Furniture of America CM7966-F User manual

MODEL #
CM7966-F
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
Phillips
Screwdriver
(Not Included)
(Included)
Allen Wrench
1 / 8
VERSION # 21-04-14
3 - People
Recommended

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2 / XXXXXXX8

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3 / XXXXXXX8

4 / XXXXXXX8

FULL BED
CM7966-F
Headboard Footboard
#A 4pcs
Headboard Leg(L&R)
Wood Dowel
M10x40mm Bolt Wood Screw
5/16" x 1 9/16"
#B 4pcs #C 8pcs #D 8pcs
Footboard Leg(L&R)
Side Rail Bed Slat
1387x45x18mm Bed Slat Support 225x30x30mm
Lock Washer M6 Flat Washer M6
Allen Key m4
Bolt 1/4" x 1 3/8"
Wood Button
#E 8pcs
#F 1pc #G 4pcs
CSK M4 x 32mm
#H 8pcs
CSK M4 x 16mm
#I 16pcs
Bracket
#J 4pcs
5 / 8
1830x140x18mm

6 / 86 / 8
CM7966-F is packed in 2 cartons
Carton Designation HardwarePart
CM7966-F
-HBFB
Full Size
Bed HB
Full Size
Bed FB
#6
#7
#A x 4pcs
#B x 4pcs
#C x 8pcs
#D x 8pcs
#E x 8pcs
#F x 1pc
#G x 4pcs
#H x 8pcs
#I x 16pcs
#J x 4pcs
Headboard
Leg
CM7966-F-R #5
Footboard
Leg
Bed Slat
Bed Slat
Support
Side Rail

ASSEMBLY INSTRUCTIONS
2
#C #D #E
#F
#F #B#G #A
#A
STEP 3-1
STEP 3-3
STEP 3-2
#3
#3
#1
#1
Align the headboard legs (#3) to headboard panel
(#1),then secure by using bolts (#B,C)
with washers (#D,E).
Align the footboard legs (#4) to footboard panel
(#2),then secure by using bolts (#B,C)
with washers (#D,E).
#A #1
#F #B#G #A#3 #1
#4#C #D #E
#F
Part #2 x1pc
Part #4 x2pcs
Hardware #A x2pcs
Hardware #B x2pcs
Hardware #C x4pcs
Hardware #D x4pcs
Hardware #E x4pcs
Hardware #G x2pcs
1
Part #1 x1pc
Part #3 x2pcs
Hardware #A x2pcs
Hardware #B x2pcs
Hardware #C x4pcs
Hardware #D x4pcs
Hardware #E x4pcs
Hardware #G x2pcs
STEP 3-1
STEP 3-3
STEP 3-2
7 / 8
#2
2) Align HB legs (#3) to the headboard
(#1), then secure by using bolts (#C)
with washers (#D,E).
1) Insert dowels (#A) to the
headboard (#1)
3) Secure HB legs (#3) onto headboard (#1)
by using bolts (#B), then covering with caps
(#G).
Follow same step 1 as the headboard,
but apply it to the footboard.

3
Part #5 x2pcs
Part #6 x4pcs
Hardware #H x8pcs
Hardware #I x16pcs
Hardware #J x4pcs
ASSEMBLY INSTRUCTIONS
Adjuster
WARNING !
MAKE SURE FIXING
ACCORDINGLY
#I
#J
#5 #5
#6
#7
#6
#5
#H
#5
#6
#7
8 / 8
Part #7 x4pcs
1) Align and hook the side rails (#5) to the headboard and
footboard, then using a rubber mallet with cloth to apply pressure
on the side rails (#5) to be fully secured.
2) Align brackets (#J) to the
headboard and side rails, then
secure by using screws (#I).
3) Attach support legs (#7) to the slats (#6), then align
slats (#6) to the side rails (#5). Secure by using
screws (#H).
