Version 1, 10 November 2016, Page 1of 4
Safe-Cell®Manual Prison Tapware
PRODUCT CODES:
- 50117C - 50133C
- 50120C - 50138C
SPECIFICATIONS
−Designed for maximum protection against vandalism, Safe-Cell®Wall Top Assemblies are made from
heavy duty components and feature rear installation. They are also designed to be ligature resistant for
added safety.
−The wall top assemblies are made of chrome plated brass.
−Quarter turn ceramic disc.
−Machined cold or hot identification button.
−Anti-ligature design.
−Available with either Ezy-Grip or Multi-Grip handle (as shown above).
IMPORTANT: All Safe-Cell®Wall Top assemblies are tested in accordance with AS/NZS 3718 and leave our
premises in good working order.
TECHNICAL DATA
Inlet
G5/8” BSP - Male
Outlet N/A
Headwork Ceramic
Working Pressure Range (kPa) Min 50
Max 500
Working Temperature (°C) Min 5
Max 85
Nominal Flow Rate (LPM) N/A
Finish Chrome
NOTE: Galvin Specialised continually strive to improve their products. Specifications may change without notice.
PRE-INSTALLATION
MOUNTING DETAILS
Wall body
−Measure the depth that the body is recessed into the wall,
−Wall body must be G5/8”. If the depth is greater than 10mm
−then contact Galvin Specialised on 1300 514 074 for 20mm
spindle extension (Item# 50190)
TOOLS REQUIRED
−Spanner and hex key
−Thread tape
Ezy-Grip
Handle
Multi-Grip
Handle
Version 1, 10 November 2016, Page 2of 4
INSTALLATION
IMPORTANT: Galvin Specialised products must be installed in accordance with these installation instructions and
in accordance with AS/NZS 3500, the PCA and your local regulatory requirements. Water and/or electrical supply
conditions must also comply to the applicable national and/or state standards. Failing to comply with these
provisions shall void the product warranty and may affect the performance of the product.
1. Disassembly
−Disassemble components
−Separate body washer, cartridge and locknut
2. Fit cartridge
−Fit ceramic cartridge in to the wall body. Fit
body washer
−Do not over tighten and do not use spindle to
tighten.
3. Fit locknut
−Fit locknut and tighten onto the cartridge,
ensuring fiber washer seals have a similar
tension to the conventional jumper valve
headpart.
4.Fit dress flange
−Fit dress flange onto the locknut and tighten.
5.Fit dress flange with anti-rotation pin
−If the anti-rotation option is required, fit dress
flange onto locknut and mark the wall. Remove
the flange and drill 3/16” hole 10mm deep.
−Replace the flange and screw in the grub screw
to lock.
6.Fit lock sleeve
−Fit lock sleeve and tighten to lock entire unit in
position.
Version 1, 10 November 2016, Page 3of 4
7.Assemble handle
−Fit handle with tamper proof screw, ensure the
correct water temperature identification button
is in the handle
−Screw must be tightened before the unit is
tested
8. Testing
−Once temperature indicator is fitted, check the
operation of the unit and inspect for any leaks.
TROUBLESHOOTING
PROBLEM CAUSE RECTIFICATION
Taps are dripping water Ceramic cartridge is worn or
damaged Remove and inspect the cartridge, remove
debris and /or replace cartridge if damaged
Water is not flowing from tap Water is turned off Turn on water
Version 1, 18 November 2016, Page 4
WARRANTY
The warranty set forth herein is given expressly and is the only warranty given by the Galvin Engineering Pty Ltd.
With respect to the product, Galvin Engineering Pty Ltd makes no other warranties, express or implied. Galvin
Engineering Pty. Ltd. hereby specifically disclaims all other warranties, express or implied, including but not limited
to the implied warranties of merchantability and fitness for a particular purpose.
Galvin Engineering Pty Ltd products are covered under our manufacturer’s warranty available for download from
www.galvinengineering.com.au Galvin Engineering Pty Ltd expressly warrants that the product is free from
operational defects in workmanship and materials for the warranty period as shown on the schedule in the
manufacturer’s warranty. During the warranty period, Galvin Engineering will replace or repair any defective
products manufactured by Galvin Engineering without charge, so long as the terms of the Manufacturer’s warranty
are complied with.
The remedy described in the first paragraph of this warranty shall constitute the sole and exclusive remedy for
breach of warranty, and Galvin Engineering Pty Ltd shall not be responsible for any incidental, special or
consequential damages, including without limitation, lost profits or the cost of repairing or replacing other property
which is damaged if this product does not work properly, other costs resulting from labour charges, delays,
vandalism, negligence, fouling caused by foreign material, damage from adverse water conditions, chemical,
electrical or any other circumstances over which Galvin Engineering has no control. This warranty shall be
invalidated by any abuse, misuse, misapplication, improper installation or improper maintenance or alteration of the
product.
