Fytech FY-6CH User manual

Instruction Manual
Our equipment is approved by the following car manufacturers
FY-6CH

CONTENTS
1. Precautions
2. Specifications
3. Installation
4. Controls
5. Operation
6. Troubleshooting
1) Troubleshooting
2) Light Tube Replacement
7. Exploded View
8. Circuit Diagram
1
2
3
4
5
7
8
9
10

Page 1
1. Read this manual carefully before installing or using this equipment.
2. This equipment is designed for paint drying applications. Adjust to the correct
temperature and check minimum safe distance from the heat source when using.
Improper use may cause paint surface damage.
3. Installation and servicing must be performed by a qualified installer or service
agency.
4. The system has been designed for easy installation, low operating costs and minimal
maintenance. The warranty does not cover lamp tube defects resulting from misuse
or improper operation.
5. Disconnect power source when the equipment is not in use for a long time.
6. The light tube should not be perpendicular to the ground when the equipment is in
operation. Otherwise, it will shorten the useful life of the light tube.
7. Make sure the cassette plug is tightly connected before using to prevent it from
burning.
1. PRECAUTION

Model
Input Voltage
Input Power
Curing Area
Temperature
Time Setting
Light Intensity
FY-6CH
380V / 1-ph / 50-60Hz
6 × 1000W
1800 × 1000mm
35°C - 100°C adjustable
0min-99min adjustable
10% - 100%
2. SPECIFICATIONS
Page 2
1600mm 2050mm
2400mm

3. INSTALLATION
Page 3
2
3
4
5
1
6
7
8
9
1. Distance sensor
2. Pull rod
3. Cassette
4. Column
5. Lifter
6. Lifter switch
7. Power switch
8. Overcurrent protection switch
9. Base
10. Caster
1
3
4
5
6
7
8
9
10
2
The shortwave infrared curing lamp is divided into 3 parts (a base, a column and a cassette).
1) Installation of the base.
a. Open the packing of the base.
b. Install the four wheels on the base respectively and tighten up the screws. Usually, the
wheels with brakes should be mounted on the rear of the base.
2) Installation of the column.
a. Open the packing of the column.
b. Put the column vertically on the top of the base, directly engage the screw holes and
tighten up using the screws.
c. Connect the support arm with the column for supporting the cassette.
d. Connect the lifter with the column to control the up and down movement of the cassette.
3) Installation of the cassette.
a. Open the packing of the cassette with care.
b. Connect cassette with support arm and tighten up with the screws.
c. Connect control wires and adjust the angle of cassette.

4. CONTROLS
Page 4
AUT O
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
Pull-up this handle
for cassette moving
up and down.
1
2
3
4
5
6
8
9
10
11
12
13
7
1. Time display
2. Time adjustment
3. Power display
4. Power adjustment
5. Distance display
6. Distance adjustment
7. Lamp selector (each lamp can be controlled
separately)
8. Pulse
9. Routine
10. Auto
11. Nearest distance adjustment (press this button
first then press Button 6 to adjust the nearest
distance)
12. Farthest distance adjustment (press this button
first then press Button 6 to adjust the farthest
distance)
13. Start/Stop
Press “Auto” (Button 10) after switching on the power to set parameters such as time,
power, distance, routine and pulse according to different paint requirements. The lamp is
in routine mode when “Routine” (Button 9) is on and it is in pulse mode when “Pulse”
(Button 8) is on. Press “Start” (Button 13) after setting up parameters, the lamp will enter
into automatic working procedure.

5. OPERATION
Page 5
00:00
100
050
1. Automatic Mode
a. Properly assemble the curing system according to the instruction (see page 3).
b. Switch on the power supply. The display will go through the start-up procedure and
automatically default to Automatic Mode. The system is ready to use when the
parameters appears on the display screen as follows:
c. Move the cassette forward or backward from the paint surface to adjust to the best
distance for curing. The distance data will be detected and shown on the display screen
automatically. The curing distance between the cassette and paint surface should be
set according to the paint material and weather conditions (air humidity). Usually,
keeping a distance of about 35-45cm from the paint surface is recommended.
d. Press the button “Start/Stop” to start automatic curing mode. Once the automatic
mode is selected, two related cure programs become available to the user – Program
1-2 (Fig. A and Fig. B).
e. Protect the lamp against shocks and vibrations when the lamp is in use.
g. After this program is completed, the system is able to carry out other programs. Make
sure to turn off the system when the equipment is not in use and keep the equipment
securely in place.
1. Pulse Time (min)
2. Power (%)
3. Routine Time (min)
4. Power (%)
5. Pulse Time (min)
6. Power (%)
7. Routine Time (min)
8. Power (%)
1. 3:00min
2. 70%
3. 15:00min
4. 70%
5. 5:00min
6. 70%
7. 10:00min
8. 70%
Program 1
Program 2
Fig.A Fig.B

5. OPERATION
Page 6
00:00
100
2. Manual Mode
a. Press the button “Auto” to shut down the automatic mode.
b. Press the button to select "Routine" or "Pulse”.
c. Press the button "Start".
d. The curing distance between the cassette and paint surface should be set according to
the paint material and weather(air humidity). Usually, keeping a distance of about
35-45cm from the paint surface is recommended.
e. The curing time and power should be set according to the requirements of the paint
material. Usually, "Pulse" is set to 5 mins and "Routine" to 10 mins.
f. Press the button “Start/Stop”.
g. Turn off the equipment when the work is completed.
3. Pulse Mode
a. Press the button “Auto” when the lamp is ready to use to shut down the automatic
mode. Set power and time. Press the button “Pulse".
b. Press the button “Start/Stop".
c. The curing distance between the emitters and paint surface should be set according to
the material of paint and weather (air humidity). Usually, keeping a distance of about
35-45cm from the paint surface is recommended.
d. After this program is completed, the system is able to carry out other programs. Make
sure to turn off the system when the equipment is not in use.
Time Adjustment
Power Adjustment

1. Troubleshooting
Page 7
6. TROUBLESHOOTING
PROBLEM
Light tube does not work
Light tube does not turn
off
Digital display is blank or
is incomplete
Temperature and time
cannot be adjusted
CAUSE
a. Light tube damaged
b. Lamp is not plugged in
c. Control silicon damaged
a. Control silicon damaged
a. Unplugged flat wire in
circuit board
b. Digital display damaged
a. Switch imbalance
b. Keyboard has exclusion
SOLUTION
a. Check light tube
b. Check the connections
c. Check control silicon
a. Check control silicon
a. Check flat wire
b. Check digital display
a. Check the installation
of switch
b. Check keyboard exclusion

2. Light Tube Replacement
(a)
(b)
(c)
(d)
(e)
(f)
a.
replacement.
b. Remove the grille of cassette.
c. Remove the plates from both ends
of the cassette.
d. Remove the fixed plates from both
ends of the cassette.
e. Loosen fixed screws and cut off
connections, the light tube can
be replaced.
f. Repeat the steps above in reverse
order to replace the light tube.
Prepare the cassette which needs
6. TROUBLESHOOTING
Page 8

7. EXPLODED VIEW
NO
1
2
3
4
5
6
7
8
NO
9
10
11
12
13
14
15
16
NO
17
18
19
20
21
22
23
24
NO
25
26
27
28
29
NAME
Upright post
Top cover
Plastic band
Connecting axle
Bracket
Connector (left)
Connecting rod
Clamping bar
NAME
Cassette
Distance sensor
Plastic nut
Connector (right)
Handle
Lower connecting rod
Upper connecting rod
Lifter
NAME
Lifter handle
Front wheel
U-type base
Back wheel
Cover plate (lower)
Relay
Flange
Power switch
NAME
Control silicon
Handle
Transformer
Cover plate (upper)
Circuit board
Page 9
1
2
34
5
6
78
9
10
9
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
28
27
29

8. CIRCUIT DIAGRAM
Page 10
8. CIRCUIT DIAGRAM
Page 10
PCB2
PCB1
Distance
sensor
Control Transformer
K2 G2 K1 G1
K2
G1
G2
K2
SCR
12V
220V
OUT
I N
F
L 1 L 2 L 3
P C B
GND CON D C 1 2 V
G N D C O N D C 1 2 V
Control Silicon
Control Transformer
Power Switch
Fan
A/C Contactor
PCB for Distance
