UN3005B
Pull Out Tray
Installation Guide
FLATLINE VAN CO • [e-mail] • 888-667-5576

All Flatline Van Co products must be properly assembled and secured before attaching to your
vehicle. Improper attachment could result in an automobile accident, and could cause serious bodily
injury or death to you or to others involved. You are responsible for assembling and securing Flatline
Van Co products to your vehicle, checking the mounting points and attachments prior to use, and
regularly inspecting the products for wear and or damage. We always recommend you use a
professional to install any aftermarket accessories to your vehicle. If you have no mechanical
experience and are not thoroughly familiar with the installation procedures, you must have the
product installed by a professional installer or other qualified persons. The responsibility is yours
and must be taken seriously for everyone's safety.
1
FLATLINE VAN CO • [e-mail] • 888-667-5576
thanks.

2
FLATLINE VAN CO • [e-mail] • 888-667-5576
THANK YOU!
ARE YOU EXCITED ABOUT YOUR NEW PULL OUT TRAY? HERE ARE A FEW THINGS TO
DO BEFORE BEGINNING THE INSTALLATION PROCESS--
• PLEASE INSPECT THE PRODUCT TO ENSURE THERE WAS NO
DAMAGE INCURRED DURING SHIPPING.
• IF THERE IS DAMAGE TO REPORT, PLEASE CONTACT OUR
CUSTOMER SERVICE DEPARTMENT AS SOON AS POSSIBLE.
• NEXT, USING THE “PACKAGE CONTENTS” PAGE, CHECK
INVENTORY AND FAMILIARIZE YOURSELF WITH THE PARTS
AND HARDWARE.
• GATHER ALL TOOLS REQUIRED FOR INSTALL.
TOOLS WILL BE DEPENDENT ON YOUR INSTALL METHOD
ESTIMATED INSTALL TIME- 1 HR
ADDITIONAL HELP IS SUGGESTED FOR A FEW OF THE INSTALL STEPS.
NOTE-
NO HARDWARE IS INCLUDED TO SECURE THE PULLOUT TRAY TO YOUR VAN. WE
SUGGEST APPROPRIATE HARDWARE IN THE PAGES THAT FOLLOW.
TOOLS

PACKAGE CONTENTS
3
FLATLINE VAN CO • [e-mail] • 888-667-5576
PULL OUT TRAY
QTY - 1

FLATLINE VAN CO • [e-mail] • 888-667-5576
LET’S GET STARTED!
1. OUR RECOMMENDED INSTALL METHOD TO ENSURE YOU CAN SAFELY LOAD
THE MAXIMUM CAPACITY REQUIRES DRILLING ALL THE WAY THROUGH YOUR
FLOOR TO THE BOTTOM OF THE VAN AND THROUGH BOLTING (3/8 BOLT,
WASHER, THROUGH PULL OUT TRAY AND FLOOR, LARGE FENDER WASHER,
NYLOCK NUT) THIS METHOD REQUIRES MAPPING OUT YOUR INSTALL
LOCATION AND ENSURING YOU ARE DRILLING IN A SAFE PLACE THAT WON’T
PENETRATE WIRES/BRAKE LINES/FUEL TANKS/ETC.
NOTE- IF YOU HAVE A SUBFLOOR INSTALLED IN YOUR VAN THAT IS
3/4” OR THICKER YOU MAY BE ABLE TO SCREW DIRECTLY INTO THAT
USING #14 SCREWS WITH WASHERS, BUT THE THROUGH BOLT
METHOD IS MUCH STRONGER
2. YOU WILL NEED TO EXTEND THE PULL OUT TRAY ALL THE WAY OUT TO
REVEAL THE MOUNTING HOLES LOCATED IN THE BASE. WITH THE TRAY
FULLY EXTENDED IT WILL BE NECESSARY TO EITHER PROP THE PROTRUDING
TRAY UP OR HAVE SOMEONE HELP YOU BY HOLDING THE EXTENDED END.
SEE NEXT STEP FOR MORE DETAIL ON MOUNT HOLE LOCATIONS AND
RECOMMENDATIONS.
NOTE- IF YOU ARE MOUNTING THE PULL OUT TRAY IN THE BACK OF
YOUR VAN (MOST COMMON LOCATION) PLEASE ENSURE ENOUGH
CLEARANCE TO CLOSE YOUR REAR DOORS AND NOT MAKE CONTACT
WITH THE DRAWER RELEASE LEVERS.
4

FLATLINE VAN CO • [e-mail] • 888-667-5576 5
3. THERE ARE A NUMBER OF MOUNT HOLE LOCATIONS LASER CUT INTO THE
MOUNT BASE. WE RECOMMEND A MINIMUM OF 6 FASTENERS TO SECURE THE
PULL OUT TRAY.
NOTE- THE MOST SECURE METHOD TO FASTEN WOULD BE TO PLACE
A FASTENER IN EACH CORNER AND TWO IN THE CENTER LOCATIONS.
4. DOUBLE CHECK ALL OF YOUR MEASUREMENTS AND FITMENT AND ENSURE
THAT THERE WILL BE NO OBSTRUCTIONS DURING OPERATION OF THE PULL
OUT TRAY.
MOUNT HOLE LOCATIONS
SIZED FOR UP TO 3/8” FASTENER
WASHER REQUIRED FOR SMALLER FASTENERS

FLATLINE VAN CO • [e-mail] • 888-667-5576 6
1. IF THE SLIDE MOUNT SCREWS ON YOUR PULLOUT TRAY COME LOOSE; SLIDE
THE TRAY OUT TO EXPOSE THE SCREWS FROM THE INSIDE. YOU MAY NEED
TO MOVE THE INNER SLIDE MECHANISM AROUND TO GET THE ACCESS
WINDOW TO LINE UP WITH EACH SCREW.
NOTE- EVERY MOUNT SCREW IS ACCESSIBLE FROM THE INSIDE BY
MOVING THE INNER SLIDE MECHANISM BACK AND FORTH. OUR
CUSTOMER SERVICE TEAM CAN PROVIDE A VIDEO DEMONSTRATING
THIS, PLEASE REACH OUT IF YOU NEED IT.
2. OCCASIONAL VACUUMING AND CLEANING OF THE INSIDE OF THE PULL TRAY
WILL EXTEND THE LIFE OF THE DRAWER SLIDES AND ENSURE SMOOTH
OPERATION.
SERVICE & MAINTENANCE
ACCESS HOLE FOR
SLIDE MOUNT SCREWS
MOVE THE INNER SLIDE
INDEPENDENTLY TO ACCESS
ALL SCREWS
