Gaggenau AF 2 Series User manual

Gaggenau
Use and care manual and installation instructions
Notice d’utilisation et de montage
Instrucciones de uso y montaje
AF 2..
Hood
Hotte aspirante
Campana extractora

2
Table of Contents Useandcaremanualandinstallationinstructions
Use and care manual 3
Safety Definitions 3
IMPORTANT SAFETY INSTRUCTIONS 4
General notes 4
Fire Safety 4
Burn Prevention 5
Child Safety 5
Cleaning Safety 6
Safe use 6
Proper Installation and Maintenance 6
State of California Proposition 65 Warnings 7
Causes of damage 7
Protecting the environment 8
Saving energy 8
Operating modes 8
Exhaust air mode 8
Recirculation 8
Operating the appliance 9
Operating the appliance 9
Turn on the fan 9
Intense level 9
Run-on function 9
Interval ventilation 9
Lighting 10
Saturation notification 10
Cleaning and maintenance 10
Troubleshooting 12
Customer service 13
Accessories 13
Installation Instructions 13
IMPORTANT SAFETY INSTRUCTIONS 14
Appliance Handling Safety 15
Safety Codes and Standards 15
Electric Safety 15
Related Equipment Safety 16
State of California Proposition 65 Warnings 16
Before You Begin 17
Tools and Parts Needed 17
Parts Included 17
Safety clearances 17
General notes 18
Exhaust air mode 18
Ventilation line 18
Preparing the units 19
Preparing the appliance 20
Electrical connection 20
Installation 21
Mounting the appliance 21
Detaching the appliance 21
Final assembly 22
Removing the appliance 22

3
Use and care manual
Additional information on products, accessories,
replacement parts and services can be found at
www.gaggenau.com and in the online shop
www.gaggenau-eshop.com
Safety Definitions
9WARNING
This indicates that death or serious injuries
may occur as a result of non-observance of
this warning.
9CAUTION
This indicates that minor or moderate injuries
may occur as a result of non-observance of
this warning.
NOTICE: This indicates that damage to the appliance
or property may occur as a result of non-compliance
with this advisory.
Note: This alerts you to important information and/or
tips.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
4
IMPORTANTSAFETYINSTRUCTION READ AND SAVE THESE INSTRUCTIONS
WARNING
When properly cared for, your new appliance has
been designed to be safe and reliable. Read all
instructions carefully before use. These precautions
will reduce the risk of burns, electric shock, fire, and
injury to persons. When using kitchen appliances,
basic safety precautions must be followed, including
those in the following pages.
General notes
Examine the appliance after unpacking it. In the event
of transport damage, do not plug it in.
Fire Safety
Always have a working smoke detector near the
kitchen.
WARNING
TO REDUCE THE RISK OF A RANGE TOP GREASE
FIRE:
a) Never leave surface units unattended at high
settings. Boilovers cause smoking and greasy
spillovers that may ignite. Heat oils slowly on low
or medium settings.
b) Always turn hood ON when cooking at high heat.
c) Clean ventilating fans frequently. Grease should
not be allowed to accumulate on fan or filter.
d) Use proper pan size. Always use cookware
appropriate for the size of the surface element.
Do not flambé under the extractor hood or work with a
naked flame. When switched on, the extractor hood
draws flames into the filter. There is a risk of fire due
to deposits on the grease filter!
CAUTION
For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
Do not operate any fan with a damaged cord or plug.
Discard fan or return to an authorized service facility
for examination and/or repair.
Do not run cord under carpeting. Do not cover cord
with throw rugs, runners, or similar coverings. Do not
route cord under furniture or appliances. Arrange
cord away from traffic area and where it will not be
tripped over.
In the event that personal clothing or hair catches fire,
drop and roll immediately to extinguish flames.
Smother flames from food fires other than grease fires
with baking soda. Never use water on cooking fires.
WARNING
TO REDUCE THE RISK OF INJURY TO PERSONS IN
THE EVENT OF A RANGE TOP GREASE FIRE,
OBSERVE THE FOLLOWING:
‒SMOTHER FLAMES with a close-fitting lid,
cookie sheet, or metal tray, then turn off the
burner. BE CAREFUL TO PREVENT BURNS. If
the flames do not go out immediately, EVACUATE
AND CALL THE FIRE DEPARTMENT.
‒NEVER PICK UP A FLAMING PAN – You may be
burned.
‒DO NOT USE WATER, including wet dishcloths
or towels – a violent steam explosion will result.
‒Use an extinguisher ONLY if:
‒You know you have a Class ABC extinguisher,
and you already know how to operate it.
‒The fire is small and contained in the area
where it started.
‒The fire department is being called
‒You can fight the fire with your back to an exit.
Have an appropriate fire extinguisher available,
nearby, highly visible and easily accessible near the
appliance.
Whenever possible, do not operate the ventilation
system during a cooktop fire. However, do not reach
through fire to turn it off.
WARNING
Risk of fire
Grease deposits in the grease filter can ignite.
Clean the grease filter at least every two months.
Never operate the appliance without the grease filter.

5
9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
WARNING
Risk of fire
Grease deposits in the grease filter can catch fire.
Never work with a naked flame near the appliance
(e.g. flambéing). Install the unit near a heat-producing
appliance for solid fuels (e.g. wood or coal) only if
there is a closed, non-detachable cover. There must
be no flying sparks.
WARNING
Risk of fire
When gas burners are in operation without any
cookware placed on them, they can build up a lot of
heat. A ventilation appliance installed above the
cooker may become damaged or catch fire. Only
operate the gas burners with cookware on them.
WARNING
Risk of fire
During simultaneous use of multiple gas cooktops, a
great deal of heat is created. A ventilation device
located above it can become damaged or catch fire.
Never use two gas cooktops together at maximum heat
for longer than 15 minutes. One large burner with over
17,000 Btu/hr (5 kW) (wok) is equal to the wattage of
two gas burners.
WARNING
Risk of fire
Operating several gas burners at the same time gives
rise to a great deal of heat. The ventilation appliance
may become damaged or catch fire. The ventilation
appliance must only be combined with gas burners
that do not exceed the maximum total output of 61,000
Btu/hr (18 kW). If 41,000 Btu/hr (12 kW) is exceeded,
the local regulations concerning room ventilation,
room size, and combination with ventilation devices in
exhaust and recirculating operation must be heeded.
WARNING
Risk of fire
Hot oil and fat catch fire fast. Never leave hot oil and
fat unsupervised. Never extinguish a fire with water.
Switch off the cooking position. Suffocate flames
carefully with a lid, a fire blanket or similar.
Burn Prevention
WARNING
Risk of burns
The accessible parts get hot during operation. Never
touch hot parts. Keep children away.
Child Safety
When children become old enough to use the
appliance, it is the legal responsibility of the parents
or legal guardians to ensure that they are instructed in
safe practices by qualified persons.
Remove all tape and packaging before using the
appliance. Destroy the packaging after unpacking the
appliance. Never allow children to play with packaging
material.
Do not allow anyone to climb, stand, lean, sit, or hang
on any part of an appliance, especially a door,
warming drawer, or storage drawer. This can damage
the appliance, and the unit may tip over, potentially
causing severe injury.
Do not allow children to use this appliance unless
closely supervised by an adult. Children and pets
should not be left alone or unattended in the area
where the appliance is in use. They should never be
allowed to play in its vicinity, whether or not the
appliance is in use.
CAUTION
Items of interest to children should not be stored in an
appliance, in cabinets above an appliance or on the
backsplash. Children climbing on an appliance to
reach items could be seriously injured.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
6
Cleaning Safety
WARNING
Be sure the entire appliance (including the grease
filters and light bulbs, if applicable) has cooled and
grease has solified before attempting to clean any
part of the appliance.
Do not use steam cleaners to clean the appliance.
Safe use
WARNING
Do not repair, replace or remove any part of the
appliance unless specifically recommended in the
manuals. Improper installation, service or
maintenance can cause injury or property damage.
Refer to this manual for guidance. All other servicing
should be done by a qualified technician.
WARNING
Risk of injury
Items placed on the appliance may fall down. Do not
place any objects on the appliance.
WARNING
Risk of injury
The light emitted by LED lights is very dazzling, and
can damage the eyes (risk group 1). Do not look
directly into the switched on LED lights for longer
than 100 seconds.
Proper Installation and Maintenance
Have the installer show you the location of the circuit
breaker or fuse. Mark it for easy reference.
This appliance must be properly installed and
grounded by a qualified technician. Connect only to
properly grounded outlet. Refer to Installation
Instructions for details.
This appliance is intended for normal family
household use only. It is not approved for outdoor
use. See the Warranty. If you have any questions,
contact the manufacturer.
Do not store or use corrosive chemicals, vapors,
flammables or nonfood products in or near this
appliance. It is specifically designed for use when
heating or cooking food. The use of corrosive
chemicals in heating or cleaning will damage the
appliance and could result in injury.
Do not operate this appliance if it is not working
properly, or if it has been damaged. Contact an
authorized servicer.
Do not repair or replace any part of the appliance
unless specifically recommended in this manual. Refer
all servicing to a factory authorized service center.
CAUTION
Grease left on filters can remelt and move into the
vent.
CAUTION
Turn power off at breaker before removing a damaged
bulb. Do not touch the bulbs immediately after use.
The bulbs will remain hot for several minutes.
WARNING
Make sure the appliance and lights are cool and
power to the appliance has been turned off before
replacing the light bulb(s). Failure to do so could
result in electrical shock or burns.The lenses (if
equipped) must be in place when using the
appliance.The lenses (if equipped) serve to protect
the light bulb from breaking.The lenses (if equipped)
are made of glass. Handle carefully to avoid breaking.
Broken glass can cause an injury.
Hidden surfaces may have sharp edges. Use caution
when reaching behind or under appliance.

7
WARNING
When the hood is operated in exhaust-air mode
simultaneously with a different burner which also
makes use of the same chimney (such as gas, oil or
coal-fired heaters, continuous-flow heaters, hot-water
boilers) care must be taken to ensure that there is an
adequate supply of fresh air which will be needed by
the burner for combustion.
Safe operation is possible provided that the under
pressure in the room where the burner is installed
does not exceed 4 Pa (0.04 mbar).
This can be achieved if combustion air can flow
through non-lockable openings, e.g. in doors,
windows and via the air-intake/exhaust-air wall box or
by other technical measures, such as reciprocal
interlocking, etc.
WARNING
Avoid carbon monoxide poisoning – Provide
adequate air intake so combustion gases are not
drawn back into the room.
An air-intake/exhaust-air wall box by itself is no
guarantee that the limiting value will not be
exceeded.
Note: When assessing the overall requirement, the
combined ventilation system for the entire household
must be taken into consideration. This rule does not
apply to the use of cooking appliances, such as
cooktops and ovens.
State of California Proposition 65
Warnings
WARNING
This product contains chemicals known to the State
of California to cause cancer, birth defects or other
reproductive harm.
Causes of damage
NOTICES:
▯Risk of damage due to corrosion. Always turn
appliance on when cooking to avoid
condensation buildup. Condensation can lead to
corrosion damages.
▯Risk of damage due to ingress of humidity into
the electronic circuitry. Never clean operator
controls with a wet cloth.
▯Surface damage due to incorrect cleaning.
Clean stainless steel surfaces in the grind
direction only. Do not use any stainless steel
cleaners for operator controls.
▯Surface damage due to strong or abrasive
cleaning agents. Never use strong and abrasive
cleaning agents.
▯Risk of damage from condensation back flow.
Install exhaust vent at a slight downward slope
away from the appliance (1° slope).

8
Protecting the environment
Your new appliance is particularly energy-efficient.
Here you can find tips on how to save even more
energy when using the appliance, and how to
dispose of your appliance properly.
Unpack the appliance and dispose of the packaging
in line with environmental requirements.
Saving energy
▯When cooking, ensure that there is sufficient
supply air so that the extractor hood works
efficiently and quietly.
▯Fan level adjust to the intensity of the cooking
fumes. Only use the intensive mode if necessary.
A lower fan level means lower energy
consumption.
▯With intensive cooking fumes, select a higher
fan level early on. Cooking fumes that are
already distributed in the kitchen mean that the
extractor hood will have to be operated longer.
▯Switch off the extractor hood when it is no
longer required.
▯Switch off the lighting when it is no longer
required.
▯Clean and change the filter at the specified
intervals in order to increase the effectiveness
of the ventilation and prevent a risk of fire.
Operating modes
You can use this appliance in the air extraction or the
recirculation mode.
Exhaust air mode
Note: Ventilation may not exit through an already
operational smoke or exhaust chimney, nor a duct
used for ventilating furnace installation areas.
▯If the ventilation is intended to pass through a
smoke or exhaust that is not in operation, the
responsible area heating inspector must give
approval.
▯If the ventilation passes through an external wall,
use a telescope wall sleeve.
Recirculation
Note: You must install an activated charcoal filter to
bind odors in the recirculation mode. Refer to the
manual or ask your specialist dealer for details of the
various options for operating the appliance in the
recirculation mode. You can obtain the necessary
accessories from specialist dealers, from our after-
sales service or in the online shop.
The air that is drawn in is cleaned by
the grease filters and conveyed to the
exterior by a pipe system.
The aspirated air is cleaned by the grease
filters and an activated charcoal filter and
is returned to the kitchen.

9
Operating the appliance
Note: Turn the extractor hood on when you start
cooking and switch it off again a few minutes after
you have finished cooking. This is the most effective
way to eliminate cooking vapor.
Operating the appliance
Control panel
Turn on the fan
Switching on
Press down lightly in the middle of the handle strip to
extend the filter pull-out.
1Press the ÿbutton to switch on the appliance.
The fan starts in setting 2.
2With the buttons 1, 2, 3 or Ž, set the fan speed
according to the cooking situation.
Switching off
Use the ÿ button to switch the appliance off.
Intense level
For especially strong odor or vapor, use the intense
level.
1Press the ÿbutton to switch on the appliance.
The fan starts in setting 2.
2Press the Ž button to switch on the Intensive
setting.
Note: If the button was pressed while the fan is
running on speed 1, 2 or 3, the electronics
automatically switch back to the previously-
selected fan speed after 5 minutes.
3To switch off the Intensive setting earlier, press
the ÿbutton or the button for another fan
speed.
Setting the duration
You can set the duration after which the Intensive
setting switches off automatically.
The factory setting is set to 5 minutes.
Run-on function
The run-on function can be set for any fan speed.
1First press the button for the desired fan speed
1, 2, 3 or Ž and then press the žbutton.
Notes
‒The run-on time is ten minutes for all fan
speed settings. Once this time has elapsed,
ventilation switches off automatically.
‒If the lighting is switched on, it remains on.
2To switch off the run-on function earlier, press
the ÿbutton.
Interval ventilation
For interval ventilation, the device is switched on
automatically for five minutes per hour.
1Press the ÿ button to switch on the appliance.
The fan starts at level 2. The interval ventilation
can be used on level 1, 2 or 3.
2Press the run-on button ž twice.
Note: This mode is indicated by alternating
lighting up of the ž button with the
corresponding speed.
3To end interval ventilation, press the ÿbutton.
Explanation
#Fan On/off
1 Fan speed 1
2 Fan speed 2
3 Fan speed 3
ŽIntensive setting
žRun-on funcion
œSaturation display
cLight on/off
Duration Press buttons simultaneously
3 minutes Žand 1
5 minutes Žand 2
10 minutes Žand 3

10
Lighting
The lighting can be switched on and off
independently of the ventilation.
Press the @button.
Setting the brightness
Press and hold the @button until the desired
brightness is reached.
Saturation notification
After 30 hours of operation, the saturation display œ
of the grease filter blinks.
▯At the latest now the metal mesh grease filter
should be cleaned. For instructions on how to
clean the metal mesh grease filter, please see
the chapter about Cleaning and maintenance.
▯While the saturation display is blinking, it can be
reset with the œbutton.
Cleaning and maintenance
9WARNING
Risk of burns
The appliance will become hot when in use,
especially in the area surrounding the bulbs.
Let cool before cleaning.
9WARNING
Risk of electric shock
Penetrating damp can cause electric shock.
Only clean appliance with a damp cloth. Prior
to cleaning, pull the plug or flip the breaker in
the fusebox.
9WARNING
Risk of electrical shock
Moisture entering the appliance can cause an
electrical shock. Don't use a high-pressure
cleaner or steam cleaner.
9WARNING
Risk of injury
Components inside the appliance may have
sharp edges. Wear protective gloves.
Cleaning agents
To prevent various surfaces from becoming damaged
due to incorrect cleaning agents, follow the
specifications given in the table. Do not use
▯cleaning agents that are harsh or scouring,
▯cleaning agents with high alcohol content,
▯hard scouring pads or sponges,
▯high-pressure cleaners or steam cleaners.
Thoroughly rinse all new sponges before use.
Observe all instructions and warnings accompanying
cleaning agents.
Area Cleaning agents
Stainless steel Warm soapy water:
Clean with a dish rag and dry with a
soft towel.
Only clean stainless steel with the
grain.
Specific products for stainless steel
care are available from customer ser-
vice or from specialized retailers.
Apply a thin layer of the care product
with a soft cloth.
Varnished sur-
faces
Warm soapy water:
Clean with a damp dish rag and dry
with a soft towel.
Do not use stainless steel cleaner.
Aluminum and
plastic
Glass cleaner:
Clean with a soft cloth.
Glass Glass cleaner:
Clean with a soft cloth. Do not use a
glass scraper.
Controls Warm soapy water:
Clean with a damp dish rag and dry
with a soft towel.
Risk of damage to electronics due to
permeating damp. Never clean
controls with a wet cloth.
Do not use stainless steel cleaner.

11
Cleaning the metal grease filter
These instructions apply to several appliance
models. It is possible that individual features are
described that do not apply to your appliance.
9WARNING
Risk of fire
Grease deposits in the grease filter can ignite.
Clean the grease filter at least every two
months.
Never operate the appliance without the
grease filter.
Notes
‒Do not use any aggressive, acidic or alkaline
cleaning agents.
‒When cleaning the metal grease filters, also
clean the metal grease filter holder in the
appliance with a moist cloth.
‒You can clean the metal grease filters in a
dishwasher or by hand.
By hand:
Note: You can use a special grease solvent if soiling
is stubborn. You can order it via the online shop.
▯Soak the metal grease filters in hot soapy
solution.
▯Use a brush for cleaning and then rinse the
filters well.
▯Allow the metal grease filters to drip dry.
In the dishwasher:
Note: Slight discoloration is possible when cleaning
the grease filters in the dishwasher. This does not
affect the metal grease filter's functioning.
▯Do not clean extremely dirty metal grease filters
with dishes.
▯Loosely position the metal grease filter in the
dishwasher. The metal grease filters must not be
jammed in.
Uninstalling metal grease filter
1Open the lock and fold down the metal grease
filter. While doing this, place your other hand
under the metal grease filter.
2Take the metal grease filter out of the holder.
Notes
‒Grease can accumulate in the bottom of the
metal grease filter.
‒Hold the metal grease filter level to prevent
fat from dripping out.
3Clean the metal grease filter.
On appliances with a glass plate in the filter pull-out:
▯The glass plate can easily be removed and can
be cleaned in the dishwasher.
▯To remove it, carefully lift the glass plate.

12
Installing metal grease filter
1Insert metal grease filter.
Simultaneously use your other hand to grasp
under the metal grease filter.
2Flip metal grease filter up and snap the latch
into place.
Troubleshooting
You can often easily eliminate problems that may
occur on your own. Before calling customer service,
take into account the following information.
9WARNING
Risk of electric shock
Improper repairs are dangerous. Only an after-
sales technician trained by us may perform
repairs and may replace damaged connecting
leads. Remove the mains plug or deactivate
the fuse in the fuse box if the appliance is
defective. Call after-sales service.
Troubleshooting table
--------
LED lights
Defective LED lights may be replaced by the
manufacturer, his customer service or a qualified
technician (electrician) only.
9WARNING
Risk of injury
The light emitted by LED lights is very
dazzling, and can damage the eyes (risk group
1). Do not look directly into the switched on
LED lights for longer than 100 seconds.
Disruption Possible
cause
Solution
Appliance is
not working
Plug is not
plugged in
Connect the appliance to
the mains
Power outage Check whether other
kitchen appliances are
working
Fuse defective Check in the fuse box
whether the fuse for the
appliance is in working
order

13
Customer service
Our customer service department is there for you if
your appliance requires repair. We'll always find a
suitable solution, also to avoid unnecessary
technician visits.
When calling, please give the Product Number
(P-No.) and the Serial Number (S-No.) so that we can
offer you the most competent service. The
identification plate listing the numbers can be found
inside of the appliance (remove metal grease filter to
find it).
So that you don't have to search for them when you
need them, you can enter your appliance information
and the customer service number here.
Please note that a visit from a customer service
technician in the event of incorrect operation is not
free of charge, even during the warranty period.
Please find the contact data of all countries in the
enclosed customer service list.
To book an engineer visit and product advice
You can rely on the manufacturer’s expertise. Rest
assured that the repair will be handled by trained
service technicians who have the original
replacement parts for your appliance.
Accessories
(not included in the delivery)
Note: These instructions apply to several appliance
models. It may be the case that an optional
accessory that is listed does not apply to your
appliance.
Note: Observe the installation instructions in the
accessory.
--------
Installation Instructions
P-No. S-No.
Customer serviceO
USA 877 442 4436
toll-free
CANADA 877 442 4436
toll-free
Basic equipment
CleanAir air recirculation module
Spin-on filter for CleanAir air recircula-
tion module
AA210812
AA210110
Lowering frame:
Appliance width: 24" (60 cm) AA210460
Lowering frame:
Appliance width: 36” (90 cm) AA210490
Installation kit:
Top cabinet: 36" (90 cm) AA210491

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
14
IMPORTANTSAFETYINSTRUCTION READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THESE INSTRUCTIONS WITH
THE APPLIANCE AFTER INSTALLATION IS
COMPLETE.
IMPORTANT: SAVE THESE INSTRUCTIONS FOR
THE LOCAL ELECTRICAL INSPECTOR'S USE.
WARNING
If the information in this manual is not followed
exactly, fire or shock may result causing property
damage or personal injury.
WARNING
Do not repair, replace or remove any part of the
appliance unless specifically recommended in the
manuals. Improper installation, service or
maintenance can cause injury or property damage.
Refer to this manual for guidance. All other servicing
should be done by a qualified technician.
WARNING
WARNING – TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS,
OBSERVE THE FOLLOWING
‒Installation work and electrical wiring must be
done by qualified person(s) in accordance with all
applicable codes and standards, including fire-
rated construction.
‒Sufficient air is needed for proper combustion
and exhausting of gases through the flue
(chimney) of fuel burning equipment to prevent
back drafting. Follow the heating equipment
manufacturer’s guideline and safety standards
such as those published by the National Fire
Protection Association (NFPA), and the American
Society for Heating, Refrigeration and Air
Conditioning Engineers (ASHRAE), and the local
code authorities.
‒When cutting or drilling into wall or ceiling, do
not damage electrical wiring and other hidden
utilities.
‒Ducted fans must always be vented to the
outdoors.
WARNING
The applicable regulations of the energy supply
companies and the regional construction regulations
must be observed when installing the hood.
WARNING
Risk of fire
Grease deposits in the grease filter can catch fire.
Never work with a naked flame near the appliance
(e.g. flambéing). Install the unit near a heat-producing
appliance for solid fuels (e.g. wood or coal) only if
there is a closed, non-detachable cover. There must
be no flying sparks.
WARNING
Risk of fire
Operating several gas burners at the same time gives
rise to a great deal of heat. The ventilation appliance
may become damaged or catch fire. The ventilation
appliance must only be combined with gas burners
that do not exceed the maximum total output of 61,000
Btu/hr (18 kW). If 41,000 Btu/hr (12 kW) is exceeded,
the local regulations concerning room ventilation,
room size, and combination with ventilation devices in
exhaust and recirculating operation must be heeded.
WARNING
To reduce risk of fire and to properly exhaust air, be
sure to duct air outside. Do not vent exhaust air into
spaces within walls, ceilings, attics, crawl spaces or
garages.
WARNING
To reduce the risk of fire, use only metal ductwork.

15
9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
WARNING
When the hood is operated in exhaust-air mode
simultaneously with a different burner which also
makes use of the same chimney (such as gas, oil or
coal-fired heaters, continuous-flow heaters, hot-water
boilers) care must be taken to ensure that there is an
adequate supply of fresh air which will be needed by
the burner for combustion.
Safe operation is possible provided that the under
pressure in the room where the burner is installed
does not exceed 4 Pa (0.04 mbar).
This can be achieved if combustion air can flow
through non-lockable openings, e.g. in doors,
windows and via the air-intake/exhaust-air wall box or
by other technical measures, such as reciprocal
interlocking, etc.
WARNING
Avoid carbon monoxide poisoning – Provide adequate
air intake so combustion gases are not drawn back
into the room.
An air-intake/exhaust-air wall box by itself is no
guarantee that the limiting value will not be exceeded.
Note: When assessing the overall requirement, the
combined ventilation system for the entire household
must be taken into consideration. This rule does not
apply to the use of cooking appliances, such as
cooktops and ovens.
CAUTION
For general ventilating use only. Do not use to exhaust
hazardous or explosive materials and vapors.
Risk of damage from condensation back flow. Install
exhaust vent at a slight downward slope away from the
appliance (1° slope).
Appliance Handling Safety
Unit is heavy and requires at least two people or
proper equipment to move.
Hidden surfaces may have sharp edges. Use caution
when reaching behind or under appliance.
WARNING
Risk of injury
The appliance may fall from the wall if it is not
attached properly. All fastening components must be
fixed firmly and securely in place.
Safety Codes and Standards
This appliance complies with the latest version of one
or more of the following standards:
▯UL 507 - Electric Fans
▯CAN/CSA C22.2 No. 113 - Fans and Ventilators
It is the responsibility of the installer to determine if
additional requirements and/or standards apply to
specific installations.
Electric Safety
WARNING
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an
electrical short circuit, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current.
This appliance is equipped with a cord having a
grounding wire with a grounding plug. The plug must
be plugged into an outlet that is properly installed and
grounded.
WARNING
Improper grounding can result in a risk of electric
shock. Consult a qualified electrician if the grounding
instructions are not completely understood, or if
doubt exists as to whether the appliance is properly
grounded. Do not use an extension cord. If the power
supply cord is too short, have a qualified electrician
install an outlet near the appliance.
WARNING
Before you plug in an electrical cord or turn on power
supply, make sure all controls are in the OFF position.

9IMPORTANT SAFETY INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
16
For appliances equipped with a cord and plug, do not
cut or remove the ground prong. It must be plugged
into a matching grounding type receptacle to avoid
electrical shock. If there is any doubt as to whether
the wall receptacle is properly grounded, the
customer should have it checked by a qualified
electrician.
If required by the National Electrical Code (or
Canadian Electrical Code), this appliance must be
installed on a separate branch circuit.
WARNING
To reduce the risk of fire or electric shock, do not use
this fan with any solid-state speed control device.
Installer – show the owner the location of the circuit
breaker or fuse. Mark it for easy reference.
Before installing, turn power OFF at the service panel.
Lock service panel to prevent power from being
turned ON accidentally.
WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK,
OR INJURY TO PERSONS, OBSERVE THE
FOLLOWING:
‒Use this unit only in the manner intended by the
manufacturer. If you have questions, contact the
manufacturer.
‒Before servicing or cleaning unit, switch power
off at service panel and lock the service
disconnecting means to prevent power from being
switched on accidentally.
When the service disconnecting means cannot be
locked, securely fasten a prominent warning
device, such as a tag, to the service panel.
Be sure your appliance is properly installed and
grounded by a qualified technician. Installation,
electrical connections and grounding must comply
with all applicable codes.
WARNING
Risk of electric shock
Parts inside the appliance can have sharp edges. The
connection cable can be damaged. Do not bend or
pinch connection cables during installation.
Related Equipment Safety
Remove all tape and packaging before using the
appliance. Destroy the packaging after unpacking the
appliance. Never allow children to play with packaging
material.
The appliance is only guaranteed safe to use if
installed by a specialist in accordance with these
installation instructions. The installer is liable for any
damage resulting from incorrect installation.
Never modify or alter the construction of the
appliance. For example, do not remove leveling legs,
panels, wire covers or anti-tip brackets/screws.
State of California Proposition 65
Warnings
WARNING
This product contains chemicals known to the State of
California to cause cancer, birth defects or other
reproductive harm.

17
Before You Begin
These instructions apply to several appliance
models. It is possible that individual features are
described that do not apply to your appliance.
Tools and Parts Needed
▯Measuring tape
▯Pencil
▯Torx screwdriver TX20
▯Drill with the following bits: 5/16" (8 mm)
▯Spirit-level
▯Aluminum tape (DO NOT use insulating tape)
▯Exhaust channel (configuration depends on the
installation situation)
▯Additional sheet metal screws (if necessary for
installation of the exhaust air duct)
Parts Included
Appliance width 24" (60 cm):
Appliance width 36" (90 cm):
Safety clearances
9WARNING
Risk of fire
Grease deposits in the grease filter may catch
fire. The specified safety distances must be
observed in order to prevent an accumulation
of heat. Observe the specifications for your
cooking appliance. If gas and electric
cooktops are operated together, the largest
specified distance applies.
Only one side of the appliance may be
installed directly next to a high-sided unit or a
wall. The distance between the appliance and
wall or high-sided unit must be at least 2"
(50 mm).
[
[
[
[
[
[
[
[
[
PP
PP

18
The minimum distance between the supporting
surface for the cooking equipment on the hob and
the lowest part of the range hood must be not less
than 17 " (430 mm) from electric cookers and 25^"
(650 mm) from gas or mixed cookers.
If the instructions for installation for the gas hob
specify a greater distance, this must be adhered to.
General notes
▯This appliance is installed in a top cabinet.
▯Follow the enclosed installation instructions for
additional special accessories (e.g. for
circulating-air mode).
▯The surfaces of the appliance are sensitive.
Avoid damaging them during installation.
Exhaust air mode
9WARNING
Risk of death
Risk of poisoning from flue gases that are
drawn back in. The exhaust air must not be
conveyed into a functioning smoke or exhaust
gas flue or into a shaft that is used to ventilate
installation rooms that contain heating
appliances. If the exhaust air is to be conveyed
into a non-functioning smoke or exhaust gas
flue, you must obtain the consent of the
heating engineer responsible.
If the exhaust air is conveyed through the outer wall,
a telescopic wall box should be used.
Ventilation line
Note: The appliance manufacturer does not assume
any warranty for complaints attributable to the pipe
section.
▯The appliance achieves its optimum
performance by means of a short, straight
exhaust air pipe and as large a pipe diameter as
possible.
▯As a result of long rough exhaust air pipes, many
pipe bends or pipe diameters that are smaller
than 6” (150 mm), the optimum extraction
performance is not achieved and fan noise is
increased.
▯The pipes or hoses for laying the exhaust air line
must consist of non-combustible material.
Round pipes
An inner diameter of 6” (150 mm), but at least 4 _”
(120 mm), is recommended.
Flat ducts
The inner cross-section must correspond to the
diameter of the round pipes.
dia. 6” (150 mm) approx. 27^ sq in (177 cm2)
dia. 4 _” (120 mm) approx. 26_sq in (113 cm2)
▯Flat ducts should have no sharp deflections.
▯Use sealing strip for deviating pipe diameters.
êPP
!
PP
!

19
Preparing the units
▯The fitted unit must be level and have sufficient
load-bearing capacity.
▯The max. weight of the extractor hood is 40 lbs
(18 kg).
Appliance dimensions and safety clearances
▯Observe the appliance's dimensions.
▯Comply with the safety clearances.
If the installation instructions for the gas cooking
appliances specify a different distance, the largest
distance must always be provided for.
Fitted units must be heat-resistant up to 194° F
(90 °C). The stability of the fitted unit must also be
guaranteed after the cut-out work.
To install the extractor hood in a top cupboard, the
extractor hood must be provided with the following
dimensions:
1Make cut-out for the exhaust air pipe. To do this,
make an opening in the top or back panel of the
fitted unit with an additional recess for the
power cord.
2Remove cabinet base, if installed. Mark the
fastening points on the inside of the cabinet and
use a bradawl to make indentations where the
holes are to be. To help you mark the fastening
points, use the mounting piece provided.
Body wall thickness: 5/8" (16 mm)
1Screw the mounting pieces to the body on the
left and right. ¨
2Remove the tabs from the bottom of the
mounting pieces. ©
Width 24" (600 mm)
Depth min. 12 5/8" (320 mm)
Depth min. 13 ¾" (350 mm) with lowering frame
Elevation min. 16 9/16" (420 mm)
Elevation min. 24" (600 mm) with CleanAir air recir-
culation module
èç¼ʓʘ
PP
PLQèè¼ʓʘ
PP
ëPP

PP
ç¼ʚ
PP
ʌ¼ʓʘ
PP
$
%
[
ʌ¼ʚPP

20
Body wall thickness: 3/4" (19 mm)
1Fold out the tabs on both of the mounting
pieces. ¨
2Screw the mounting pieces to the body on the
left and right. ©
3Remove the tabs from the bottom of the
mounting pieces. ª
Preparing the appliance
Insert the enclosed power cord into the appliance.
Electrical connection
9WARNING
Risk of electric shock
Parts inside the appliance can have sharp
edges. The connection cable can be damaged.
Do not bend or pinch connection cables
during installation.
The necessary connection information is located on
the identification plate in the appliance interior,
remove metal grease filter to access it.
Length of the connecting cable: Approx. 4]ft
(1.30 m)
This appliance meets EC radio interference
suppression requirements.
9WARNING
Risk of electric shock
It must always be possible to disconnect the
appliance from the electricity supply. The
appliance must only be connected to a
protective contact socket that has been
installed correctly. If the plug is no longer
accessible following installation of the
appliance, or a fixed connection is required, an
all-pole isolating switch must be present on
the installation side with a contact gap of at
least X” (3 mm). The fixed connection may
only be installed by an electrician.
The branch-circuit breakers ampacity, the wire sizes
and the connections must conform to the
requirements of the National Electrical Code or
Canadian Electrical Code and all local codes and
ordinances.
This appliance is connected with a plug
▯Plug has to be conform with NEMA
CONFIGURATIONS FOR PLUGS AND
RECEPTACLES.
▯The appliance must be properly grounded.
▯Plug must be rated not less than type 6-20 P (2-
pole 3-wire grounding).
▯Only a qualified electrician should connect the
plug.
▯Install a socket outlet earthed in accordance
with regulations approx. 27" (700 mm) above the
floor behind the appliance. The socket outlet
must still be accessible after installation.
%
&
[
$
èç¼ʓʘPP
ëPP
$
%
