Gardenline GLCS 85 E User manual

AFTER SALES SUPPORT
[email protected]
MODEL: GLCS 85 E • 91568 • 09/2014
 1300 922 271
Chainsaw Sharpener
User Guide
GLCS_85_E_AUS_SPK7.indb 1 05.06.14 13:56

2
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
Warranty Details
Chainsaw Sharpener
The product is guaranteed to be free from defects in
workmanship and parts for a period of 36 months
from the date of purchase. Defects that occur within
this warranty period, under normal use and care, will
be repaired, replaced or refunded at our discretion.
The benefits conferred by this warranty are in
addition to all rights and remedies in respect of the
product that the consumer has under the Competition
and Consumer Act 2010 and similar state and territory
laws.
Our goods come with guarantees that cannot be
excluded under the Australian Consumer Law. You are
entitled to a replacement or refund for a major failure
and for compensation for any other reasonably
foreseeable loss or damage. You are also entitled to
have the goods repaired or replaced if the goods fail
to be of acceptable quality and the failure does not
amount to a major failure.
GLCS_85_E_AUS_SPK7.indb 2 05.06.14 13:56

3
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
Table of contents
02 Warranty Details
04 Safety information
11 Items supplied
12 Layout
14 Instructions for use
15 Before starting the equipment
17 Operation
21 Data
GLCS_85_E_AUS_SPK7.indb 3 05.06.14 13:56

4
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
Important!
When using the equipment, a few safety precautions
must be observed to avoid injuries and damage. Ple-
ase read the complete operating instructions and sa-
fety regulations with due care. Keep this manual in a
safe place, so that the information is available at all
times. If you give the equipment to any other person,
hand over these operating instructions and safety re-
gulations as well. We cannot accept any liability for
damage or accidents which arise due to a failure to
follow these instructions and the safety instructions.
CAUTION!
Read all safety regulations and instructions.
Any errors made in following the safety regulations
and instructions may result in an electric shock, fire
and/or serious injury.
Keep all safety regulations and instructions in a safe
place for future use.
Warning! When using electric tools, basic safety pre-
cautions should always be followed to reduce the risk
of fire, electric shock and personal injury, including
the following. Read all these instructions before att-
empting to operate this product and safe these inst-
ructions.
1. Keep work area clean
Cluttered areas and benches invite injuries.
1Safety information
GLCS_85_E_AUS_SPK7.indb 4 05.06.14 13:56

5
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
2. Consider work area environment
Don‘t expose power tools to rain. Don‘t use pow-
er tools in damp or wet locations. Keep work area
well lit. Don‘t use power tools in presence of flam-
mable liquids or gases.
3. Guard against electric shock
Prevent body contact with grounded surfaces (e.g.
pipes, radiators, ranges and refrigerators).
4. Keep children away
Do not let visitors contact tool or extension cord.
All visitors should be kept away from work area.
5. Store idle tools
When not is use, tools should be stored in dry,
high, or locked-up place, out of the reach of child-
ren.
6. Don‘t force tool
It will do the job better and safer at the rate for
which it was intended.
7. Use right tool
Don‘t force small tools or attachments to do the
job of heavy duty tool. Don‘t use tools for purpo-
ses not intended: for example, don‘t use circular
saw for cutting tree limbs or logs.
8. Dress properly
Do not wear loose clothing or jewellery. They can
be caught in moving parts. Rubber gloves and
nonskid footwear are recommended when wor-
king outdoors. Wear protective hair covering to
contain long hair.
9. Use safety glasses
Also use face or dust mask if cutting operation is
dusty.
GLCS_85_E_AUS_SPK7.indb 5 05.06.14 13:56

6
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
10.Don‘t abuse cord
Never carry tool by cord or yank it to disconnect
it from receptacle. Keep cord from heat, oil and
sharp edges.
11. Secure work
Use clamps or a vise to hold work. It‘s safer than
using your hand and it frees both hands to operate
tool.
12.Don‘t overreach
Keep proper footing and balance at all times.
13.Maintain tools with care
Keep tools sharp and clean for better and safer
performance. Follow instructions for lubricating
and changing accessories. Inspect tool cords peri-
odically and, if damaged, have repaired by autho-
rised service facility. Inspect extension cords perio-
dically and replace if damaged. Keep handles dry,
clean and free from oil and grease.
14.Disconnect tools
When not in use, before servicing, and when chan-
ging accessories such as blades, bits and cutters.
15.Remove adjusting keys and wrenches
Form the habit of checking to see that keys and
adjusting wrenches are removed from tool before
turning it on.
16.Avoid unintentional starting
Don‘t carry plugged-in tool with finger on switch.
Be sure switch is off when plugging in.
17. Outdoor use extension cords
When tool is used outdoors, use only extension
cords intended for use outdoors and so marked.
GLCS_85_E_AUS_SPK7.indb 6 05.06.14 13:56

7
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
18.Stay alert
Watch what you are doing. Use common sense. Do
not operate tool when you are tired.
19. Check damaged parts
Before further use of the tool, a guard or other
part that is damaged should be carefully checked
to determine that it will operate properly and per-
form its intended function. Check for alignment of
moving parts, binding of moving parts, breakage
of parts, mounting, and any other conditions that
may affect its operation. A guard or other part that
is damaged should be properly repaired or repla-
ced by an authorised service center unless otherwi-
se indicated elsewhere in this instructions manual.
Have defective switches replaced by an authorised
service center. Do not use tool if switch does not
turn it on and off.
20.Warning
The use of any other accessory or attachment
other than recommended in this operating instruc-
tion may present a risk of personal injury.
21.Have your tool repaired by an expert
This electric appliance is in accordance with the re-
levant safety rules repairing of electric appliances
may be carried out only by experts otherwise it
may cause considerable danger for the user.
22.Connect the dust extraction device
Wherever there are facilities for fitting a dust ext-
raction system, make sure it is connected and used.
GLCS_85_E_AUS_SPK7.indb 7 05.06.14 13:56

8
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
Special safety instructions
• Check that the speed shown on the grinding tool is
the same as, or faster than, the rated speed of the
grinder.
• Check that the dimensions of the grinding tool
match those of the grinder.
• Grinding disks must always be used and stored
with care in accordance with the instructions of
the manufacturer.
• Always check the grinding disk before use. Never
use any disks with pieces broken off, which are
cracked or are in any other way damaged.
• Check that grinding tools are attached in ac-
cordance with the instructions of the manufactu-
rer.
• Always use backing layers if they are supplied with
the grinding tool and their use is specified.
• Check that the grinding tool is properly attached
and fastened before use and allow to run without
load in a safe position for 30 seconds. Stop imme-
diately if it should vibrate heavily or if any other
fault should become apparent. Examine the machi-
ne to find the cause of the fault.
• Never use the electric tool without the guard if a
guard is included in delivery.
• Do not use separate reducer sleeves or adapters to
make grinding disks with large holes fit properly.
• For grinding tools with threaded inserts, check that
the thread is long enough for the length of the
spindle.
• Ensure that the tool is securely fastened.
GLCS_85_E_AUS_SPK7.indb 8 05.06.14 13:56

9
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
• Take care to ensure that any sparks generated du-
ring use do not cause any danger, e.g. by hitting
persons or igniting inflammable substances.
• Take care to ensure that the air vents are not blo-
cked whenever you carry out work involving the
generation of dust. Should you have to remove
any dust, first disconnect the electric tool from the
mains power supply (only use non-metallic objects)
and avoid any damage to inner parts.
• Use safety goggles and ear-muffs.
• You should also wear protective clothing and
equipment such as a dust mask, work gloves,
apron and helmet.
• The grinding tool runs on after the tool is switched
off.
• The tool may only be used in the open air with
extension cables which have been certified as sui-
table for the purpose. The extension cables used
must have cross-sections of least 1.5 mm2. The
plug-and-socket connections must be equipped
with earthing-contacts and protection against rain-
water.
• Do not use any saw blades.
Always keep these Safety Instructions in a safe place.
GLCS_85_E_AUS_SPK7.indb 9 05.06.14 13:56

10
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
Caution!
Read the operating instructions to reduce the risk of
inquiry.
Wear ear-muffs.
The impact of noise can cause damage to hearing.
Wear safety goggles.
Sparks generated during working or splinters, chips
and dust emitted by the device can cause loss of
sight.
Wear a breathing mask.
Dust which is injurious to health can be generated
when working on wood and other materials. Never
use the device to work on any materials containing
asbestos!
GLCS_85_E_AUS_SPK7.indb 10 05.06.14 13:56

11
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
2Items supplied
• Open the packaging and take out the equipment
with care.
• Remove the packaging material and any packaging
and/or transportation braces (if available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for trans-
port damage.
• If possible, please keep the packaging until the end
of the guarantee period.
Danger!
The equipment and packaging material are not toys.
Do not let children play with plastic bags, foils or
small parts. There is a danger of swallowing or suffo-
cating!
Equipment supplied
• Original operating instructions
• Chainsaw Sharpener
GLCS_85_E_AUS_SPK7.indb 11 05.06.14 13:56

12
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
3Layout
1. Chain stopper
2. Chain stopper setting screw
3. Scale for setting grinding angle
4. Locking screw for grinding angle setting
5. Chain bar for chain
6. Chain locking screw
7. Setting screw for limiting depth
8. Grinding wheel
9. ON/OFF switch
10. Grinding head
11. Power cord
GLCS_85_E_AUS_SPK7.indb 12 05.06.14 13:56

13
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
1
2
1
2
3
4
6 5
7
8
10
10
9
117
5
GLCS_85_E_AUS_SPK7.indb 13 05.06.14 13:56

14
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
4Instructions for use
The chain sharpener is designed for sharpening saw
chains.
The machine is to be used only for its prescribed pur-
pose. Any other use is deemed to be a case of misuse.
The user / operator and not the manufacturer will be
liable for any damage or injuries of any kind caused
as a result of this.
Please note that our equipment has not been desig-
ned for use in commercial, trade or industrial applica-
tions. Our warranty will be voided if the machine is
used in commercial, trade or industrial businesses or
for equivalent purposes.
The machine must only be used for its intended pur-
pose! Even when the equipment is used as prescribed
it is still impossible to eliminate certain residual risk
factors. The following hazards may arise in connec-
tion with the machine’s construction and layout:
• Contact with the grinding wheel where it is not
covered.
• Catapulting of parts from damaged grinding
wheels.
• Catapulting of workpieces and parts of workpieces
from the machine.
• Damage to hearing if ear-muffs are not used as ne-
cessary.
GLCS_85_E_AUS_SPK7.indb 14 05.06.14 13:56

15
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
5Before starting the equipment
Before you connect the equipment to the mains sup-
ply make sure that the data on the rating plate are
identical to the mains data.
Always pull out the power plug before making ad-
justments to the equipment.
Assembly (Fig. 3-6)
• Place the chain clamping mechanism in the chuck
(Fig. 3) and screw from underneath using the star
screw (Fig. 4).
• Before starting the chain sharpener, fasten it se-
curely to a suitable surface (e.g. a workbench) at a
suitable place (protected against dust, dry, well-lit)
using M8 fixing screws and washers (Fig. 5).
• Make sure when doing so that the mounting plate
of the chain sharpener is pushed onto the surface
as far as it will go (Fig. 6).
GLCS_85_E_AUS_SPK7.indb 15 05.06.14 13:56

16
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
5 6
3 4
GLCS_85_E_AUS_SPK7.indb 16 05.06.14 13:56

17
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/2014
91568
6Operation
Important! Always switch the appliance off and un-
plug the power plug before making any adjustments.
6.1 Insert the chain that is to be sharpened into the
chain bar (Fig. 7)
To do this, loosen the chain locking screw (6)
6.2 Set the grinding angle according to the specifica-
tions for your chain (Fig. 8) (normally between 30-
35º)
• Slacken the locking screw for setting the grinding
angle (4)
• Set the desired grinding angle using the scale (3)
• Tighten the locking screw (4) again
7 8
6
3
4
GLCS_85_E_AUS_SPK7.indb 17 05.06.14 13:56

18
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
6.3 Set the chain stopper (Fig. 9/10)
• Fold the chain stopper (1) onto the chain.
• Pull the chain backwards against the chain stopper
(1) until the latter stops a cutting link (A).
• Important! You must make sure that the angle of
the stopped cutting link coincides with the grin-
ding angle. If it does not, pull the chain one link
further.
• Fold the grinding head (4) down until the grinding
wheel (8) is touching the chain link (A) that is to
be ground. (To do so, you can move the chain back
and forth a little using the setting screw of the
chain stopper (3)
6.4 Set the depth limit (Fig. 10)
• Fold the grinding head (4) down and set the grin-
ding depth using the setting screw (7)
Important! The grinding depth should be set so
that the full cutting edge of the cutting link is shar-
pened.
9 10
3
A
1
7
6
4
8
GLCS_85_E_AUS_SPK7.indb 18 05.06.14 13:56

19
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
6.5 Lock the chain (Fig. 7)
Tighten the chain locking screw (6)
6.6 Grinding the chain links (Fig. 10/11)
Important!
• Only use the equipment for sharpening saw chains.
Never grind or cut other materials.
• Before sharpening the saw chain clamp it into the
chain bar. This will prevent jamming of the grin-
ding wheel caused by a loose saw chain.
• Slowly guide the grinding wheel to the saw blade.
If the grinding wheel approaches the saw chain
too quickly or jerkily, this may cause damage to
the grinding wheel. Injuries may result from cata-
pulting parts!
• Switch the appliance on at the ON/OFF switch (9)
• Carefully bring the grinding wheel (8) with grin-
ding head (10) so that it is against the set link
• Switch the appliance off at the ON/OFF switch (9)
• Every second link in the chain must be sharpened
in this way. To know when every second link in
the entire chain has been sharpened, mark the
first link (e.g. with chalk). Once all cutting links on
one side have been sharpened, the grinding angle
must be set to the same number of degrees on the
other side. You can then begin to sharpen the links
of the other side (without having to make any
further adjustments).
GLCS_85_E_AUS_SPK7.indb 19 05.06.14 13:56

20
AFTER SALES SUPPORT 1300 922 271 service.australia@
isc-gmbh.info
GLCS 85 E
09/201491568
6.7 Set the depth limiter spacing (Fig. 12/13)
Once the chain has been fully sharpened, you must
make sure that the depth limiter spacing is kept (the
depth limiters (B) must be lower than the cutting links
(A). You may need to file the depth limiters (B) to the
specifications for your chain using a file (C) (not inclu-
ded in delivery).
11 12
13
9
C
A
B
GLCS_85_E_AUS_SPK7.indb 20 05.06.14 13:56
