Galvin Specialised Safe-Cell 50110C Instruction sheet

Version 2, 6 September 2017, 1 of 4
Safe-Cell® Ezy-Grip Basin Tapware
PRODUCT CODE:
- 50110C
SPECIFICATIONS
 Designed for maximum protection against vandalism, Safe-Cell® basin assemblies are made from heavy
duty components and can be installed from the rear.
 Ideal for high risk facilities such as prisons, detention centres, mental health and behaviour centres.
 The basin assembly is finished in bright chrome plate for easy cleaning and durability.
 Quarter turn ceramic disc.
 Anti-ligature and tamper resistant design.
IMPORTANT: All Safe-Cell® Ezy-Grip basin sets are tested in accordance with AS/NZS 3718 and leave
our premises in good working order.
TECHNICAL DATA
Inlet ½” CU / BSP
Outlet Aerator
Headwork Ceramic
Working Pressure Range (kPa) Min 50
Max 500
Working Temperature Range (°C) Min 5
Max 75
Nominal Flow Rate (LPM) 7
Finish Chrome
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without
notice.
PRE-INSTALLATION - MOUNTING DETAILS
 If the mounting holes do not already exist, mark out and drill the holes in the bench/trough, as shown in
rough-in dimensions.
Note: Distance between outlet and basin bodies is 218mm maximum.
22
33
218mm MAX
ROUGH-IN DIMENSIONS
V/R AERATOR
6LPM
22
100
1/2" BSP/CU
1/2" BSP
67
NOM
MAX
25
59
218
MAX

Version 2, 6 September 2017, 2 of 4
TOOLS REQUIRED
 Power drill
 Spanner or adjustable crescent
 Thread tape/sealant
INSTALLATION
IMPORTANT: Galvin Specialised products must be installed in accordance with these installation
instructions and in accordance with AS/NZS 3500, the PCA and your local regulatory requirements. Water
and/or electrical supply conditions must also comply to the applicable national and/or tate standards. Failing
to comply with these provisions shall void the product warranty and may affect the performance of the
product.
1. Fit spout
 Fit the Safe-Cell® Basin spout into the bench.
 Ensure the sealing washer is placed
underneath the base body.
 Position the spout to the front and secure
underneath with the supplied flanged back nut.
 Take care not to over-tighten.
2. Cut copper breach
 Measure the distance between the basin
body holes.
 Mark out the base copper tee using this
measurement, subtracting 15mm from
each end to allow for the basin body
compression nuts.
 Ensure there is an equal distance from the
centre.
 Cut to size with pipe cutter and de-burr
both ends.
3. Fit basin bodies to breach
 Assemble basin bodies to the copper breach
 Ensure the olive is positioned over the copper
breach for sealing.
 Tighten the compression nut, taking care not to
overtighten as this may damage the olive.
4. Fit basin body assembly
 Insert the basin body assembly up through
the pre-cut holes.
 Centre the basin bodies.
 Carefully insert the copper breach into the
spout to avoid damage to the o-rings.

Version 2, 6 September 2017, 3 of 4
5. Secure basin body assembly
 Secure in place with supplied washer and locking
nut.
 Ensure that the set is installed with hot and cold
in the correct location.
6. Fit dress flanges
 Fit washer onto dress flange and tighten.
7. Fit dress flange with anti-rotation pin
 If the anti-rotation option is required, fit dress
flanges onto body and mark the basin/sink,
remove the flange and drill 3/16” hole
 Replace the flanges and screw in the grub
screw to lock.
8. Fit lock sleeves
 Fit lock sleeves and tighten to lock entire
unit in position.
 Take care not to over tighten.
9. Assemble handles
 Fit handles with tamper proof screws, ensure
the correct water temperature identification
buttons are in the handle
 Screws must be tightened before the unit is
tested
10. Testing
 Connect water supply to basin body inlet.
 Turn the handles and ensure that there is
flow from outlet.
 Inspect the tap and check for any leaks.

Version 2, 6 September 2017, 4 of 4
TROUBLESHOOTING
PROBLEM CAUSE RECTIFICATION
Water is not flowing from
tap
Water supply not on Turn water on
Aerator or flow regulator is blocked by
debris
Remove aerator or flow regulator from
tap and remove debris. Install an inline
strainer to stop further blockages.
Taps are dripping water Ceramic cartridge is worn or damaged
Remove and inspect the cartridge,
remove debris and /or replace
cartridge if damaged
Tap seat is damaged Refurbish tap seat usiing a reseating
tool
Handle is loose Screw has come loose Tighten handle screw
Flange does not screw
down onto basin surface Tap body are set too far out Re-position tap body and breach piece
