Güttler GreenMaster 600 User manual

06.2021
GRASSLAND MAINTENANCE
GreenMaster 600 750 800
GreenMaster 450 600 Alpin
GreenMaster 600 TINE SEED
Instruction manual

2
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Table of contents
Person responsible for this document:
Managing Director
Hans Güttler
73230 Kirchheim unter Teck, den 11.01.2021
EC Declaration of Conformity
Manufacturer: GÜTTLER® GmbH, Karl-Arnold-Straße 10, 73230 Kirchheim unter Teck
Product: GreenMaster
We hereby declare that the above-mentioned product complies with all the relevant provisions, in
particular with the essential health and safety requirements of the Machinery Directive 2006/42/EC.
The following standards were consulted for the proper implementation of the Directive:
EN ISO 12100: EN ISO 12100 Safety of machinery
General principles of design - Risk assessment and risk reduction
2 EC Declaration of conformity
3 EG-Konformitätserklärung Pneumatikstreuer EPS 5
4 Safety regulations
7 General information
9 Safety symbols
10 Three-point kinematics
11 Operation of the machine
12 Setting of the machine (with levelling bar)
13 Setting of the machine (with Ripperboard)
14 Setting of the machine (with front linkage Alpin 440 600)
15 Setting of the machine (drive shaft)
16 TINE SEED
17 Coupling kit
18 Hydraulic connections
19 Calibration test (EPS 5)
20 Working with the machine
21 Calibration table
22 Sowing table
23 Dosing roller - guide values dosing roller
24 Important information
25 Area meter ha
27 Electric fan
29 Hydraulic fan

3
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
EG-Konformitätserklärung

4
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Safety regulations
Foreword
These instructions will help you in getting to know your
machine and in using it optimally for its intended purpose.
Read carefully the instruction manual before starting up
the machine and observe all operating rules listed in the
manual, including all working, safety and maintenance
instructions. By doing so, you will avoid hazards, reduce
repair costs and downtime, and increase the reliability and
service life of your machine.
Every person who is going to work with or on the machine
should read the instruction manual and pay attention to it.
In particular, this concerns all activities during:
• Operation (including preparation, fault elimination during
operation, machine care)
• Maintenance (maintenance and inspection)
• Transportation
GÜTTLER® will not accept any liability for any damage or
malfunctions resulting from failure to comply with the
operating instructions.
The manual includes a replacement parts list and a machine
registration form. Our sales representatives or distributors
will instruct you regarding operation and maintenance of
your machine. Following this, the machine registration form
must be completed and returned to GÜTTLER®. This con-
firms your formal acceptance of the machine. The warranty
period begins on the date of delivery, irrespective of when
the machine registration form is sent.
Illustrations and information on technical data, dimensi-
ons and weights in this instruction manual are subject to
change.
Handling material defects
Although the greatest care is exercised during produc-
tion and assembly of this machine, material damages or
defects can never be completely ruled out. For cases of
material damages or defects the warranty claim request
must be submitted by your GÜTTLER® sales represen-
tative to GÜTTLER® Kirchheim unter Teck. Only requests
that have been completed in full and submitted no later
than 4 weeks after the occurrence of the damage can be
processed. Warranty repairs must be carried out in the
dealer workshop. Repairs which are going to be made by
third-party firms or which are expected to require more
than 2 hours of repair time must be agreed with GÜTTLER®
in advance.
In the case that old parts are reclaimed with warranty
repairs, these must be cleaned, emptied and returned to
GÜTTLER® within 4 weeks, accompanied by a warranty
claim and a precise description of the fault. If no request
is made for return of the old parts, these parts must be
kept for a further period of 12 weeks until a final decision
is taken.
Original GÜTTLER® replacement parts and accessories are
specially designed for this machine. Replacement parts
and accessories that are not supplied by us have not been
checked or approved by us. The installation or the use of
Güttler®-foreign products can therefore negatively change
structurally predetermined properties of the machine and
thereby affect the safety of human and machine. Conse-
quently, only original replacement parts should be used for
any repairs (reference for evidence).
If replacement parts that have not been approved by
GÜTTLER® are used, the warranty entitlement for the
whole machine lapses. GÜTTLER® will not accept any lia-
bility for damage or malfunctions arising from the use of
non-original replacement parts.

5
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Safety regulations
Intended use
The machine is constructed using the latest technologies
and in accordance with the relevant recognised safety
regulations. However, risks of injury for the user or other
persons and impairment of the machine or other property
may arise during use.
The machine may only be operated in technically perfect
condition and in accordance with its intended use, in a
safety-conscious and hazard-conscious manner and in
compliance with the operating instructions. Faults or
damage that may endanger the safety of human or the
machine must immediately be eliminated. Only persons
who are familiar with the machine and who have been
briefed on the dangers should use, maintain, repair or
transport the machine.
The machine is intended for normal use for soil cultivati-
on in the agricultural sector. Any use other than the one
described in this instruction manual shall be considered as
improper use.
GÜTTLER® accepts no liability whatsoever for damage and
malfunctions resulting from improper use.
The relevant accident prevention regulations and other
generally recognised safety, occupational health and road
traffic regulations must be complied with.
Consequential damage
The machine has been manufactured by GÜTTLER® with
the greatest care. Nevertheless, damage can occur even
when used as intended, due to:
• external influences
• incorrect or inappropriate speeds, working or driving
speeds
• incorrect installation or adjustment of the machine
• non-compliance the instruction manual
• lack of or improper maintenance and care
• missing, worn or broken working tools
Therefore, always check your machine before and during
each use to ensure a correct function and adjustment.
Authorised users
Only persons who have been commissioned and
instructed by the operator may work on the machine. The
minimum age for users is 16 years. Users must be
in possession of a valid driving license. Users are
responsible for third parties within the working area.
The operator must:
• make the instruction manual is available to the user.
• make sure that the user has read and understood the
manual.
The instruction manual is part of the machine.
Safety equipment
• You need the following protective equipment
to operation and maintain the machine:
• close fitting clothes
• protective gloves and goggles.
• safety shoes

6
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Safety regulations
Operational safety
Read all safety instructions contained in this instruction
manual and all warning labels attached to the machine.
Keep the warning labels in a legible condition and replace
all damaged or missing labels immediately.
The machine may only be used if all safety-relevant
protective devices (e.g. detachable protections) are pre-
sent and fully functional.
Check nuts and screws regularly for tightness and tighten
if necessary. Check tyre pressure regularly and/or before
starting work.
In the case of malfunction, stop the machine immediately
and secure it.
Accident prevention
In addition to the instruction manual, the accident pre-
vention regulations of the agricultural employers’ liability
insurance associations must be observed!
Road traffic safety
When driving on public roads, path and public areas, it is
important to observe the according road traffic laws.
Observe the permitted transport widths and attach the
lighting, warning and protective devices! If the outer edge
of the mounted attachment has a distance more than 40
cm from the light-emitting surfaces of the tractor’s limiting
and rear lamps, additional front and rear position lamps
are required. If official registrations plates are covered by
attachments, these must also be attached to the machine.
Observe the transport height.
Pay attention to the permitted axle loads, tyre loads and
total weights. The front axle of the tractor must be loaded
with at least 20% of the tractor’s unladen weight in order to
maintain sufficient steering and braking ability.
The driving behaviour is influenced by attachments.
During cornering, the large overhang and inertia of the
machine must be taken into consideration.
Clean the entire machine before driving on the public road
from soil that has been picked up.
Riding on the machine is strictly forbidden.
Exemption for overwidth
For machines with more than 3 m transport width a certifi-
cate of exemption is required to drive on public roads and
path. The conditions of the exemption certificate must be
strictly observed.
Prior to use
Before each use, always check that all the screw and plug
connections are tight, for example:
• safe fixing of the wheels and tyres
• safe fixing of the hydraulic cylinders
• the bolts, clevis and locking screws
• the clamp connections
• the hitch on the tractor
Pay attention to the “floating” mount of the levelling bar!
During operation
• Check the area around the machine (children) before
starting. Ensure that there is sufficient visibility.
• None of the prescribed and provided protective devices
may be removed.
• No persons are allowed within the swivel range of
hydraulically actuated parts.
• Use ladders and platforms only while the machine is at
a standstill. Riding on the machine during operation is
strictly forbidden!

7
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
General information
Hydraulics
The hydraulic system is under high pressure. Any damage
must be repaired without delay!
Spraying oil can cause injuries and fires. In case of injury,
consult immediately a doctor!
• Check all hydraulic lines for damage before first use
• Check all hydraulic lines at least once a year
• After 6 years, all hydraulic hoses must be replaced
Coupling and uncoupling
While coupling and uncoupling the machine to the hitch of
the tractor there is a risk of injury. It is forbidden to stand
in the area between the tractor and the machine during
coupling and uncoupling!
Coupling
• Secure the machine against rolling away.
• Make sure that the locking clips on the folding mechanism
are closed and secured against unintentional opening.
• Pay special attention when reversing the tractor. Stan-
ding between the tractor and the machine is forbidden.
• First attach the lower links, then the upper link and close
the locks.
• Connect the machines’ lighting system with the tractors’
on-board electrics and check that the lights operate cor-
rectly.
• Connect the hydraulic lines.
• Lift the machine and move the stands upwards. Secure
the stands!
• Check the transport lock for function. Mount the trans-
port lock and secure it.
Uncoupling
• The machine may only be parked on level and stable
ground. Before uncoupling the trailed machine, park it
on the ground.
• Extend the stands and lock them in place.
• Secure the machine for to prevent a rolling away.
• Check the transport lock for function. Mount the trans-
port lock and secure it. Disconnect the hydraulic lines.
• Disconnect the plug for the lights.
• Firstly, unlock and uncouple the upper link and then the
lower links.
Hydraulic connection
• The hydraulic hoses may only be connected to the
tractor when the hydraulic system is depressurised.
• The hydraulic system is under high pressure. Inspect all
pipes, hoses and screw fittings regularly for damage and
leaks.
• Repair any damage without delay! Spraying oil can cause
injuries and fires.
• In case of injury, consult immediately a doctor.
• To prevent accidents caused by unintentional hydrau-
lic movements or movements caused by other persons
(children, passengers), the control units on the tractor
must be secured or locked when not in use or in trans-
port position.
Operation of the hydraulic system requires special care.
Incorrect operation may cause injuries to human and da-
mage to the machine!
Climbing onto the machine
When climbing onto the machine, do not step on the
tyres, roller or other rotating parts. These could spin and
you could sustain the most serious injuries from a fall.

8
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
General information
Maintenance
For maintenance work, park the machine on a stable and
level ground. Secure it for to prevent a rolling away and an
accidentally falling.
Inspect the machine regularly for abrasion marks and
damage and repair any defects without delay.
Check the lighting system regularly to avoid endangering
other road users through negligence. Before working on
the electrical system, the machine must be disconnected
from the power supply.
After cleaning the machine, check all hydraulic lines for
leaks and loose connections and lubricate all lubrication
points so that rust cannot form in the moving parts.
Retighten screw connections that have been loosened
during maintenance work.
Do not clean new machines with a steam or high-pres-
sure cleaner. The varnish is only hardened after approx.
3 months and could be damaged beforehand.
Lubrication of moving parts
The ball bearings and folding hinges must be greased
every 10 operating hours with high pressure grease. For
these works the grease nipples on the ball bearings are
accessible from below.
All joints and moving parts must be oiled regularly.
Retightening of screw connections
All screw connections must be controlled and, if necessary,
retightened after every use of the machine or every 50
operating hours at the latest.
After the season
At the end of the season, carry out a complete and thoro-
ugh cleaning of the machine and then lubricate all lubrica-
tion points.
Inspect the machine completely for wear and damage.
Replace missing or worn parts immediately and repair
paint damage without delay.
Park the machine on a dry, level, and stable ground that
is protected from the weather. Secure it for to prevent a
rolling away and an accidentally falling.
Protect the machine against rust, especially the piston
rods of the hydraulic cylinders. Use only biological oils for
spraying, such as rapeseed oil.
Do not spray plastic or rubber parts with oil or anti-
corrosion agent. The parts could become brittle and
break.

9
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Safety symbolsSafety symbols
Symbol Meaning Symbol Meaning
Turn off the tractor before
carrying out any repairs or
maintenance.
Before operating the machine,
read and take account of the
instruction manual andsafety
instructions!
During operation and while
coupling and uncoupling the
tractor, it is forbidden to stand
in the area between the tractor
and the machine!
Cutting tools!
Caution: risk of cuts!
Pay attention to leaks:
hydraulic hoses are under
high pressure!
Caution: risk of crushing!
Never reach into the crushing
danger area while parts may
move there!
Marking of lubrication
points.
Loading hook.
Clip the lifting device for loading
work here!
It is forbidden to remain within
the swing range of the machine
during operation!
Persons are only
permitted within the danger
zone if a lifting cylinder safety
device is engaged.
It is forbidden to remain
in the danger zone
of the machine during
operation.
All screw connections must be
controlled and, if necessary,
retightened after every use of the
machine or every 50 operating
hours at the latest.
Important!
Do not clean the machine within-
the first 3 months with a steam
cleaner!
Damaged or missing stickers must be replaced immediately!
min. 60 cm
max. 100 bar
max. 50°C
!
Bei Verwendung der Stützfüße, dürfen an den Koppelpunkten keine
Geräte angekoppelt sein. Nur auf ebenem, festem Untergrund abstellen!
Lors de l‘utilisation des pieds de support aucun dispositif ne peut être attelé. Dételer uniquement sur sol plat et ferme !
When using the support feet it is not allowed to have devices docked on trailer couplings. Use only on even and paved ground!
www.guettler.de

10
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Three-point kinematics
Three-point kinematics
When coupling machines with a three-point hitch, you
need to pay attention to the ideal pull point, the imaginary
intersection point of the upper link and the lower links. In
working position of the machine, the lower links must be
horizontal, at rear linkage the upper link must rise 20 to 25
cm, at front linkage 5 to 10 cm towards the machine. This
results in an ideal pull point below the rear axle.
This guarantees that no tractor weight is transferred to the
machine and avoids damage caused by overloading. Thus
the tractor can work with its whole traction and lowest fuel
consumption, while the steerability is maintained.
Rear linkage in working position
Front linkage in working position

11
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Operation of the machine
The GreenMaster harrow is ideally suited for the mo-
dern maintenance of pastureland. With its tines it combs
the turf and increases the yield and nutritional value, it
reduces the weed density and prevents gaps in which
weed can crow.
Front-mounted implements level molehills and cow pats
and the tines distribute the organic material. Additionally,
the tines dethatch and aerate the turf, they comb the weed
and create gaps which can be overseeded with valuable
seeds.
Unfolding the machine
1. Open the interlock at the
cylinder.
2. Unfold the cantilevers
completely by help of the
tractors‘ hydraulic.
Folding the machine
1. Fold the cantilevers com-
pletely by help of the
tractors‘ hydraulic.
2. Close the interlock at the
cylinder.
Attention:
The interlocks at the hydraulic cylinders must be closed
during transporting the machine on roads and during
parking!
Hydraulic connection
Connect the (blue) hydraulic lines of the folding mechanism
to the tractors‘ hydraulic.
For couppling a trailed roller like the Master or Mayor, the
GreenMaster has separate hydraulic lines for the transport
wheels of the roller (red hydraulic lines of the roller). Thus,
the hydraulic of the trailed roller can be connected directly
at the GreenMaster and not at the traktor.
Coupling a trailed roller
It is possible to connect a Master or Mayor the the Green-
Master harrow.
To do this, attach the lower link hitch of the trailed roller
with the coupling frame of the GreenMaster.
Connect the hydraulic folding mechanisme of the trailed
roller (blue) with the folding hydraulic of the GreenMaster.
Connect the hydraulic of the transport wheels of the trai-
led roller with the connections at the GreenMaster, provi-
ded for this purpose. Ensure, that these hydraulic connec-
tions are connected to the tractor.
During transport of the roller, it is essential to observe the
notes for safety regulations on page 5.
Attention:
Make absolutly sure, that the hydraulic lines for the folding
mechanisme of the roller (blue) is connected with folding
mechanisme of the GreenMaster (blue). Interchanging the
connections can cause damage to the machine!
Stands for parking in folded state
The machine may only be parked on level an stable ground.
It must be ensured, that no roller is attached. The stands
must not be carried along during work and transport.
Operation of the machine

12
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Setting of the machine (with levelling bar)
2
1
3
4
2
1
3
4
1. Adjusting the inclination of the tines:
Adjust the inclination of the tines by moving the adjus-
ment lever to the rear and lock it behind the vertical
adjustment frame.
Lever to the rear = tines steeper = more aggressive
2. Adjusting the working depth:
Adjust the working depth of the tines with the depth
adjustment frame at the wheel rocker.
Stands higher = tines deeper = more aggressive
3. Levelling bar
Basic setting: Approx. 1-2 cm pending above the turf.
The levelling bar should only have soil contact in the
case of molehills!
4. Parallelogram guide rod
The „floating“ parallelogram of the levelling bar allows
it to deviate upwards in case of soil contact (obstacles)
and, at the same time, serves as predetermined brea-
king point.
Therefore, always fit the upper parallelogram guide
rod twice, i.e. two parts for each adjusting spindle top
right and left, and one on each side at the bottom.
5. Adjustment of the levelling bar
Adjust the working depth with the lever and fix it with
the pin.
Attention:
During work, the tines have soil contact. Therefore always
lift the machine for driving or rolling backwards!
If the machine is not lifted the tines can hook in the soil
and break.

13
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
1
2
1. Adjusting the inclination of the tines:
Adjust the inclination of the tines by moving the adjus-
ment lever to the rear and lock ist behind the vertical
adjustment frame.
Lever to the rear = tines steeper = more aggressive
2. Adjusting the working depth:
Adjust the working depth of the tines with the depth
adjustment frame at the wheel rocker.
Stands higher = tines deeper = more aggressive
Adjustment of the incline of the Ripperboard:
For the incline of the Ripperboard there are several
fixed setting points.
Adjust the incline with the lever and fix it with the pin.
3. Adjustment the depth of the Ripperboard:
Adjust the desired working depth of the Ripperboard
with the lever and fix it with the pin.
Attention:
During work, the harrow tines and also the tines of the
Ripperboard have soil contact. Therefore always lift the
machine for driving or rolling backwards!
If the machine is not lifted the tines can hook in the soil
and break.
Setting of the machine (with Ripperboard)
HarroFlex 250 mit Ripperboard
3

14
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
2
3
4
Adjustment of the levelling bar and Ripperboard
For the adjustment of the levelling bar and the Ripper-
board see the previous pages.
1. Mounting of the three-point front:
The three-point front ist hooked into the quick-connect
latches and secured. The support ist then mounted bet-
ween the DPT and the main frame in front.
• Connect the stands self steering at the lower link
points of the main frame
• Attach the front warning lights
2. Adjustment lower link:
lower link horizontal
3. Adjustment upper link:
Insert upwards the upper link by one hole, parallel to
the lower link
4. Adjustment of the stands with self steering:
Place the levelling bar and the Ripperboard uppermost
and adjust the harrow tines to the desired inclination.
By adjusting and fixing of the rear- and front wheels
parallel to the soil, the working depth is set. Adjust the
levelling bar and the Ripperboard as described on the
pages 12 and 13.
Setting of the machine (with front linkage Alpin 440 600)
1

15
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Setting of the mashine (drive shaft)
Before the first start-up of the drive shaft:
If necessary the the length of the drive shaft must be ad-
justed to the tractor by a specialist workshop, as described
in the supplied instruction manual of the manufacturer of
the drive shaft.
The drive shaft haft must have the prescribed installation
length with a minimum overlap. The tractor sign on the dri-
ve shaft indicates its tractor site connection.
Mounting and demounting of the drive shaft:
Bevore starting works controll the protection of the drive
shaft!
Secure the protection of the drive shaft against rotation by
hooking-up the chain!
Check, whether the selected PTO shaft speed of the tractor
corresponds to the permitted number of drives of the fan.
Mounting and demounting only with interrupted PTO shaft
and stopped tractor motor also as with engaged parking
brake and removed ignition key. Do not stand between the
tractor and the machine during mounting and demounting!
Be careful with after-running inertia mass, wait for stand-
still!
For securing, place the demounted drive shaft on the hol-
der provided for this purpose, do not use the chains for to
suspend the drive shaft.
Observe the accident prevention regulations and the ope-
rating instructions from the manufactuerer of the drive
shaft.
Maintenance and repair work:
Only with stopped motor and removed ignition key!
Observe the instruction manual of the manufacturer!
PTO shaft speed:
The PTO shaft speed of the
mechanic fan is factory-set at
540 / 750 revolutions
per minute.
Adjustment - only by the specialist workshop

16
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
TINE SEED
GreenMaster 600 TINE SEED
• Blower pressure not under 80 bar, better 100 bar.
• Run the fan before starting sowing, for that humidity in
the system can dry.
• Use only sorted seeds. High dust content leads to the
seed sticking during distribution.
• Check the hoses for cracks, kinks or other damage
before using.
Technical data
Transport height
GreenMaster 600: 3,00 m
GreenMaster 750: 3,85 m
GreenMaster 800: 4,15 m
With 25 cm ground clearance!
Transport width
Tines max. adjustment:
281 cm
Ripperboard max.:
298 cm
NonStop double tines with seed tube
Check the seed tubes regularly and before each sowing
for tight fit, blockages and damage!
We explicitly like to point out that no liability is accepted
for consequential damage caused by:
• Sowing mistakes
• Badly germing seeds
• No check of the mashine

17
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Coupling kit
Coupling kit STANDARD for trailed rollers with
Cat. 2 connection
The hydraulic connections and the lighting cable of the
trailed rollers Mayor or Master are coupled directly to the
GreenMaster..
Required hydraulic connections:
• 1x da for common pivoting GreenMaster harrow and
trailed roller
• 1x da for transport wheels trailed roller
• 1x single acting and 1x pressureless return for Pneu-
matic seeder with hydraulic fan
Coupling kit PREMIUM for trailed rollers with
Cat. 2 connection
All hydraulic functions of the two machines are triggered by
one hydraulic control block, which is supplied by only one
double-acting control unit of the tractor. The required func-
tion is pre-selected on the control panel in the driver‘s cab.
Necessary is:
• 1x 3-Pin socket 12 V
• 1x da for control block
• 1x aingle acting and 1x pressureless return for Pneu-
matic seeder with hydraulic fan
Hydraulic function:
Folding harrow / folding roller / controlling transport
wheels / hydraulic lifting of ground drive wheel
Folding
harrow
Folding
roller
Transpor
wheels
Ground
wheel

18
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Hydraulic connections
Unfolding the roller Folding the roller
Roller transport wheels
lift up
-
The tail wheel moves up
Pressureless return
for the fan
+
+
-
-
-
Roller transport
wheels lower
Permanent pressure of
18–20l/min for the fan
Always pay attention to the correct connection
of the hydraulic lines!
When connecting the hydraulic lines, the hydraulic system
must be depressurised on both at the tractor and at the
machine!
+

19
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Calibration test (EPS 5)
A calibration test is always required when the exact
application rate should be determined. Proceed as follows:
1. Release the cover of the seeder.
2. Take off the cover.
3. Take out the chute below the dowing roller.
4. Fit the chute above the dowing roller.
5. Calibration bag.
6. Turn the tail wheel in direction of travel. The number
of turns you can see in the table. Weigh the quantity
and compare it with the table. If necessary change
the seed quantity and repeat the calibration test.

20
INSTRUCTION MANUAL | GreenMaster
Except errors, subject to technical changes. Non-contractual photos and pictures.
Working with the machine
Setting the seed quantity
Set the seed quantity with the lever on the left.
Attention:
The scale is for guidance only and is not an indication of
kilograms (kg)!
Calculate the quantity of seeds:
The calibrated rate for 1 are (in gramme) x 100 = quantity
per hectare!
Example:
215 g calibrated quantity x 100 = 21500 g/ha
= 21,5 kg/ha
Setting the scraper distance
With the lever on the right you adjust the distance bet-
ween the scraper and the dosing roller. By shifting the
scraper you change the seed quantity.
The smaller the seeds, the smaller should be the distance
between scraper and dosing roller. For grass seeds we
recommend the setting 0 to 1.
If the desired seed quantity is not reached with the lever
for the seed quantity, you can increase or reduce the seed
quantity by the scraper distance.
Attention:
The higher the distance between dosing roller and
scraper, the more differs the actual seed quantity from the
calibrated quantity.
Depending on the seed and the quantity it can be
necessary to change the dosing roller.
Quick emptying of the seed tank
The slider for quick emptying is located on the right side
of the dosing unit.
To open the slider, first press the button upwards and then
pull it out.
The remaining seed trickles out through the grey tube at
the front.
