Fusion VECTOR AC/DC NX85 User manual

VECTOR AC/DC NX85
OpErATInG InSTrUCTIOnS
Please keep for future reference
Input 110-240V AC 1A
or 12-14V DC
Output 4-8 Cell Ni-Cd/NiMH (4.8-9.6V)
Charge Rate 0.5, 1, 2, 3.5 or 5 Amps
Delta Peak Cut-off
•Adjustable charge rates.
•Reverse Polarity Protection on Output.
•Delta Peak cut-off.
www.logicrc.com
Logic RC Limited, 12-18 Hartham Lane, Hertford, SG14 1QN, UK
SpECIFICATIOnS
FEAturEs

•Connect the required battery charge leads to the charger by clamping the
bare ends of the lead into the output. Please ensure correct polarity (+ =
red, - = black).
•Connect either the mains or 12V input power lead into the relevant socket
on the back of the charger and connect this power lead to the appropriate
power source.
•Select the correct charge rate for the battery pack being charged.
•Connect the battery to be charged to the output. When connected, the Red
LED will glow to indicate fast charging.
•When the battery is fully charged, the peak circuitry will terminate the fast
charge and the Green LED will glow to indicate that the battery is now fully
charged.
The charging time for a discharged pack can be calculated by:-
Time (hours) = Battery Capacity (mAh) / Change Rate (mA) x 1.2
•DO NOT charge packs that cannot accept fast charging at the selected
rate.
•ALWAYS monitor the battery pack being charged and disconnect from the
charger if the pack becomes excessively hot.
•NEVER leave the charger unattended whilst charging.
•DO NOT fast charge batteries immediately after use while they are still
warm. Allow to cool to ambient temperature before charging.
•DO NOT charge non-rechargeable or Lithium batteries using this charger.
•This appliance can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way and understand
the hazards involved. Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children without
supervisions. rev. 12-2014
opErAtion
SAFEty prEcAutions
