Inder Power P-30 Operator's manual
AUTOMATIC POWER
PIPE CLEANER MINI ROOTER
User’s Instruction Manual
Model : P-30
Note : Before using this Automatic Power Pipe Cleaner Mini Rooter
carefully read through this INSTRUCTIONS MANUAL to ensure efficient,
safe operation. It is recommended that these INSTRUCTIONS be kept
readily available as an important reference when using this Automatic Power
Pipe Cleaner Mini Rooter.
NE958SI 1
C
O
PWER
Page : # 4 M : 30
INSTRUCTION MANUAL OF AUTOMATIC POWER PIPE CLEANER MINI ROOTER
SAFE OPERATION
10. Connect dust extraction equipment
If the tool is provided for the connection of dust extraction and collecting
equipment, ensure these are connected and properly used.
11. Do not abuse the cord
never yank the cord to disconnect it from the socket. Keep the cord away from
heat, oil and sharp edges
12. Secure work
Where possible use clamps or vice to hold the work. It is safer than using your
hand.
13. Do not overreach
Keep proper footing and balance at all times.
14. Maintain tools with care
Keep cutting tools sharp and clean for better and safer performance.
Follow instruction for lubricating and changing accessories.
Inspect tool cords periodically and if damaged have them have them repaired by
an authorized service facility.
Inspect extension cords periodically and replace if damaged.
15. Disconnect tools
When not in use, before servicing and when changing accessories such as
blades, bit and cutters, disconnect tools from the power supply.
16 Remove adjusting keys and wrenches
Form the habit of checking to see that keys and adjusting wrenches are
removed from the tool before turning it on.
17. Avoid unintentional starting
Ensure switch is in "off" position when plugging in.
18. Use outdoor extension leads
When the tool is used outdoors, use only extension cords intended for outdoor
use and so marked.
19. Stay alert
Watch what you are doing, use common sense and do not operate the tool when
you are tired.
20. Check damaged parts
Before further use of tool, it should be carefully checked to determine that if
would operate properly and perform its intended function.
Check for alignment of moving parts, binding of moving parts, breakage of parts,
mounting and any other conditions that may affect its operation.
A guard or other part that is damaged should be properly repaired or replaced by
an authorized service center unless otherwise indicated in this instruction
manual.
Have defective switches replaced by an authorized service center.
Do not use the tool if the switch does not turn it on and off.
Page : # 2 M : 30
FEATURES : - Automatic Power Pipe Cleaner Mini Rooter is design for both indoor and outdoor application
Dia 32mm-100mm (1.¼” - 4”) in lavatories, bathrooms and kitchens etc. Its entirely sealed structure, soft
flexible shafts made of high quality steel wire coiled around the steel wire rope tightly and special treated,
10mm x 15Mtrs. Inner -core cable are put in barrels, to ensure cleaner and more convenient use.
SPECIFICATION
Prod. NO. 30
Size (mm/inch) 32 - 100mm/1.¼” - 4”
Specification 220V, 50Hz or 110V, 60Hz optional,
Input 300W, Rotate Speed 250rpm,
Feeding speed 0 - 5m/min. Cleaning Cable
Dia (mm) x (Length) (Mtrs.) 10 x 15
Weight (Kgs.) 28.000
OPERATION
Automatic device effect feeding and backing with maximum Cable rotation adjusted by pressing wheel.
Cable Feeding and relative speed controlled drive handle.
Inner - core cable Inner - core cable High - tensile Anti - Twisting Anti - Kinking
Effect reverse Rotation by adjustment switch.
Protection hose for convenient, safe and clean operation.
•Different drill and cutter for various of blockage in
pipeline
KeyFlexible olive-shape
dhelical drill
Collection Helical
Drill
Spade-Shaped
Cutters
C-shaped cutter
INSTRUCTION MANUAL OF AUTOMATIC POWER PIPE CLEANER MINI ROOTER
Page : # 3 M : 30
Adjustable hand for conveint transport
Description
Including : 10mm x 15M (3/8 x 50”)
Enhanced inner core flexible soft shafts
Including : Drilling
INSTRUCTION MANUAL OF AUTOMATIC POWER PIPE CLEANER MINI ROOTER
SAFE OPERATION
1. Keep work area clear
Cluttered area and benches invite injuries.
2. Consider work area environment
Do not expose tools to rain.
Do not tools in dam or wet locations.
Keeps work area well lit.
Do not use tools in the presence of flammable liquids or gases.
3. Guard against electric shock
Avoid body contact with earthed or grounded surfaces (e. g. Pipes, radiators,
ranges, and refrigerators).
4. Keep other persons away
Do not let persons, especially children, not involved in the work touch the tool or
the extension cord and keep them away from the work area.
5. Store idle tools
when not in use, tools should be stored in a dry locked - up place, out of reach
of children .
6. Do not force the tool
Do not force small tools to do the job of a heavy duty tool.
Do not use tools for purposes not intended; for example does not use circular
saws to cut tree limbs or logs.
7. Use the right tool
do not force small tools to do the job of a heavy duty tool.
Do not use tools for purposes not intended for example do not use circular saws
to cut tree limbs or logs.
8. Dress properly
Do not wear loose clothing or jewelry, the can be caught in moving parts.
Non - skid footwear is recommended when working outdoors.
wear protective hair covering to contain long hair.
9. Use protective equipment
Use safety glasses.
Use face or dust mask if working operations create dust.
