Fusion GHPF456LB.6165 User manual

REV H DATE: 10/28/2022
FUSION SELF-SERVICE AMBIENT BAKERY MERCHANDISERS
USER MANUALS\20-29787_FUSION_USER MANUAL_GHPF(L)(H)LB_AMBIENT_SLF-SVC_BAKERY CASE
GHPF456LB and GHPF552LB
(With Standard Wire Racks And Optional Wire Baskets)
GHPF656LB.5882A
(With Optional Wicker Baskets)
CDR5838 (With Standard Wire Racks, Curved
Top Glass and Caesarstone® Solid Surface)
GHPF656LB
(With Optional Wicker Baskets) GHPF456LB.5882
(With Optional Wicker Baskets)
GHPF356LB
(With Optional Wicker Baskets)
GHPF456LB.6165 (With Two Front Drawers
And Two Front Work Surfaces)
CDR7586B (With Laminate Packaging Ledge, Tissue
Dispensers, and Reflective Rear Sliding Doors
SCC P/N
20-29787
USER
MANUAL
FUSION
CAREFULLY FOLLOW THESE INSTRUCTIONS
Structural Concepts Corp. ∙ 888 E. Porter Rd ∙ Muskegon, MI 49441 Phone: [phone] Fax: [phone] ∙ www.structuralconcepts.com

2
TABLE OF CONTENTS
OVERVIEW / TYPE / COMPLIANCE / WARNINGS / PRECAUTIONS / PLUGS / WIRING DIAGRAM
INSTALLATION: REMOVAL OF UNIT / POSITIONING CASE / FRAME SUPPORT RAILS …...…….
INSTALLATION, CONTINUED: BOLTING UNITS TOGETHER / ELECTRICAL RATINGS /
BALLAST BOX ………………………………………………………………………………………….
START-UP AND OPERATION: LED STYLE LIGHT FIXTURES / WARNINGS & CAUTIONARY
NOTES …………………………………………………………………………………………………...
MAINTENANCE: SHELF ASSEMBLY / DOOR ACTUATOR / TISSUE BOX / TRASH ………………..
MAINTENANCE, CONT’D: WIRE RACKS AND BASKETS / OPEN LAMINATED STORAGE AREA
SERIAL LABEL INFORMATION AND LOCATION …...…………...…..………………..……………….....
CLEANING SCHEDULE .………………………………….…………...………………….……………...........
HI-MACS® NATURAL ACRYLIC STONE™ CARE & MAINTENANCE ………………………………….
CAESARSTONE® SOLID SURFACE CARE & MAINTENANCE ………………………………………...
TROUBLESHOOTING ………………………………………………………………………………..………..
TECHNICAL SERVICE CONTACT INFORMATION / WARRANTY INFORMATION ….….……….......
3
4
5
6
7
8
9
10
11
12
13
14

3
OVERVIEW
• These Structural Concepts cases should be installed and
operated according to these instructions to ensure proper
performance. Improper use will void warranty.
• This unit is designed to display of products in ambient
store conditions with a max. temperature of 80 °F (27 °C) .
COMPLIANCE
• Performance issues when in violation of applicable NEC,
federal, state or local electrical codes are not covered by
warranty. See below.
WARNING
Risk of electric shock.
Disconnect ALL ELECTRICAL SOURCES before servicing.
WARNING
ELECTRICAL
HAZARD
COMPLIANCE
This equipment MUST be installed in compliance with all applicable NEC,
federal, state and local electrical and plumbing codes.
PRECAUTIONS
• Following are important precautions to prevent damage
to unit or merchandise. Read carefully!
WIRING DIAGRAM
• Each case has its own wiring diagram folded and in its
own packet. It may be placed near ballast box, field
wiring box, raceway cover, or other related location.
CAUTION! POWER CORD AND PLUG MAINTENANCE
Risk of electric shock. If cord or plug becomes damaged,
replace only with cord and plug of same type.
CAUTION! GFCI BREAKER USE REQUIREMENT
If N.E.C. (National Electric Code) or your local code
requires GFCI (Ground Fault Circuit Interrupter) protection,
you MUST use a GFCI breaker in lieu of a GFCI receptacle.
OVERVIEW / COMPLIANCE / WARNINGS / PRECAUTIONS / WIRING DIAGRAM / CORDS & PLUGS
CAUTION! LAMP REPLACEMENT GUIDELINES
If LED lamps are used, they must be size, shape and overall design.
Any replacements must meet factory specifications.
WARNING: This product can expose you to chemicals, including
Urethane (Ethyl Carbamate), which are known to the state of
California to cause cancer and birth defects or other reproductive
harm. For more information go to P65Warnings.ca.gov.

4
INSTALLATION: REMOVAL OF UNIT / POSITIONING CASE / FRAME SUPPORT RAILS
1. Remove Unit From Skid
Slide unit to rear of skid and tip backward off skid.
Case can be repositioned with pallet truck when front
lower panel is removed. Blocking may be necessary
to obtain adequate height.
Slide
Skid
Out
B
A
2. Position & Align Case Alongside Other Cases
• Before shimming, check that the case is in proper
position and, if required, aligned with adjoining
cases.
• This may require repositioning of the case you are
installing or the already positioned cases.
• Align multiple units carefully in areas A, B & C.
3. Frame Support Rails Must Be Shimmed
• Illustration at right shows case with frame
support rails.
• Shims are provided with all cases that have
frame support rails.
• Use shims to level case.
• Note: After case is in position, it must be
sealed to floor to prevent entry or leakage
of liquid or moisture.
C
Frame
Support
Rails

5
INSTALLATION, CONT’D: BOLTING UNITS TOGETHER / ELEC. RATINGS / FIELD ACCESS BOX
4. Bolting Units Together (Not All Cases)
Bolt units together at lower base as indicated.
• Remove front and rear panels (no screw removal
required) to drill clearance hole through end panel
and into unit it is being attached to.
• End panel is shown transparent for illustrative
purposes.
• Use SCC-supplied screws for adjoinment.
5. Electrical Ratings
• See SERIAL LABEL LOCATION &
INFORMATION LISTED / TECH INFO &
SERVICE section in this manual for instructions on
attaining electrical information for your case.
--- Model GHPF356LB ---
--- Model GHPF356LB ---
Field Access / Electrical Box
Model GHPF456LB.5882 Shown / Model GHPF456LB
Has Field Access Box In Same Location
Field Access Box
Ballast Box
6. Field Access Box / Ballast Box / 4 x 4 Box
• Field access box with ballasts (for LED lights)
may be either at rear or at underside of unit (as
shown in illustrations below).
--- Model GHPF456LB.6165 ---
Field Access Box Ballast Box

6
START-UP AND OPERATION: LED STYLE LIGHT FIXTURES / WARNINGS & CAUTIONARY NOTES
1. LED Style Light Fixtures
Removal of Faulty LED Lights:
• LED lights rarely require change-out.
• Contact Structural Concepts’ Technical Service
Department for replacement LED lights.
• Turn off LED light switch.
• To remove faulty LED light, follow these steps:
A. Disconnect plug from LED light.
B. Using both hands, grasp LED light assembly
(with its magnetic mounting clips). Pull
downward and off its shelf (or header).
C. Remove magnetic mounting clips from LED
light by pressing against flange part of clip
with thumb.
>> Note: Mounting clips MAY be riveted to shelf or
header. In such instances, simply remove LED light
from mounting clips by pressing against flange part
of clips with thumb.
Replacement of LED lights:
• Attach magnetic mounting clips onto LED light.
• Adjust magnetic mounting clips so they are equally
spaced on LED light.
• Reattach LED light assembly to its shelf/header.
• Position properly in shelf/header.
>> Note: If mounting clips are riveted to shelf (or
header), attach by placing LED in base of clip and
then snapping into clip at FLANGE SIDE.
• Press plug’s barrel-shaped insert all the way into
LED light’s orifice.
• Important: If plug is not inserted ALL THE WAY IN
the LED light’s orifice, light may not energize. See
“BAD” vs. “GOOD” insertion illustrations below.
• Turn LED light switch back on.
2. Warnings & Cautionary Notes
Warning! Disconnect power before providing
maintenance and service to unit.
Caution: Lamps have been treated to resist
breakage. Replace only with such treated lamps.
Note: Warranty will be void if claims arise from
negligence, misuse of goods, extreme
environmental conditions or improper
maintenance.
A
Plug
Barrel
Shaped
Insert
LED
Light
Magnetic Mounting
Clip View #2
LED
Lights
B
C
Magnetic Mounting
Clip View #1
LED Lights
LED Light
Switch
No Gap
Gap

7
MAINTENANCE: SHELF ASSEMBLY / DOOR ACTUATOR / TISSUE BOX / TRASH
LED Light at
Underside
Rear Rack Support
Shelf Bracket
Bracket
Retainers
1. Shelf Assembly Removal
• Remove and set aside glass
or wire shelves.
• For lighted shelving, unplug
light cord and detach from
rear shelf support.
• Slide light assembly back to
unlock, then rotate up to
separate from brackets.
• Slide rear support back to unlock and rotate up to
separate from brackets.
• Remove brackets. Note, it may be necessary to
remove the nylon shipping bracket retainer.
• Pliers will be required to accomplish this task.
2. Door Actuator Removal (For Repair, etc.)
• Remove false deck (no tools required).
• Remove screw from actuator arm.
• Remove 4 screws from actuator cover plate.
• Remove 2 mounting screws that secure actuator to
mounting flange.
• Withdraw actuator.
3. Tissue Box
• See illustration below.
4. Trash
• Hinged, spring-actuated flip door provided.
• Drawer may be pulled out to empty trash container.
Wire Rack
(Typical)
Bag Placement
Trash (Drawer
May Be Pulled
Out To Empty)
Tissue Holder
Actuator Arm
(Typical)
Cover Plate (Typ.)

8
MAINTENANCE, CONTINUED: WIRE RACKS AND BASKETS / OPEN LAMINATED STORAGE AREA
Note: Information on This Sheet is
Applicable To Model GHPF456LB Only
1. Wire Racks and Baskets
• Wire racks and baskets are removable for
cleaning purposes.
• See cleaning schedule for cleaning specifics.
2. Open Laminated Storage Area
• Open laminated storage area is at case front.
• See cleaning schedule for cleaning specifics.
Wire Basket
Wire Basket
Wire Rack
Open Laminated Storage Area
Model GHPF456LB (Partially
Disassembled For Illustrative
Purposes Only)

9
SERIAL LABEL LOCATION & INFO LISTED / TECH INFO & SERVICE - AMBIENT/HEATED CASES ONLY
--- Sample Serial Label For Ambient/Heated Cases ---
MODEL NRS3648RXV-SAMPLE
SERIAL NO. 12345X30DZ098765
888 E. Porter Rd - Muskegon, MI 49441
3048256
Conforms to UL Std. 65
CERTIFIED TO CAN/CSA
STD C22.2 NO 120
120 VOLTS 60HZ
FOR PARTS OR SERVICE CALL
STRUCTURAL CONCEPTS
AT 1-800-433-9489
SINGLE PHASE 1.84 AMPS
Serial Label Location & Information Listed /
Technical Information & Service
• Serial labels are affixed at a wide range of places
(on the header, at case rear, behind panels or
toe-kicks, on electrical boxes, etc.).
• Serial labels contain electrical information as well
as regulatory standards to which the case
conforms.
• Sample serial label shown below.
• For additional technical information and service, see
the TECHNICAL SERVICE page in this manual for
instructions on contacting Structural Concepts’
Technical Service Department.
Sample QR Code
SCAN FOR PRODUCT LITERATURE
Reveal
Harmony
Fusion
Impulse
Addenda
Blend
Grocerant
Oasis

10
CLEANING SCHEDULE
Cleaning Daily Weekly Monthly Task
Clean Case
Exterior XClean glass doors, sides and top with household or commercial glass cleaner.
X
HiMacs® Natural Acrylic Stone (Solid Surface): See
HI-MACS® NATURAL ACRYLIC STONE™ CARE
& MAINTENANCE section in this operating
manual.
X
Open laminated storage area (Model GHPF456LB
only): clean with soft cloth dipped in warm soapy
water. Wipe down with paper towel or cloth dipped
in clean water to rinse away soap residue.
X
Rear doors and door track: Remove rear doors and
clean with a household or commercial cleaner.
Clean out door track with moist cloth.
X
Toe-kicks: To remove dirt, dust and scuffs, clean with
soft cloth or soft-bristled brush dipped in warm, soapy
water. Wipe down with rag dipped in clean water to
rinse away soap residue.
Clean Case
Interior XClean glass doors, sides and top with household or commercial glass cleaner.
X
Wicker baskets can be removed and residue brushed
out. For fine, powdery residue, use vacuum with
brush attachment.
X
Caesarstone solid surface: See CAESARSTONE®
SOLID SURFACE CARE & MAINTENANCE section
in this operating manual.
X
Decking and drawers may be cleaned with soap and
water solution and soft cloth. For hardened residue,
use soapy water and scrub with non-metallic,
soft-bristled brush.
X
Remove wire racks and wire baskets (and clear
plastic liners, if any) and wipe down with soft cloth
dipped in warm soapy water. For hardened residue
(or for more thorough cleaning), submerse in warm,
soapy water and scrub with non-metallic,
soft-bristled brush.

HI-MACS® NATURAL ACRYLIC STONE™ CARE & MAINTENANCE
GENERAL STAINS
TOUGHER STAINS
ACIDIC CLEANING AGENTS
HOT OBJECTS
BURN MARKS
SHARP OBJECTS
----------------- HI-MACS® NATURAL ACRYLIC STONE™ STAIN vs. CLEANING AGENT LEGEND ------------------
SCC P/N 20-29836
Rev A Date: 7.25.2013
I:\Oper Manuals\Specialty\Hi-Macs Natural Acrylic Stone Care 20-29836.pub

CaesarStone® Care & Maintenance
TAKING CARE OF YOUR QUARTZ SURFACE
CaesarStone quartz surfaces blend modern sophistication
and timeless luxury with unbeatable strength and
durability. The ever-lasting finish requires only simple and routine care to maintain its good looks.
MINIMAL MAINTENANCE
Virtually maintenance-free, CaesarStone’s hard, non-porous surfaces require no sealing to renew the
luster and are simple to clean. In most cases, dip a clean, soft cloth into a solution of water and soap
(or mild detergent) solution and wipe away dust, smudges and residue; then rinse with clean water to
remove residue. This simple treatment is usually enough to keep your CaesarStone countertop
looking like new. If necessary, use a non-abrasive soft soap along with a non-scratch or delicate
scrub pad. Afterwards, thoroughly rinse with clean water to remove residue.
STUBBORN STAINS OR DRIED SPILLS
If needed, apply a non-abrasive household cleaners (a non-abrasive cleaner will not dull the surface
shine); rinse to remove residue. To remove adhered material such as food, gum, nail polish or even
dried paint, first scrape away excess material with a plastic putty knife and then use a damp cloth to
remove any marks or residual dirt. For extra-stubborn stains, use a no-scratch Scotch-Brite® pad
along with the non-abrasive cleaner recommended by your local CaesarStone® distributor.
HEAT TOLERANCE
CaesarStone is more heat resistant than other stone surfaces including most granite, marble and
limestone; it is not affected by temperatures lower than 300 °F (149 °C). However, like all stone
material, CaesarStone can be damaged by sudden and rapid temperature changes. Therefore, do not
place hot pots or pans directly placed on the surface. Instead place a hot pad or trivet on the surface
under cooking units such as electric frying pans, crock pots, or roaster ovens.
SCRATCH RESISTANT
CaesarStone is a highly scratch resistant surface; however avoid abuse of the surface by refraining
from using sharp objects such as sharp knives or screw drivers directly onto the surface.
CLEANING AGENTS TO AVOID
• It’s important to be aware that like any other surface, CaesarStone can be permanently damaged
if exposed to strong chemicals and solvents that can damage its physical properties.
• Never clean your CaesarStone surface with products that contain Trichlorethane or Methylene
chloride, such as paint removers or strippers.
• Avoid the use of highly aggressive cleaning agents such as oven/grill cleaners and dishwasher
polishing agents that have high alkaline/pH levels (pH 8.5 or higher).
• Products containing oils or powders may leave a residue and should be rinsed off thoroughly.
Should your surface accidentally be exposed to any of these damaging products, rinse
immediately with clean water to neutralize the effect.
CAESARSTONE® SOLID SURFACE CARE & MAINTENANCE
12

13
TROUBLESHOOTING
Issue Resolution of Issue
Product is Drying Out Check the relative humidity in the store.
Case Lights Not Working Check that light switch is on.
If power cord is used, check the unit is properly plugged in.
Be sure ALL lights are plugged in properly.
Check bulb for proper installation and connection.
Check for burned out bulb.
Clean dirt and dust from the bulbs to prevent flickering.
Trained Service Providers Only: After performing all other checkpoints and
lights are still not working, check for faulty ballast or circuit breaker box for
tripped circuits.

STRUCTURAL CONCEPTS TECHNICAL SERVICE CONTACT INFORMATION & LIMITED WARRANTY
14
TECH SERVICE/WARRANTY CONTACT INFO:
1 [phone] / EXTENSION 1
DAYS/HOURS AVAILABLE:
MONDAY - FRIDAY (CLOSED HOLIDAYS)
8:00 a.m. TO 5:00 p.m. EST
YOU MUST HAVE THE FOLLOWING INFO AVAILABLE
BEFORE CONTACTING STRUCTURAL CONCEPTS:
SERIAL NO. / MODEL NO. / STORE NO. / STORE
ADDRESS / DETAILS (PHOTOS, LEAK LOCATIONS,
DAMAGE, STORE’S AMBIENT CONDITIONS, ETC.)
To Access The Limited Warranty To Your
Case, Follow These Instructions:
> If Viewing This Document on Smart Phone,
Tablet or Computer, Select/Click On The QR
Code at Right.
> If Viewing This Document In Print (Hard
Copy), Scan The QR Code at Right With Your
Smart Phone or Tablet.
