VL051
142_58300000122107_ara_en_b.doc – 02.02.09 Seite 1 von 16
1SAFETY........................................................2
1.1 Safety instructions..............................................................2
1.2 Repair instructions .............................................................2
2INSTALLATION............................................3
2.1 Installation dimensions......................................................3
2.2 Installation position 1.........................................................5
2.3 Installation position 2.........................................................6
2.4 Installation position 3.........................................................7
3OPERATION.................................................8
3.1 Features...............................................................................8
3.2 Display.................................................................................8
3.3 Switching on the appliance................................................9
3.4 Switching off the appliance................................................9
3.5 Run-on .................................................................................9
3.6 Vacation lock.......................................................................9
4COMPONENTS...........................................10
4.1 Equipment configuration..................................................10
4.2 Electronics module...........................................................10
4.3 Current and power table with GB 031-107......................11
4.4 Lifting motor......................................................................11
4.5 Spare part - Pipe socket...................................................12
5FUNCTIONS ...............................................13
6REPAIR.......................................................13
7FAULT DIAGNOSTICS...............................14
7.1 Switch logic S1-S4............................................................ 14
7.2 Plastic hose is twisting.................................................... 15
7.3 Too little air power............................................................ 15
8TECHNICAL SPECIFICATIONS.................16
8.1 Performance characteristic VL 051 with GB 031 ........... 16

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 2 von 16
1 SAFETY
1.1 Safety instructions
Warning of dangerous electrical voltage!
To prevent electric shocks, always comply with the following
instructions:
►Repairs may be carried out by a qualified electrician only!
►The user may be put at risk and injured by improper repairs!
►Observe the installation and repair instructions for the
appliances!
►If the appliance is faulty, the housing and frame may be live!
►Electric shock may occur if live components are touched
inside the appliance!
►Before commencing repairs, disconnect the appliance from
the power supply!
►If tests have to be performed while the appliance is live,
always use a residual-current-operated circuit-breaker!
►When repairs are complete, conduct a test in accordance
with VDE 0701 or the corresponding national regulations!
The protective conductor is crucial for personal safety and
appliance function.
►The test in accordance with VDE 0701 is conducted via the
mains plug. Measure the protective conductor resistance,
insulation resistance and substitute leakage or protective
conductor current and check the measured values!
►When repairs are complete, perform a function and safety
test.
1.2 Repair instructions
To prevent unnecessary repair costs, observe the following repair
instructions:
►NEVER attempt repairs by randomly replacing components!
►Always proceed systematically and observe the trouble-
shooting instructions in the technical documentation.
►As a rule, components are not repaired but are completely
replaced with original spare parts. Exceptions are documented
separately.
1.2.1 Pictograms
The following pictograms are used in the repair instructions:
Warning of a hazardous area!
Warning of cutting hazards!
Wear protective gloves!
Attention!
Note!

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 3 von 16
2 INSTALLATION
2.1 Installation dimensions
Note
¾A wok, e.g. VG 231, must not be installed next
to the VL 051.
¾If operated next to a gas appliance, the swivel
arm must be extended at least as far as the
upper edge of the pan.
¾ If installed next to a gas appliance, e.g. VG 232,
a locking pin must be fitted to prevent the
swivel arm from swivelling over the gas
appliance.
¾Extend swivel arm to
the middle
¾Remove cover plate from
the rear
¾Insert locking pin into
the black plastic ring

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 4 von 16
2.1.1 Installing retaining clamp

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 5 von 16
2.2 Installation position 1

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 6 von 16
2.3 Installation position 2

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 7 von 16
2.4 Installation position 3

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 8 von 16
3 OPERATION
3.1 Features
1 Grease filter
2 Cover
3 Swivel arm
4 Trough
5 Fascia
3.2 Display
6 Control knob for height setting
7 Filter indicator light
8 Control knob for power setting
Fig. 3
Fig. 2

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 9 von 16
3.3 Switching on the appliance
¾Rotate power setting control knob to the required setting.
¾The swivel arm moves automatically into the roasting position.
¾The swivel arm can be set to any height with the height-
adjustment knob.
¾The arm can be swivelled manually from a height of 100 to
410 mm.
¾If the arm is extended without preselection of a power setting,
the fan runs at a basic setting.
3.4 Switching off the appliance
¾Rotate power setting to Pos. 0.
¾Rotate height adjustment to left to “retract” position.
3.5 Run-on
¾Rotate power setting knob to left to “run-on” position. The fan
continues running for 10 min at setting 1.
¾To end run-on early, set the switch to 0.
3.6 Vacation lock
¾Four hours after the last operation, the appliance switches off.
Fig. 4 Fig. 5

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 10 von 16
4 COMPONENTS
4.1 Equipment configuration
Pos. A Electronics module
Pos. B Capacitor 12 µF
Pos. C Lifting motor
Pos. D Limit switch
4.2 Electronics module
Pos. A Microswitch connector
grill position, lower end
Pos. B Microswitch connector
crush protection, upper end
Pos. C Fan motor connector
Pos. D Lifting motor connector
A
B
A
D
B
C
D
C

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 11 von 16
At the outputs L1, L2 for the blower only 0 or 230V can be measured
against N.
The individual speeds are generated by upstream capacitors and
resistors. See table
Output L1 Output L2 Circuit
Off and pipe
retracted 0 0 ---
Basic setting
Pipe extended 230 V 0 12 µF + 8 µF + 2.7 KΩ
Setting 1 0 230 V 8 µF + 2.7 KΩ
Setting 2 230 V 0 12 µF
Setting 3 0 230 V Without circuit
4.3 Current and power table with GB 031-107
The measured values may differ due to fluctuating mains.
The following values were measured at 228 V
Current I in A Power P in W
Off 0 0
Basic setting 0.55 49
Setting 1 0.78 105
Setting 2 0.90 165
Setting 3 0.86 195
4.4 Lifting motor
The lifting motor is a direct-voltage motor 24 V DC.

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 12 von 16
4.5 Spare part - Pipe socket
The spare part pipe socket is supplied as individual part…
… and must be separated before the assembly.

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 13 von 16
5 FUNCTIONS
6 REPAIR
There are no error messages

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 14 von 16
7 FAULT DIAGNOSTICS
7.1 Switch logic S1-S4
The 4 limit switches are connected to the electronics module via two
connectors X5 and X6.
The limit switches are break contacts, i.e. when the appropriate
position is reached, the electric signal is “0”.
If there is a line break or if a connector is not plugged in, the input
signals are also “0”.
S1
lower
end
S2
grill
position
S3
upper
end
S4
crush
protection
Lifting motor and fan
output
0 0 1 1
Lifting motor runs to
upper end
1 0 0 0
Lifting motor and
fan motor do not run
0 1 0 0
Basic setting is running,
Fan can be switched
to any setting
Lifting motor does not
run
0 0 1 0
Lifting motor and
fan motor do not run
S1
S2
S3
S4

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 15 von 16
7.2 Plastic hose is twisting
Fault description:
¾The swivel arm can no longer be extended. (mechanically
blocked)
Cause of fault:
¾The plastic hose has become so twisted that the swivel arm
is blocked.
Troubleshooting:
¾Remove the appliance, loosen the pipe clip and fit plastic hose
without twisting it.
7.3 Too little air power
Complaint:
¾Extraction is too weak or the fumes go past the extraction arm.
Cause:
¾Units VL 051 and GB 031 have a free-blowing air power
of 350 m³/h. (See performance characteristic)
Additional pipelines reduce the power further. Flat ducts are
unsatisfactory as regards air flow and should not be used.
¾The intake area of the swivel arm is very small in comparison
with a hood. Depending on the position of the hob, not all fumes
are detected.
Rectification:
¾Check direction of rotation of the fan.
Viewing the intake connection
from above, the fan impeller must
rotate in a clockwise direction.
¾ Check pipe installation. If pipelines are long or flat ducting is
used , the air power is reduced considerably.

142_58300000122107_ara_en_b.doc – 02.02.09 Seite 16 von 16
8 TECHNICAL SPECIFICATIONS
Type Voltage Frequency Power
VL051-107 220–240 V 50 Hz maximum
280 W
8.1 Performance characteristic VL 051 with GB 031
VL 051-107 with GB 031-107
Setting 0
Setting 1
Setting 2
Setting 3
Volumetric flow in m³/h
Stat. pressure difference in Pa
