Güralp RADIAN User manual

RADIAN
QUICK-START GUIDE
MINIMUM SIZE, MAXIMUM RANGE, UNRIVALLED VERSATILITY
POSTHOLE

Deployment Log
Date deployed Date recovered Location Comments
Serial number:

Power cable (with
bare ends), GPS
receiver, GPS cable,
and Ethernet cable
are supplied with
the Minimus
Accessory Pack.
Analogue and
digital sensor cables
are supplied with
the respective
sensors.
No power supply is
included.
Connect all the
hardware using the
cables supplied, as
shown above.
Switch on the power
supply (12–36 V DC).
The LED indicator
on the Minimus will
behave as shown in
the table:
1
2
1
m m ini u s
GPS receiver
and cable
Surface
Interface
Unit
(Minimus)
26-way
analogue
sensor cable
Power / Signal
cable
Example
power
Supply
Power
cable
Ethernet
cable
Laptop or PC
Radian
post-hole
Radian Post-hole
Initial Hardware Setup
QUICK-START GUIDE
LED flash
Status
WHITE flashing
rapidly
booting-up (10-20 s)
quick flash RED
followed by 1 s pause
Removable microSD
present, no fixed microSD
card
2 quick flashes RED
followed by 1 s pause
Fixed microSD present,
no removable microSD
3 quick flashes RED
followed by 1 s pause
microSD cards present
Missing or poor GPS
GREEN flash every 4 s
microSD cards and GPS all
OK (may take up to 10 min)

Installing Güralp Discovery software
Ensure that your version of
Discovery is up to date. To do
this, in Discovery, click on the
Help menu and select About.
Click on the Update button and
follow the on-screen instructions.
Download Güralp Discovery from
http://www.guralp.com/sw/download-discovery.shtml
(Please contact [email protected] for other operating systems.)
If you see a dialogue from
Windows Firewall saying that it
has “blocked some features of
this app”, select one or more
networks frrom the list provided
and then click .
Run the installer that you have
downloaded, follow the on-screen
instructions to install and then
launch Discovery.

View live waveforms and instrument status
The Live View window will
open and start streaming all
available data from the
Radian (and any other
connected instruments).
Streams can be added or
removed from the viewer
using the Channel List panel
on the left-hand side.
Amplitude and time
zoom/pan can be controlled
using the keyboard arrow-
keys or the mouse-wheel.
To configure the Radian system
(view instrument state-of-
health information, configure
station metadata and network
preferences, manage data
storage and data flow), right-
click on the Minimus in
Discovery’s main window and
select View Web Page.
Launch Discovery software.
The serial number (as shown on
the base of the Minimus)
should appear in the main
window . If the instrument does
not appear, check your
Ethernet connection and then
press the Scan locally button
(more troubleshooting details in
Minimus user’s manual in
section 4.1) Select the
instrument and click on the
View toolbar to select Live View
then GDI only.

For detailed information on usage, control &
configuration of the Radian, Güralp highly
recommends first reading the Minimus
Manual MAN-MIN-0001:
www.guralp.com/documents/MAN-MIN-0001
followed by he Radian Manual,
MAN-RAD-0001:
www.guralp.com/documents/MAN-RAD-0001
It may also be important to update firmware on the Minimus
- refer to Section 5.18 of MAN-MIN-0001 for more details.
Next steps
Caution: The Radian Posthole system contains sensitive mechanical
components which can be damaged by mishandling. If you are at all
unsure about the handling or installation of the instrument, please
contact Güralp Systems support - [e-mail] - for assistance.
For further assistance please contact our technical support team on
[email protected] or call us on +441189819056.
Android:
https://play.google.com/store/apps/details?id=com.guralp.whisper
IOS:
https://itunes.apple.com/us/app/id1208418113
GüVü is an app for monitoring the state of health of
G seismic instrumentation. It is available for both üralp
Android and IOS:
https://play.google.com/store/apps/details?id=com.guralp.gcfviewer
GCF Viewer is an android app which allows you to
view GCF files and live data on your mobile device:
GüVü and GCF Viewer Apps
GCF Viewer

Notes

Güralp Systems Limited
Midas House
Calleva Park
Aldermaston
Reading
RG7 8EA
United Kingdom
T [phone]
F [phone]
E [email protected]
www.guralp.com
MSH-RAD-0001 Issue H
