Furniture of America FGI-1992C24 User manual

VERSION # 19-06-05
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
ASSEMBLY RATING
EASY DIFFICULT
Hammer
(Not Included)
(Not Included)
Philips
Screwdriver
TOOLS REQUIRED
2 - People
Recommended
Furniture of America
E-Commerce by Enitial Lab
MODEL #
FGI-1992C24
FGI-1992C32
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
Questions?
1 / 14

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture America
E-Commerce by Enitial Lab
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
of
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessorieslisted on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2 / 14

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3 / 14

IT IS THE USER'S RESPONSIBILITY TO MAINTAIN THE FURNITURE. THE HARDWARE MAY LOOSEN
OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS
INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY.
Turn clockwise to tighten and
only tighten when step is
completed or when instructed
to do so.
Use the appropriate hand tools
or power tools for assembly.
Select steps, such as tightening
screws and/or bolts, may require
hand tools to avoid causing
damage during assembly.
Position each part correctly
and insert screws or bolts into
their respective holes.
Save the instructions and store
any supplied tools for later
maintenance.
After two weeks, check and
tighten any loose hardware and
repeat again every six months
thereafter.
FAILURE TO FOLLOW THE GUIDELINES BELOW MAY
RESULT IN INJURY AND/OR PROPERTY DAMAGE.
ASSEMBLY
AND
CARE ADVICE
4 / 14

Note :
Every cam lock bolt must have a cam
lock connector in order to fasten the
parts together.
CAM LOCK FASTENER
ASSEMBLY
INSTRUCTIONS
cam bolt cam lockscrewdriver
4
Turn the cam lock clockwise gently
until it will not turn any more.
2
Insert the cam bolt into the
bolt hole of joint panel.
3
Align the cam lock with its side opening
(or arrow) pointing to cam bolt.
1
Screw the cam
bolt into panel.
5 / 14

6 / 14

GET READY
Please group boards as below.
7 / 14

8 / 14

9 / 14

10 / 14

11 / 14

12 / 14

13 / 14

14 / 14
Keep this handy!
Please retain this instruction
manual and any order-related
information for future reference.
Lift, don’t drag!
To avoid damage to product
please always LIFT the product
when transporting of adjusting
the placement.
