Futuro Futuro RACCOLTA INSERT User manual

Futuro Futuro
Futuro Futuro
RANGE HOOD
INSTALLATION MANUAL
MODEL: RACCOLTA INSERT
NOTE: PRIOR TO INSTALLATION
Please inspect range hood visually,
as well as connect it to power supply
and test its operation.
2For easier installation, remove the cabinet
and install the range hood in cabinet,
then install the hood+cabinet assembly.
Recommended
Installation
Height
26” - 28”
from cooktop
to bottom
of hood
1
3Insert hood into cabinet, and secure with screws.
Adjust & level as necessary.
Note: you may also use ller panels / transoms, as needed.
All manuals and user guides at all-guides.com
all-guides.com

FEATURE: REAR EXHAUST (THROUGH-WALL VENTING)
THIS MODEL CAN EXHAUST THROUGH THE TOP, OR THE REAR. TO EXHAUST THROUGH THE REAR (THROUGH WALL):
1.) REMOVE 8 SCREWS & LIFT OUT BLOWER MODULE (AS SHOWN); 2.) DISCONNECT THE POWER PLUG (NOT PICTURED).
3.) TURN THE BLOWER MODULE & RE-INSERT INTO HOOD; 4.) RECONNECT THE POWER PLUG & REPLACE 8 SCREWS.
RACCOLTA
24” VERSION
DIMENSIONS
RACCOLTA
36” VERSION
DIMENSIONS
NOTE: Dimensions are provided as a general reference. The manufacturer strongly recommends measuring
the actual range hood unit on-site, and to avoid making any commitments to cutting or customizing cabinetry
until these measurements are made.
20 1/4”
28 1/2”
21”
29”
10 1/4”
10 1/4”
10 3/4”
10 3/4”
1” 1”
