Gaggenau BSP2601 1 Series User manual

en User manual and installation instructions
BSP2601.1,
BSP2611.1
Combi steam oven
Gaggenau

en Safety
2
Table of contents
INFORMATION FOR USE
1 Safety....................................................................2
2 Preventing material damage ...............................4
3 Environmental protection and saving en-
ergy .......................................................................6
4 Familiarising yourself with your appliance ........7
5 Accessories........................................................11
6 Before using for the first time ...........................12
7 Basic operation ..................................................13
8 Timer functions ..................................................14
9 Long-term timer .................................................16
10 Childproof lock...................................................16
11 Automatic programmes.....................................17
12 Individual recipes...............................................18
13 Core temperature probe ....................................19
14 HomeConnect ...................................................21
15 Basic settings.....................................................24
16 Cleaning and servicing......................................26
17 Troubleshooting.................................................30
18 Disposal..............................................................33
19 How it works.......................................................33
20 Customer Service...............................................53
21 Declaration of Conformity .................................54
22 INSTALLATION INSTRUCTIONS .......................54
22.1 General installation instructions.......................54
1 Safety
Observe the following safety instructions.
1.1 General information
¡Read this instruction manual carefully.
¡Keep the instruction manual and the
product information safe for future refer-
ence or for the next owner.
¡Do not connect the appliance if it has been
damaged in transit.
1.2 Intended use
This appliance is designed only to be built
into kitchen units. Read the special installation
instructions.
Only a licensed professional may connect ap-
pliances without plugs. Damage caused by in-
correct connection is not covered under the
warranty.
Only use this appliance:
¡To prepare meals and drinks.
¡In private households and in enclosed
spaces in a domestic environment.
¡Up to an altitude of max. 4000m above
sea level.
1.3 Restriction on user group
This appliance may be used by children aged
8 or over and by people who have reduced
physical, sensory or mental abilities or inad-
equate experience and/or knowledge,
provided that they are supervised or have
been instructed on how to use the appliance
safely and have understood the resulting
dangers.
Do not let children play with the appliance.
Children must not perform cleaning or user
maintenance unless they are at least 15 years
old and are being supervised.
Keep children under the age of 8 years away
from the appliance and power cable.
1.4 Safe use
WARNING‒Risk of fire!
Combustible objects that are left in the cook-
ing compartment may catch fire.
▶Never store combustible objects in the
cooking compartment.
▶If smoke is emitted, the appliance must be
switched off or the plug must be pulled out
and the door must be held closed in order
to stifle any flames.
Loose food remnants, fat and meat juices
may catch fire.
▶Before using the appliance, remove the
worst of the food residues and remnants
from the cooking compartment, heating ele-
ments and accessories.

Safety en
3
Opening the appliance door creates a
draught. Greaseproof paper may come into
contact with the heating element and catch
fire.
▶Never place greaseproof paper loosely
over accessories when preheating the ap-
pliance and while cooking.
▶Always cut greaseproof paper to size and
use a plate or baking tin to hold it down.
WARNING‒Risk of burns!
The appliance and its parts that can be
touched become hot during use.
▶Caution should be exercised here in order
to avoid touching heating elements.
▶Young children under 8 years of age must
be kept away from the appliance.
Accessories and cookware get very hot.
▶Always use oven gloves to remove ac-
cessories or cookware from the cooking
compartment.
When the cooking compartment is hot, any al-
coholic vapours inside may catch fire. The ap-
pliance door may spring open. Hot steam and
jets of flame may escape.
▶Only use small quantities of drinks with a
high alcohol content in food.
▶Do not heat spirits (≥ 15% vol.) when undi-
luted (e.g. for marinating or pouring over
food).
▶Open the appliance door carefully.
WARNING‒Risk of scalding!
The accessible parts of the appliance become
hot during operation.
▶Never touch these hot parts.
▶Keep children at a safe distance.
Hot steam may escape when you open the
appliance door. Steam may not be visible, de-
pending on the temperature.
▶Open the appliance door carefully.
▶Keep children at a safe distance.
If there is water in the cooking compartment
when it is hot, this may create hot steam.
▶Never pour water into the cooking compart-
ment when the cooking compartment is
hot.
WARNING‒Risk of injury!
Scratched glass in the appliance door may
develop into a crack.
▶Do not use any harsh or abrasive cleaners
or sharp metal scrapers to clean the glass
on the oven door, as they may scratch the
surface.
The appliance and its parts that can be
touched may have sharp edges.
▶Take care when handling and cleaning
them.
▶If possible, wear protective gloves.
The hinges on the appliance door move when
the door is opened and closed, which could
trap your fingers.
▶Keep your hands away from the hinges.
The light emitted by LED lights is very
dazzling, and can damage the eyes (risk
group 1).
▶Do not look directly into the switched on
LED lights for longer than 100 seconds.
WARNING‒Risk of electric shock!
Incorrect repairs are dangerous.
▶Repairs to the appliance should only be
carried out by trained specialist staff.
▶Only use genuine spare parts when repair-
ing the appliance.
▶If the power cord of this appliance is dam-
aged, it must be replaced with a special
connection cable, which is available from
the manufacturer or his Customer Service.
If the insulation of the power cord is dam-
aged, this is dangerous.
▶Never let the power cord come into contact
with hot appliance parts or heat sources.
▶Never let the power cord come into contact
with sharp points or edges.
▶Never kink, crush or modify the power
cord.
An ingress of moisture can cause an electric
shock.
▶Do not use steam- or high-pressure clean-
ers to clean the appliance.
If the appliance or the power cord is dam-
aged, this is dangerous.
▶Never operate a damaged appliance.
▶Never pull on the power cord to unplug the
appliance. Always unplug the appliance at
the mains.
▶If the appliance or the power cord is dam-
aged, immediately unplug the power cord

en Preventing material damage
4
or switch off the fuse in the fuse box and
turn off the water tap.
▶Call customer services. →Page53
WARNING‒Risk of suffocation!
Children may put packaging material over
their heads or wrap themselves up in it and
suffocate.
▶Keep packaging material away from chil-
dren.
▶Do not let children play with packaging ma-
terial.
Children may breathe in or swallow small
parts, causing them to suffocate.
▶Keep small parts away from children.
▶Do not let children play with small parts.
1.5 Steam
Follow these instructions when using a steam
function.
WARNING‒Risk of scalding!
Hot steam is generated in the cooking com-
partment.
▶Do not reach into the cooking compartment
when using steam.
Hot liquid may spill over the sides of the ac-
cessory when it is removed from the cooking
compartment.
▶Remove hot accessories with care and al-
ways wear oven gloves.
WARNING‒Risk of burns!
Hot steam may escape during operation.
▶Do not touch the ventilation openings.
▶Keep children away from the appliance.
1.6 Core temperature probe
Follow these safety instructions when using
the core temperature probe.
WARNING‒Risk of electric shock!
An incorrect core temperature probe may
damage the insulation.
▶Only use the core temperature probe that is
suitable for this appliance.
1.7 Cleaning
Follow these safety instructions when cleaning
the appliance.
WARNING‒Risk of scalding!
The descaling tablets may cause chemical
burns in the mouth, throat, eyes and on the
skin.
▶Follow the safety instructions on the pack-
aging of the descaling tablets.
▶Avoid the skin coming into contact with the
descaling tablets.
▶Keep children away from the descaling tab-
lets.
The descaling solution may cause chemical
burns in the mouth, throat and eyes or on the
skin.
▶Avoid the skin coming into contact with the
descaling solution.
▶Keep children away from the descaling
solution.
▶Do not drink the descaling solution.
▶The descaling solution must not come into
contact with food.
▶Clean the water tank in the dishwasher or
thoroughly by hand before you next use the
appliance.
2 Preventing material damage
2.1 General
ATTENTION!
A build-up of heat may damage the appliance.
▶Do not place anything directly on the cooking com-
partment floor.
▶Do not line the cooking compartment floor with alu-
minium foil.
▶Always place cookware in a perforated cooking con-
tainer or on a wire rack.
Chlorinated tap water (>40mg/l) may damage the ap-
pliance.
▶Use low-chloride non-carbonated mineral water.
▶You can obtain information about your tap water
from your water supplier.
Chloride and acids may damage the stainless steel sur-
face.
▶Remove any residues of salt, hot sauces, e.g.
ketchup or mustard, salted food, e.g. salted roasts,
or other foods containing chloride or acid immedi-
ately.
Aluminium foil can cause permanent discolouration on
the door pane.
▶Ensure that the aluminium foil does not come into
contact with the door pane.
Fruit juice can cause permanent stains in the cooking
compartment.
▶Always remove fruit juice immediately.
▶Wipe with a damp cloth, followed by a dry cloth.

Preventing material damage en
5
The prolonged presence of moisture in the cooking
compartment leads to corrosion.
▶Do not keep moist food in the cooking compartment
for a long time with the door closed.
▶Do not store food in the cooking compartment.
Rusting material may lead to corrosion in the cooking
compartment.
▶Only use original accessories in the cooking com-
partment.
▶Do not use any enamelled baking trays or grill trays.
▶Never use serving plates or cutlery that may rust.
Small parts that are not original may damage the appli-
ance.
▶Only use original small parts, e.g. knurled nuts.
▶If necessary, order small parts from our spare parts
service.
Heat can damage stainless steel cooking containers.
▶Only heat stainless steel cooking containers up to
230°C.
▶Do not use stainless steel cooking containers in the
oven.
Leaving the appliance to cool down with the door open
will damage the front of neighbouring kitchen units over
time.
▶Always allow the cooking compartment to cool
down with the door closed after cooking at high
temperatures.
▶Take care not to trap anything in the appliance
door.
▶Only leave the cooking compartment to dry with the
door open if a lot of moisture was produced during
operation.
If the seal is very dirty, the appliance door will no
longer close properly during operation. This may dam-
age the front of adjacent kitchen units.
▶Keep the seal clean at all times.
▶Never operate the appliance if the seal is damaged
or missing.
Sitting or placing objects on the appliance door may
damage it.
▶Do not place, hang or support objects on the appli-
ance door.
▶Do not place cookware or accessories on the appli-
ance door.
2.2 Steam
ATTENTION!
Dripping liquids may damage the cooking compart-
ment.
▶To catch any dripping liquids, when steaming using
a perforated cooking container, always insert the un-
perforated cooking container underneath.
Silicone bakeware is not suitable for combined opera-
tion with steam.
▶Cookware must be heat- and steam-resistant.
Using cookware with rust spots may cause corrosion in
the cooking compartment. Even the smallest spots of
rust can cause corrosion.
▶Do not use cookware with rust spots.
If descaling solution comes into contact with the control
panel or other delicate surfaces, it will damage them.
▶Remove descaling solution immediately with water.
2.3 Core temperature probe
WARNING‒Risk of electric shock!
An incorrect core temperature probe may damage the
insulation.
▶Only use the core temperature probe that is suitable
for this appliance.
ATTENTION!
Temperatures above 250°C damage the core temper-
ature probe.
▶Only use the core temperature probe in your appli-
ance at a maximum temperature of 230°C.
You may damage the cable of the core temperature
probe with the appliance door.
▶Do not trap the cable of the core temperature probe
in the appliance door.
The heat of the grill heating element may damage the
core temperature probe.
▶Ensure that the distance between the grill heating
element and the core temperature probe and the
cable of the core temperature probe is a few centi-
metres. In doing so, ensure that the meat can ex-
pand during the cooking process.
Moisture may damage the core temperature probe.
▶Do not clean the core temperature probe in the
dishwasher.
2.4 Cleaning
ATTENTION!
Limescale may damage the appliance.
▶Descale the appliance regularly.
Using the wrong descaler may damage the appliance.
▶Only use the specified descaling tablets.
Improper care of the appliance can lead to corrosion in
the cooking compartment.
▶Follow the care and cleaning instructions for the ap-
pliance.
→"Cleaning and servicing", Page26
▶Clean the cooking compartment each time you use
it as soon as the appliance has cooled down.
▶After cleaning the cooking compartment, use the
drying programme →Page28 to dry it.
The descaling tablet may damage the cooking com-
partment.
▶Use the descaling tablet for the descaling pro-
gramme only.
▶Place the descaling tablet into the water tank.
▶Never place the descaling tablet in the cooking
compartment or heat it up in the cooking compart-
ment.
Heat damages the water tank.
▶Do not dry the water tank in the hot cooking com-
partment.

en Environmental protection and saving energy
6
3 Environmental protection and saving energy
3.1 Disposing of packaging
The packaging materials are environmentally compat-
ible and can be recycled.
▶Sort the individual components by type and dispose
of them separately.
3.2 Saving energy
If you follow these instructions, your appliance will use
less power.
When steaming, you can cook on several levels at the
same time.
¡With steam, various dishes can be prepared at the
same time without the different flavours mixing.
When preparing dishes with different cooking times,
those with the longest cooking time should be
placed in the oven first.
When cooking multiple dishes, do so in succession or
in parallel.
¡The cooking compartment is heated after cooking
the first dish. This reduces the cooking time for the
following dishes.
If the cooking time is relatively long, you can switch
the appliance off 10minutes before the cooking time
ends.
¡There will be enough residual heat to finish cooking
the dish.
Use dark-coloured, black-coated or enamelled baking
tins.
¡These types of baking tin absorb the heat particu-
larly well.
Open the appliance door as little as possible during
operation.
¡This maintains the temperature in the cooking com-
partment and eliminates the need for the appliance
to reheat.
Remove any accessories that are not being used from
the cooking compartment.
¡Accessories that are not being used do not need to
be heated.
Allow frozen food to defrost before cooking.
¡This saves the energy that would otherwise be re-
quired to defrost it.

Familiarising yourself with your appliance en
7
4 Familiarising yourself with your appliance
4.1 Appliance
You can find an overview of the parts of your appliance
here.
1 2 3 4
567
1
Door seal
2
Ventilation slots
3
Glass ceramic grilling surface
4
Connection socket for core temperature probe
→Page19
5
Water tank for descaling programme
6
Drain filter
7
Grease filter
Cooking compartment
The cooking compartment has three shelf levels. Count
the shelf levels from the bottom up.
ATTENTION!
A build-up of heat may damage the appliance.
▶Ensure that the cooking compartment floor always
remains clear.
▶Do not place anything directly on the cooking com-
partment floor.
▶Do not line the cooking compartment floor with alu-
minium foil.
▶Always place cookware in the perforated cooking
container or on the wire rack.
The accessories may tip.
▶Do not push the accessories between the shelf posi-
tions.
When steaming, defrosting, dough proving and reheat-
ing, you can use up to three shelf levels at a time. You
can only bake on one level. Use level 2 for baking or,
for taller baking tins, use level 1. For very small baked
goods, you can also use two levels, e.g. level 1 and
level 3.
Water tank for descaling programme
Your appliance is equipped with a water tank with a
maximum capacity of 1.7litres.
If you open the appliance door, you can see the water
tank for the descaling programme →Page28. You
can remove the lid for cleaning.
Grease filter
The grease filter prevents the components of the appli-
ance becoming soiled with grease.
Leave the grease filter in the cooking compartment for
all applications.
Clean the grease filter with hot soapy water or in the
dishwasher every time heavy dirt deposits have been
left behind after cooking.
Controls
You can use the control panel to configure all functions
of your appliance and to obtain information about the
operating status.
On certain models, specific details such as colour and
shape may differ from those pictured.
All appliance types are operated in an identical man-
ner.
112
3
4

en Familiarising yourself with your appliance
8
1
Touch
fields
These areas are touch-sensitive.
Touch a symbol to select the cor-
responding function.
2
Display The display shows current settings
and selection options, for ex-
ample.
3
Rotary se-
lector
Use the rotary selector to select
the temperature and change addi-
tional settings.
4
Function
selector
Use the function selector to select
the type of heating, cleaning or
the basic settings.
Symbols
Use the symbols to start or stop functions, or to navig-
ate in the menu.
Symbol Function
Start
Stop
Pause or end
Cancel
Delete
Confirm or save settings
Selection arrow
Call up additional information
Call up important information and
prompts indicating that an action is
required
Rapid heating with status display
Call up automatic programmes or in-
dividual recipes
Record menu
Edit settings
Enter a name
Delete letters
Childproof lock
Call up the timer menu
Symbol Function
Call up the long-term timer
Demo mode
Core temperature probe →Page19
Start steam injection
End steam injection
Starting steam removal
Stopping steam removal
Network connection (HomeConnect)
Colours
The different colours are used to guide the user in the
relevant setting situations.
Orange ¡Initial settings
¡Main functions
Blue ¡Basic settings
¡Cleaning
White Adjustable values
Appearance
Depending on the situation, the appearance of sym-
bols, values or the entire display changes.
Zoom The appliance zooms in
on the setting that you
have just changed.
If you have set a time and
it is about to run out, it
will appear larger on the
display just before it runs
out, e.g. if you have set
the timer.
Pared-down display After a short while, the ap-
pliance reduces the
amount of information
shown on the display and
only the most important
information remains. This
function is preset. You
can change the setting in
the basic settings.
Position of the function selector
Use the function selector to select the functions or types of heating.

Familiarising yourself with your appliance en
9
Position Function/type of heating Temperature Use
⁠ Zero setting
⁠ Light Switch on the interior lighting
Access to other functions, e.g.
automatic programmes, indi-
vidual recipes, remote start via
HomeConnect
⁠
Hot air + 100% humidity
30-230°C
Default temperature
100°C
Steaming at 70°C to 100°C:
For vegetables, fish and side
dishes
The food is completely surroun-
ded by steam.
Combination mode at 120°C to
230°C: For puff pastry, bread
and bread rolls
The appliance combines hot air
and steam.
⁠
Hot air + 80% humidity
30-230°C
Default temperature
170°C
Combination mode: For puff
pastry, meat and poultry
The appliance combines hot air
and steam.
⁠
Hot air + 60% humidity
30-230°C
Default temperature
170°C
Combined operation: For yeast-
risen baked goods and bread
The appliance combines hot air
and steam.
⁠
Hot air + 30% humidity1
30-230°C
Default temperature
170°C
Cooking without added liquid:
For baked items
With this setting, the appliance
does not generate any steam.
Any moisture escaping from the
food remains in the cooking com-
partment and prevents the food
from drying out.
⁠
Hot air + 0% humidity
30-230°C
Default temperature
170°C
Hot air: For cakes, biscuits and
bakes
The fan in the back panel of the
oven distributes the heat evenly
throughout the cooking compart-
ment.
⁠
Low-temperature cooking
30-90°C
Default temperature 70°C
Low-temperature cooking for
meat
Gentle slow cooking for a particu-
larly tender result
⁠
Sous-vide cooking
50-95°C
Default temperature 60°C
Cooking food in a vacuum at low
temperatures between 50-95°C
and with 100% steam: Suitable
for meat, fish, vegetables and
desserts
A vacuum-sealing machine uses
heat to hermetically seal the food
in a special heat-resistant cook-
ing bag. The protective envelope
retains the nutrients and flavours.
⁠
Full surface grill setting 1 + hu-
midity
30-230°C
Default temperature
170°C
Grill mode with humidity: For
bakes and gratins
⁠ ⁠
Full surface grill setting 2 + hu-
midity
30-230°C
Default temperature
170°C
Grill mode with humidity: For
stuffed vegetables
The grill output is increased.
1Type of heating used to determine the energy efficiency class in accordance with EN60350-1.

en Familiarising yourself with your appliance
10
Position Function/type of heating Temperature Use
⁠ ⁠
Full surface grill + air recircula-
tion
30-230°C
Default temperature
230°C
For au gratin dishes at the end of
the cooking time at 230°C. For
grilling vegetable skewers and
prawn skewers at 180°C.
⁠ ⁠
Dough proving
30-50°C
Default temperature 38°C
Proving: For yeast dough and
sour dough
The dough rises considerably
more quickly than at room tem-
perature. Hot air and steam are
combined so that the surface of
the dough does not dry out.
The optimal temperature setting
for yeast dough is 38°C.
⁠ ⁠
Defrosting
40-60°C
Default temperature 45°C
For vegetables, meat, fish and
fruit
The appliance uses the moisture
to gently transfer the heat to the
food. The food does not dry out
or lose its shape.
⁠ ⁠
Reheating
60-180°C
Default temperature
120°C
For cooked food and baked
goods
For gently reheating cooked
food. The steam ensures that the
food does not dry out.
Reheat plated meals at 120°C
and baked goods at 180°C.
⁠ ⁠ Basic settings Adapt the appliance to individual
requirements in the basic set-
tings →Page24
⁠ ⁠ Drying programme Use the drying programme
→Page28 to dry the cooking
compartment quickly, e.g. after
cleaning
⁠ ⁠ Descaling programme Use the descaling programme
→Page28 to remove limescale
from the appliance
1Type of heating used to determine the energy efficiency class in accordance with EN60350-1.
4.2 Standby
The appliance switches to standby mode if no function
is set or the childproof lock is activated. The standby
screen appears if you do not implement any settings
for a long time.
Different displays can be shown in standby mode. The
GAGGENAU logo and the time are preset.
In standby mode, the brightness of the control panel is
reduced. The brightness of the display depends on the
vertical viewing angle. You can change the display and
the brightness at any time in the basic settings
→Page24.
When "Off" is selected for the standby display in the
basic settings, you must turn the function selector to
exit standby mode.
When the door is open, the interior lighting switches off
after a short time.
4.3 Additional information
Press ⁠ to display additional information, e.g. informa-
tion about the type of heating that is set or the current
cooking compartment temperature.
During continuous operation after heating up, slight
temperature fluctuations are normal.
