Washer 3/4”
#4 x 1 pc
Table Glass
Page 3 of 6
#A x 1 pc
Allen Wrench
#B x 16 pcs
Bolt 5/16”x7/8”
#G x 8 pcs
Flat Washer 5/8”
#H x 8 pcs
Metal Plate
#I x 8 pcs
Plastic Cap

Step 1
Align the metal plate (#H) onto the two pre-drilled holes of the
leg (#2). Secure that plate with the leg by using theAllen
wrench (#A) to tighten the two flat-head bolt (#C).
Repeat the process for the other side and for the remaining 3
legs.
Step 2
I. With the help of another person,
carefully place the table top (#1)
facing down on a protective
surface. Take the assembled leg
(#2) and align the metal plates (#H)
with the 4 pre-drilled holes on the
back of the table top (#1)
II. Prepare a bolt assembly by
inserting FIRST the spring washer
(#E) onto the bolt (#B) and then the
flat washer (#F) onto the SAME
bolt (#B), in that order.
III. Insert the bolt assembly through
the hole of the metal plate (#H) and
secure that bolt using the Allen
wrench (#A) to lock it in with the
table top. Repeat the process for
the remaining 3 holes of the metal
plates.
IV. Repeat the process for the other
assembled leg as pictured.
Turn right (clockwise) to tighten
Turn right (clockwise) to tighten
Page 4 of 6
#1
#2
#2

Page 5 of 6
Step 4 For the other half of the table, repeat Step 2 and
Step 3 again. Make sure you use the correct
hardware with the proper parts.
Step 3
#1
#2
I. Align the connecting frame (#3)
onto the two pre-drilled holes of
the leg (#2).
II. Prepare a bolt assembly by
inserting FIRST the spring
washer (#E) onto the bolt (#D)
and then the flat washer (#G)
onto the SAME bolt (#D), in that
order.
III. Insert the bolt assembly through
the hole of the connecting frame
(#3) and secure that bolt using
the Allen wrench (#A) to lock it in
with the leg.
IV. Use the plastic cap (# I) to cover
the hole. Repeat the process
for the other hole of the
connecting frame.
V. Repeat the process for the other
connecting frame as pictured.
#2
Turn right (clockwise) to tighten
Turn right (clockwise) to tighten
#2
#3

Page 6 of 6
Step 6
To install the batteries (not included),
remove the screw that holds the
battery cover by using a Phillips
screwdriver. Install new AA-size 1.5-
volt alkaline batteries with correct
polarity (,) following the illustration
inside the battery cover. Close the
battery cover and tighten back the
screw.
Step 5
#1 #2
With the help of another person,
carefully turn the table upright. Due to
the fragile nature of the glass, take
caution when inserting the table glass
(#4) onto the table top (#1).
Caution:
Use only batteries of the same type.
Do not mix old and new batteries.
Do not mix alkaline, standard (carbon-zinc), or rechargeable (nickel-cadmium) batteries.
Do not use rechargeable batteries.
Do not try to recharge non-rechargeable batteries.
Remove exhausted or corroded batteries.
Remove batteries to extend their life and to prevent corrosion if the light is not be used for at least 2 weeks.
