Garmin VIRB Series Instruction manual

VIRB™ Series
Quick Start Manual
คู่มือ Quick Start
Panduan Cepat Pengoperasian
퀵 스타트 매뉴얼

Introduction
WARNING
See the Important Safety and Product
Information guide in the product box for
product warnings and other important
information.
It is your responsibility to use the device
in a safe manner. Garmin®will not be
responsible for any property damage,
injuries or deaths resulting from any use
of this device in any activities.
Installing a Memory Card
You must install a microSD™ memory
card up to 64GB to use your device. For
optimal performance, use a class 10 or
better memory card.
1 Turn the D-ring counter-clockwise,
and pull up to remove the cover.
2 If necessary, remove the battery
pack.
3 In the battery compartment, slide the
card holder ➊toward the lens, and
lift up.
4 Place the memory card ➋with the
gold contacts facing down.
5 Close the card holder.
6 Slide the card holder away from the
lens to lock it.
7 Replace the battery pack.
8 Replace the battery cover, and turn
the D-ring clockwise.
Installing the Battery Pack
WARNING
This product contains a lithium-ion
battery. To prevent the possibility of
personal injury or product damage
caused by battery exposure to extreme
heat, store the device out of direct
sunlight.
1 Turn the D-ring counter-clockwise,
and pull up to remove the cover.

2
2 Locate the metal contacts on the end
of the lithium-ion battery.
3 Insert the battery into the
compartment, contacts rst.
4 Press the battery into place.
5 Replace the battery cover, and turn
the D-ring clockwise.
Charging the Lithium-Ion Battery
Pack
NOTICE
To prevent corrosion, thoroughly dry the
mini-USB port, the weather cap, and
the surrounding area before charging or
connecting to a computer.
Do not attempt to use the device to
charge a battery that was not provided by
Garmin. Attempting to charge a battery
that was not provided by Garmin can
damage the device and void the warranty.
NOTE : The battery will not charge when
outside the temperature range of 32 to
114°F (0 to 45°C).
You can charge the battery using a
standard wall outlet or a USB port on
your computer. You can also use an
optional battery charger accessory. Go
to www.garmin.com/outdoor for more
information.
1 Pull up the weather cap ➊from the
mini-USB port ➋.
2 Plug the small end of the USB cable
into the mini-USB port.

3
3 Plug the USB end of the cable into
the AC adapter or a computer USB
port.
4 Plug the AC adapter into a standard
wall outlet.
When you connect the device to a
power source, the device turns on.
The LED is orange while the battery
is charging.
5 Charge the battery completely.
The LED turns green when the
battery is fully charged.
6 Remove the USB cable and fully
close the weather cap.
Attaching the Device to the
Mount
When attaching the device to the mount,
the recommended temperature range is
from 70° to 100°F (21° to 38°C).
Your device includes an assortment of
mounting bases and arms, which can
be used in many congurations. These
instructions provide an example of one
possible conguration. You can also
purchase additional mounts for your
device, such as wearable mounts, vehicle
mounts, or a tripod mount. Go to www.
garmin.com/outdoor for more information.
NOTE : By default, the camera should
be mounted with the screen facing up
to record correctly oriented video. You
can adjust the settings to record with the
screen facing down.
1 Thoroughly clean the mounting
surface using water or alcohol.
2 Remove the lm from the base ➊,
and press the base rmly onto the
mounting surface.
You can use either the at base or
the curved base, depending on the
contour of the mounting surface.

4
3 Allow the base to bond to the
mounting surface for at least 24
hours.
4 Place the coupler ➋into the base.
5 Place the threaded ring ➌over the
coupler, and tighten it onto the base.
6 Snap the mounting arm ➍into the
coupler.
7 Insert a thumbscrew ➎into the joint,
and tighten the thumbscrew to lock
the angle of the joint.
8 Snap the camera mount ➏into the
top of the mounting arm.
9 Insert a thumbscrew into the joint,
and tighten the thumbscrew to lock
the angle of the joint.
10 Place the tab ➐on the back of the
camera mount into the slot in the
back of the camera.
11 Squeeze the buttons ➑on the sides
of the mount, press the front of the
camera ➒down, and release the
buttons.
The camera should be held tightly
and should not move in the mount
when properly secured.
12 If the camera feels loose in the
mount, press the front of the camera
into the mount until it clicks.

5
Keys
Select to scroll through menus
and settings.
Select to scroll through menus
and settings.
OK Select to choose menu options
or to take a photo.
MODE Select to scroll through modes.
Hold to turn the device on
and off.
REC Slide toward the lens to record
video.
Turning On the Device
You can turn on the device using either
or REC .
• Select .
The device turns on and displays the
viewnder.
• Slide REC toward the lens.
The device turns on and starts
recording video.
Turning Off the Device
NOTICE
To prevent loss of data, always turn off
the device before removing the battery.
NOTE : You cannot turn off the device
while recording video.
1 If necessary, slide REC away from
the lens.
2 Hold .
appears on the screen while the
device saves track log data and turns off.
If you need to remove the battery, wait
until the screen turns off before removing
the battery.
Modes
You can operate your device in several
modes.
VIEWFINDER : Displays the camera
viewnder and status information.

6
PLAYBACK : Allows you to view
recorded videos and photos.
DASHBOARD : Displays sensor data
in charts and data elds (VIRB Elite
only).
SETUP : Allows you to change camera
settings.
Changing Modes
1 Select MODE to cycle through the
available modes.
2 Stop selecting MODE when the
desired mode appears on the screen.
Video
Recording a Video
NOTE : If the battery power becomes
very low while recording video, the device
automatically stops recording, saves the
video, and safely turns off.
1 Slide REC toward the lens to start
recording video.
If the device is off, it turns on
automatically. The device starts
recording video immediately.
2 Slide REC away from the lens to
stop recording video.
The video is saved on the memory
card as an MP4 le, and the track log
for the video is saved on the memory
card as a GPX le.
Video Settings
Select MODE > SETUP > VIDEO .
Mode : Sets the resolution, aspect ratio,
and frame rate.
Field of View : Sets the zoom level.
Loop : Enables loop recording and sets
the number of minutes of video to
store when recording a video loop.
Auto Record : Enables automatic
recording. When Moving
automatically starts recording when
the device is in motion. Ski Mode
automatically starts recording when
the device is moving downhill (VIRB
Elite only).
Microphone : Enables the microphone.
Advanced Recording Settings
Select MODE > SETUP > ADVANCED .
Lens Correct : Corrects wide-angle
barrel distortion in photos and
video. Automatically sets Field of
View to Wide in the video settings.

7
On +Stabilize turns on image
stabilization to reduce shaky video.
Flip Camera : Sets the camera to capture
video and images with the screen
facing up or down. This Side Down
captures correctly oriented video
and photos with the screen facing
downward.
Photos
Taking a Photo
Your device provides several methods for
taking a photo.
• Select MODE > VIEWFINDER , aim
the camera using the viewnder, and
select .
• From anywhere except the playback
screen, hold .
The device displays the photo briey
and returns to the page you were
using.
• While recording a video, select
to capture a photo at the same
resolution as the video recording.
Photos taken while recording a
video always use normal photo
mode. Burst mode is ignored while
recording video.
Photos Settings
Select MODE > SETUP > Photos .
Resolution : Sets the photo resolution.
Mode : Sets the shooting mode. Burst
mode takes several photos in quick
succession to capture a specic
instance, such as the nish line
during a race.
Self Timer : Sets the timer to delay taking
a photo. Repeat On automatically
repeats the time interval and
captures a photo until you press
again.
Date Stamp : Adds a date stamp to your
photo.
Playback
Viewing Photos and Videos
You can view your photos and recorded
videos on the device screen.
1 Select MODE > PLAYBACK .
2 Select and to select a photo or
video.
Videos are indicated with .

8
3 Select OK .
You can control video playback using
the on-screen controls.
Deleting Photos and Videos
1 Select MODE > PLAYBACK .
2 Select and to select a photo or
video.
3 Select OK > .
Dashboards
NOTE : This feature is available for VIRB
Elite only.
A dashboard is a grouping of data elds,
charts, or graphs of data from the device
sensors and connected ANT+™ sensors.
The dashboards provide real-time and
historical views of the sensor data
recorded to the track log.
Viewing the Dashboards
1 Select MODE > DASHBOARD .
2 Select and to scroll through
the dashboards.
Pairing Your ANT+ Sensors
When you pair a compatible ANT+
sensor with your device, the sensor data
is included in the track log, and you can
view dashboards for the sensor data.
1 Turn on the sensor, and bring the
device and sensor within 10 ft. (3 m)
of each other.
2 On the device, select MODE >
SETUP > SENSORS .
3 On the device, select the type of
sensor to pair.
The icon for the sensor blinks. When
the icon turns solid, the sensor is
paired and connected.
Tracks
NOTE : This feature is available for VIRB
Elite only.
A track is a recording of your path. The
track log contains information about
points along the recorded path, such as
time, location, and elevation for each
point. If you have paired ANT+ sensors
with your device, data from connected
sensors is included in the track log.
The device records a continuous track log
while it is on. This track is saved as a FIT
le on the memory card each time you

9
turn off the device. The device also
records a separate track log for each
video recording. Video track logs are
saved as GPX les on the memory card
each time you stop recording video. The
track logs include track point data at one-
second intervals.
You can view GPX and FIT track logs on
your computer using the BaseCamp™
application. Go to www.garmin.com/
basecamp for more information. You can
also view and upload FIT track logs to
Garmin Connect™. Go to http://connect.
garmin.com for more information.
Device Information
System Settings
Select MODE > SETUP > SYSTEM .
GPS : Enables the device to receive GPS
satellite signals. When Recording
enables GPS reception only when
the camera is recording video (VIRB
Elite only).
Record Light : Turns the recording light
on or off.
Tones : Turns audible tones on or off.
Time : Sets the time and date formats.
Units : Sets the units of measure.
Language : Sets the on-screen text
language.
Reset Settings : Restores the default
device settings.
About : Displays important software
information and your unit ID.
Cleaning the Device
NOTICE
Do not use a dry cloth to clean the lens.
Use of a dry cloth may damage the fog
resistant coating on the lens.
Wipe the device with a soft, non-
scratch cloth dampened with water or
alcohol.
Specications
Battery type Rechargeable Lithium-
ion battery
Battery life Up to 3 hours
Water resistance Water resistant to IEC
60529 IPX7
Operating
temperature
range
From 5º to 140ºF (from
-15º to 60ºC)

10
Charging
temperature
range
From 32º to 113°F (0º
to 45°C)
Radio
frequency/
protocol
2.4 GHz ANT+ wireless
communications
protocol Wi-Fi®IEEE
802.11 b/g at 2.4 GHz
Getting More Information
You can nd more information about this
product on the Garmin website.
• Go to www.garmin.com/outdoor.
• Go to www.garmin.com/
learningcenter.
• Go to http://buy.garmin.com,
or contact your Garmin dealer
for information about optional
accessories and replacement parts.
Support and Updates
The Garmin VIRB application provides
easy access to these tools and services
for your device.
• Reviewing and editing recorded
videos
• Reviewing track logs
• Linking track logs to your recorded
videos
• Software and feature updates
The Garmin VIRB application is available
for Windows®and Mac®computers.
Go to www.garmin.com/VIRB for more
information.

11
Important Safety and Product
Information
WARNING
Failure to avoid the following potentially
hazardous situations could result in an
accident or collision resulting in death or
serious injury.
Installation Warnings
• When installing the device in a vehicle, place
the device securely so it does not obstruct
the driver’s view of the road ➊or interfere
with vehicle operating controls, such as the
steering wheel, foot pedals, or transmission
levers. Do not place unsecured on the
vehicle dashboard ➋. Do not place the
device in front of or above any airbag ➌.
➋
➌
➊
• The windshield mount may not stay attached
to the windshield in all circumstances. Do
not place the mount where it will become
a distraction if it should become detached.
Keep your windshield clean to help ensure
that the mount stays on the windshield.
Off-Road Navigation Warnings
Some Garmin recreational products are able
to suggest off-road routes for various outdoor
activities, such as biking, hiking, and all-terrain
vehicles. Follow these guidelines to ensure
safe off-road navigation.
• Always use your best judgment and exercise
common sense when making off-road
navigational decisions. The Garmin device is
designed to provide route suggestions only.
It is not a replacement for attentiveness and
proper preparation for outdoor activities. Do
not follow the route suggestions
if they suggest an illegal course
or would put you in an unsafe
situation.
• Always carefully compare information
displayed on the device to all available
navigation sources, including trail signs,
trail conditions, weather conditions, and
other factors that may affect safety while
navigating. For safety, always resolve any
discrepancies before continuing navigation,
and defer to posted signs and conditions.
• Always be mindful of the effects of the
environment and the inherent risks of
the activity before embarking on off-road
activities, especially the impact that weather

12
and weather-related trail conditions can have
on the safety of your activity. Ensure that you
have the proper gear and supplies for your
activity before navigating along unfamiliar
paths and trails.
Street Navigation Warnings
Some Garmin recreational products are able
to accept street maps and suggest routes that
follow roads. Follow these guidelines to ensure
safe on-road navigation.
• Always use your best judgment, and operate
the vehicle in a safe manner. Do not
become distracted by the device
while driving, and always be fully
aware of all driving conditions.
Minimize the amount of time spent viewing
the device screen while driving.
• Do not input destinations, change settings,
or access any functions requiring prolonged
use of the device controls while driving.
Pull over in a safe and legal manner before
attempting such operations.
• When navigating, carefully compare
information displayed on the device to all
available navigation sources, including road
signs, road closures, road conditions, trafc
congestion, weather conditions, and other
factors that may affect safety while driving.
For safety, always resolve any discrepancies
before continuing navigation, and defer to
posted signs and conditions.
• The device is designed to provide route
suggestions. It is not a replacement for
driver attentiveness and good judgement.
Do not follow route suggestions if
they suggest an illegal maneuver
or would place the vehicle in an
unsafe situation.
Battery Warnings
Your GPS device uses user-replaceable
batteries. If these guidelines are not followed,
the batteries may experience a shortened life
span or may present a risk of damage to the
device, re, chemical burn, electrolyte leak,
and/or injury.
• Do not leave the device exposed to a heat
source or in a high-temperature location,
such as in the sun in an unattended vehicle.
To prevent damage, remove the device from
the vehicle or store it out of direct sunlight,
such as in the glove box.
• Do not use a sharp object to remove the
batteries.
• Do not puncture or incinerate the device or
battery.
• Keep the batteries away from children.

13
• Never put batteries in mouth. If swallowed,
contact a physician or poison control center.
• Do not disassemble, puncture, or damage
the batteries.
• Only replace the battery with the correct
replacement battery. Using another battery
presents a risk of re or explosion.
• Replaceable coin cell batteries may
contain perchlorate material. Special
handling may apply. See www.dtsc.ca.gov/
hazardouswaste/perchlorate.
• Contact your local waste disposal
department to dispose of the device/battery
in accordance with applicable local laws and
regulations.
• In addition, the GPS device may use an
internal, non-user-replaceable battery for
various purposes, such as the real-time
clock. Do not remove or attempt to remove
the non-user-replaceable battery.
NOTICE
Windshield Mounting Legal Restrictions
Before using the suction cup mount on your
windshield, check the state and local laws
and ordinances where you drive. Some
state laws prohibit drivers from using suction
mounts on their windshields while operating
motor vehicles. Other state laws allow the
suction mount to be located only in specic
locations on the windshield. Many other states
have enacted restrictions against placing
objects on the windshield in locations that
obstruct the driver’s vision. IT IS THE USER’S
RESPONSIBILITY TO MOUNT THE GARMIN
DEVICE IN COMPLIANCE WITH ALL
APPLICABLE LAWS AND ORDINANCES.
Where required, other Garmin dashboard or
friction mount options should be used. Always
mount your Garmin device in a location that
does not obstruct the driver’s view of the road.
Garmin does not assume any responsibility for
any nes, penalties, or damages that may be
incurred as a result of any state or local law or
ordinance relating to the use of your Garmin
device.
Map Data Information
Garmin uses a combination of governmental
and private data sources. Virtually all
data sources contain some inaccurate or
incomplete data. In some countries, complete
and accurate map information is either not
available or is prohibitively expensive.
Product Environmental Programs
Information about Garmin’s product recycling
program and WEEE, RoHS, REACH, and

14
other compliance programs can be found at
www.garmin.com/aboutGarmin/environment.
Declaration of Conformity
Hereby, Garmin, declares that this product is
in compliance with the essential requirements
and other relevant provisions of Directive
1999/5/EC. To view the full Declaration
of Conformity, go to www.garmin.com/
compliance.
FCC Compliance
This device complies with part 15 of the FCC
Rules. Operation is subject to the following
two conditions: (1) this device may not cause
harmful interference, and (2) this device must
accept any interference received, including
interference that may cause undesired
operation.
This equipment has been tested and found
to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC
rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses, and can radiate
radio frequency energy and may cause
harmful interference to radio communications
if not installed and used in accordance with the
instructions. However, there is no guarantee
that interference will not occur in a particular
installation. If this equipment does cause
harmful interference to radio or television
reception, which can be determined by
turning the equipment off and on, the user is
encouraged to try to correct the interference by
one of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and the receiver.
• Connect the equipment into an outlet that is
on a different circuit from the GPS device.
• Consult the dealer or an experienced radio/
TV technician for help.
This product does not contain any user-
serviceable parts. Repairs should only be
made by an authorized Garmin service center.
Unauthorized repairs or modications could
result in permanent damage to the equipment,
and void your warranty and your authority to
operate this device under Part 15 regulations.
Industry Canada Compliance
Category I radiocommunication devices
comply with Industry Canada Standard
RSS-210. Category II radiocommunication
devices comply with Industry Canada Standard
RSS-310. This device complies with Industry
Canada license-exempt RSS standard(s).

15
Operation is subject to the following two
conditions: (1) this device may not cause
interference, and (2) this device must accept
any interference, including interference that
may cause undesired operation of the device.
Limited Warranty
Garmin’s non-aviation products are warranted
to be free from defects in materials or
workmanship for one year from the date of
purchase. Within this period, Garmin will, at its
sole option, repair or replace any components
that fail in normal use. Such repairs or
replacement will be made at no charge to
the customer for parts or labor, provided
that the customer shall be responsible for
any transportation cost. This warranty does
not apply to: (i) cosmetic damage, such as
scratches, nicks and dents; (ii) consumable
parts, such as batteries, unless product
damage has occurred due to a defect in
materials or workmanship; (iii) damage caused
by accident, abuse, misuse, water, ood, re,
or other acts of nature or external causes;
(iv) damage caused by service performed
by anyone who is not an authorized service
provider of Garmin; (v) damage to a product
that has been modied or altered without the
written permission of Garmin; or (vi) damage
to a product that has been connected to power
and/or data cables that are not supplied by
Garmin. In addition, Garmin reserves the right
to refuse warranty claims against products
or services that are obtained and/or used in
contravention of the laws of any country. This
product is intended to be used only as a travel
aid and must not be used for any purpose
requiring precise measurement of direction,
distance, location or topography. Garmin
makes no warranty as to the accuracy or
completeness of map data in this product.
THE WARRANTIES AND REMEDIES
CONTAINED HEREIN ARE EXCLUSIVE
AND IN LIEU OF ALL OTHER WARRANTIES
EXPRESS, IMPLIED, OR STATUTORY,
INCLUDING ANY LIABILITY ARISING UNDER
ANY WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR
PURPOSE, STATUTORY OR OTHERWISE.
THIS WARRANTY GIVES YOU SPECIFIC
LEGAL RIGHTS, WHICH MAY VARY FROM
STATE TO STATE.
IN NO EVENT SHALL GARMIN BE LIABLE
FOR ANY INCIDENTAL, SPECIAL, INDIRECT
OR CONSEQUENTIAL DAMAGES,
INCLUDING, WITHOUT LIMITATION,
DAMAGES FOR ANY TRAFFIC FINES OR

16
CITATIONS, WHETHER RESULTING FROM
THE USE, MISUSE OR INABILITY TO USE
THE PRODUCT OR FROM DEFECTS IN
THE PRODUCT. SOME STATES DO NOT
ALLOW THE EXCLUSION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE
ABOVE LIMITATIONS MAY NOT APPLY TO
YOU.
Garmin retains the exclusive right to repair
or replace (with a new or newly-overhauled
replacement product) the device or software
or offer a full refund of the purchase price at
its sole discretion. SUCH REMEDY SHALL
BE YOUR SOLE AND EXCLUSIVE REMEDY
FOR ANY BREACH OF WARRANTY.
To obtain warranty service, contact your local
Garmin authorized dealer or call Garmin
Product Support for shipping instructions and
an RMA tracking number. Securely pack the
device and a copy of the original sales receipt,
which is required as the proof of purchase for
warranty repairs. Write the tracking number
clearly on the outside of the package. Send the
device, freight charges prepaid, to any Garmin
warranty service station.
Online Auction Purchases: Products
purchased through online auctions are not
eligible for warranty coverage. Online auction
conrmations are not accepted for warranty
verication. To obtain warranty service, an
original or copy of the sales receipt from
the original retailer is required. Garmin will
not replace missing components from any
package purchased through an online auction.
International Purchases: A separate
warranty may be provided by international
distributors for devices purchased outside
the United States depending on the country.
If applicable, this warranty is provided by the
local in-country distributor and this distributor
provides local service for your device.
Distributor warranties are only valid in the area
of intended distribution. Devices purchased in
the United States or Canada must be returned
to the Garmin service center in the United
Kingdom, the United States, Canada, or
Taiwan for service.
Australian Purchases: Our goods come
with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled
to a replacement or refund for a major failure
and for compensation for any other reasonably
foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced
if the goods fail to be of acceptable quality and
the failure does not amount to a major failure.

17
The benets under our Limited Warranty are
in addition to other rights and remedies under
applicable law in relation to the products.
Garmin Australasia, Unit 19, 167 Prospect
Highway, Seven Hills, NSW, Australia, 2147,
Phone: [phone]

18
บทนำ�
คำ�เตือน
ดูคำ�แนะนำ� ข้อมูลเกี่ยวกับผลิตภัณฑ์
และคว�มปลอดภัย ได้ในกล่อง
ผลิตภัณฑ์เพื่อศึกษ�คำ�เตือนและ
ข้อมูลสำ�คัญ
อื่น ๆ ของผลิตภัณฑ์
เป็นคว�มรับผิดชอบของคุณที่จะ
ใช้อุปกรณ์ในลักษณะที่ปลอดภัย
Garmin® จะไม่รับผิดชอบสำ�หรับ
คว�มเสียห�ยต่อทรัพย์สินใด ๆ ได้รับ
บ�ดเจ็บหรือเสียชีวิตที่เกิดจ�กก�รใช้
อุปกรณ์นี้ในกิจกรรมใด ๆ
ก�รติดตั้งก�ร์ดหน่วยคว�มจำ�
คุณต้องติดตั้งก�ร์ดหน่วยคว�มจำ�
microSD™ ได้ถึง 64GB เพื่อใช้กับ
อุปกรณ์ของคุณ เพื่อประสิทธิภ�พ
สูงสุด ให้ใช้ก�ร์ดหน่วยคว�มจำ� class
10 หรือดีกว่�
1 หมุนวงแหวนรูปตัว D ทวนเข็ม
น�ฬิก� และดึงขึ้นเพื่อถอดฝ�
ครอบ
2 ห�กจำ�เป็นให้ถอดแบตเตอรี่แพ็ค
3 ในช่องใส่แบตเตอรี่ ให้เลื่อนช่อง
เสียบก�ร์ด ➊ ไปท�งเลนส์และ
ยกขึ้น
4 ใส่ก�ร์ดหน่วยคว�มจำ� ➋ โดยให้
ด้�นสัมผัสสีทองคว่ำ�หน้�ลง
5 ปิดช่องเสียบก�ร์ด
6 เลื่อนช่องเสียบก�ร์ดออกห่�งจ�ก
เลนส์เพื่อล็อค
7 ใส่แบตเตอรี่แพ็คกลับลงไป
8 ใส่ฝ�ครอบแบตเตอรี่และหมุน
วงแหวนรูปตัว D ต�มเข็มน�ฬิก�
ติดตั้งก้อนแบตเตอรี่แพ็ค
คำ�เตือน
ผลิตภัณฑ์นี้ประกอบด้วยแบตเตอรี่ลิ
เธียมไอออน เพื่อป้องกันคว�มเป็นไป
ได้ของก�รบ�ดเจ็บส่วนบุคคล หรือ
คว�มเสียห�ยของผลิตภัณฑ์ที่เกิด
จ�กก�รปล่อยให้แบตเตอรี่โดนคว�ม
ร้อนสูงจัด เก็บอุปกรณ์ให้พ้นจ�กถูก
แสงแดดส่องโดยตรง

19
1 หมุนวงแหวนรูปตัว D ทวนเข็ม
น�ฬิก� และดึงขึ้นเพื่อถอดฝ�
ครอบ
2 ห�ด้�นสัมผัสโลหะที่ส่วนท้�ยของ
แบตเตอรี่ลิเธียมไอออน
3 สอดแบตเตอรี่เข้�ไปในช่อง โดย
ให้ด้�นสัมผัสลงก่อน
4 กดแบตเตอรี่เข้�ไปในช่อง
5 ใส่ฝ�ครอบแบตเตอรี่และหมุน
วงแหวนรูปตัว D ต�มเข็มน�ฬิก�
ก�รช�ร์จแบตเตอรี่แพ็คลิเธียม
ไอออน
ข้อสังเกต
เพื่อป้องกันก�รกัดกร่อน ให้เช็ดพอร์ต
mini-USB, ฝ�ปิดป้องกันอ�ก�ศ, และ
พื้นที่โดยรอบให้แห้งสนิท ก่อนก�ร
ช�ร์จหรือก�รเชื่อมต่อกับคอมพิวเตอร์
อย่�พย�ย�มใช้อุปกรณ์ช�ร์จแบตเตอรี่
ที่ไม่ได้ม�จ�ก Garmin คว�มพย�ย�ม
ที่จะช�ร์จแบตเตอรี่ที่ไม่ได้ม�จ�ก
Garmin ส�ม�รถทำ�ให้อุปกรณ์เกิด
คว�มเสียห�ยและก�รรับประกันเป็น
โมฆะ
หม�ยเหตุ: แบตเตอรี่จะไม่ช�ร์จ
เมื่ออยู่นอกช่วงอุณหภูมิ 32-114° F
(0-45° C)
คุณส�ม�รถช�ร์จแบตเตอรี่โดยใช้
เต้�เสียบผนังม�ตรฐ�นหรือพอร์ต
USB บนคอมพิวเตอร์ของคุณ คุณ
ยังส�ม�รถใช้อุปกรณ์เสริมที่ใช้ช�ร์จ
แบตเตอรี่ ไปที่ www.garmin.com/
outdoor สำ�หรับข้อมูลเพิ่มเติม
1 ดึงฝ�ครอบป้องกันอ�ก�ศ ➊
ออกจ�กพอร์ต mini-USB ➋
