Speedrooter 92R®
Operating Instructions
For 3” through 10”
(75mm—250mm)
Your Speedrooter 92R is designed to
give you years of trouble-free, profitable
service. However, no machine is better
than its operator.
Read, understand and follow all safety
warnings and instructions provided with
the product. Failure to follow the warnings
and instructions may result in electric
shock and/or serious injury. Save all warn-
ings and instructions for future reference.
SAVE THESE INSTRUCTIONS!
Pour français voir la page 11
Para ver el español vea la paginá 21

WARNING! Read and understand all
instructions. Failure to follow all instructions
listed below may result in electric shock, fire
and/or serious personal injury. Replacement
manuals are available upon request at no
charge, or may be downloaded from our web-
site, www.drainbrain.com. Instructional videos
are available for download on our website, and
may be ordered. If you have any questions or
problems, please call General’s customer
service department at 412-771-6300.
SAVE THESE INSTRUCTIONS!
GENERAL SAFETY RULES
Speedrooter 92R®
Electric shock resulting in
death can occur if you plug
this machine into an improp-
erly wired outlet. If the ground
wire is electrified, you can be
electrocuted by just touching
the machine, even when the
power switch is off. A ground
fault circuit interrupter will not pro-
tect you in this situation. Use a
UL approved tester to determine
if the outlet is safe.
Do not operate power tools in
explosive atmospheres, such
as in the presence of flamma-
ble liquids, gases, or dust.
Power tools create sparks which
may ignite the dust of fumes.
Only wear leather gloves.
Never use any other type of
glove, such as cloth, rubber, or
coated gloves. Never grasp a
rotating cable with a rag.
These items could become
wrapped around the cable and
cause serious injury.
Always wear safety glasses
and rubber soled, non-slip
shoes. Use of this safety equip-
ment may prevent serious injury.
Never operate machine with
belt guard removed. Fingers
can get caught between belt and
pulley.
Do not overstress cables.
Overstressing cables may cause
twisting, kinking, or breaking of
the cable and may result in seri-
ous injury.
These instructions are intended to
familiarize all personnel with the safe
operation and maintenance
procedures for the Speedrooter 92R.
DANGER indicates a hazard with a high level of risk
which, if not avoided, will result in death or serious injury.
WARINING indicates a hazard with a medium level of risk
which, if not avoided, could result in death or serious injury.
CAUTION indicates a hazard with a low level of risk which,
if not avoided, will result in minor or moderate injury.
This is the safety alert symbol. It is
used to alert you to potential personal
injury hazards. Obey all safety mes-
sages that follow this symbol to avoid
possible injury or death.
2

Speedrooter 92R®
3
GENERAL SAFETY RULES
Work Area
1. Keep work area clean and well lit. Cluttered benches and dark
areas invite accidents.
2. Do not operate power tools in explosive atmospheres, such
as in the presence of flammable liquids, gases, or dust.
Power tools create sparks which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operat-
ing a power tool. Distractions can cause you to lose control.
Electrical Safety
1. Grounded tools must be plugged into an outlet, properly
installed and grounded in accordance with all codes and
ordinances. Never remove the grounding prong or modify
the plug in any way. Do not use any adapter plugs. Check
with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the tool should electrically
malfunction or break down, grounding provides a low resistance
path to carry electricity away from the user.
2. Avoid body contact with grounded surfaces such as pipes,
radiators, ranges and refrigerators. There is an increased risk
of electric shock if your body is grounded.
3. Do not expose power tools to rain or wet conditions.Water
entering a power tool will increase the risk of electric shock.
4. Do not abuse the cord. Never use the cord to carry the tools or
pull the plug from an outlet. Keep cord away from heat, oil, sharp
edges or moving parts. Replace damaged cords immediately.
Damaged cords increase the risk of electric shock.
5. When operating a power tool outside use an outdoor exten-
sion cord marked “W-A” or “W”. These cords are rated for
outdoor use and reduce the risk of electric shock.
6. Test the Ground Fault Circuit Interrupter (GFCI) provided
with the power cord to insure it is operating correctly before
operating machine. Machine must have a properly functioning
ground fault circuit interrupter on the power cord. GFCI reduces
the risk of electric shock.
7. Extension cords are not recommended unless they are
plugged into a Ground Fault Circuit Interrupter (GFCI) found
in circuit boxes or outlet receptacles. The GFCI on the ma-
chine power cord will not prevent electric shock from the exten-
sion cords.
8. Only use proper three-wire extension cords in good condi-
tion which have three-prong grounding plugs and three-pole
receptacles which accept the tool’s plug. Use of damaged,
inferior, or other extension cords will not ground the tool. In-
creases the risk of electric shock and bodily injury or death.
9. Keep all electric connections dry and off the ground. Re-
duces the risk of electric shock.
10. DO NOT touch plugs or tools with wet hands. Reduces the
risk of electric shock.
Personal Safety
1. Stay alert, watch what you are doing and use common sense
when operating a power tool. Do not use tool while tired or
under the influence of drugs, alcohol, or medication. A mo-
ment of inattention while operating power tools may result in
serious personal injury.
2. Dress properly. Do not wear loose clothing or jewelry. Con-
tain long hair. Keep your hair, clothing, and gloves away
from moving parts. Loose clothes, jewelry, or long hair can be
caught in moving parts.
3. Avoid accidental starting. Be sure switch is off before plug-
ging in. Plugging in tools that have the switch on invites acci-
dents.
4. Remove adjusting keys or switches before turning the tool
on. A wrench or key that is left attached to a rotating part of the
tool may result in personal injury.
5. Do not overreach. Keep proper footing and balance at all
times. Proper footing and balance enables better control of the
tool in unexpected situations.
6. Use safety equipment. Always wear safety glasses. Dust
mask, non-skid safety shoes, hard hat, or hearing protection
must be used for appropriate conditions.
Tool Use and Care
1. Use clamps or other practical way to secure and support the
workpiece to a stable platform. Holding the work by hand or
against your body is unstable and may lead to loss of control.
2. Do not force tool. Use the correct tool for your application.
The correct tool will do the job better and safer at the rate for
which it is designed.
3. Do not use tool if switch does not turn it on or off. Any tool
that cannot be controlled with the switch is dangerous and must
be repaired.
4. Disconnect the plug from the power source before making
any adjustments, changing accessories, or storing the tool.
Such preventative safety measures reduce the risk of starting the
tool accidentally.
5. Store idle tools out of reach of children and other untrained
persons. Tools are dangerous in the hands of untrained users.
6. Maintain tools with care. Keep cutting tools sharp and clean.
Properly maintained tools, with sharp cutting edges are less likely
to bind and are easier to control.
7. Check for misalignment or binding of moving parts, break-
age of parts, and any other condition that may affect the
tool’s operation. If damaged, have the tool serviced before
using. Many accidents are caused by poorly maintained tools.
8. Only use accessories that are recommended by the manu-
facturer for your model. Accessories that may be suitable for
one tool may become hazardous when used on another tool.
Service
1. Tool service must be performed only by qualified repair per-
sonnel. Service or maintenance performed by unqualified repair
personnel could result in injury.
2. When servicing a tool, use only identical replacement parts.
Follow instructions in the Maintenance section of this man-
ual. Use of unauthorized parts or failure to follow Maintenance
Instructions may create a risk of electric shock or injury.
WARNING
Read and understand all instructions. Failure to follow all in-
structions listed below may result in electric shock, fire, and/or
serious injury.
SAVE THESE INSTRUCTIONS!

Speedrooter 92R®
THE SECTION OF CORD BETWEEN THE WALL PLUG
AND THE GFCI IS NOT IN THE PROTECTED CIRCUIT.
4
Cable Application Chart (Table 1)
Cable Size Pipe Size Typical Applications
3/4” 4” to 10” Large Drains, Long Runs, Roots
5/8” 3” to 6” Floor Drains, Roots
SPECIFIC SAFETY RULES
1. Only wear leather gloves.Never use any other type of glove,
such as cloth, rubber, or coated gloves. Never grasp a rotating
cable with a rag. These items could become wrapped around the
cable and cause serious injury.
2. Never operate machine with belt guard removed.Fingers can
get caught between belt and pulley.
3. Never operate machine without Guide Tube in place. Can result in
significant hand injury.
4. Do not overstress cables. Keep leather-gloved hand on the
cable for control when machine is running. Overstressing cables
because of an obstruction may cause twisting, kinking, or break-
ing of the cable and may result in serious injury.
5. Place the machine at a distance not greater than two feet
from the opening. Greater distances can result in cable twisting
or kinking.
6. Machine is designed for ONE-PERSON operation. Operator
must control foot switch and cable.
7. Do not operate machine in reverse (REV). Operating machine
in reverse can result in cable damage and is used only to back
cutting tool out of an obstruction.
8. Keep hands away from rotating drum. Do not reach into drum
unless machine is unplugged. Hand may be caught in the moving
parts resulting in serious injury.
9. Be careful when cleaning drains where cleaning chemicals
have been used. Avoid direct contact with skin and eyes. Drain
cleaning chemicals can cause serious burns as well as damage
the cable.
10. Do not operate machine if operator or machine is standing
in water. Will increase risk of electrical shock.
11. Wear safety glasses and rubber soled, non-slip shoes. Use
of this safety equipment may prevent serious injury.
12. Before starting each job, check that the cable in the drum is
not broken or kinked, by pulling the cable out and checking
for wear or breakage.Always replace worn out (kinked or bro-
ken) cables with genuine GENERAL replacement cables.
13. Only use this tool in the application for which it was de-
signed. Follow the instructions on the proper use of the ma-
chine. Other uses or modifying the drain cleaner for other appli-
cations may increase risk of injury.
FEATURES
Folding Handle
V-Belt
Truck Loading Wheel
Open
Drum Flexitube Spring
Distributor Tube
Belt Guard
Feed Pressure
Control Knob
Momentary
Contact
Motor Switch
Cutter
Feed Control
Lever
Stair
Climbers
Passive
Brake
Cord Wrap
Guide Tube
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
Electric shock resulting in death can occur if you
plug this machine into an improperly wired outlet. If
the ground wire is electrified, you can be electrocuted
by just touching the machine, even when the power
switch is off. A ground fault circuit interrupter will not
protect you in this situation. Use a UL approved tester to
determine if the outlet is safe.
Do not overstress cables. Overstressing cables may
cause twisting, kinking, or breaking of the cable and may
result in serious injury.
Ground Fault Circuit Interrupter (GFCI)
Your machine is equipped with a ground fault circuit interrupter, which
protects you against shock if a short circuit should occur. Check that
receptacle is properly grounded. Test the GFCI before each use.
1. Plug into 120-volt receptacle.
2. Push test button. Indicator light will go out and power to machine
should cut off.
3. If light does not go out when test button is pushed, equipment
should not be used until proper repairs can be made.
4. To restore power after test, push reset button. With the reset
button depressed, if the machine doesn't start, stops while run-
ning, or if the operator experiences a mild shock, do not use the
machine! Tag the machine out of service and take it to a motor
repair center or return it to the factory for repairs.
Condensed
Operating
Instructions
Foot Pedal

Speedrooter 92R®
5
1. Place machine at a distance not
greater than two feet (.6m) from the
drain opening. Be sure the Speed-
rooter Guide Tube (S92-GT) is in
place. If you can't get the machine
this close to the drain opening, run
the cable through the optional Guide
Tube Extension (GTE) or a metal
guide tube to prevent cable whip-
ping.
2. Position the air foot pedal for easy accessibility. The machine is
designed for one-person operation. Be sure you can quickly re-
move your foot from the pedal in an emergency.
3. Be sure the motor switch is in the off position.
4. Make sure the Power Cable Feed is set to match the cable size
you have selected. If you’re using 3/4" or 5/8” cables, the feed
should be assembled with the raised side of the lower two caps
outward.
5. Select the proper cutting tool (See Cutter Application Chart—
Table 2). A good tool to start with is the Spearhead or 2” U-
Cutter. If you are having difficulty getting around a P-Trap or
close bend, try the flexible leader. After the line has been
opened, follow with larger blades, which scrape the inside edges
of the pipe, assuring a real cleaning job.
6. Insert the cutter into the female connector at the end of the cable
and tighten the connecting screw and lock washer firmly in
place.
OPERATION
SET-UP
MAKE SURE THE MOTOR SWITCH IS IN
THE ‘OFF’ POSITION!
Note: There are no fixed rules for what cutter to use. If one tool
doesn’t take care of a stoppage, simply try another.
Cutter Application Chart (Table 2)
Cutter Cat. # Typical Applications
Spear
Head SHD Starting Drill—gets water flowing.
2”
U-Cutter 2UC For Cutting and Scraping
3” Heavy
Duty Side
Cutter
Blades
3HDSC For Cutting & Scraping walls
of pipe.
3” Heavy
Duty Saw
Blade
3HDB For Cutting Roots
Large
Retrieving
Tool
RTR-2 For removing loose objects or
broken cables.
INSTALLING THE GUIDE TUBE HOLDER
1. To install the Guide Tube Holder on The Metro, follow the as-
sembly shown in the diagram below. Place the Guide Tube
Holder on the mounting knob, then thread it onto the bolt to se-
cure the Power Cable Feed. (See diagram below.)
2. To secure the end of the Guide Tube, place it between the frame
support tubes.
THE CABLE AND SPRING ARE UNDER TENSION
WHEN ATTACHED TO THE HOLDER.
USE CAUTION WHEN RELEASING THE GUIDE
TUBE FROM THE HOLDER.
3. Bend the Guide Tube back into the Holder so that it catches a
coil near the end of the Guide Tube. (See photo below.)

Speedrooter 92R®
6
SPECIAL OPERATIONS
IF CABLE GETS CAUGHT IN LINE
The motor can be reversed for a few seconds at a time to free the
cable if it gets caught in line. (Note: if using Power Cable Feed, put-
ting motor in reverse will cause the feed control lever to operate oppo-
site of normal.)
1. Hold momentary contact motor switch in the reverse position.
2. Step on the foot pedal while pulling on the cable.
3. After cable is loose, move the motor switch back into forward
position.
IF CABLE TANGLES IN DRUM
This is caused by using too much pressure, running the machine in
reverse, or a poorly lubricated or frozen roller in the feed. To untangle
the cable, rotate the drum in opposite direction (See Feed Mainte-
nance). This will usually get the cable to lie in the drum properly.
If the cable has become badly tangled, which shouldn’t occur if used
properly, it may be necessary to pull the entire cable out of the drum
and reinstall it. (See “How to Install Cable” section.)
OPERATION
1. Before stepping on the foot pedal, place the guide tube and cable
into the drain opening.
2. Tighten the knob at top of the Power Cable Feed so that the feed
roller presses against the cable. Be sure not to over tighten since
this could cause excess cable wear.
3. The feed lever controls the feeding rate and direction of the ca-
ble. Move the lever down to feed cable out of drum. The further
the lever is moved downward, the faster the cable will feed out.
Move lever up to retract cable into drum. When the lever is in the
middle (neutral) position, cable will spin in place.
4. Move the motor switch to the forward position.
5. With a gloved hand on the Guide Tube, step on the air foot pedal
to start machine. Feed the cable into the line. Adjust the feeding
rate to the resistance met. Do not force the cable - let the cutter
do the work. The job won’t go any faster and you could damage
the cable and you could injure yourself.
6. If the cable starts to buckle or twist, release pressure on the foot
pedal. Move the feed lever up and step on the foot pedal to re-
tract excess cable back into the drum, then continue.
7. If you're having trouble getting around tight bends, try putting the
machine in reverse for several seconds while applying steady
pressure. If your machine is equipped with a momentary contact
reverse switch, you must hold the switch in the reverse position.
8. If you still cannot get the cable getting around a bend, you may
be using too large a cable. Switch to a 5/8” cable, or smaller
machine. (See Cable Application Chart—Table 1)
9. When the cable reaches the stoppage, move the feed lever to-
ward neutral to allow the cable to progress forward slowly, chew-
ing into the stoppage as it goes. This slow forward movement will
reduce stress on the cable while doing a more thorough cleaning
job. A back and forth action often works best.
HOW TO INSTALL CABLE IN DRUM
1. Connect the male end of the cable to the drum connecting cable
already attached to the drum.
DISCONNECT MACHINE FROM POWER SOURCE
BEFORE INSTALLING CABLE IN DRUM!
Forward
Neutral
Reverse
Raised Cap
Feed Pressure
Knob
Feed
Control
Lever
DO NOT RUN MOTOR IN REVERSE FOR MORE THAN A
FEW SECONDS AT A TIME SINCE THIS COULD CAUSE
THE CABLE TO KINK OR TANGLE IN THE DRUM.
DO NOT USE REVERSE TO PULL THE CABLE OUT
OF THE DRAIN. RUNNING MACHINE IN REVERSE
CAN CAUSE THE CABLE TO TANGLE IN THE DRUM.
10. Be careful not to let the cutter get caught in the stoppage as you
work through it. This can cause kinking and breaking of the ca-
ble. When you feel the cable starting to twist, stop the machine
and retract the cable. This will free the cutter from the obstruc-
tion. Then allow the cable to move forward slowly into the stop-
page. Remember, no cutting takes place when the blades stop
turning.
11. After the line has been opened, retract the cable by moving the
feed lever up. Make sure the motor switch is in the forward posi-
tion.
12. When you hear the end of the cable near the drain opening, take
your foot off of the pedal to stop drum rotation. Never retract the
cutter from the drain while the cable is rotating. The cable could
whip and cause serious injury. Do not retract cutter into the guide
tube.
Hint: It's often helpful to have a small stream of water running in
the line to wash the cuttings away while the machine is in operation
and after.

Speedrooter 92R®
7
HOW TO INSTALL DRUM
1. Lay the machine frame on its side and roll the drum, with inner
drum installed, between the front post and drum shaft. Be sure
the front of the drum is facing the front post.
2. While standing behind the frame, line the drum shaft up with the
hole in the back of drum, slightly lift the frame, and slide the drum
shaft into the back of the drum until it contacts the thrust washer
on the shaft. Make sure the needle roller bearings inside the hub
of the drum stay in place.
3. Thread the drum retaining bolt into the drum shaft, just finger
tight.
DISCONNECT MACHINE FROM POWER SOURCE
BEFORE INSTALLING DRUM ON MACHINE!
Note: The cable should lay in the drum in a
clockwise direction.
HOW TO REMOVE DRUM
1. Remove belt guard by loosening the knob above the motor and
pulling the guard forward.
2. Push the motor down far enough to slide the V-Belt off of the
drum.
3. Remove the cutter and connecting screw from the cable end.
4. Loosen the knob at the top of the Power Cable Feed.
5. Unscrew knob behind the front post and pull the Power Cable
Feed off of the machine.
6. With one hand on the cable, loosen
the knob on front post cap, then
open clamp. The Flexitube may
spring up out of the cap. (See Fig-
ure 1.)
7. Use a 3/4" socket with extension to
loosen and remove the drum retain-
ing bolt.
8. Tip the Speedrooter on its side.
9. Remove the drum retaining bolt with
3/4" socket with extension.
10. Stand behind the machine, lift the frame slightly off the ground,
and slide the frame away from the drum until the drum is off the
shaft.
11. Then, roll the drum away from the machine.
Figure 1
DISCONNECT MACHINE FROM POWER SOURCE
BEFORE REMOVING DRUM FROM MACHINE!
5. Slide the V-Belt (62”) over the drum and hang it from the slip
clutch. Push down on the motor enough to slide the V-Belt onto
the drum.
6. Pull about 12” of cable out beyond the front post.
7. Slide the Flexitube, spring end first, onto the cable and into the
inner drum. (See Figure 3)
8. Then guide the knurled portion of the Flexitube spring into the
front post clamp. (See photo)
9. With one hand on the cable in front
of the front post, push the cable
down to secure the Flexitube in
position with the clamp. Make sure
the Flexitube seats properly over
the guide pin in the base of the
clamp.
10. Then, close the clamp and tighten
the knob with your other hand.
11. Slide the Power Cable Feed over the cable and align the bolt
with the hole in the front post and the guide pins with the holes in
the clamp. When flush with the front post, secure with bolt and
washer behind the front post.
12. Slide the belt guard over the stud on top of the motor and tighten
the knob.
Figure 2
Figure 3
4. Stand the machine upright, then tighten the retaining bolt with a
3/4” socket with extension. (See Figure 2)
2. Remove the V-Belt.
3. Turn the drum clockwise with one
hand while pushing the cable into
the drum with the other.
4. Be certain that the cable goes into
the drum in a clockwise direction as
you look at the front of the machine,
or the cable will tangle in the drum.
5. Replace the V-Belt after cable is
installed.

Speedrooter 92R®
MAINTENANCE
To keep your machine operating smoothly, it is essential that all bear-
ings be lubricated. Oiling moving parts is particularly important where
machine comes in contact with sand, grit and other abrasive material.
8
DAMAGED ROLLER
Excessive use may wear a roller to the point of failure. It is recom-
mended that all three rollers be replaced at the same time (Cat # PO-
703). The replacement roller is an assembly consisting of one (1)
Feed Roller, two (2) Feed Roller Bearings, and two (2) Bearing Spac-
ers.
Note: The Bearing Spacers must be installed between the Carrier
and each Feed Roller Bearing (as illustrated below) in order to
ensure proper operation and to obtain maximum Feed Roller life.
To Replace the Feed Roller Assembly:
DISCONNECT MACHINE FROM POWER SOURCE
BEFORE PERFORMING MAINTENANCE!
TANGLED CABLE
If a cable loops over itself in the drum, it will not feed properly. Re-
move and reload the cable to restore function. If the cable kinks, it is
evidence of abuse and results from the use of too much pressure or
use of the wrong size cable for the line. Do not force the cable —let
the cutter do the work.
FEED MAINTENANCE
Keep feed free of excessive soil and grit. It is recommended that the
feed be flushed with fresh water followed by a light oiling of the mov-
ing parts. No disassembly is normally required. Failure to feed can
usually be traced to the following possibilities:
DIRT ACCUMULATION
Over time, dirt can harden enough to stop roller rotation. Flushing
with water followed by liberal oiling can usually restore function. If
disassembly is required, proceed as follows:
1. Remove the feed tension knob, springs and spring plunger. Note
the positioning of these parts to ease re-assembly. The top roller
can now be removed.
2. Remove the end caps and thrust washers from the bottom hous-
ing cylinders. The bottom rollers can now be removed.
3. Re-assembly is done in reverse order.
CABLE MAINTENENCE
To get maximum service from your cables,
be sure that they are clean and well oiled.
This not only provides running lubrication
but greatly extends the life of the cables as
well. Some users periodically pour oil di-
rectly into the drum. Then, as the drum
turns, the cables get complete lubrication.
Our SNAKE OIL is ideally suited for this
purpose, since it not only lubricates the
cables, it deodorizes them as well.
1. Remove the Feed Roller Assembly by unscrewing and removing
the Feed Roller Axle.
2. For convenience, the components are assembled and wired
together at the factory. Before attempting to install the assembly,
hold the assembly together and remove the wire.
3. While still holding the Feed Roller Assembly together, insert it
into the slot opening of the Carrier.
4. In order to help align the Spacers and Bearings, insert a pencil
point or similar object through the un-threaded end of the Axle
hole in the Carrier. After removing the pencil point, continue to
maintain the alignment of the components.
5. The Feed Roller Axle should then be inserted through the same
un-threaded Axle hole and should continue to be guided through
the Spacers and Bearings to the threaded Axle hole on the other
side of the Carrier.
6. Securely tighten the Axle to the Carrier with a 3/16” allen wrench.

Speedrooter 92R®
TROUBLE SHOOTING GUIDE (Table 3)
Problem Probable Cause Solution
Cable kinks or breaks. Operator forcing the cable. Do not force the cable. Let the cutter do the work.
Too much slack between machine and
drain.
Allow no more than two feet between machine and drain.
Cable used in wrong size drain line. A cable that is too large or too small in diameter for a line is
more likely to kink. (Consult Table 1—Cable Applications.)
Cable exposed to acid. Clean and oil cables regularly.
Operator forcing the cable. Do not force the cable. Let the cutter do the work.
Cable tangles in drum.
Machine running in reverse. Do not run the machine in reverse to retract the cable from the
drain.
Drum stops while foot pedal de-
pressed.
Hole in pedal or hose. Replace as required.
Hole in diaphragm switch. If no hole found in pedal or hose, replace diaphragm switch.
Motor has overheated. Allow motor to cool, then press motor reset button.
Drum turns in one direction but not
other.
Reverse switch failure or momentary
contact switch.
Replace switch. Note: Momentary contact switch must be held
in position to use reverse.
Ground fault circuit interrupter trips
and will not reset.
Damaged power cord or extension
cord.
Replace cords.
Short circuit in motor. Take motor to authorized repair center.
Faulty ground fault circuit interrupter. Replace ground fault circuit interrupter.
Motor turns but drum does not. Safety Slip Clutch engaged. Do not force cable.
Failure to feed. Cable tangled in drum. Do not run machine in reverse. Use proper cable size. (Consult
Cable Application Chart—Table 1).
Feed misadjusted. If feed tension knob is too loose the cable will slip. If it is too
tight the feed rollers will wear prematurely.
Feed roller frozen. Clean and lubricate feed rollers regularly. Replace worn rollers.
Worn cable. When cable coils wear flat, cable should be replaced.
9
