Fuzi HIDEKO User manual

HIDEKO MASSAGE CHAIR
OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS

01
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
TABLE OF CONTENTS
02-03
04-08
09
10-11
12-13
14-39
14
14-31
32-33
34
35
35
36-37
37-38
39
39
39
40
Safety and Maintenance
Safety Warning
Name of Components
Function
Introduction to the Remote Controller
Method of Usage
I.Turn on the power supply of this product
II.Massage Function Control Operation
III.Introduction to Armrest Shortcut Keys
IV.Voice Control Mode
V.Operation Instructions for Bluetooth Speaker Play
VI.Turn off the power and stop massage
VII.Installation Instructions for Armrests
VIII.nstallation Instructions for Legrest
IX.Instructions for Removal and Use of Head Cushion and Backrest
X.Floor Protection
XI.Instruction for Movement
Product Specification

0302
Safety and Maintenance Safety and Maintenance
1.Important Safety Warnings
·Do not allow children to touch any movable part of this product.
·Use the well-grounded power supply unit suitable for this product.
·Pull out the plug after use or before cleaning to avoid any physical injury or damage to
the product.
·Operate this product as instructed in this manual.
·Do not use any parts or accessories which are not recommended.
·Do not use this product outdoors.
·Please read the Operation Instructions carefully before operation.
·Never use this product for any other purpose not listed herein.
·20 minutes of usage each time is recommended.
·Do not use this product if the leather is broken or damaged.
·Do not use this product if the cover or leather is broken or damaged.
·Do not use this product if the radiator hole is covered or blocked.
·Do not drop anything into this product.
·Never fall asleep while using this product.
·Do not use this product if you are drunk or feel unwell.
·Do not use this product within one hour after a meal.
·Do not use this product with excessive force to avoid any injury.
·Do not carry any fragile, explosive, or combustible material in your pocket, such as a
mobile phone and lighter when using the massage chair.
2. Operating Environment
·Do not use this product in a very moist environment such as the bathroom.
·Stop using this product immediately when the ambient temperature changes sharply.
·Do not use this product in any heavily-dusty or caustic environment.
·Do not use this product in a small space or a place without good ventilation.
·The normal room temperature ranges from 0 °C to 35 °C.
·Do not use this product in an excessively humid room such as a bathroom. Use it at a
relative humidity between 20% and 80%.
·Do not use this product outdoors.
·Avoid direct sunlight.
·Keep this product away from any heat source such as a stove and air outlet of an air
conditioner.
·Do not use this product during thunder or lightning weather.
·Do not use this product in dusty places.
3. The following populations should not use this product:
·Patients with osteoporosis.
·Patients with heart disease or wearing electronic medical devices such as a
pacemaker.
·People who have a fever.
·Pregnant women or women on their menstrual period.
·Patients who are injured or have a skin disease.
·When unsupervised, any children are under the age of 14 and those unconscious are
not allowed to use this product.
·People who are told by their physicians to have rest or who feel unwell.
·People whose bodies are wet are forbidden to use this product.
·This product has a hot surface. Persons insensitive to heat must pay attention when
using this product.
4. Safety Precautions
·Check whether voltage is consistent with the specification of this product.
·Never insert or pull out the plug with a wet hand.
·Do not let water flow into this product to avoid electric shock or cause damage to this
product.
·Do not pull the power cord when plugging or unplugging it. Rough handling is
forbidden.
·Do not damage the wire or modify the circuit of this product.
·Do not clean live parts of this product with a wet cloth such as a power switch and plug.
·Be away from this product in case of power failure to avoid any injury if power is
restored suddenly.
·Stop using this product at once while it works abnormal, and consult your local supplier.
·Stop using this product if you feel unwell, and consult your health care practitioner.
·This product is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning the use of this product by
the personnel responsible for their safety. Children should be supervised to ensure that
they do not play with this product.
·If the power cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified staff in order to avoid hazards.
5. Product Service and Maintenance
·This product should be maintained by the service center designated by the
manufacturer only. No user should disassemble or maintain it without permission.
·Do not forget to turn off the main power switch after usage.
·Do not use this product if the power socket becomes loose.
·If this product will be left unused for a long period of time, it is necessary to roll up the
power cord of this product and store this product in a dry and dust-free environment.
·Do not store this product at a high temperature or near open flame. Avoid prolonged
exposure to direct sunshine.
·Please clean this product with dry cloth. Never use thinner, benzene or alcohol.
·The mechanical components of this product are specially designed and manufactured,
so no special maintenance is needed.
·Do not use a sharp object to stab at this product.
·Do not roll or pull this product on any uneven ground. Instead, it should be lifted before
moving.
·Please use this product intermittently. Do not keep it working continuously for a long
period of time.
6. Solutions to Ordinary Malfunctions
·If the motor sounds during operation of this product, this is the normal operation sound.
·If the controller cannot work normally, check whether the plug and the power socket are
connected reliably, and whether the power switch is turned on.
·If the rated working time is over, this product will automatically activate the power-off
button; If this product keeps operating for a long period of time, the temperature
protector will stop this product automatically. The product can be used again after half
an hour.
7. Storage Conditions
·Storage room temperature: -5 °C to 35 °C.
·Relative humidity (RH) between 20% and 80%; free of corrosive gases, and a well-
ventilated room.

0504
Safety Warning Safety Warning
Warning Warning
When the legrest of the massage chair is lifted, nobody should apply pressure on
the legrest to prevent the massage chair from falling forward which will damage this
product or result in personal injuries.
Do not remove or pull out the remote controller cable or the power cord in the
standby or power-on state to avoid any damage to this product or accidental electric
shock of a body part. You are advised to unplug the remote controller cable and the
power cord and put them away after you use the massage chair.
Warning
Before sitting on the massage chair, make sure that the massage chair manipulator
does not stay in the seat cushion position to avoid discomfort to the buttocks during
the body pressing down and any damage to the massage chair manipulator.
Warning
When the zero-gravity lying function is enabled, be sure to check whether there is
any child or pet staying or playing under the bottom of the legrest and backrest, in
order to avoid any damage to this product or physical injury.
No downward pressure

06 07
Safety Warning
Warning
Before using the massage chair, remove any hard objects in your pocket(s) or any
jewelry carried with you (e.g. key, watch, other similar portable hard objects) to
avoid any damage to this product or physical injury during massage.
Warning
Do not unplug the power cord, or directly turn off the power switch on the back of
the massage chair during massage, in order to avoid any damage to this product or
physical injury.
Warning
Warning
Please do not fall asleep on the massage chair while using to avoid personal injury
caused by unconscious use.
The massage chair should not be used by more than two people at the same time to
avoid product failure or personal injury. In addition, do not let children play on the
massage chair or climb onto the lower leg, seat cushion, foot, backrest or armrest.
Otherwise, accidents or injuries may be caused.
Safety Warning

1
2
4
613
10
20
22
16
18
19
7
21
15
12
8
11
3
14
5
17
9
08 09
Safety Warning
Warning
When adjusting the footrest retractable function or when footrest is declining, please
be sure not to put hard objects (such as keys, mobile phones, Etc.) or put the hand
into the gap of the footrest, and the intersection with the armrest; To avoid product
damage or personal injury caused during the process.
Warning
Before turning on the massage chair, check the surroundings to make sure
that there are no people, pets or other objects around the massage chair
Avoid damage to the product or other objects or personal injury during the
operation of the massage.
Name of Components
1.Head cushion
2.3D digital audio
3.Anion generator
4.Upper arm airbag
component
5.Waist airbag component
6.Remote controller
7.Remote controller slot
8.Arm airbag component
9.Salient massage belt
and magnetic t therapy
10.Legrest
11.Footrest
12.back cushion
13.Phone wireless charge
14.Shortcut button
15.Armrest
16.LED atmosphere lamp
17.Armrest decoration
18.Side cover
19.Backrest cover
20.Drive box cover
21.Move wheel
22.Power cord and plug
23.Power switch
24.Power cord fuse
25.Power input
22 2423
FUSE:
T5AL 250V POWER INPUT
ON/ OFF

1110
FunctionFunction
and right upper arms. The Bluetooth function of the smart device can be used to
play music wirelessly.
·Wireless charging function is provided in the mobile phone placement slot at the
front of the left armrest.
·There is an anion generator on the right capsule.
·The left armrest is equipped with calf lifting key, linkage lying key, heating treatment
key, voice control wake-up key, automatic key, zero gravity key, switch (pause) key,
3D massage manipulation strength rotation button.
·In the air bags for the left and right palms, there are salient massage with magnetic
therapy function.
·Leg stretching massage function: the lower legs and backrest can be lifted and
lowered for automatic lying, as well as automatic cyclic lying. Meanwhile, the leg air
bags and the back manipulator simultaneously cooperate with each other for
massage, and the legs can be stretched for massage.
·This product is equipped with the leg kneading massage function: the kneading
and airbag squeezing massage functions are provided on the leg rest to relieve the
stiffness or tension of the leg muscles caused by standing for a long period of time.
·This product is equipped with the salient scraping massage for the calf: It can
relieve fatigue, tightness, and pain of the calf muscles, effectively promote the
blood circulation, massage meridians, effectively improve the stiffness or tension of
the leg muscles, and relieve local swelling and restore vitality.
·The massage chair is equipped with the independent up/down adjustment function
of the leg rest and the backrest, the linkage up/down adjustment function of the
backrest, and the zero-gravity automatic lying angle adjustment function.
·The foot roller massage function is available for the feet bottoms. Three sets of
rollers roll to massage the roots of the toes; rolling and scraping massage is
available for the foot arch; there are three speed levels for adjustment.
·The foot rest is equipped with the function of automatically detecting the length of
the foot rest. When the calf frame rises or falls to an appropriate angle, the foot rest
will automatically detect the length of the foot and detect the most comfortable
massage part.
·The foot rest is equipped with an electric telescopic adjustment function, which can
adjust the telescopic distance according to the leg length of the user to achieve the
most comfortable massage position and length for the foot.
·The left and right armrests are equipped with LED atmosphere lamps.
·Such functions as shutdown, automatic sitting up, and automatic manipulator
resetting are available.
·The product has a remote controller with TFT color screen.
·This product is designed with a set of intelligent 3D massage manipulators with
silent design that can move up and down and extend from front to back.
·It is designed with automatic detection and micro-adjustment functions of the
shoulder position, as well as automatic detection function of the human body curve
and shiatsu massage points. Therefore, according to the detected human body
curve and shiatsu massage points, it can automatically adjust the manipulators to
extend from front to back, making the massage more user-friendly and scientific.
·21 special automatic massage functions are available: fast massage, comfortable
massage, relaxing massage, stretching massage, full body massage, neck &
shoulder massage, back & waist massage, and full airbag massage, Stress
relieving, Energy, Good-night sleep, Joint care, Spine massage, Office regimen,
Sport recovery, Neck & shoulder care, Brain refresh, Spine care, Waist care, Legs
care and Rejuvenation.
·There are five intelligent memory functions (M1, M2, M3, M4, M5): Remarks on
saved massage functions and techniques are available (e.g. father, mother,
daughter, son, or none).
·Manual massage range selection is available for the manipulators: including five
massage ranges for your option (i.e. full range, local, fixed point, upper back and
lower back).
·Manual massage function selection is available for the manipulators: 17 massage
techniques are available, including kneading(Seven modes of kneading can be
switched cyclically), tapping (Tapping I, Tapping II), simultaneous kneading and
tapping, shiatsu (Shiatsu I, Shiatsu II), shoulder lifting, 3D (3D I, 3D II, 3D III, 3D
IV), etc.
·Massage adjustment function: 7 massage adjustment functions are available,
including 5 speed levels for back massage adjustment, 5 intensity levels for back
massage adjustment, 5 range levels for massage adjustment, 5 width levels for
massage adjustment, 5 intensity levels for airbag adjustment, 3 speed levels for
roller adjustment, 4 time levels for massage adjustment.
·Airbag massage function for the upper body: palm arm air pressure massage
function (built-in 8 air bags), upper arm air pressure massage function (built-in 4 air
bags), waist air pressure massage function (built-in 8 air bags), five levels of air
pressure intensity adjustment.
·Airbag massage function for the lower body: airbag massage function for the legs
(6 built-in air bags), airbag massage function for the feet (22 built-in air bags), and
5 intensity levels for airbag adjustment.
·Such function as back heating function(graphene heating system) is available
·The slide rail technology for the backrest ensures zero space between the
backrest and wall, so as to save the space to the greatest extent.
·The backrest guide adopts the curve guide technology, so it completely fits the
curve of the human back. The full body can enjoy full massage from the head to
the thighs.
·This product is equipped with the intelligent voice control and recognition function.
·The music player system is available. 3D digital audio systems are built into left

1312
Introduction to the Remote Controller Introduction to the Remote Controller
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
1
1.Display:
·TFT color LCD showing the massage functions in the running state.
2.Switch:
·Turn on or off the massage.
3.AUTO key:
·Enter the automatic function mode selection interface. For more information about the
functions, refer to Page 16 of the Operation Instructions.
4.Zero-gravity key:
·Adjust the angle of the massage chair for zero gravity. There are a total of four modes
to choose from (i.e. 1st pressing is Level 1; 2nd pressing is Level 2; 3rd pressing is
Level 3; and 4th pressing makes the massage chair restore to the original state).
5.Up key:
·Up navigation key: select an object upward in the menu, or adjust the massage position
upward.
6.OK:
·Confirm the selected massage function for massage.
7.Left button:
·Left navigation key: return to the previous menu, or select an object leftwards.
8.Down key:
·Down navigation key: select an object downward in the menu, or adjust the massage
position downward.
9.Foot rest shortening key:
·Shorten and adjust the foot rest according to the height to the most comfortable
massage position.
10.Legrest Up key:
·Adjust the legrest upward according to your own massage needs for the most
comfortable massage posture.
11.Legrest down key:
·Adjust the leg rest downward according to your own massage needs for the most
comfortable massage posture.
12.Foot rest elongation key:
·Elongate and adjust the foot rest according to the height to the most comfortable
massage position.
13.Pause button:
·Pause all the massage functions currently in service. Press this button again to
continue to run all the massage functions before such pause.
14. Menu button:
·Enter the main menu selection interface. For more information about the functions, refer
to Page 15 of the Operation Instructions.
15.Right button:
·Right navigation key: enter the submenu, or select an object rightwards.
16.Linkage sitting key:
·According to the required massage angle, simultaneously adjust the linkage sitting
function of the backrest and the leg rest for the most comfortable linkage sitting
massage posture.
16.Linkage lying key:
·According to the required massage angle, simultaneously adjust the linkage lying
function of the backrest and the leg rest for the most comfortable linkage lying massage
posture.

1514
Method of UsageMethod of Usage
II. Massage Function Control Operation:
1.Standby
30:00
Fast massage
Auto program 30:00
00:00
I. Turn on the power supply of this product:
·After the massage chair is powered on and turned off,
the remote controller is blank in the standby state (i.e.
the LED lamp is off) and cannot perform any operation
(except the key switch). You can use the armrest shortcut
keys to adjust the angle of the backrest and leg rest. You
can also use the voice control button for wakeup.
2.Start massage (power switch)
·Press the switch to start massage. Enter the start-up screen. The backrest will
maintain the default position, and the leg rest will be slightly raised. Just wait for
any one of automatic function programs in the automatic function selection
interface to start massage. If no "AUTO" function is selected within 5 minutes, the
massage chair will automatically shut down.
1) Lying angle adjustment
·After selecting any automatic function, the positions of the backrest and the leg
rest will be adjusted to the preset angles.
· After the angle is adjusted, the massage chair will automatically perform the
shoulder position and body shape detection. Wait for completion of such detection
(alternatively, press "OK" to skip the step).
2) Shoulder position adjustment
·After detecting the shoulder position, the buzzer will beep. If there is any difference
from the actual shoulder position, adjust it to the appropriate position by pressing
the "UP" or "DOWN" key. The shoulder position has 11 adjustable levels. If there is
no shoulder position adjustment within 10 seconds, the massage function will start
automatically. Press "OK" directly to start massage immediately. If no shoulder
position can be detected, massage will be started according to the shoulder height
by default. Note: During massage, under the information interface, you can press
"Right Button" to select the "Shoulder Adjustment" menu, and press "OK" to enter
the shoulder adjustment interface. You can also use "Up Key" or "Down Key" to
adjust the shoulder position.
Comfort massage
Select the object with ▲▼ and press OK
Relax massage
Stretch massage
Full body massage
Meck&shoulder massage
Auto lying down
Attention! Ensure that there
are no objects around the
massage chair
Press OK to skip
Body sensing
Just a moment......
Press OK to skip
Auto Mode
Fast massage>
Knead
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
Shoulder position
Please use ▲▼ to adjust the shoulder position and press OK
·High shoulder position
·Suitable shoulder position
·Low shoulder position
Plugging-in diagram Product connection
diagram
Power switch diagram
of the product
POWER IN PUT
ON/OF F
FUSE:
T5AL 250V
POWE R INPUT
ON/OF F
FUSE:
T5AL 250V

1716
Method of UsageMethod of Usage
Note: you can't adjust the massage position when it is in auto program.
MainMenu
Auto program
30:00
·If you need to adjust the shoulder position after the massage program is started,
you can directly select "Shoulder Position Adjustment" to enter the shoulder
position adjustment interface; you can press "Up Key" or "Down Key" to adjust the
shoulder position height; you can press "Left Button" to return to the previous
menu, or wait for 10 seconds to automatically return to the information interface
·After entering the massage program, if you need to adjust the massage position,
you can press the "Menu" button on the remote controller to select "Manual
Function" to enter; you can select any one of the manual functions, and then press
"Left Button" to return to the information interface (i.e. The information interface will
switch to the manual function interface)
·In the manual function interface, if the massage range shows a fixed point or local
area, you can directly press "Up Key" or "Down Key" to adjust the manipulator
upward and downward
·In the manual function interface, if the massage range displays neither fixed point
nor local area, you need to select "Massage Adjustment" to enter, and then select
"Massage Range", and a fixed point or local area, and press "Left Button" to return
to the information interface. Next, you need to press "Up Key" or "Down Key" to
adjust the manipulator upward and downward
3.Pause button
·While the massage function is in service, press "Pause" button to temporarily stop
all the massage functions; press "Pause" button again to continue the massage
function before pause. If the pause time exceeds 20 minutes, all the massage
functions will be automatically turned off.
3) Massage position adjustment
Button Description
Move the massage balls upward to a suitable shoulder position
Move the massage balls downward to a suitable shoulder position
4.Menu button
·Press "Menu Button" to enter the massage function selection interface of the main
menu, including automatic, manual, and other functions, intelligent storage, angle
adjustment, settings and other function interfaces.
·Enter the menu interface. Press "Up Key" or "Down Key" to select the function.
Confirm via "OK" to enter the next level of selection; press "Left Button" to return to
the previous menu interface.
30:00
00:00
Auto Mode
Fast massage>
Knead
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
Select the object with ◀▶ and press OK
30:00
Shoulder position
Please use ▲▼ to adjust the shoulder position and press OK
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
30:00
00:00
ManualMode
Knead>
Range:Spot
Width:2
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
use ▲▼ to adjust the massage position at the Spot and Partial
Pause
Pressthepausebuttonagain
toresumeusing

1918
Method of UsageMethod of Usage
Function
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the automatic functions. Press "OK" (or press "AUTO Key" directly in
the information interface) to enter the selection of automatic functions.
· 21 special automatic massage functions are available: fast massage, comfortable
massage, relaxing massage, stretching massage, full body massage, neck &
shoulder massage, back & waist massage, and full airbag massage, Stress
relieving, Energy, Good-night sleep, Joint care, Spine massage, Office regimen,
Sport recovery, Neck & shoulder care, Brain refresh, Spine care, Waist care, Legs
care and Rejuvenation.
· Enter the automatic function interface. Press "Up Key" or "Down Key" to select any
automatic function massage program. It will automatically return to the information
interface, which will be displayed as the automatic function information interface.
1) Automatic function (main menu - automatic function)
Fast
massage Experience all the massage effects quickly.
The most comfortable massage experience.
Gentle and comfortable deep massage to relieve your body
fatigue and relax the body.
Stretch your legs and waist through the leg rest and the backrest to
effectively remove fatigue,relieve joint pain and restore vitality.
Deep massage to rejuvenate your body.
With the unique massage technique for the neck and shoulder, the
effective massage for the cervical spine and scapula can be
performed to relieve the neck and shoulder pain and reduce fatigue
on the neck and shoulder.
Focus on the back and waist massage to relieve the pain on the
back and waist.
Focus on the full-body airbag massage to achieve full relaxation
and deep massage of the body and fully relieve the fatigue and
pain from your body.
Comfortable
massage
Relaxing
massage
Stretching
massage
Full body
massage
Neck&
shoulder
massage
Back&waist
massage
Full airbag
massage
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
30:00
Fast massage
Auto program
Comfort massage
Select the object with ▲▼ and press OK
Relax massage
Stretch massage
Full body massage
Meck&shoulder massage
Description
Neck &
shoulder
care
With the unique massage technique for the neck and shoulder, the
effective massage for the cervical spine and scapula can be
performed to relieve the neck and shoulder pain and improve the
blood supply to the brain.
Restore the full body from fatigue and pain; achieve relaxation,
improve micro-circulation, and quickly relieve fatigue for the back
and limbs.
Stress
Relieving
Energy
Good-night
Sleep
Joint Care
After a night of rest, the body can have a rest; the whole body
muscles are massaged to quickly wake up the body functions and
start a new day of vitality.
Through the massage for the twelve major acupoints for healthcare,
it helps the body to adjust balance, quickly improve your sleep and
your sleep quality.
Care for the health of all your limbs and joints by pushing, pulling,
stretching, and other massage modes.

2120
Method of UsageMethod of Usage
Note: The automatic functions in service already selected will be displayed in the
massage function status bar.
2) Manual function (main menu - manual function)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the manual function, and press "OK" to enter the manual function
interface.
·11 manual massage techniques/functions: OFF, kneading, Tapping I, Tapping II,
simultaneous kneading and tapping, Shiatsu I, Shiatsu II, shoulder lifting, 3D I, 3D
II, 3D III, 3D IV, etc.
·After entering the manual function interface, press “Up Key” or “Down Key” to
select the required manual massage technique. Press “OK” to confirm(There are
seven modes of kneading, press the "confirm key" to switch cyclically). After
selecting the technique, you will not automatically return to the information
interface. Press "Left Button" to return to the previous interface. After returning to
the information interface, you will find that you have entered the information
interface of the manual function.
Legs Care
Office
Regimen
Sport
Recovery
Brain
Refresh
Spine Care
Waist Care
For sitting in the office for a long period of time, this function can
increase physical exercise by massage and improve the body
functions.
Make you quickly recover from physical fatigue after exercise.
Relieve the neck and shoulder pain; promote the blood supply to the
brain by massaging the YUZHEN and DAZHU points.
Care for the health of spine and perform improvements for the lack
of exercise.
Focus on improving the health of the lumbar spine and alleviating
the stiffness of the waist muscles.
Quickly relieve the pain of the lower extremities and the muscle
fatigue.
Improve the quality of nap and work efficiency.
Rejuvenation
Spine
Massage
Improve humpback and chest down; massage for each vertebra;
care for the spine health; and improve the protrusion of
intervertebral disc.
Manual mode 30:00
TapⅠ
TapⅡ
Knead & Tap
ShiatsuⅠ
Kneading(Seven modes of
kneading can be switched cyclically)
Tapping(Tapping I, Tapping II)
Function
Description
Shiatsu(Shiatsu I, Shiatsu II)
Simultaneous kneading and tapping
Shoulder lifting
3D(3D I, 3D II, 3D III, 3D IV)
Speed, Width
Speed, Width, Speed
Speed, Width
Speed, Width, Speed
Speed, Width
Speed, Width, Speed
·5 speed levels
adjustable
·5 width levels
adjustable
·5 speed levels
adjustable
Note: In 3D massage technique mode, the width of 3DⅠ and 3DⅡ cannot be
adjusted; the width of 3DⅢ and 3DⅣ can be adjusted.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
Stop
Knead
Select the object with ▲▼ and press OK
3) Other functions (main menu key - other functions)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select other function icons. Press "OK" to enter another function interfaces.
·Other functions include: airbag massage for the upper body, airbag massage for
the lower body, back heating, leg kneading, negative ions and other massage
functions.
·After entering another function interface, press "Up Key" or "Down Key" to select
the massage function. After selecting any one of the functions, use "Right Button"
to enable or disable the function. Then press "OK" to confirm. Press "Left Button"
to return to the previous menu interface.

2322
Method of UsageMethod of Usage
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
01) Other functions - airbag massage for the upper body
·Airbag massage for the upper body: including airbag massage for the upper arms
pressure, airbag massage for the arms, airbag massage for the waist, and other
airbag massage functions.
·Enter another function interface. Press “Up Key” or “Down Key" to select the airbag
massage function for the upper body. Use “Right Button” to enable or disable the
airbag massage function for the upper body. Then press “OK” to confirm. Press
"Left Button" to return to the previous menu interface.
02) Other functions - airbag massage for the lower body
·Airbag massage for the lower body: including airbag massage functions for the
legs, feet, etc.
·Enter another function interface. Press “Up Key” or “Down Key" to select the airbag
massage function for the lower body. Use “Right Button” to enable or disable the
airbag massage function for the lower body. Then press “OK” to confirm. Press
"Left Button" to return to the previous menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK Select the object with ▲▼ and press OK
Auto Mode 30:00
Back speed Back intensity
Upper air Roll speed
00:00
Fast massage＞
Knead
Shoulder
Adjustment
Select the object with ◀▶ and press OK
03) Other functions - back heating
·Back heating: enable or disable the back heating function; the back will become
warmer after such heating for 3min.
·Enter another function interface. Press “Up Key” or “Down Key" to select the back
heating function. Use “Right Button” to enable or disable such function. Then press
“OK” to confirm. Press "Left Button" to return to the previous menu interface.
Auto Mode 30:00
00:00
Fast massage＞
Knead
Back speed Back intensity
Upper air Roll speed
Shoulder
Adjustment
Select the object with ◀▶ and press OK
30:00
00:00
Auto Mode
Fast massage＞
Knead
Back speed Back intensity
Upper air Roll speed
Shoulder
Adjustment
Select the object with ◀▶ and press OK
Negative ions
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Negative ions
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Negative ions
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Negative ions
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK

2524
Method of UsageMethod of Usage
30:00
00:00
Fast massage＞
Knead
Back speed Back intensity
Upper air Roll speed
Shoulder
Adjustment
Select the object with ◀▶ and press OK
Auto Mode
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Negative ions
05) Other functions - Negative ions
·Negative ions: enable or disable the negative ions function.
·Enter another function interface. Press “Up Key” or “Down Key” to select the
negative ions function. Use “Right Button” to enable or disable such function. Then
press “OK” to confirm. Press “Left Button” to return to the previous menu interface.
Otherfunctions 30:00
Upper air
Lower air
Back heat
Calf knead
ON
OFF
Select the object with ▲▼ and press OK
Negative ions
04) Other functions - leg kneading
·Leg kneading: enable or disable the leg kneading function.
·Enter another function interface. Press “Up Key” or “Down Key" to select the leg
kneading function. Use “Right Button” to enable or disable such function. Then
press “OK” to confirm. Press "Left Button" to return to the previous menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
4) Intelligent storage (main menu - intelligent storage)
·Press the "Menu Button" to enter the menu interface. Press "Up Key" or "Down
Key" to select the intelligent storage icon. Press "OK" to enter the intelligent
storage interface, including: intelligent storage call, intelligent storage saving,
cancellation and other storage functions.
·Intelligent storage call includes: M1, M2, M3, M4, and M5.
·Intelligent storage saving include: M1, M2, M3, M4, and M5.
·Call: Call the stored massage mode, massage technique, airbag mode and
intensity under the current running status, the positions and angles of the leg rest
and the backrest, and other massage functions.
·Storage: Store the massage mode, massage technique, airbag mode and intensity
under the current running status, the positions and angles of the leg rest and the
backrest, and other massage functions.
·Cancellation is the exit option.
Note: When saving the massage method, you can comment on the saved
massage function and method (e.g. father, mother, son, daughter, or none).
MemoryUse
MemorySave
Cancel
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
01) Intelligent storage - save or cancel
·After entering the intelligent storage (saving) interface, press "Up Key" or "Down
Key" to select the massage function to be stored. Press "OK" to save or cancel.
·Enter the intelligent storage (saving) interface. Press "Up Key" or "Down Key" to
select any one of the M1-M5 saving procedures. Select "OK" to confirm, and
comment on the saved massage function; press "Left Button" to return to the
previous menu interface.

2726
Method of UsageMethod of Usage
Note: Note: You can comment on the saved massage functions and techniques
(e.g. father, mother, daughter, son, or none).
Memory Save 30:00
M1
M2
M3
M4
M5
Adderuser
Dad
Mom
Son
Daughter
None
Memory Use30:00
M1
M2
M3
M4
M5
02) Intelligent storage - call or cancel
·After entering the intelligent storage (call) interface, press "Up Key" or "Down Key"
to select the massage function to be called. Press "OK" to enter the call or
cancellation interface.
·Enter the intelligent storage (call) interface. Press "Up Key" or "Down Key" to
select any one of the M1-M5 call procedures required to call the saved massage
program; press "Left Button" to return to the previous menu interface.
MemoryUse
MemorySave
Cancel
Select the object with ▲▼ and press OK
MemoryUse
MemorySave
Cancel
Select the object with ▲▼ and press OK
5) Settings (Main Menu-Settings)
·Press "Menu Button" to enter the main menu interface. Press "Up Key" or "Down
Key" to select the settings icon. Press "OK" to enter the settings interface.
·Settings include: language settings, Bluetooth settings, intelligent voice control,
Equipment ID and other settings functions.
·After entering the settings interface, press the “Up Key” or “Down Key” to select
the desired settings function. Select any one of the settings functions, and then
press “Right Button” to set the selected settings function. Press the “OK” to
confirm; press "Left Button" to return to the previous menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
01) Settings - language settings
·Voice settings: including Chinese and English (the function has memory, that is,
after such selection, power-off and restart, it will be the last selected state).
·Enter the settings interface. Press "Up Key" or "Down Key" to select the language
settings. Press "Right Button" to enter the language settings. Press "OK" to select
the required Simplified Chinese or English; press "Left Button" to return to the
previous menu interface.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
Select the object with ▲▼ and press OK
中⽂简
English
02) Settings - Bluetooth settings
·Bluetooth settings (OFF by default): After the Bluetooth function of the massage
chair is enabled, the Bluetooth-enabled audio source device (e.g. mobile phone,
MID tablet) can be connected with the Bluetooth module of the massage chair, and

2928
Method of UsageMethod of Usage
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
03) Intelligent Voice Control
·Intelligent voice control: enable or disable the intelligent voice control function (the
function has a memory, that is, after such selection, power-off and restart, it will be
the last selected state); Note: When the intelligent voice control is disabled, voice
wakeup cannot be performed.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the intelligent
voice control function. Press "Right Button" to enter the intelligent voice control
function settings. Press "OK" to select the required ON or OFF; press "Left Button"
to return to the previous menu interface.
04) Equipment ID
·Equipment ID: Display the current device ID number.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the equipment
ID and check the equipment number of the current device.
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
ON
OFF
Select the object with ▲▼ and press OK
MainMenu
Auto program
30:00
Manual Mode
Other functions
Customise
Angleadjustment
Setting
Select the object with ▲▼ and press OK
Setting 30:00
Language
Bluetooth
Voice control
ID CODE
Select the object with ▲▼ and press OK
2003140001
30:00
00:00
Adjustment 30:00
BackSpeed
Backintensity
Massagearea
Massagewidth
Airintensity
RollSpeed
1
2
3
4
5
6) Massage adjustment
·In the state of the information interface, press "Left Button" or "Right Button" to
select the massage adjustment button, and press "OK" to enter the massage
adjustment interface.
·Massage adjustment includes: 7 massage adjustment functions can be selected,
including back massage speed, back massage intensity, massage range, massage
width, airbag intensity, roller speed, and massage time.
·After entering the massage adjustment interface, press "Up Key" or "Down Key" to
select the desired massage adjustment function. After selecting any one of the
desired massage adjustment functions, use "Right Button" to enter the massage
level selection interface. Then press "OK" to confirm the selected level. Press "Left
Button" to return to the previous menu interface.
Auto Mode
Fast massage>
Knead
Back speed Back intensity
Upper air Roll speed
Adjustment Shoulder
Select the object with ◀▶ and press OK Select the object with ▲▼ and press OK
the music played by the audio source device can be wirelessly transmitted to the
audio system of the massage chair via Bluetooth for music playback.
·Enter the settings interface. Press "Up Key" or "Down Key" to select the Bluetooth
settings. Press "Right Button" to enter the Bluetooth ON/OFF interface. Press "OK"
to select the required ON or OFF; press "Left Button" to return to the previous
menu interface.

3130
Method of UsageMethod of Usage
Function
Description
Back massage
speed 5 speed levels adjustable
Back massage
intensity 5 intensity levels adjustable
Massage range There are 5 modes for your choice: fixed point, local area,
full back, upper back, and lower back
Massage width 5 width levels adjustable
Airbag intensity 5 intensity levels adjustable
Roller speed Choose from 4 modes including OFF and Level 1-3
Massage time Choose from 4 modes: +10min, +5min, -5min, -10min
Note:
·According to the remaining massage time, when the displayed time is not enough
for the addition and subtraction of a certain time, the operation will not be displayed
(the upper limit of the time display is 40 minutes). For example: If the display time of
the remote controller is 39 minutes, the massage time adjustment range will be: -
5min, -10min (+10min or +5min cannot be displayed).
·The adjustment of airbag intensity can only be used when the airbag function or the
automatic function is enabled (for more information about how to enable the airbag
function, refer to Page 18 of the Operation Instructions).
5.Zero-gravity key
·Press "Zero-gravity Key" to adjust the position of zero gravity. You can choose
different angle positions for zero gravity according to your own needs (i.e. 1st
pressing is Level 1; 2nd pressing is Level 2; 3rd pressing is Level 3; and 4th
pressing makes the massage chair restore to the original state).
Button
Description
Zero-gravity Key: Once it is pressed, the positions of the leg rest and
the backrest can be automatically adjusted to the positions for zero
gravity.There are three zero-gravity modes and the lying OFF mode,
which can be switched.
6.Lying angle adjustment button
Button
Description
Calf frame ascending key: Press and hold this key to slowly ascend the
lower leg frame, and stop ascending when released; After the calf
frame ascends, the calf frame will automatically detect the foot length.
Calf frame descending key: Press and hold this key to slowly descend
the leg frame, and stop descending when released; After the calf frame
descends, the calf frame will automatically detect the foot length.
Foot rest shortening key: Press and hold this key to manually adjust
the foot rest to shorten slowly, and then stop when released.
Foot rest elongation key: Press and hold this key to manually adjust
the foot rest to slowly elongate, and then stop when released.
Linkage sit-up key: Press and hold this key to slowly raise the backrest
frame while the calf frame slowly descends; Release this key to stop
the backrest frame from rising and the calf frame from descending;
After the linkage sit-up action is completed, the calf frame will
automatically detect the foot length.
Linkage lying key: Press and hold this key to slowly lower the backrest
frame while slowly rising the calf frame; Release this key to stop the
backrest frame from falling and the calf frame from rising; After the
linkage sit-up action is completed, the calf frame will automatically
detect the foot length.

3332
-+
Method of UsageMethod of Usage
1
3D
2
3
4
5
6
7
8
9
10
11
12
III. Introduction to Armrest
Shortcut Keys Button Description
1.Power button: press for two seconds to open or close the massage chair.
2.3D intensity knob button: adjust the massage intensity of 3D massage hand.
3.linkage sitting key: adjust linkage sitting angle.
4.linkage lying down key: adjust linkage lying down angle.
5.automatic button: automatic massage function switch.
6.heating treatment key: open or close the back heating function.
7.Wireless charging position: wireless charging of mobile phone.
8.voice control microphone: built-in voice control microphone.
9.zero gravity button: adjust to the massage chair zero gravity Angle.
10.Legrest down key: adjust the crus frame down.
11.Legrest up key: adjust the leg lift.
12.Voice control wake-up button: press this button to wake up the voice, long press
for 3 seconds, turn on or off the voice control function.
Power button: short press this key to pause the operation, long press
2 seconds to start the key. If you pause for more than 20 minutes
during the massage, all massage functions will be automatically turned
off.
3D intensity knob key: adjust the 3D massage hands massage
intensity (counterclockwise for weakening, clockwise for strengthening)
intensity range from 1 to 5.
Linkage sitting button: press this button to slowly rise the backrest,
while the calfrest slowly fall, release to stop the backrest frame rising
and calfrest falling.
Linkage lying down button: press this button to slowly descend the
backrest, while the calfrest slowly rise, release it to stop the backrest
and calfrest falling and rising.
Automatic mode key: every time press, automatic massage function
switch.
heating treatment key: press this button to turn on or off the back
heating function.
Zero gravity key: every time you press the key, automatically adjust the
position of the calf and backrest frame to the zero gravity position, a
total of three zero gravity lying mode, cycle switch.
Legrest up button: press this button to lift the crus slowly, release it
and stop rising.
Legrest down button: press this button to slowly descend the crus,
release to stop falling.
Voice and voice control wake-up button: Short press this button to
wake up the voice control function, long press it for 3 seconds to turn
on or off the function; If no valid voice entry is recognized within 6
seconds, the voice function will be automatically turned off (this button
is only effective when the voice control switch is turned on).

3534
Method of UsageMethod of Usage
·When the massage chair is open or in standby mode, say "hi, Alice" or press the
voice control wake-up button on the right armrest to wake up the voice control
function.
·Long press 3 seconds to turn on or off the voice control function.
·After such function is enabled successfully, the massage chair will reply "I am
here". At this moment, once a corresponding voice control entry to be implemented
is given within six seconds, the corresponding voice control function can be
performed after a reply is received from the massage chair; if no correct voice
control entry is given within six seconds, the voice control function automatically
will be off automatically and needs to be enabled again.
·Note: When the voice control function is enabled, please speak English. The
speaking speed cannot be too fast. The speech instruction should be issued
according to the voice control entry.
IV. Voice Control Mode
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
No.
Voice Control Entry
Entry: “hi Alice”. Answer: I am here.
Voice control entry
Massage on
Massage close
Comfort Massage
Relax massage
Full body massage
Neck and shoulder massage
Back and waist massage
Stretch massage
Fixed massage
Change the other mode
Go little down
Go little up
Open the air pressure
Close the air pressure
Up the seat position
Down the seat position
Stop adjustment
Answer entry
Answer: Ok, massage on
Answer: Ok, massage close
Answer: Ok, comfort massage
Answer: Ok, relax massage
Answer: Ok,full body massage
Answer: Ok,Neck and shoulder massage
Answer: Ok,back and waist massage
Answer: Ok,stretch massage
Answer: Ok,fixed massage
Answer: Ok, change the other mode
Answer: Ok, go little down
Answer: Ok, go little up
Answer: OK, Open the air pressure
Answer: OK , Close the air pressure
Answer: Ok, Up the seat position
Answer: Ok, Down the seat position
Answer: Ok, stop adjustment
1.Enter the smart device main menu. Open "Settings" and select the "Bluetooth"
option. Open "Bluetooth", and Bluetooth will automatically "Search for a New
Bluetooth Device".
2.The smart device will search for the corresponding Bluetooth model (e.g. IMCM-
XXXX). Click the "Match" button. If you are asked whether to match with the
device, you just select "Match" to complete matching.
3.Turn on "Music Player" in the smart device and select the song to play.
V. Operation Instructions for Bluetooth Speaker Play
VI. Turn off the power and stop massage
·If the power button is pressed during massage, it will stop all the massage
functions immediately, and the backrest, the legrest and massage chair
manipulators will go back to the default positions. When the preset massage time
is up, all the massage functions will be OFF. The backrest and the legrest will not
go back to the default positions.
Power Shut-off Diagram of the Product
Disconnection Diagram
Unplugging Diagram
POWE R INPUT
ON/OF F
POWE R INPUT
FUSE:
T5AL 250V
ON/OF F
FUSE:
T5AL 250V
·Shut off the power supply of this product, as shown in the attached figure (Power
Shut-off Diagram of the Product).
Resetting......
Please wait for the chair to stop
completely before you gel up

Method of UsageMethod of Usage
VII. Installation Instructions for Armrests
1 Locate the connector plug and air pipe (two wires, two air pipes) corresponding to.
the armrests from the rail bracket. Pass them from the rear end of the rail bracket
(Figure 1).
2. After passing the connector plug from the rear end of the rail bracket, correspond
to each butt connection plug and air pipe (butt connection as per the mark on the
physical butt connections) (Figure 2).
Figure 1 Figure 2
3 Pass the connector from the bottom of the steel rail bracket, and correspond to.
the armrest connector and insert it to the position firmly. Similarly, insert the air
pipe connector to the position firmly (Figure 3).
4 After connecting with the corresponding connection wires, gently insert them into.
the bottom of the steel rail bracket from the rear side of the middle of the steel
pipe of the steel rail bracket by hand, and take care to avoid the air pipe bending
(Figure 4).
5. Holding the front and rear ends of the armrest with both hands, insert the
positioning shaft at the rear end of the armrest into the positioning shaft card at
the lower end of the rail frame first and then gently push the armrest up, and
check whether or not the armrest positioning shaft is inserted firmly (Figure 5).
6. Pick up the armrest with both hands and then insert the front hook of the armrest
into the front square opening of the massage chair frame (Figure 6).
Figure 3 Figure 4
Figure 5 Figure 6
7. Then use 4 cross-recessed pan head tapping screws M6X16 combined with Φ5
flat washer to lock the armrest whose front hook has been inserted into the front
square opening of the massage chair frame in the second step with the main
body tightly on the inner side of the front end of the armrest (Figure 7).
8.Unzip the upper arm cover, and lock the armrest with the configured flat gasket
and M6*25 screw.(Figure 8).
Figure 7 Figure 8
1 2
VIII. Installation Instructions for Legrest
·After connecting the wires and the air hose between the legrest and the massage
chair, remove the cable ties and insert the connecting part into the seat (Figure 1).
·Place the round tubes on the left and right sides of the legrest onto the legrest
support (Figure 2)
3736
